Reappearance and Optimization of the FedDyn Algorithm

Zhao Zhang

Sussex Institute of Artificial Intelligence, Zhejiang Gongshang University, Hangzhou, Zhejiang Province, 310018, China

Keywords: FedDyn Algorithm, MNIST, F-MNIST.

Abstract: Federated learning has been widely used as a way to protect data privacy. However, the existing federated

learning algorithms have the problems of large differences in data distribution and low efficiency of model

updating. Therefore, the FedDyn algorithm was born to solve the above problems. This paper uses Python

programming software and FedDyn algorithm to build a simple federated learning framework composed of

five major parts: a fully connected neural network model, client model training function, global model

aggregation function, global model test function, and main function and carries out model training and

performance improvement optimization of the framework, as well as code efficiency and performance.

Three aspects of system stability and reliability were optimized, and two different data sets, Modified

National Institute of Standards and Technology (MNIST) and Fashion-MNIST (F-MNIST), were used to

test whether the algorithm optimization strategy proposed in this paper improved the algorithm performance.

Finally, it is concluded that the algorithm can be optimized effectively by adjusting multiple parameters of

the experimental model simultaneously.

1 INTRODUCTION

In the era of big data, with the improvement of

privacy protection awareness, federated learning that

can protect data privacy has attracted wide attention

to (Zhao et al. 2023). As a distributed learning

paradigm, federated learning allows multiple devices

or servers to jointly train models while maintaining

data localization, to help preserve data privacy

(Mónica & Haris 2024). However, when the client

data is not independent and identically distributed

(non-IID), that is, the data is not evenly distributed

on each client, traditional federated learning

algorithms (such as FedAvg) may encounter the

problem of the performance performance. This is

because the update of the model on different clients

may move in different directions, causing the global

model to converge to the optimal state (Li et al.

2019).

The study of the FedDyn algorithm is of great

significance to the field of federated learning

because it directly solves a key challenge in the

federated learning system: client data heterogeneity

(Yiyang 2022). In practice, there are often

significant differences in the distribution of the data

held by different clients, which will lead to the

deviation of the model locally trained by each client,

and affect the performance and generalization ability

of the global model. FedDyn By introducing

dynamic regularization terms, it effectively reduces

the difference in model parameters between clients,

thus helping to improve the accuracy of the global

model (Wenbo 2023).

The proposal of the FedDyn algorithm is of great

research significance for realizing a more efficient

and fair federated learning model. First, it addresses

the impact of data heterogeneity on model training

through dynamic regularization techniques, which is

crucial to improving the model performance on

real-world diverse datasets. Second, FedDyn helps

to improve the global convergence rate of the model,

enabling the federated learning system to achieve

better learning results in a shorter time. Finally, the

design concept of the algorithm has also inspired

other studies in the field of federated learning,

providing new ideas on how to design more robust

distributed learning algorithms.

Although the FedDyn algorithm has achieved

significant theoretical progress, and partly achieves

the goal of model consistency. However, in practice,

especially in large-scale deployment, the algorithm

still faces some unresolved problems and challenges

to (Acar et al. 2021). For example, the

computational efficiency of algorithms, adaptability

Zhang, Z.

Reappearance and Optimization of the FedDyn Algorithm.

DOI: 10.5220/0012839100004547

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Data Science and Engineering (ICDSE 2024), pages 569-576

ISBN: 978-989-758-690-3

569

to different types of data sets, and performance in

environments with limited practical communication

still need to be further studied. Moreover, how to

reduce the computational and communication

burden of clients while maintaining the effect of the

algorithm is also an important direction for future

research. Finally, it is also a research gap worth

exploring in choosing and adjusting the dynamic

regularization terms in the FedDyn algorithm to

accommodate different learning tasks and network

conditions.

This paper uses Python programming software,

using the FedDyn algorithm to build a simple

federated learning framework, and proposes the

framework into three categories, a total of 13

optimization methods. This paper aims to test

whether the proposed algorithm optimization

strategy indeed improves the algorithm performance

with two different datasets. The final study shows

that simultaneously adjusting multiple parameters of

the experimental model can effectively optimize the

experimental conclusion of the algorithm.

2 CODE REPETITION OF FedDyn

ALGORITHM

The code for reproducing the FedDyn algorithm

implements a simple federated learning scenario,

which includes the following main parts:

1. Fully connected neural network model (class

SimpleModel):

This is a simple neural network with a fully

connected layer used to flatten 28x28 images into a

vector and output to a layer with 10 output nodes

(corresponding to 10 categories in the Fashion-

Modified National Institute of Standards and

Technology (F-MNIST) dataset).

2. Client model training function

(train_client_model):

This function is responsible for training the

model for the individual clients. It receives the

client's model, optimizer, data loader, regularization

strength alpha, global model weights, and device

information (Central Processing Unit (CPU) or

Graphic Processing Units (GPU)). The training

process includes forward propagation, loss

calculation (including the dynamic regularization

term in the FedDyn algorithm), backpropagation,

and parameter update.

3. Global model aggregation function

(aggregate_global_model):

After all clients complete the training, this

function is responsible for aggregating the model

updates for all clients into a global model. The

aggregation is done by calculating the average of all

client updates.

4. Global model test function (test_model):

This function is used to evaluate the performance

of the global model on the test set. It calculates the

test loss and accuracy.

5. Main function (main):

This is the entry point of the program, it sets the

training parameters (such as equipment information,

regularization strength alpha, client number,

communication rounds, batch size, learning rate,

etc.), load and preprocess data set, divides data set to

different clients, initialize the global model, and

cycle the client model training and global model

aggregation, finally test the performance of the

global model.

The entire process simulates the process of

federated learning, where multiple clients train the

model locally and then send the model updates to a

central server for aggregation. This process is

repeated until the predetermined number of

communication rounds is reached. The goal of

federated learning is to protect data privacy in this

way because the raw data does not need to leave the

local client.

Results were obtained by training the fully

connected neural network on the MNIST dataset and

the FMNIST dataset as shown in Table 1.

The mean values of the initial model loss values

were 0.0107 and 0.0183 on the MNIST and

FMNIST datasets.

On the MNIST and FMNIST data sets, the

proportion of the correct samples with the initial

model predictions was (90.49%) and (79.70%).

Table 1: Experimental results of FedDyn algorithm.

Data set MNIST FMNIST

Experimental result Average loss: 0.0107, Accuracy: 9049/10000

(90.49%)

Average loss: 0.0183, Accuracy:

7970/10000 (79.70%)

ICDSE 2024 - International Conference on Data Science and Engineering

570

3 THE SHORTCOMINGS AND

IMPROVEMENT SCHEME OF

THE REPEATED FedDyn

ALGORITHM

There are three main disadvantages of code:

Model training and performance improvement:

Ⅰ. Single-round training: adjust the number of

rounds that each client trains locally. 1. Fixed

regularization strength: adjust the regularization

strength parameter alpha, which may affect the

generalization ability of the model. 2. Model

initialization: Using different initialization strategies,

may affect the model convergence rate and

performance. 3. Client selection: Choosing different

clients or different data distributions may affect the

accuracy and generalization ability of the model.

Ⅱ. Code Efficiency and Performance

Optimization: Data loader performance: optimize the

performance of the data loader, such as through

prefetching, multithreaded loading, etc.

III. System Stability and Reliability: 1. Exception

handling: Add the exception handling mechanism to

ensure the stable operation of the system. 2. Random

seeds: Random seeds were set to ensure reproducible

experiments. 3. Model complexity: Adjusting model

complexity may affect training time and model

performance.

In these optimization scenarios, the following

scenarios may directly improve the model accuracy:

1. Single-round training: Increasing the number of

local training rounds may improve the performance

of each client model, thus improving the accuracy of

the global model. 2. Fixed regularization strength:

finding a suitable regularization strength can help

the model to generalize better, which may improve

the accuracy. 3. Client selection: If the selected

client has more representative data or a more

balanced data distribution, the accuracy of the model

may be improved (Bo 2020).

Other optimization schemes may indirectly affect

the accuracy of the model, such as making more

training rounds possible by improving the training

efficiency or accelerating the model convergence by

improving the model initialization strategy.

However, most optimization schemes focus on

improving code efficiency, reducing resource

consumption, and increasing the stability of the

system (Wirth et al. 2023).

4 OPTIMIZATION RESULTS OF

THE REPRODUCED FedDyn

ALGORITHM

4.1 Fully Connected Neural Network

Model (Class SimpleModel)

1. Increase the number of training rounds from 2 to

5,7,10 rounds: The fully connected neural network

was trained on the MNIST dataset. The results are

shown in Table 2 when the number of training

rounds is 5, 7, and 10 rounds. On the MNIST

dataset, the new model loss values averaged

0.0095,0.0092 and 0.0090. On the MNIST dataset,

the number of samples predicted by the new model

was (91.44%), (91.60%) and (91.87%).

Table 2. Experimental results of the optimized algorithm.

Number of training

rounds

5 7 10

Training results Average loss: 0.0095

Accuracy: 9144/10000

(91.44%)

Average loss: 0.0092

Accuracy: 9160/10000

(91.60%)

Average loss: 0.0090

Accuracy: 9187/10000

(91.87%)

Loading part of the data set: replace datasets.

MNIST with datasets. Fashion MNIST updates the

mean and standard deviation of the data conversion

and completes the data set change. Replace the

MNIST with the FMNIST dataset. The experimental

results are shown in Table 3 when the number of

training rounds was 5,7, and 10 rounds. On the

FMNIST dataset, the mean values of the new model

loss values were 0.0163,0.0158 and 0.0153. On the

FMNIST dataset, the number of samples predicted

by the new model was (81.76%), (82.52%) and

(82.59%).

Reappearance and Optimization of the FedDyn Algorithm

571

Table 3: Experimental results of the optimized algorithm.

Number of trainin

rounds 5 7 10

Training results Average loss: 0.0163

Accuracy:

8176/10000 (81.76%)

Average loss: 0.0158

Accuracy:

8252/10000 (82.52%)

Average loss: 0.0153

Accuracy: 8259/10000

(82.59%)

Experimental findings suggest that increasing the

number of training rounds may improve the

performance of the model. If the number of training

rounds is continuously increased, the model may

eventually be overfitting.

2. Adjust the regularization intensity [0.0001,

0.001, 0.01, 0.1, 1]:

The experimental results of the FMNIST dataset

are shown in Table 4 [0.0001, 0.001, 0.01, 0.1, 1].

On the FMNIST dataset, the mean values of the new

model loss values were 0.0182, 0.0182, 0.0182,

0.0189, and 0.0245. On the FMNIST dataset, the

proportion of the total sample number that the new

model predicted correctly was (79.87%), (79.83%),

(80.01%), (79.53%), and (75.46%).

Table 4: Experimental results of the optimized algorithm.

rice 0.0001 0.001 0.01 0.1 1

Experimental

result

Average loss:

0.0182

Accuracy:

7987/10000

(79.87%)

Average loss:

0.0182,

Accuracy:

7983/10000

(79.83%)

Average loss:

0.0182,

Accuracy:

8001/10000

(80.01%)

Average loss:

0.0189,

Accuracy:

7953/10000

(79.53%)

Average loss:

0.0245,

Accuracy:

7546/10000

(75.46%)

Furthermore, an alpha_values list can be set to

try different alpha values and evaluate model

performance using each validation set after training

rounds, selecting the best alpha value. In federated

learning, the regularization strength alpha is an

important hyperparameter that controls the degree to

which the local model weights are close to the global

model weights (Tivnan et al. 2023). Experiments

find that alpha is set too high, so the local model

may overfit the weight of the global model, which

may ignore the specificity of the local data; Set too

low, the local model may overfit the local data, not

enough to the global model, which may reduce the

generalization performance of the global model.

3. Model initialization:

In the train_client_model function, can directly

use global_weights instead of extracting them from

global_model every time. In the

aggregate_global_model function, can use methods

outside of torch. stack to aggregate model updates,

such as directly calculating the average, instead of

stacking first before averaging. In the test_model

function, one can avoid using the division by

directly accumulating the losses and the number of

correct predictions. These optimizations may have

some minor impact on performance but may be

more pronounced when training large models or

processing large amounts of data. New code is

compared to the source code.

When calculating the dynamic regularization

term in the train_client_model function, it treats the

global_weights [param _ key] differently:

In the new code, global_weights [param _ key]

was transferred to the corresponding device. In the

source code, global_weights [param _ key] is used

directly without device transfer. This change is made

to ensure that the model parameters and the global

weights are on the same device (CPU or GPU) to

avoid operational errors. The calculation of test loss

in the test_model function. In the new code, the loss

is calculated and multiplied by data. size (0) to get

the average loss for the entire data set. In the source

code, the loss value is not multiplied by the size of

the batch. This change is made to correct the

calculation method of the test loss, ensuring that the

average loss of the entire test set is obtained.

The variable name in the

aggregate_global_model function:

In the new code, the update is used as the

temporary variable name in the loop. In the source

code, client_update is used as the temporary variable

name in the loop: This change is just a different

choice of variable names and has no impact on the

code logic. The variable name of the client data

loader is different. In the new code, the dataset is

used as the temporary variable name in the loop. In

the source code, client_dataset is used as the

temporary variable name in the loop:

ICDSE 2024 - International Conference on Data Science and Engineering

572

This change is also just a different choice of

variable names and has no impact on the code logic.

In conclusion, the main changes are the calculation

method of device transfer of the global weights in

the train_client_model function and correcting the

test loss in the test_model function. Other changes

involve only different choices of variable names.

The experimental results are shown in Table 5.

On the MNIST data set, 0.3437 was the mean of the

new model loss value on the dataset. On the MNIST

dataset, the total number of samples as predicted

correctly by the new model was (90.45%). On the

FMNIST dataset, the average of the new model loss

value was 0.5820. On the FMNIST data set, the

proportion of the correct samples predicted by the

new model was (80.15%).

Table 5: Experimental results of the optimized algorithm.

Data set MNIST FMNIST

Experimental result Average loss: 0.3437, Accuracy:

9045/10000 (90.45%)

Average loss: 0.5820, Accuracy:

8015/10000 (80.15%)

4. Client selection:

A new mechanism is introduced to select a

portion of the clients for training instead of training

all clients for each round. This approach is often

called client sampling in federated learning

(Chenyang 2022). Differences between the old and

new codes. A new variable client_fraction was

added to the main function to specify the proportion

of clients selected in each round of training. In each

round, a portion of clients were randomly selected

by the random. Sample method instead of training

all clients. Only the model updates for the selected

client are aggregated into the global model. This

approach can reduce computational resource

consumption and is shown in practice to be able to

improve the efficiency of federated learning without

significantly reducing model performance.

The experimental results on the FMNIST dataset

are shown in Table 11. On the FMNIST data set, the

mean value of the new model loss value was 0.0182.

On the FMNIST data set, the proportion of correct

sample numbers by the new model is (80.08%).

Table 6: Experimental results of the optimized algorithm.

Data set FMNIST

Experimental result Average loss: 0.0203, Accuracy: 7799/10000 (77.99%)

Avera

e loss: 0.0182, Accurac

: 8008/10000 (80.08%)

4.2 Code Efficiency and Performance

Optimization

1. Performance of the data loader:

The old and new codes are the same for most of

the content, which all define a simple fully

connected neural network model, training and

aggregation of client models, and testing the

performance of the global model. However, there are

some differences, mainly focusing on the creation

and configuration of the data loader (DataLoader).

The specific differences are shown as follows:

Use of the num_workers parameter: In the new

code, num _ workers, the parameter, was not used

when creating DataLoader in the old code. The

num_workers parameter determines the number of

child processes used during the data loading process.

If set to 0 (or not set, such as old code), all data

loading is completed in the main process. If set to a

positive integer, the data loading operation is

performed in parallel in a specified number of child

processes.

Value of the 3num_workers parameter: In the

new code, num_workers is set to 4, which means

that the data loading process will try to load in

parallel the data.

These two differences may have an impact on the

speed and efficiency of data loading. Using multiple

work processes can speed up data loading, especially

when processing large datasets and/or running on a

multi-core CPU. However, in some cases, increasing

the number of working processes does not always

result in a performance improvement, as it may

cause overhead in inter-process communication,

especially when the number of working processes

exceeds the number of CPU cores.

The experimental results on the FMNIST dataset

are shown in Table 9. On the FMNIST dataset, the

mean of the new model loss value was 0.0183. On

the FMNIST data set, the proportion of correct

sample numbers by the new model is (80.10%).

Reappearance and Optimization of the FedDyn Algorithm

573

Table 7: Experimental results of the optimized algorithm.

Data set FMNIST

Experimental result Avera

e loss: 0.0183, Accurac

: 8010/10000 (80.10%)

Device allocation optimization typically involves

ensuring that all models and data are on the right

device (e.g., GPU or CPU) and reducing

unnecessary data transfers when global model

weights are shared between multiple clients.

Compared to the source code, the optimization

points in the new code include:

1. The weights of the global model

(global_weights) are now extracted from the global

model at the beginning of each round and used in the

whole round, which avoids re-extracting the weights

from the global model at each client training,

reducing the transmission of data between devices.

2. After the aggregation update, now only update

the weight dictionary (global_weights) of the global

model, rather than reloading the state of the global

model after each client update. This reduces

unnecessary state-loading operations.

3. Finally, after all training rounds, only need to

load the final global weight into the global model

once to test the model performance.

These optimizations reduce memory operations

and data transfer, especially on GPU devices, which

may lead to performance improvements. In the new

code, controling the proportion of clients

participating in each round by the client_fraction

parameter, rather than having all clients trained. This

can reduce the consumption of computational

resources and may improve the generality of the

model. The experimental results on the FMNIST

dataset are shown in Table 7. On the FMNIST data

set, the mean value of the new model loss value was

0.0133. On the FMNIST data set, the proportion of

the correct samples predicted by the new model is

(73.25%).

Table 8: Experimental results of the optimized algorithm.

Data set FMNIST

Experimental resul

Avera

e loss: 0.0133, Accurac

: 7325/10000 (73.25%)

4.3 System Stability and Reliability

1. Exception handling:

To optimize the code and add exception

handling, make changes to ensure that the code can

handle exceptions when it encounters problems and

provide useful feedback. Capture exceptions that can

occur when the data loads, such as network

problems that can occur when downloading the

MNIST dataset. Capture errors that may occur

during model training, such as gradient explosion or

gradient vanishing. Ensure that device-related

abnormalities are captured when using devices (e.g.,

Compute Unified Device Architecture (CUDA)).

When the aggregate model updates, ensure that the

update is valid and that there are no numerical

issues. When testing the model, ensure the data

loads correctly and the evaluation process is not an

error.

In the modified code, several tries...except blocks

were added to capture and process exceptions that

may occur. This way if the code encounters any

problems during execution it will print out an error

message and terminate or skip the error part instead

of causing the entire program to crash. In addition,

KeyboardInterrupt abnormalities were captured so

that the training process could be interrupted by

pressing Ctrl + C.

2. Random seeds:

The new code adds the following parts to set the

random seed rather than the code without the

random seed: A function to set random seeds is

defined, set _ random _ places, which accepts a

parameter seed_value with a default value of 42. The

function of this function is to ensure that the random

number generators of NumPy and PyTorch use the

same seeds such that the same is generated for each

run of the code, guaranteeing the reproducibility of

the experiment. If using CUDA, it also sets random

seeds for all CUDA devices. In the main function,

the set_random_seeds function is called.

In this way, the random seed is set up before the

model is trained.

Except for the above, the rest of the code should

be the same as the code without a random seed. The

random seed is mainly set to ensure that each time,

the initialized weight, the segmentation of the data

set, and other operations relying on the random

number generator can get the same results, thus

making the experimental results reproducible. The

ICDSE 2024 - International Conference on Data Science and Engineering

574

experimental results on the FMNIST dataset are

shown in Table 8. On the FMNIST data set, the

mean value of the new model loss value was 0.0183.

On the FMNIST data set, the number of samples

predicted by the new model was (79.74%).

Table 9: Experimental results of the optimized algorithm.

Data set FMNIST

Experimental resul

Avera

e loss: 0.0183, Accurac

: 7974/10000 (79.74%)

3. Model complexity:

Two hidden layers and the ReLU activation

functions were added. The first hidden layer has 512

neurons, and the second hidden layer has 256

neurons. Use the ReLU as the activation function.

The last layer is a linear layer, used for

classification. The main difference between the old

and new codes lies in the complexity of the neural

network model used. In the new code, a more

complex fully connected neural network model,

ComplexModel, includes three fully connected

layers and the ReLU activation function. While in

the old code, a simple fully connected neural

network model, SimpleModel, is used, which only

contains a fully connected layer with no activation

function.

Here are the specific differences:

1. Different class definitions of the neural

network model.

ComplexModel Contains three fully connected

layers (fc 1, fc 2, fc 3) and the ReLU activation

function.SimpleModel It contains only one fully

connected layer (fc).

2. In the main function main (), the classes of

initialized global and local models are different:

In the new code, use the ComplexModel.In the

old code, use the SimpleModel.

Other parts of the code, including data loading,

client-side model training, model aggregation, and

testing, remain unchanged. This means that the two

codes implement the same federated learning

framework, but the complexity of the neural network

model trained on the client side varies.

The experimental results are shown in Table 10.

On the FMNIST data set, the mean value of the new

model loss value was 0.0182. On the FMNIST data

set, the proportion of correct sample numbers by the

new model is (80.04%).

Table 10: Experimental results of the optimized algorithm.

Data set FMNIST

Experimental result Test set: Average loss: 0.0202, Accuracy: 7806/10000 (78.06%)

Test set: Average loss: 0.0182, Accuracy: 8004/10000 (80.04%)

Through experiments, after optimizing the code,

it is sometimes found that theoretically, the accuracy

of the code will increase, but in fact, the accuracy

does not change significantly, even decreasing rather

than rising. The following is the reason analysis:

1. Learning rate: If the learning rate is not set

appropriately, the model may fail to converge to the

best solution. Too high a learning rate may cause the

model to oscillate near the optimal solution, while

too low a learning rate may lead to too slow

convergence.

2. Regularized Strength: In the code, the alpha

parameter controls the intensity of the regularization

term. If this parameter is set too high, it may lead to

over-penalizing the model weights, thus hindering

the learning process. If too low, it may not

adequately prevent overfitting.

3. Client data distribution: If the data distribution

between clients is uneven (i.e., there is a Non-IID),

the model may perform better on some clients and

perform poorly on other clients, which will affect the

accuracy of the global model.

4. Model update aggregation: Aggregation

methods may affect the performance of the global

model. For example, simple averaging may not be

the optimal aggregation method, especially in cases

where the client data is evenly distributed.

5. Number of training rounds: If the number of

training rounds is too small, the model may not have

enough time to learn the characteristics of the data.

6. Batch size: Batch size affects the accuracy of

gradient estimation and the stability of the training

process. Batch processing too small can cause too

much noise, while batch processing too large can

cause memory problems or slow training.

7. Code change: Any code change can cause

unexpected side effects. For example, if data loading

or preprocessing steps are optimized, data leakage

Reappearance and Optimization of the FedDyn Algorithm

575

may have been accidentally introduced or data

distribution changed.

8. Randchasticity (Randomness): Due to the

randomness of initialization weights, data shuffling

and other factors, multiple runs may get different

results even under the same setting.

Therefore, in practical application, the

optimization of one model should take into account

the influence of one parameter on another parameter.

When optimizing the model, it is best to adjust

multiple parameters at the same time, and the

experimental effect will be better than adjusting only

a single parameter.

5 CONCLUSION

It is worth noting that this study has some limitations.

This experiment only constructed a simple algorithm

model, which is only used as a code repetition of

FedDyn algorithm theory. However, in practice, the

FedDyn algorithm model is much more complex,

and more factors and challenges need to be

considered. For example, issues such as data

distribution, communication delays between clients,

privacy protection, and security all need to be fully

considered. Moreover, to improve the performance

and generalization capabilities of the models, more

complex neural network structures, optimization

algorithms, and regularization techniques may be

required to be used. Alternatively, the datasets in

practical application may be larger and more

complex than the datasets are used in this study. This

requires more computational resources and more

efficient algorithm design to handle large-scale

datasets. In addition, the FedDyn algorithm may also

need to be integrated with other techniques and

methods in practical applications. For example,

problems such as model aggregation, client selection,

and task scheduling in federated learning all need to

be considered comprehensively.

Future studies could further explore the

following aspects:

1. Algorithm optimization: In practical

application, the performance and efficiency of the

FedDyn algorithm can be further optimized. For

example, researchers can explore more efficient

model aggregation methods, client-side selection

strategies, and task scheduling algorithms to

improve the convergence speed and accuracy of the

model.

2. Privacy protection: Privacy protection in

federal learning is an important issue. Future studies

could explore how to train and update models while

protecting user privacy effectively. This may involve

further research in areas such as differential privacy

technology, encryption computing, and secure

multi-party computing.

In conclusion, future studies can further explore

and improve various aspects of the FedDyn

algorithm to improve its performance, privacy

protection, and scalability and apply it to a wider

range of practical scenarios. This will bring greater

development and innovation to the field of federated

learning and distributed machine learning.

REFERENCES

X. Zhao, Z. Mao, H. Li, et al. (2023, March). “Big data

security risk control model based on federated learning

algorithm”. In Second International Conference on

Green Communication, Network, and Internet of

Things, Vol. 12586, (CNIoT, 2022), pp. 178-183.

R. Mónica, V. Haris. Pattern Recognition 148: 110122,

(2024).

X. Li, K. Huang, W. Yang, et al. arXiv preprint arXiv:

1907. 02189, (2019).

L. Yiyang. Donghua University, (2022).

Z. Wenbo. Applied Sciences 13.9, (2023).

D. A. E. Acar, Y. Zhao, R. M. Navarro, et al. arXiv

preprint arXiv:2111.04263, (2021).

L. Bo. Huazhong University of Science and Technology,

(2020).

G. Wirth, P. A. Alves, R. D. Silva. Fluctuation and Noise

Letters, 2350027, (2023).

M. Tivnan, G. J. Gang, W. Wang, et al. Journal of Medical

Imaging, 10(3), 033501-033501, (2023).

L. Chenyang. Computer Science, 49(09): 183-193, (2022).

ICDSE 2024 - International Conference on Data Science and Engineering

576
