Towards Building a Reputation-Based Microservices Trust Model Using

Similarity Domains

Zhongyi Lu

1 a

, Declan T. Delaney

2 b

, Tong Li

3 c

and David Lillis

1 d

School of Computer Science, University College Dublin, Dublin 4, Ireland

School of Electrical and Electronic Engineering, University College Dublin, Dublin 4, Ireland

Faculty of Information Technology, Beijing University of Technology, Beijing 100124, China

Keywords:

Microservices, Trust Management, Open Systems, SOA.

Abstract:

Microservices have been seen as a solution to open systems, within which microservices can behave arbitrarily.

This requires the system to have strong trust management. However, existing microservices trust models

cannot fully support open systems. In this paper, we propose a reputation-based trust model designed for

open microservices that groups similar microservices within the same “similarity domain” and includes a trust

bootstrapping process and a comprehensive trust computation method. Our proposal introduces a new concept

called “trust balancing” to assure that all microservices can fairly be incorporated into the operation of the

system. The design of the evaluation plan is also introduced to demonstrate the suitability of the proposed

model to open microservice systems.

1 INTRODUCTION

The microservices architecture (MSA) is the state of

the art of large-scale software development (Fritzsch

et al., 2019). Typically, microservices within a sys-

tem are designed to trust their peers (Mateus-Coelho

et al., 2021). However, an untrustworthy microser-

vice can cause system breakdowns (Sun et al., 2015).

Therefore, trust models are essential to protect open

microservice systems from vulnerabilities (Pourghe-

bleh et al., 2019). A number of approaches to mi-

croservices trust models have been adopted, includ-

ing those based on “zero-trust” (Hong et al., 2023),

regarding trust as a reﬂection of its reputation among

other microservices (Ruan et al., 2021), decomposing

the feedback that the truster gives to an entire solu-

tion (Adewuyi et al., 2022), and managing trust using

control models (Ven

ckauskas et al., 2023).

MSA is seen as the solution for building open sys-

tems (Fritzsch et al., 2019), which face unpredictable

challenges in open environments (Baresi et al., 2006).

Our previous survey (Lu et al., 2023) showed that ex-

isting microservices models cannot fully support open

https://orcid.org/0000-0002-6428-8782

https://orcid.org/0000-0001-7028-3307

https://orcid.org/0000-0002-8881-0037

https://orcid.org/0000-0002-5702-4463

systems and may cause problems. Thus, a speciﬁc

trust model for open microservice systems is needed.

In this paper, we propose a reputation-based trust

model for open microservice systems. Trust is “a be-

lief of a truster in a trustee that the trustee will provide

or accomplish the services that it says it will provide

and meet the expectations of the truster within a spe-

ciﬁc context for a speciﬁc period of time.” (Lu et al.,

2023) The model groups similar microservices into

“similarity domains” to manage trust. Microservices’

trust scores are based on feedback from recent inter-

actions and various Quality of Service (QoS) metrics.

We also outline an evaluation plan to demonstrate the

model’s suitability for open microservice systems.

2 RELATED WORK

This section brieﬂy reviews existing trust models for

MSAs, focusing on the requirements of open sys-

tems and the integration of newly-added microser-

vices. Due to the similarities between MSAs and Web

services architectures, we also examine relevant lit-

erature from the latter, where extensive research has

been conducted.

Lu, Z., Delaney, D., Li, T. and Lillis, D.

Towards Building a Reputation-Based Microservices Trust Model Using Similarity Domains.

DOI: 10.5220/0012838000003753

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Software Technologies (ICSOFT 2024), pages 169-176

ISBN: 978-989-758-706-1; ISSN: 2184-2833

169

2.1 Microservices Trust Models

Microservice systems require trust models to moni-

tor connections and establish trust between individ-

ual microservices, thereby mitigating trust-related at-

tacks (Abdelghani et al., 2016) and system dam-

age (Dragoni et al., 2017). While several publications

have addressed this issue, the literature on trust in mi-

croservices is relatively limited. Existing microser-

vice trust models fall into four categories: Zero-Trust-

based, socio-based, composition-based, and control-

based (Lu et al., 2023).

• Zero-trust-based models trust no microservices.

Authentication and authorisation are required be-

fore any interaction (Gilman and Barth, 2017).

• Socio-based trust models treat the system as a so-

ciety of microservices. Trust scores of microser-

vices reﬂect their reputation within society.

• Composition-based trust models compose a group

of microservices as one solution. The trusters will

rate the solution, which will then be decomposed

into trust scores for individual microservices.

• Control-based trust models manage trust using

the same logic as control models, which can con-

trol the trafﬁc within the system.

2.2 Trust Models for Open Microservice

Systems

Within open systems, microservices from diverse ori-

gins may join or leave the system arbitrarily, posing

additional challenges for trust management.

Previously, we proposed a set of qualities for trust

models for open microservice systems (Lu et al.,

2023), including: i) a comprehensive trust bootstrap-

ping process; ii) resilience to missing microservices;

iii) defence against trust manipulation; iv) separate

calculation of trust value for each microservice; v)

tolerance for occasional failures; vi) reﬂection of re-

cent trustworthiness; vii) equitable distribution of ser-

vice calls to all microservices; and viii) integration of

QoS metrics in trust calculation.

2.3 Web Services Trust Management

The MSA extends the Service-Oriented Architec-

ture (SOA), which encapsulates functionalities as

network-available services for integration into busi-

ness solutions (Laskey and Laskey, 2009). Despite

MSA being a superior enterprise solution compared

to Web services-based SOA (Raj and Ravichandra,

2018), the latter has a longer history, making it valu-

able to learn from previous Web service trust models.

2.3.1 Web services Trust Model

Wang and Vassileva (Wang and Vassileva, 2007) in-

troduced a three-level hierarchy for Web services trust

model classiﬁcation, which includes:

• Centralised/Decentralised: In a centralised sys-

tem, a central node manages reputations. For ex-

ample, TRUSS (Tang et al., 2017), which com-

bines objective and subjective trust assessments as

the trust evaluation middleware.

In a decentralised system, there is no central node.

(Nguyen et al., 2010) proposed a Bayesian net-

work trust and reputation model for each con-

sumer to build trust with Web services.

• Agent(Person)/Resource: Agent systems model

the reputation of agents representing people.

RATEWeb (Malik and Bouguettaya, 2009a) as-

sesses trust with the reputation of service vendors.

Resource systems focus on modelling the reputa-

tions of resources. Galizia et al. (Galizia et al.,

2007) managed trust using Web service Trust On-

tology, which embeds the trust-based selection of

Web services into a classiﬁcation problem.

• Global/Personalised: Global reputation systems

are based on public opinions. Caballero et al.

proposed a model to manage reputation using the

Web service Modelling Ontology in a P2P envi-

ronment (Caballero et al., 2006).

Personalised systems build reputation on subjec-

tive opinions. In the trust model proposed by (Liu

et al., 2014), the Web service network is regarded

as a small-world, where any two services can be

connected through at most six services.

2.3.2 Trust Bootstrapping

Trust evaluation relies on past information about in-

stances. Without such history, newcomers have no

chance to compete with existing Web services for se-

lection by trusters (Nguyen et al., 2012). The cold

start problem then arose as there was typically no

way to judge initial trust (Malik and Bouguettaya,

2009b). The initial trust should not be too high

or too low, so existing services or the new service

would be disadvantaged (Sensoy et al., 2013). Thus,

it is vital to strike a balance when assigning initial

trust to any incoming component. Previous mea-

sures can be divided into three categories: default

value, punishment-based, and adaptive (Zhang and

Li, 2022).

Default value approaches set the initial trust to

a constant default value (Wang and Vassileva, 2007;

Malik and Bouguettaya, 2009b; Jøsang, 2016). How-

ICSOFT 2024 - 19th International Conference on Software Technologies

170

ever, inappropriate default values may disadvantage

either existing services or the new service.

Punishment-based approaches assume newcomers

are not trustworthy and set their initial trust value to

a low value (Friedman et al., 2007; Wu et al., 2015;

Zacharia et al., 2000; Yahyaoui and Zhioua, 2013).

However, a low initial trust score increases the risk of

never being invoked.

Adaptive approaches determine the initial trust

value of newcomer services based on their charac-

teristics or similarity with existing services. Three

mechanisms were proposed in (Nguyen et al., 2012):

inheritance, referral, and guarantee mechanisms. The

inheritance mechanism sets trust based on the ven-

dor’s trust degree if they have uploaded other services.

The referral mechanism assesses the newcomer’s be-

haviour in other systems. The guarantee mechanism

assigns high trust to services promising quality and

reimbursement for failures. In (Wu et al., 2015),

a reputation bootstrapping method was introduced,

which used artiﬁcial neural networks to learn correla-

tions between service features and performance. Pre-

set communities were created in (Malik and Bouguet-

taya, 2009b), which store similar services. The ser-

vice providers decide which community they believe

their services belong to. In (Sensoy et al., 2013), on-

tology graphs were used to match newcomers with ex-

isting patterns for trust bootstrapping.

2.4 Computing the Trust of

Microservices and Web Services

While both microservices and Web services are re-

lated to SOA, their trust computation methods differ.

While Web services trust models are person-

centred or agent-centred, microservices trust mod-

els are resource-centred (Wang and Vassileva, 2007).

Web services aim to build trust and reputation for

vendors selling services over the World Wide Web

(Kreger, 2003), whereas microservices focus on elim-

inating vendor lock-in (Kecskemeti et al., 2016), sug-

gesting less emphasis on building trust for vendors.

MSA favours decentralised governance compared

to Web services and requires ﬁne-grained services,

unlike Web services, which can encapsulate multiple

responsibilities in one service. This complexity poses

challenges for trust modelling, demanding more ro-

bust trust models for MSA..

Existing Web services trust models struggle with

malicious services in composite architectures (Wahab

et al., 2015). MSA, being more vulnerable than Web

services, requires stronger defences against trust at-

tacks (Baresi and Garriga, 2019).

Therefore, existing Web service trust models are

not directly applicable to microservices. Separate

trust models are needed for both microservice sys-

tems and open microservice systems, albeit some as-

pects of microservices trust models may be informed

by pre-existing Web services models.

3 TRUST MODEL OVERVIEW

We propose a trust model that is suitable for an open

microservice system.

In a MSA, “domains” are organisational units that

form the systems (Steinegger et al., 2017). Allocating

microservices into different domains based on some

criteria (e.g., the context of the system (Rademacher

et al., 2018)) is a common way to manage microser-

vices. This has inspired us to group functionally sim-

ilar microservices into the same domain. We iden-

tiﬁed the similarity metric that we proposed in (Lu

et al., 2024). Unlike the similarity mentioned in (Ma-

lik and Bouguettaya, 2009b), this similarity metric is

computed fully by the system, which avoids the risk

that may be brought about by dishonest vendors being

permitted to choose a domain for their microservices.

There are ﬁve architectural components in the

model: Domain Manager, Similarity Evaluator, Simi-

larity Domains, Trust Managers, and Monitors.

Figure 1: An example structure of the model.

Similar microservices are allocated to the same

Similarity Domain, which are all managed by one

Domain Manager. The Domain Manager is a mi-

croservice that maintains domain lists, receives simi-

larity evaluation results, and allocates newcomer mi-

croservices to domains. The Similarity Evaluator is

a microservice that encapsulates a similarity metric,

which evaluates the similarity between a newcomer

microservice and existing services, ﬁnds it a match-

ing domain, and sends it to the Domain Manager.

Within each Similarity Domain, there is a Trust

Manager, which is a microservice that manages trust

scores of the services and returns trustee services to

trusters based on a probabilistic selection mechanism.

A key feature of the Trust Manager is that it main-

Towards Building a Reputation-Based Microservices Trust Model Using Similarity Domains

171

tains a “trust record” for each microservice to com-

pute trust. This records data relating to the most re-

cent interactions that the microservice has engaged in.

A Monitor also monitors the services within the do-

main to support a penalty scheme that deters trust ma-

nipulation and the QoS performance of services.

In order to support large-scale systems, data will

be distributed. Trust Managers will broadcast their

data to other Trust Managers to avoid any runtime

failures. There will also be backups for the Domain

Manager and Similarity Evaluators to avoid failures.

4 TRUST MANAGEMENT

Trust management comprises three major processes:

trust bootstrapping for newcomer microservices; trust

value computation; and trust balancing with a proba-

bilistic selection strategy.

4.1 Trust Bootstrapping

When a new microservice joins the system, the Sim-

ilarity Evaluator will use the similarity metric to ﬁnd

a suitable domain. The result will then be passed to

the Domain Manager and the Trust Manager of the

matching domain.

The Trust Manager of the domain that the new-

comer microservice belongs to has responsibility for

computing a bootstrapping trust score. The initial

trust score of the new microservice i is the mean value

of the trust score of all the other microservices in the

domain. However, if the newcomer service is the only

microservice in the domain, the initial trust value will

be set to 0.5. Formally, the initial trust score for mi-

croservice i (denoted as T

) is given by

(1)T

(

∑

j∈D

{

}

|−1

: |D

| > 1

0.5 : |D

|= 1

where D

is the similarity domain that i is associated

with (i.e., microservices within that domain).

4.2 Trust Computation

Later, once the microservice has been added to the

system and begun to satisfy requests, its overall trust

score is computed based on its reputation score R

its QoS score Q

, and possibly a penalty if any trust

manipulation has been observed by the Monitor.

The reputation score of a microservice is the ag-

gregation of its previous trusters’ opinions. It is com-

puted based on the ratings r that the trusters give to the

trustees after each interaction. A rating is an integer

between 0 and n, reﬂecting the opinion of the truster.

The higher r is, the more trustworthy the truster thinks

the trustee is during their interaction.

Equation 2 demonstrates a rating scale for n = 5.

opinion =











cannot perform, if r

i,t

= 0

extremely poor, if r

i,t

= 1

bad, if r

i,t

= 2

average, if r

i,t

= 3

good, if r

i,t

= 4

excellent if r

i,t

= 5

(2)

The reputation score that trustee microservice i re-

ceives for the t-th interaction that is stored in its inter-

action record is normalised to lie between 0 and 1, as

follows:

(3)R

i,t

The QoS score is used to reﬂect how well mi-

croservices comply with the QoS metrics. QoS is

commonly used in Web service trust models as a fac-

tor to evaluate trust. Combining the deﬁnition of QoS

given by W3C (Connolly, 1997) and the selection of

QoS metrics that are often used in previous trust mod-

els, the QoS metrics used in the proposed model are:

i) Availability that shows if a microservice instance

can be retrieved and reached via the network; ii) La-

tency, which is the time interval between the creation

of a request and the completion of the request; iii)

Cost, which is the resource usage during service ex-

ecution time, e.g., CPU utilisation, storage, etc.; iv)

Throughput, which is the number of requests that

the microservice instance has served in a certain pe-

riod of time; and v) Reliability, which is the ratio of

successful responses to all responses that the service

instance returns. Responses that do not match the ex-

pectations based on the API ﬁle are unsuccessful. Re-

liability reﬂects whether a microservice can provide

services that are compliant with its API description.

Availability, latency and throughput quantify whether

a microservice can be accessed by trusters in a certain

period of time. Cost is also a major factor that will

affect trusters’ views of the microservice.

Equation 4 explains the calculation of the QoS

score, which is computed by the Monitor within each

domain. In order to avoid the overhead of constant re-

calculations, several QoS metrics are calculated peri-

odically based on microservice interactions that have

occurred within a speciﬁed time period (which may

be in the order of minutes). In the following formu-

lae, x denotes the duration of the most recent time

period for which such a recalculation has occurred.

Equations 5 to 10 explain how each metric score is

calculated.

ICSOFT 2024 - 19th International Conference on Software Technologies

172

The overall QoS for the t-th interaction in i’s trust

record, Q

i,t

is deﬁned as a weighted sum of several

component metrics, as follows:

i,t

= α × A

i,t

+ β × L

i,t

+ γ × Θ

i,t

+ δ × ρ

i,t

+ ε ×C

i,t

(4)

where α through ε are the respective positive weights

associated with the component metrics deﬁned be-

low. Speciﬁc weights can be chosen to suit particu-

lar system requirements, provided that the sum of the

weights equals 1.

The availability score associated with microser-

vice i for the t-th interaction in its trust record, A

i,t

given by

(5)A

i,t

i,x

min(τ

, x)

where a

i,x

is the time that i has been available during

the calculation period, and τ

is the lifetime duration

of i (i.e., the elapsed time since i joined the similarity

domain), to adjust for new microservices that were

not in operation at the start of the calculation period.

The latency score for the t-th interaction of i, L

i,t

is given by

(6)L

i,t

= 1 −

i,t

− l

min

max

− l

min

where l

i,t

is the latency of the t-th interaction of i.

The score is normalised. l

max

and lmin are the maxi-

mum and minimum latencies of any interaction in the

record of any microservice in the domain.

The throughput score for i at its t-th iteration, Θ

i,t

is given by

(7)Θ

i,t

req

i,x

min(τ

, x)

where req

i,x

is the number of requests processed by i

during the time interval x.

The reliability score associated with the t-th inter-

action of i, ρ

i,t

is given by

(8)ρ

i,t

i,x

+ u

i,x

where s

i,x

is the number of requests that i successfully

satisﬁed during time period x, and u

i,x

is the number

of requests that i did not successfully satisfy during

that time period.

The ﬁnal component of the QoS computation is

the cost associated with i satisfying request t (denoted

as cost

i,t

). This is deﬁned ﬂexibly in the model to

allow for multiple measures of cost to be dynami-

cally chosen according to the speciﬁc use case of a

system. Each such measure is described as a “us-

age perspective”. Common usage perspectives would

include CPU or memory usage, but consumption of

other scarce or expensive resources may be a critical

feature of certain systems. It is given by:

cost

i,t

∑

j=0

×U

i, j,t

, f or

∑

j=0

= 1, 0 ≤ U

i, j,t

≤ 1

(9)

where k is the number of usage perspectives to be in-

cluded and U

i, j,t

is the cost of microservice i engag-

ing in interaction t, as measured by usage perspec-

tive j. This cost is deﬁned in the model as a posi-

tive value that is less than 1, with speciﬁc methods

for measuring this dependent on the nature of the us-

age perspective in question (e.g., memory usage cost

may be quantiﬁed in comparison to the memory us-

age of other microservices within the same domain).

Each usage perspective has a weight, κ

associated

with it, according to system requirements. The sum

of all such weights must equal 1.

This cost score is normalised to give the nor-

malised cost score for the t-th interaction of i, denoted

as C

i,t

, which is computed by

(10)C

i,t

cost

i,t

− cost

min

cost

max

− cost

min

where cost

max

and cost

min

are the maximum and min-

imum costs of any interaction in the record of any mi-

croservice in the domain.

4.3 Trust Manipulation and Trust

Balancing

In an open system, it must be assumed that microser-

vices may act in bad faith, particularly given the exis-

tence of a notion of trust. A penalty scheme is incor-

porated into this model to punish trust manipulation

(i.e., malicious attempts to illegitimately gain a high

trust score). Each Monitor seeks to detect evidence of

trust manipulation. The following possible signs of

trust manipulation are anticipated:

• A service instance POSTed a review of another

service instance but had never interacted with the

service instance being rated.

• A service instance keeps POSTing negative re-

views to other service instances.

• A service instance POSTed a review of a service

instance that is contrary to the rest of the trust

record of the trustee.

• A service instance only POSTs reviews to one

speciﬁc service instance when there are other

trustworthy services within the domain that the re-

viewed service is in.

• A trusted service instance starts to perform un-

trustworthily (e.g., provides services that are dif-

ferent from its description).

Towards Building a Reputation-Based Microservices Trust Model Using Similarity Domains

173

With the behaviour of each microservice being

recorded, its associated Monitor will be able to anal-

yse its behaviour and detect evidence of trust manip-

ulation. The trust of any microservice i will be 0

if manipulative behaviour is detected. This will be

achieved with Prometheus, which is a third-party tool

for microservice activity monitoring. We combine the

activities of microservices with the review record of

microservices to detect manipulation behaviours.

For a microservice i, with other trust scores being

computed, the trust score that microservice i received

for the t-th interaction that is stored in its trust record,

which is their weighted sum, can be calculated as:

i,t

= ζ × R

i,t

+ µ × Q

i,t

, f or ζ + µ = 1 (11)

However, if the interaction shows evidence of trust

manipulation, then T

i,t

should be 0.

A record discarding mechanism is adopted so that

the trust score of microservices reﬂects their more

recent trustworthiness to handle open environments.

The Trust Manager for each domain stores the N most

recent trust record of a microservice, where N is ei-

ther a ﬁxed minimum threshold or all trust records

that have been created since the end of the last QoS

calculation period, whichever is greater. This is to en-

sure that all interactions required to calculate the QoS

metrics for the next calculation period are present.

The system can then calculate the overall trust

score of i with its trust records. The importance of

each record decays over time. Recent trust records

should be of signiﬁcantly higher importance to the

trust score compared to past records. The formula is:

N−1

∑

t=0

2(t + 1) ×T

i,t

N(N + 1)

(12)

4.3.1 Trust Balancing

Trust balancing is a novel concept introduced in this

model. It is derived from the concept of load balanc-

ing. The aim is to distribute the chances of microser-

vices being recommended to trusters using a proba-

bilistic strategy. The probability of a microservice n

being recommended is related to its trust score. Equa-

tion 13 explains how P

is calculated with T

ω×T

∑

j∈D

ω×T

(13)

where ω is a scaling factor that can give a dispro-

portional higher probability of being recommended

to more trustworthy microservices while ensuring

all microservices with a trust score higher than 0 a

chance of being recommended, so their trust value can

converge from the initial trust value and reﬂect their

actual trustworthiness. A byproduct is the avoidance

of overload: as all the microservices are involved in

the operation, the possibility of a microservice being

called too many times can be reduced.

5 EVALUATION PLAN

This section outlines the evaluation design that will

be conducted on the proposed model.

Firstly, we have built a microservice system based

on the real-world OpenAPI dataset introduced in (Lu

et al., 2024). To evaluate the accuracy of trust, we will

manually set the trustworthiness of microservices, ad-

just the code accordingly to reﬂect this trustworthi-

ness, and then see how well the computed trust score

matches the designed trustworthiness. It is worth not-

ing that this does not mean computed trust scores need

to have exactly the same value as the designated trust

score. As long as the trust score is within an ac-

ceptable margin of error and, more importantly, the

ranking of microservices’ trust scores reﬂects their

actual trustworthiness, the model will be considered

effective. We will upload microservices to the system

gradually while removing others in order to see how

it can support systems of different scales.

To minimise the effect of other objective factors

on QoS, we deploy all microservices on the same

server but on different ports. It is not realistic in prac-

tice that a MSA-based system is deployed on merely

one single machine. However, as the main objective

of the evaluation is the effectiveness of the trust com-

putation, this kind of implementation will not largely

affect the evaluation. In terms of single-machine de-

ployment, as it does not need to interact with other

servers, the latency could be shorter, and the cost and

throughput could be lower as the host is only working

on one system. All the experiments will be conducted

on a MacBook Pro with an Apple M1 Pro chip, 32GB

of memory, and 994.66GB of storage. The operat-

ing system is macOS Ventura Version 13.5.2 (22G91).

To monitor the performance of the model, we use

Prometheus to monitor the activity of each port.

The evaluation is designed to demonstrate

whether the proposed model can fulﬁl the eight qual-

ities for open microservice trust models proposed

in (Lu et al., 2023). The evaluation will be carried

out by comparing the performance of a microservice

system with a basic trust model and a microservice

system with the proposed model on all aspects of the

qualities, namely:

Trust Bootstrapping: Trust bootstrapping estab-

lishes initial trust in a newcomer to accommodate it

in the system. The time interval between a new mi-

croservice joining and it being assigned a trust value

ICSOFT 2024 - 19th International Conference on Software Technologies

174

and the time interval between a new microservice

joining and it being called by a trustee is recorded.

Resilience to Missing Microservices: Microservice

systems should not be affected if a commonly used

microservice is missing. We will remove some com-

monly used microservices to simulate this. The HTTP

request handling time will be recorded to see how

long the system ﬁnds a substitute and recovers.

Resistance to Trust Manipulation: Trust-

manipulative behaviours should not affect the

trust score of microservices. We will manually adjust

the code or API ﬁle of microservices to perform the

manipulative behaviours mentioned in Section 4.3

and monitor whether trust scores are affected.

Individual Trust Score Computation: As Sec-

tion 4.2 demonstrates, the trust score of each mi-

croservice is computed independently. This may not

require any further experimentation.

Failure Tolerance: The system should still give mi-

croservices chances to perform after single failures.

We will monitor the system and see how often mi-

croservices are called after single failures.

Reﬂect Recent Trustworthiness: The trust score

should represent recent trustworthiness. We will man-

ually change the code of certain microservices to

change their trustworthiness and monitor how many

interactions it takes to let the trust score change.

Distribute Chances: All microservices should have

the opportunity to be called. We will monitor how

many microservices are being called in a certain time

period to see if all microservices that are not ex-

tremely untrustworthy are being recommended.

Incorporate Objective Metrics: The proposed

model includes an objective QoS score. Thus, it in-

corporates objective metrics to compute trust.

6 CONCLUSION

Trust management is important for systems. Al-

though there is previous research on trust models for

microservices and Web services, they cannot be fully

adopted by open microservice systems. This paper

proposes a reputation-based trust model designed to

support open microservice systems. It has three ma-

jor novelties: a comprehensive trust bootstrapping

process for newcomer microservices using similarity;

an anti-manipulation trust computation process that

computes trust using recent ratings and QoS; and a

trust balancing scheme that distributes microservices’

chances of being recommended to the trusters using a

probabilistic method based on their trust score.

We also proposed the evaluation plan, which will

later be used to test the performance of the proposed

model in a simulated open microservice environment.

ACKNOWLEDGEMENTS

This research is funded under the SFI Strategic Part-

nerships Programme (16/SPP/3296) and is co-funded

by Origin Enterprises Plc.

REFERENCES

Abdelghani, W., Zayani, C. A., Amous, I., and S

edes,

F. (2016). Trust Management in Social Internet of

Things: A Survey. In Dwivedi, Y. K., M

antym

aki, M.,

Ravishankar, M., Janssen, M., Clement, M., Slade,

E. L., Rana, N. P., Al-Sharhan, S., and Simintiras,

A. C., editors, Social Media: The Good, the Bad,

and the Ugly, pages 430–441, Cham. Springer Inter-

national Publishing.

Adewuyi, A. A., Cheng, H., Shi, Q., Cao, J., Wang, X., and

Zhou, B. (2022). SC-TRUST: A Dynamic Model for

Trustworthy Service Composition in the Internet of

Things. IEEE Internet of Things Journal, 9(5):3298–

3312.

Baresi, L., Di Nitto, E., and Ghezzi, C. (2006). Toward

open-world software: Issues and challenges. Com-

puter, 39(10):36–43.

Baresi, L. and Garriga, M. (2019). Microservices: The Evo-

lution and Extinction of Web Services?, page 3–28.

Caballero, A., Botia, J. A., and Gomez-Skarmeta, A. F.

(2006). A new model for trust and reputation manage-

ment with an ontology based approach for similarity

between tasks. In Fischer, K., Timm, I. J., Andr

e, E.,

and Zhong, N., editors, Multiagent System Technolo-

gies, page 172–183, Berlin, Heidelberg. Springer.

Connolly, D. (1997). Quality of Service. https://www.w3.

org/Architecture/qos.html. Accessed: 2024-04-25.

Dragoni, N., Giallorenzo, S., Lafuente, A. L., Mazzara, M.,

Montesi, F., Mustaﬁn, R., and Saﬁna, L. (2017). Mi-

croservices: Yesterday, Today, and Tomorrow, pages

195–216. Springer International Publishing, Cham.

Friedman, E., Resnick, P., and Sami, R. (2007).

Manipulation-resistant reputation systems. Algorith-

mic Game Theory, 677.

Fritzsch, J., Bogner, J., Wagner, S., and Zimmermann, A.

(2019). Microservices Migration in Industry: Inten-

tions, Strategies, and Challenges. In 2019 IEEE In-

ternational Conference on Software Maintenance and

Evolution (ICSME), pages 481–490.

Galizia, S., Gugliotta, A., and Domingue, J. (2007). A

Trust Based Methodology for Web Service Selection.

In International Conference on Semantic Computing

(ICSC 2007), page 193–200.

Gilman, E. and Barth, D. (2017). Zero trust networks.

O’Reilly Media, Incorporated.

Hong, S., Xu, L., Huang, J., Li, H., Hu, H., and Gu,

G. (2023). SysFlow: Toward a Programmable Zero

Towards Building a Reputation-Based Microservices Trust Model Using Similarity Domains

175

Trust Framework for System Security. IEEE Transac-

tions on Information Forensics and Security, 18:2794–

2809.

Jøsang, A. (2016). Subjective logic, volume 3. Springer.

Kecskemeti, G., Marosi, A. C., and Kertesz, A. (2016).

The ENTICE approach to decompose monolithic ser-

vices into microservices. In 2016 International Con-

ference on High Performance Computing & Simula-

tion (HPCS), page 591–596.

Kreger, H. (2003). Fulﬁlling the Web services promise.

Communications of the ACM, 46(6):29.

Laskey, K. B. and Laskey, K. (2009). Service ori-

ented architecture. WIREs Computational Statistics,

1(1):101–105.

Liu, F., Wang, L., Gao, L., Li, H., Zhao, H., and Men, S. K.

(2014). A Web Service trust evaluation model based

on small-world networks. Knowledge-Based Systems,

57:161–167.

Lu, Z., Delaney, D. T., and Lillis, D. (2023). A Survey on

Microservices Trust Models for Open Systems. IEEE

Access, 11:28840–28855.

Lu, Z., Delaney, D. T., and Lillis, D. (2024). Comparing

the Similarity of OpenAPI-Based Microservices. In

Proceedings of the 39th ACM/SIGAPP Symposium on

Applied Computing, SAC ’24, page 1201–1208, New

York, NY, USA. Association for Computing Machin-

ery.

Malik, Z. and Bouguettaya, A. (2009a). RATEWeb: Rep-

utation Assessment for Trust Establishment among

Web services. The VLDB Journal, 18(4):885–911.

Malik, Z. and Bouguettaya, A. (2009b). Reputation Boot-

strapping for Trust Establishment among Web Ser-

vices. IEEE Internet Computing, 13(1):40–47.

Mateus-Coelho, N., Cruz-Cunha, M., and Ferreira, L. G.

(2021). Security in microservices architectures. Pro-

cedia Computer Science, 181:1225–1236.

Nguyen, H. T., Yang, J., and Zhao, W. (2012). Bootstrap-

ping Trust and Reputation for Web Services. In 2012

IEEE 14th International Conference on Commerce

and Enterprise Computing, page 41–48.

Nguyen, H. T., Zhao, W., and Yang, J. (2010). A Trust

and Reputation Model Based on Bayesian Network

for Web Services. In 2010 IEEE International Con-

ference on Web Services, page 251–258.

Pourghebleh, B., Wakil, K., and Navimipour, N. J. (2019).

A Comprehensive Study on the Trust Management

Techniques in the Internet of Things. IEEE Internet

of Things Journal, 6(6):9326–9337.

Rademacher, F., Sorgalla, J., and Sachweh, S. (2018). Chal-

lenges of Domain-Driven Microservice Design: A

Model-Driven Perspective. IEEE Software, 35(3):36–

43.

Raj, V. and Ravichandra, S. (2018). Microservices: A per-

fect SOA based solution for Enterprise Applications

compared to Web Services. In 2018 3rd IEEE In-

ternational Conference on Recent Trends in Electron-

ics, Information Communication Technology (RTE-

ICT), page 1531–1536.

Ruan, L., Guo, S., Qiu, X., Meng, L., Wu, S., and

Buyya, R. (2021). Edge In-Network Computing

Meets Blockchain: A Multi-Domain Heterogeneous

Resource Trust Management Architecture. IEEE Net-

work, 35(5):50–57.

Sensoy, M., Yilmaz, B., and Norman, T. J. (2013). Discov-

ering Frequent Patterns to Bootstrap Trust. In Cao,

L., Zeng, Y., Symeonidis, A. L., Gorodetsky, V. I., Yu,

P. S., and Singh, M. P., editors, Agents and Data Min-

ing Interaction, page 93–104. Springer.

Steinegger, R. H., Giessler, P., Hippchen, B., and Abeck, S.

(2017). Overview of a domain-driven design approach

to build microservice-based applications. In The Thrid

Int. Conf. on Advances and Trends in Software Engi-

neering.

Sun, Y., Nanda, S., and Jaeger, T. (2015). Security-

as-a-Service for Microservices-Based Cloud Applica-

tions. In 2015 IEEE 7th International Conference

on Cloud Computing Technology and Science (Cloud-

Com), pages 50–57.

Tang, M., Dai, X., Liu, J., and Chen, J. (2017). To-

wards a trust evaluation middleware for cloud ser-

vice selection. Future Generation Computer Systems,

74:302–312.

Ven

ckauskas, A., Kukta, D., Grigali

unas,

S., and Br

uzgien

R. (2023). Enhancing Microservices Security with

Token-Based Access Control Method. Sensors,

23(6):3363.

Wahab, O. A., Bentahar, J., Otrok, H., and Mourad, A.

(2015). A survey on trust and reputation models for

Web services: Single, composite, and communities.

Decision Support Systems, 74:121–134.

Wang, Y. and Vassileva, J. (2007). A Review on Trust and

Reputation for Web Service Selection. In 27th Inter-

national Conference on Distributed Computing Sys-

tems Workshops (ICDCSW’07), page 25–25.

Wu, Q., Zhu, Q., and Li, P. (2015). A neural network based

reputation bootstrapping approach for service selec-

tion. Enterprise Information Systems, 9(7):768–784.

Yahyaoui, H. and Zhioua, S. (2013). Bootstrapping trust

of Web services based on trust patterns and Hidden

Markov Models. Knowledge and Information Sys-

tems, 37(2):389–416.

Zacharia, G., Moukas, A., and Maes, P. (2000). Collab-

orative reputation mechanisms for electronic market-

places. Decision Support Systems, 29(4):371–388.

Zhang, J. and Li, D. (2022). A Comprehensive and Uniﬁed

Approach to Web Service Trust Evaluation Based on

Uncertainty Methodology. Entropy, 24(22):243.

ICSOFT 2024 - 19th International Conference on Software Technologies

176
