Bringing Binary Exploitation at Port 80: Understanding C

Vulnerabilities in WebAssembly

Emmanuele Massidda

, Lorenzo Pisu

, Davide Maiorca

and Giorgio Giacinto

Department of Electronic and Computer Engineering, University of Cagliari, Italy

Keywords:

Web Assembly, Wasm, Software Security, Web Security.

Abstract:

WebAssembly (Wasm) has emerged as a novel approach for integrating binaries into web applications start-

ing from various programming languages such as C, Rust and Python. Despite the numerous claims about

its memory safety, issues such as buffer overﬂow, format strings, use after free, and integer overﬂow have

resurfaced within Wasm. These vulnerabilities can be used to impact web application security, potentially

leading to critical issues like Cross-Site Scripting (XSS) and Remote Code Execution (RCE). Our work aims

to demonstrate how memory-related vulnerabilities in C codes, when compiled into Wasm, can be exploited

for XSS and RCE. Our methodology proposes proof of concepts related to exploiting important stack- and

heap-based vulnerabilities. In particular, we demonstrate for the ﬁrst time that speciﬁc vulnerabilities (such as

format string) can be effectively employed to achieve arbitrary read and write in Wasm contexts. Our results

pose serious concerns about the reliability of Wasm in terms of memory safety, which we believe should be

addressed in the next releases.

1 INTRODUCTION

Presenting itself as a fast, efﬁcient, and safe new bi-

nary instruction format, WebAssembly (Wasm) found

its way into the realm of web applications, enabling

developers to build performance-oriented websites

that run binary code directly in the browser. We-

bAssembly allows using languages such as C/C++,

C#, and Rust to be compiled into Wasm to run on

the web (Wang, 2021; Jazayeri, 2007; Ray, 2023).

This allows developers to recompile existing code for

use in their web applications, enhancing re-usability

and efﬁciency. This technology has already been

implemented in many commercial products, includ-

ing AutoCAD and Figma (Lehmann et al., 2020;

Hilbig et al., 2021), highlighting its growing popu-

larity due to its potential to enhance runtime perfor-

mance (De Macedo et al., 2022; Yan et al., 2021).

Despite its numerous advantages, adopting We-

bAssembly introduces many security challenges, par-

ticularly when porting code written in languages

known for their vulnerability to certain classes of

bugs, such as C (Sti

evenart et al., 2022). The pro-

https://orcid.org/0009-0003-9190-5648

https://orcid.org/0009-0001-0129-1976

https://orcid.org/0000-0003-2640-4663

https://orcid.org/0000-0002-5759-3017

cess of compiling code to WebAssembly, e.g. us-

ing tools like Emscripten (a compiler that uses Clang

and LLVM (Low-Level Virtual Machine) to compile

to WebAssembly and JavaScript (Zakai, 2011)), does

not neutralize the vulnerabilities within the new run-

time environment. On the contrary, their exploita-

tion may create a dangerous link between traditional

binary exploitation and contemporary web exploita-

tion tactics. The risk is ampliﬁed by WebAssembly’s

and Emscripten’s lack of built-in security features

like Address Space Layout Randomization (ASLR)

or stack canaries, which are commonly employed

in compilers for traditional binaries. Although Em-

scripten generates standard compile-time error warn-

ings similar to those of traditional compilers, it does

not detect many vulnerabilities that only emerge dur-

ing runtime, exposing WebAssembly to a wider range

of exploits.

Our work investigates how vulnerabilities typi-

cal of memory-unsafe languages (like C) manifest

within WebAssembly applications when compiled us-

ing Emscripten. Speciﬁcally, we focus on stack and

heap-based vulnerabilities whose exploitation may

lead to obtaining complete control of the target server.

We propose proof of concepts that exploit the char-

acteristics of Wasm to manipulate the program ﬂow

even in unexpected ways. We explain how these vul-

552

Massidda, E., Pisu, L., Maiorca, D. and Giacinto, G.

Bringing Binary Exploitation at Port 80: Understanding C Vulnerabilities in WebAssembly.

DOI: 10.5220/0012852400003767

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 21st International Conference on Security and Cryptography (SECRYPT 2024), pages 552-559

ISBN: 978-989-758-709-2; ISSN: 2184-7711

nerabilities can simplify traditional Web exploitation

techniques, such as Cross-Site Scripting (XSS) and

Remote Code Execution (RCE).

The main contributions of our paper can be sum-

marized as follows:

- Providing a structured presentation of Wasm vul-

nerabilities by systematically categorizing and de-

tailing them, also illustrating their potential to in-

troduce risks on both the client and server sides.

- Providing a clear and reproducible methodology

for better understanding the security aspects of

Wasm and offering a more organized and cohesive

analysis that leads to exploiting previously unex-

plored vulnerabilities (e.g., Format Strings).

- Analyzing six Wasm vulnerabilities, namely

Buffer Overﬂow (BOF), Format string, Use After

Free (UAF), Integer Overﬂow, Improper Valida-

tion of Array Index and Redirecting Indirect Calls,

and develop the related Proof of Concepts (PoC)

that allow to achieve arbitrary read and write. In

particular, we also show how exploiting these vul-

nerabilities can lead to web-related attacks such as

XSS and RCE.

To facilitate the understanding and replication of

our ﬁndings and furnish a practical resource for fur-

ther research, we have made the source code for all

PoCs available on GitHub (Massidda, 2024). We be-

lieve that our work poses major concerns to Wasm

security, and we hope it can inspire possible improve-

ments in its next releases.

2 BACKGROUND

WebAssembly is a binary instruction format for a

stack-based virtual machine designed for efﬁcient ex-

ecution on web browsers (Haas et al., 2017). It pro-

vides a portable compilation target for high-level lan-

guages like C, C++, and Rust, allowing developers

to run their code in a web environment with near-

native performance. Wasm is designed to run along-

side JavaScript, allowing developers to leverage both

languages in a single web application and combining

the performance beneﬁts of WebAssembly with the

ﬂexibility of JavaScript. A WebAssembly implemen-

tation is usually embedded into a host environment

(embedder), which speciﬁes how modules are loaded,

how imports are supplied (including deﬁnitions on the

host side), and how exports can be utilized.

WebAssembly has two concrete representations:

the binary format and the more human-readable text

format, called ”wat”. Both representations map to a

common structure, described in the form of an ab-

stract syntax.

The text representation of Wasm binaries (wat)

can be visualized directly from the browser, which

facilitates and speeds up the reverse engineering and

debugging processes.

1 ( module

2 ( fu nc $ mai n

3 i 3 2 . c o n s t 7 ; ; Push t h e numb er 7 on t h e s t a c k

4 i 3 2 . c o n s t 3 ; ; Push t h e numb er 3 on t h e s t a c k

5 i 3 2 . add ; ; Adds t h e two numbers , l e a v i n g 10 on

t h e s t a c k

6 drop ; ; Remove t h e v al u e a t t h e t o p o f t h e s t a c k

7 )

8 ( s t a r t $m ain )

9 )

Listing 1: WebAssembly function - wat format.

Listing 1, showcases the code snippet of a simple

Wasm function that pushes two values on the stack

and sums them up, subsequently removing the result

from the stack.

3 RELATED WORKS

Two main works explore C attacks in Wasm present-

ing PoCs. One (Lehmann et al., 2020), in which the

authors identify three situations from which an attack

within a Wasm module can be constructed: obtaining

a write primitive, overwriting data, and triggering un-

expected behaviour. Another (McFadden et al., 2018)

offers a broader view of the potential risks of com-

piling code from memory-unsafe languages to We-

bAssembly.

An attack that has not yet been explored thor-

oughly in current works is format strings. Lehmann

et al. brieﬂy mention this issue, whereas McFadden

et al. offer a PoC demonstrating successful exploita-

tion to leak data from the stack. Despite this success,

their attempts to achieve a write primitive were unsuc-

cessful due to JavaScript raising an exception, high-

lighting the need to explore its exploitation process.

In Subsection 4.2, we provide a PoC showing how to

successfully exploit this vulnerability to obtain arbi-

trary writing in linear memory.

Current works also highlight two critical security

problems of WebAssembly modules, which can sim-

plify the exploitation process compared to traditional

architectures. Firstly, the entirely deterministic ap-

proach to memory allocation, speciﬁcally the absence

of Address Space Layout Randomization (ASLR),

signiﬁcantly simpliﬁes the process of executing tar-

geted modiﬁcations to data in the heap. Therefore,

even a linear stack-based overﬂow, if long enough,

can lead to data corruption in the heap. Secondly,

Bringing Binary Exploitation at Port 80: Understanding C Vulnerabilities in WebAssembly

553

WebAssembly has no mechanism that makes data im-

mutable in linear memory, making ”constant” data

possibly modiﬁable, including non-scalar constants

and string literals.

Many other attacks are described in the papers

above, such as Integer Overﬂow, Stack Overﬂow,

Heap Metadata Corruption, redirecting indirect calls,

injecting code into the host environment, or overwrit-

ing application-speciﬁc data. We encourage the read-

ers to delve into the aforementioned papers to gain a

comprehensive understanding of these vulnerabilities.

4 METHODOLOGY

In this section, we will describe our methodology to

create vulnerable code for various C vulnerabilities

and their subsequent exploitation.

Table 1: Overview of Proof of Concepts implemented. The

headings are Client-Side (CS), Server-Side (SS), Data Leak

(DL), Data OVerwrite (DO), Unexpected Behaviour (UB).

The ﬁrst column has Buffer Overﬂow (BOF), Format String

(FS), Use After Free (UAF), Improper Array Index Vali-

dation (IAIV), Integer OVerﬂow (IO), Redirecting Indirect

Calls (RIC).

Vulnerability CS SS DL DO UB

BOF → XSS ✓ - - ✓ -

BOF → RCE - ✓ - ✓ -

FS ✓ ✓ ✓ ✓ -

FS → XSS ✓ - ✓ ✓ -

UAF - ✓ - ✓ -

IAIV - ✓ - ✓ -

IO - ✓ ✓ - -

RIC ✓ ✓ - - ✓

4.1 Buffer Overﬂow

The objective of this PoC was to build an application

vulnerable to a stack-based buffer overﬂow (BOF),

enabling an attacker to gain an out-of-bounds write

primitive and perform an XSS or RCE attack. The ap-

plication asks the user for input, handling it in an un-

safe way that introduces the buffer overﬂow vulnera-

bility. Furthermore, the user’s input is used inside the

function EM ASM(), which allows embedding inline

JavaScript Code inside the C language. This function

can pave the way to new security issues, especially

if combined with the eval function. If an attacker

manages to gain control over the arguments passed to

EM ASM() (and therefore to eval) they could poten-

tially inject malicious scripts, leading to XSS on the

client and RCE on the server. Notably, the impact of

RCE is even more critical, allowing an attacker to in-

ject arbitrary code to execute on the server.

4.1.1 Proof of Concept Overview

The PoC features an input ﬁeld that requests the user’s

name. This input is subsequently passed to a C func-

tion called greetings, detailed below:

Listing 2: greetings Function - PoC for buffer overﬂow

v o id g r e e t i n g s ( c ha r

name ) {

c h a r s ys c md [ 7 0 ] = ” document . w r i t e (’< h1>Welcome t o

WebAssembly !< / h1 >’) ” ;

c h a r g r e e t [ 2 0 ] ;

s t r n c p y ( g r e e t , name , s t r l e n ( name ) ) ;

EM ASM( {

e v a l ( UT F8 To String ( $0 ) ) ;

do cu me nt . w r i t e (”<h2>H ell o , ” + UTF8ToStrin g ( $1 ) +

”</h2 >”) ;

} , sy s cmd , g r e e t ) ;

}

This function uses strncpy to copy user input

to a buffer named greet on the stack. Stack-based

buffer overﬂow occurs because the input length is

used as strncpy’s third parameter, potentially over-

writing adjacent memory if the input exceeds the

buffer size. The function doesn’t limit copied charac-

ters to the greet buffer size. Another string, sys cmd,

stores JavaScript code passed to EM ASM(). Over-

writing sys cmd allows an attacker to inject arbi-

trary JavaScript code, possibly performing a Cross-

Site Scripting attack. For the RCE BOF, the applica-

tion has the same structure. There are only two dif-

ferences from the client-side PoC: sys cmd calls the

console.log function instead of document.write,

and the same happens inside the call to EM ASM.

4.1.2 Exploitation

Our attack strategy focused on ﬁnding the length of

the buffer and then overwriting the content of the

variable sys cmd, the argument of the eval function.

Supposing we are an attacker that does not have

access to the buffer length, we can send a long

sequence of characters (e.g., the 40 characters string

aaaabaaacaaadaaaeaaafaaagaaahaaaiaaajaaa)

with the aim of triggering an error that will reveal the

size of our buffer. The previous sequence will trigger

a iaaajaaa is not defined error, conﬁrming

that the ﬁrst 32 characters had ﬁlled greet and the

following 8 overwritten sys cmd.

With this information, it’s possible to craft a pay-

load consisting of a 32-character sequence followed

by JavaScript code to inject and execute. The pay-

load below injects the code alert(’XSS!’) inside

the WebAssembly module, triggering its execution:

AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAal e rt ( ’

XSS!’);

SECRYPT 2024 - 21st International Conference on Security and Cryptography

554

An essential observation regarding this vulnera-

bility is that stack-based buffer overﬂows can also

compromise data in the heap, requiring just a slightly

larger payload depending on the size and the mod-

ule’s structure. This aspect makes attacks more feasi-

ble compared to the more complex scenarios in tradi-

tional x86-64 architectures.

In a similar manner, we can craft a payload that

exploits a buffer overﬂow on a server-side application

with a payload such as AAAAAAAAAAAAAAAAAAAAAAA

AAAAAAAAconst{execSync}=require(’child p ro

cess’);console.log(execSync(’ls’).toStrin

g());//. In this case we execute the ls command

as a simple proof of concept. The choice of ls was

purely illustrative, meant to highlight the potential for

executing arbitrary system commands through the ex-

ploited vulnerability.

4.2 Format String Vulnerability

This section showcases two Proofs of Concept high-

lighting the risks associated with the format string

vulnerability in WebAssembly, both in client-side

and server-side environments. Additionally, we com-

pare the differences between the two versions of Em-

scripten employed, ﬁnding important distinctions in

the memory’s structure, which led to the creation of

two distinct payloads, one for each version. The for-

mat string vulnerability is introduced by bad coding

practices, where the user’s input is passed directly

to the printf function, like p rintf(user buffer

) instead of printf("%s",user buffer). If an at-

tacker injects format speciﬁers like %p or %x inside the

buffer, the printf function will print values found on

the stack, starting from the location of the printf

pointer, therefore leaking data from memory. The

number of values leaked corresponds directly to the

number of format speciﬁers provided by the attacker.

In addition, there exists a format speciﬁer (%n) that, if

leveraged, can give attackers arbitrary write to mem-

ory. The intended usage of this format speciﬁer is to

write the number of characters printed so far on the

standard output into a variable. However, if a variable

is not provided, the printf function will write such

value into a memory address placed at a speciﬁc stack

offset starting from the printf pointer. To direct this

write operation to a particular offset ”x”, the %x$n

syntax comes into play. For instance, a payload like

ABC%3$n would write the value 0x3 (i.e. the length

of ”ABC”) to the address contained in the third ele-

ment from the stack starting from the printf pointer

if such address is valid. Figure 1 showcases this sce-

nario.

Figure 1: Example of writing data in memory using %n.

4.2.1 Proof of Concept Overview

The application (the PoC code can be found on our

repository) displays an input ﬁeld that asks the user

for a password, which is then passed as an argu-

ment to a function named check password, where it

is compared with the correct password stored in the

stack. If the user inserts the wrong password, then

the program exposes itself to a format string vulner-

ability by directly passing the user’s input (pass) to

the printf function (printf(pass)). When a We-

bAssembly code that is compiled from C calls the

printf function, it automatically redirects this output

to the console.log function in JavaScript, allowing

us to see the output.

This PoC aims to create an exploit using the for-

mat string vulnerability, overwriting the password

stored in the stack. Speciﬁcally, we aim to over-

write the current password (”supersecretpassword”)

with the letter ”B”. Our experiments were conducted

using Emscripten version 3.1.6 on the client-side ap-

plication and Emscripten 3.1.52 on the server-side ap-

plication (Node.js).

4.2.2 Exploitation

We initiated the client-side exploitation focusing on

leaking data from memory. By crafting a payload

ﬁlled with %p format speciﬁers, each separated by the

”|” character for readability. As Figure 2 shows, the

browser’s console leaked stack values, among which

we ﬁnd we ﬁnd the correct password, represented in

hexadecimal.

Figure 2: Format String - Arbitrary Read (the highlighted

values are the hex representation of the password).

Using the WebAssembly Binary Toolkit (WABT),

we converted our WebAssembly module into the

Bringing Binary Exploitation at Port 80: Understanding C Vulnerabilities in WebAssembly

555

WebAssembly Text (WAT) format through the

wasm2wat tool. This conversion allowed us to ex-

amine the internal memory layout of the module, dis-

covering that the password was stored at the mem-

ory offset 1024. The next phase of our attack strat-

egy focused on obtaining a write primitive, achiev-

able through the format speciﬁer %n. To overwrite the

password at the address 1024, we ﬁrst need to store

the value 0x400 (1024 in hexadecimal) into a known

offset from the printf pointer. To achieve that, we

craft a payload composed of 1024 characters followed

by %2$n|%p|: given that the offset 2 initially con-

tains the value 0 (Figure 2), this payload will write

the value 0x400 at address 0.

The ﬁnal step involved writing the ASCII value of

”B” (0x42 in hexadecimal or 66 in decimal) to ad-

dress 1024. This is achieved with a payload formed

by a 66-character sequence followed by %n, thereby

writing 0x42 to the address found at the ﬁrst offset

(which is 1024), effectively overwriting the password

with the letter ”B”.

After executing this attack and deploying the crafted

payloads, we can bypass the password check by sub-

mitting the character ”B”.

The exploitation process for the server-side appli-

cation is similar to the client-side, with two key dif-

ferences. Firstly, the output of the ‘printf‘ function

is shown on the server console, not in the browser.

This prevents attackers from directly leaking stack

data or accessing the WebAssembly module to locate

the password’s offset. However, overwriting memory

is still possible, and attackers could perform a ”blind”

attack to ﬁnd the correct offset via brute force. The

second difference is related to the Emscripten version

used. To run a Node.js application that loads Wasm

modules, we needed to upgrade to Emscripten release

3.1.52. After recompiling the C code and converting

the Wasm module to the readable WAT format, we ob-

served a signiﬁcant shift in the password’s offset from

1024 to 65536, requiring a much larger payload for an

attack.

This information enabled us to craft a payload ca-

pable of writing the value 65536 (0x10000 in hex-

adecimal) into the ﬁrst offset, allowing us to overwrite

the password at the correct offset. Given the substan-

tial size of this payload, an attacker might encounter

buffer size constraints. A workaround for this issue

involves using the format speciﬁer %65536c, which

prints the speciﬁed amount of characters without ex-

ceeding buffer limits.

Contrary to previous works (McFadden et al.,

2018), we successfully exploited the format string

vulnerability within the WebAssembly environment,

managing to overwrite sensitive data in memory. The

predictability of memory address locations in We-

bAssembly, due to the lack of Address Space Lay-

out Randomization (ASLR), considerably facilitates

the exploitation process. In contrast, exploiting envi-

ronments with ASLR is more challenging due to the

randomized memory addresses. This highlights the

importance of addressing memory layout predictabil-

ity in WebAssembly’s modules.

Moreover, we observed that including the %p spec-

iﬁer is crucial for the payload %2$n|%p to success-

fully write to memory. Although this payload aims to

write to memory using the %n speciﬁer, the %p speci-

ﬁer, typically used for reading data, appears to be nec-

essary for the write operation to proceed. Omitting

the %p speciﬁer results in the payload failing to write

to memory. The exact reasons behind this remain an

area for further investigation, highlighting an intrigu-

ing aspect of format string vulnerabilities within We-

bAssembly.

4.3 Use after Free

In this PoC, we present a server-side application ex-

hibiting a Use After Free (UAF) vulnerability, high-

lighting the dangers associated with heap manage-

ment errors when developing WebAssembly applica-

tions.

4.3.1 Proof of Concept Overview

Before diving into the details of the front-end side of

the application, we focus on a snippet of the vulnera-

ble C code, which can be seen in Listing 3.

Listing 3: Code of the PoC for the Use After Free vulnera-

bility

t y p e d e f s t r u c t {

c h a r a [ 3 0 ] ;

c h a r f l a g [ 5 ] ;

} o b j e c t ;

o b j e c t

x ;

b o ol c h e c k p a s s w o r d ( c h ar

p a s s ) {

r e t u r n ( s t r c m p ( p a ss , x−> f l a g ) == 0 ) ;

}

v o id i n i t ( ) {

x = m a l l o c ( s i z e o f ( o b j e c t ) ) ;

s t r n c p y ( x−> f l a g , ” wasm ” , 5) ;

}

This code snippet deﬁnes a structure named ”ob-

ject”, which has a size of 35 bytes. The init func-

tion dynamically allocates memory for an ”object”

instance, storing its address in the variable ”x” and

initializing the ”ﬂag” ﬁeld with the string ”wasm”.

However, the check password function compares

this ”ﬂag” ﬁeld with user input, potentially after its

memory has been freed, thereby introducing a Use

After Free (UAF) vulnerability into the application.

SECRYPT 2024 - 21st International Conference on Security and Cryptography

556

Additionally, the function free memory is designed

to deallocate the memory assigned to the variable x,

resulting in x becoming a dangling pointer. Mean-

while, the alloc object function allows allocating

heap memory of any speciﬁed size using malloc.

4.3.2 Exploitation

This attack aims to modify the existing password by

overwriting the data in the ”ﬂag” ﬁeld of the ”x” vari-

able. The initial step involves deallocating the heap

chunk allocated for ”x”, by invoking free memory.

Subsequently, a call to malloc requesting a chunk of

a similar size as the one just freed results in allocat-

ing that same memory space, giving us access to the

released memory. To exploit this, we allocate a new

chunk of 35 bytes, identical to the size of ”x”, con-

taining the payload allowing us to overwrite the pass-

word. We craft a payload composed of a 30-character

sequence that ﬁlls the ”a” ﬁeld buffer, followed by the

string ”pass”, which will be the new password inside

the ”ﬂag” ﬁeld.

Summarizing, the exploitation process is com-

posed of 3 steps: (i) Free the chunk of ”x”; (ii)

Allocate a 35-byte object containing the payload

AAAAAAAAAAAAAAAAAAAAAAAAAAAAAApass; (iii) Au-

thenticate using the new password ”pass”.

We demonstrated that, if leveraged, this vulnera-

bility can cause damage within the WebAssembly en-

vironment. Depending on the application’s structure,

this vulnerability can introduce many other risks, such

as possible data leaks or memory corruption. Another

common vulnerability in heap memory is the ”Dou-

ble Free”, which we leave for future research within

WebAssembly.

4.4 Improper Array Index Validation

When an application fails to properly check or val-

idate the indices used to access elements within an

array, it can open the way to unauthorized access to

sensitive data, corruption of data, crashes, and execu-

tion of arbitrary code.

4.4.1 Proof of Concept Overview

The application provides users with two functionali-

ties: verifying their entered password and modifying a

character in their password by choosing an index and

a new character. However, the application uses the

provided index to access the user’s password, stored

in heap memory along with the admin password and

another password called unreachable password,

without any checks to ensure the index is within valid

boundaries.

Listing 4: Code snippet of the PoC for Improper Array In-

dex Validation

c h a r u n r e a c h a b l e p a s s w o r d [ 3 0 ] = ” u n r e a c h a b l e p a s s w o rd ” ;

c h a r u s e r p a s s w o r d [ 3 0 ] = ” t h i s i s y o u r p a s s w o r d ” ;

c h a r a d m i n p a ssw o r d [ 3 0 ] = ” s u p e r s e c r e t p a s s w o r d ” ;

v o id c h a n g e u s e r p a s s w o r d c h a r a c t e r ( i n t i n dex , c h a r

new c h a r ) {

u s e r p a s s w o r d [ index ] = new char ;

}

Listing 4 displays the code snippet where the three

passwords are allocated in the heap memory, along-

side the function that allows modifying the user’s

password.

4.4.2 Exploitation

Our experiments aimed to access memory indices out-

side the valid range of the user’s password, which is

between 0 and 29, with the intent to overwrite adja-

cent data in memory.

Our initial approach involved accessing indices

greater than 29 to potentially overwrite the admin’s

password stored after the user’s password in mem-

ory. We successfully overwrote the admin’s pass-

word characters starting from index 32. This al-

lowed us to modify the password and log in as ad-

mins. A strategy is to change the character at index

32 to ’A’ and set the next character to a null byte, en-

abling login with just ’A’. The second experiment in-

volved accessing indices below 0, aiming at overwrit-

ing the unreachable password. This experiment

was unsuccessful because accessing negative indices

in WebAssembly will trigger a ”memory access out

of bounds” runtime error. Unlike in languages like C,

where accessing negative indices will not necessarily

lead to a crash in the program, WebAssembly throws

this error to prevent unsafe memory operations.

This PoC highlighted the critical impact of

unchecked index boundaries, which enabled overwrit-

ing sensitive data like the admin’s password. How-

ever, WebAssembly’s protection against negative in-

dex exploitation, marked by the ”memory access out

of bounds” error, is a key security feature. Despite

this, our next Proof of Concept outlines a scenario

that, in a way, bypasses these strict memory access

controls.

4.5 Integer Overﬂow

In this Proof of Concept, we explore the Integer Over-

ﬂow vulnerability within a WebAssembly applica-

tion. Integer Overﬂow occurs when an integer vari-

able exceeds the maximum size of the integer type,

causing unexpected behaviour. In most systems, un-

signed integers are represented by 4 bytes (32 bits),

meaning that the maximum representable value is

Bringing Binary Exploitation at Port 80: Understanding C Vulnerabilities in WebAssembly

557

4,294,967,295 (2

− 1). Such value, in the C lan-

guage, is stored within the macro ”INT MAX”. In-

crementing by 1 this maximum value, the integer

overﬂows and wraps around to 0 due to the limited

number of bits. This PoC aims to demonstrate how

such an overﬂow can be exploited to compromise the

application’s integrity or security.

4.5.1 Proof of Concept Overview

Listing 5: Code snippet of the PoC for Integer Overﬂow.

c h a r s u p e r s e c r e t p a s s w o r d [ 5 ] = ” pas s ” ;

c h a r u s e r s [ 5 ] [ 2 0 ] = {

” g u e s t

u s e r ” ,

” gu e s t p a s s w o r d ” ,

” admin ” ,

” admi n p a s s wor d ”

} ;

c h a r

g e t a r r a y e l e m e n t ( i n t i n d e x ) {

p r i n t f ( ” A c c e s s i n g i n d e x : %d \n ” , i n d e x ) ;

r e t u r n u s e r s [ i n d e x ] ;

}

The C code in Listing 5 initializes a password in heap

memory, followed by an array of ﬁve strings. The

application prompts the user for an index, restraining

the input to values greater than 0 and not equal to 3.

This check is performed inside the Node.js code.

4.5.2 Exploitation

We begin our exploration by providing the value

INT MAX + 1 to the application, causing the integer

variable to overﬂow and wrap to 0, enabling us to ac-

cess and print the string in the index 0. Subsequently,

we input the number INT MAX + 4, obtaining access

to the ”forbidden” index 3, and printing the content of

the admin’s password. This PoC demonstrates the po-

tential of integer overﬂow to compromise application

security. This ﬁnding underscores the need for rig-

orous boundary checks in WebAssembly application

development. The testing phase of this PoC led to a

notable ﬁnding: accessing the array of strings using

a negative index does not trigger the ”memory access

out of bounds” error, allowing the leakage of the pass-

word instantiated before the array of strings.

4.6 Redirecting Indirect Calls

Indirect calls in WebAssembly are used to imple-

ment function pointers and virtual functions. The

call indirect instruction pops a value from the

stack, using it as an index in the table section and in-

voking the speciﬁed function if the signature matches.

The last PoC presented in this paper demonstrates

how an attacker could change the normal control ﬂow

of a WebAssembly application by redirecting indirect

calls.

4.6.1 Proof of Concept Overview

Similar to previous PoCs showcased in this paper, this

application prompts the user for a password.

Listing 6: Code of the PoC for Redirecting Indirect Calls -

Server-Side.

b o ol c h e c k p a s s w o r d ( c h ar

i n p u t ) {

b o ol (

l o g i n h a n d l e r ) ( v o i d ) = 0 ;

c h a r p a s swo r d [ 1 0 ] ;

s t r c p y ( p as swo rd , i n p u t ) ;

i f ( l o g i n h a n d l e r == 0 ) {

i f ( st r c m p ( p as swo rd , ” s e c r e t p a s s ” ) == 0 )

l o g i n h a n d l e r = ( b o o l (

) ( void ) )&a d m i n p a n e l ;

e l s e

l o g i n h a n d l e r = ( b o o l (

) ( void ) )&u s e r p a n e l ;

}

r e t u r n l o g i n h a n d l e r ( ) ;

}

Listing 6 illustrates the check password func-

tion in C, highlighting its vulnerability. This function

employs a function pointer named login handler,

which is conditionally set to the address of either the

admin panel or user panel function, based on the

user’s password input. The code introduces a buffer

overﬂow vulnerability at line 5, caused by using the

strcpy function, which lacks boundary checks.

The conditional assignment of function pointers,

as seen in the code, results in indirect function calls

within the WebAssembly environment.

4.6.2 Exploitation

To redirect the program’s control ﬂow, we ex-

ploited the buffer overﬂow vulnerability by overwrit-

ing the login handler pointer with the address of

the admin panel function, effectively bypassing the

password veriﬁcation process.

The payload we designed exploits the buffer over-

ﬂow by starting with ten ”A” characters to ﬁll the

user’s buffer and reach the function pointer, followed

by String.fromCharCode(1). This last byte over-

writes the ‘login handler‘ with ”1”, which is the

address of admin panel, effectively redirecting the

program’s execution to bypass the password check.

Low numerical addresses in WebAssembly, such

as the admin panel function’s address located at ad-

dress 1, increase security risks. Unlike traditional

systems where ASLR complicates the exploiting pro-

cess by randomizing addresses, WebAssembly’s low

and deterministic addresses simplify crafting exploits,

highlighting the need for stronger security measures

in Wasm.

SECRYPT 2024 - 21st International Conference on Security and Cryptography

558

Table 2: Comparison of Vulnerability Coverage between our work and the state of the art.

Lehmann et al. McFadden et al. Our work

Vulnerability Mention Explain PoC Mention Explain PoC Mention Explain PoC

Buffer Overﬂow (BOF) ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓

Heap Metadata Corruption ✓ ✓ ✓ ✓ - - ✓ - -

BOF → XSS ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓

BOF → RCE ✓ ✓ ✓ - - - ✓ ✓ ✓

Integer Overﬂow ✓ - - ✓ ✓ - ✓ ✓ ✓

Format String ✓ - - ✓ ✓ ✓

✓ ✓ ✓

Format String → XSS - - - - - - ✓ ✓ ✓

Format String → RCE - - - - - - ✓ ✓ -

Use After Free ✓ - - ✓ - - ✓ ✓ ✓

Double Free ✓ - - ✓ - - ✓ - -

Overwriting Constant Data ✓ ✓ - - - - ✓ - -

Redirecting Indirect Calls ✓ ✓ - ✓ ✓ - ✓ ✓ ✓

Redirecting Indirect Call → XSS - - - ✓ ✓ ✓ - - -

Redirecting Indirect Call → RCE - - - ✓ ✓ ✓ - - -

Improper Validation of Array Index - - - - - - ✓ ✓ ✓

McFadden et al. provided a PoC for the format string vulnerability without achieving arbitrary writing.

5 CONCLUSIONS

Our ﬁndings indicate a crucial need to implement

stronger security measures to protect WebAssembly

applications against potential exploits. Compiling

WebAssembly from memory-unsafe languages like C

introduces many security concerns, possibly enabling

attackers to use traditional binary exploitation tech-

niques to attack web applications. Such attack tech-

niques could signiﬁcantly impact real-world scenar-

ios, particularly when developers introduce vulner-

abilities by reusing code from other projects with-

out conducting adequate security checks. Future re-

search may focus on the study and development of re-

newed security measures inside WebAssembly com-

pilers, possibly implementing traditional mitigation

techniques such as ASLR or stack canaries. We also

plan to expand our research towards more complex

vulnerabilities and attack strategies and to examine

how WebAssembly security may impact other tech-

nologies.

ACKNOWLEDGEMENTS

This work was partially supported by project SER-

ICS (PE00000014) under the NRRP MUR program.

This work was also supported by project ”SUS-

TAIN - ﬂexible Sensors for secUre and truSTed

crowdsensing environmentAl applicatioNs”, − CUP

F25F21002720001 (D.M. 737/2021 - Interdisci-

plinary research initiatives on transversal topics for

PNR). Both projects are funded by the European

Union− NextGenerationEU.

REFERENCES

De Macedo, J., Abreu, R., Pereira, R., and Saraiva, J.

(2022). WebAssembly versus JavaScript: Energy and

runtime performance. In 2022 (ICT4S). IEEE.

Haas, A., Rossberg, A., Schuff, D. L., Titzer, B. L., Hol-

man, M., Gohman, D., Wagner, L., Zakai, A., and

Bastien, J. (2017). Bringing the web up to speed with

WebAssembly. In Proceedings of the 38th ACM SIG-

PLAN PLDI. ACM.

Hilbig, A., Lehmann, D., and Pradel, M. (2021). An empir-

ical study of real-world webassembly binaries: Secu-

rity, languages, use cases. In Proceedings of the Web

Conference 2021. ACM.

Jazayeri, M. (2007). Some trends in web application de-

velopment. In Future of Software Engineering (FOSE

’07). IEEE.

Lehmann, D., Kinder, J., and Pradel, M. (2020). Everything

old is new again: Binary security of {WebAssembly}.

Massidda, E. (2024). https://github.com/manumassi/vul

n wasm.

McFadden, B., Lukasiewicz, T., Dileo, J., and Engler, J.

(2018). Security chasms of wasm. NCC Group

Whitepaper.

Ray, P. P. (2023). An overview of webassembly for iot:

Background, tools, state-of-the-art, challenges, and

future directions. Future Internet, 15(8).

Sti

evenart, Q., De Roover, C., and Ghafari, M. (2022). Se-

curity risks of porting c programs to webassembly. In

Proceedings of the 37th ACM/SIGAPP SAC. ACM.

Wang, W. (2021). Empowering web applications with

webassembly: Are we there yet? In 2021 36th

IEEE/ACM (ASE). IEEE.

Yan, Y., Tu, T., Zhao, L., Zhou, Y., and Wang, W. (2021).

Understanding the performance of webassembly ap-

plications. In 21st ACM IMC. ACM.

Zakai, A. (2011). Emscripten: an LLVM-to-JavaScript

compiler. In OOPSLA ’11.

Bringing Binary Exploitation at Port 80: Understanding C Vulnerabilities in WebAssembly

559
