Comparison of Access Control Approaches for Graph-Structured Data

Aya Mohamed

1,2 a

, Dagmar Auer

1,2 b

, Daniel Hofer

1,2 c

and Josef K

ung

1,2 d

Institute of Application-oriented Knowledge Processing, Johannes Kepler University Linz, Linz, Austria

LIT Secure and Correct Systems Lab, Johannes Kepler University Linz, Linz, Austria

Keywords:

Access Control, Authorization Policy, ABAC, ReBAC, Graph-Structured Data, Property Graph.

Abstract:

Access control is the enforcement of the authorization policy, which deﬁnes subjects, resources, and access

rights. Graph-structured data requires advanced, ﬂexible, and ﬁne-grained access control due to its complex

structure as sequences of alternating vertices and edges. Several research works focus on protecting property

graph-structured data, enforcing ﬁne-grained access control, and proving the feasibility and applicability of

their concept. However, they differ conceptually and technically. To gain a profound overview of the current

state of research, we study works from our systematic literature review on authorization and access control

for different database models in addition to recent ones. Based on deﬁned criteria, we exclude research works

which do not protect graph-structured data, have coarse-grained approaches, consider models other than the

property graph model, or have no proof-of-concept implementation. The latest version of the remaining works

are discussed in detail in terms of their access control approach as well as authorization policy deﬁnition and

enforcement. Finally, we analyze the strengths and limitations of the selected works and provide a compar-

ison with respect to different aspects, including the base access control model, open/closed policy, negative

permission support, and datastore-independent enforcement.

1 INTRODUCTION

Access control ensures data security by protecting

assets and private information against unauthorized

access. It refers to enforcing authorization policies,

which specify access rights in terms of accessing sub-

ject, requested resource and performed action.

In graphs, data are structured as vertices con-

nected by edges to represent the relationships be-

tween objects. Vertices and edges are stored as en-

tities in graph databases, optionally including prop-

erties as key-value pairs. Fine-grained access con-

trol for graph-structured data refers to protecting ver-

tices and edges at the attribute level. Established

graph databases currently support role-based access

control (RBAC), while the latest research works ad-

dress relationships in graph-structured data, including

attributes on vertices and edges.

With this paper, we aim to discuss these latest

research works to get a profound overview of cur-

rent research approaches. The results provide guid-

https://orcid.org/0000-0001-8972-6251

https://orcid.org/0000-0001-5094-2248

https://orcid.org/0000-0003-0310-1942

https://orcid.org/0000-0002-9858-837X

ance for our further research. We select the following

access control approaches for graph-structured data

from our systematic literature review (SLR) on access

control for different database models, and include fur-

ther recent works. Rizvi and Fong (2018) extended

the relationship-based access control model (ReBAC)

to support attributes in policy speciﬁcation and en-

forcement. Mohamed et al. (2023a) presented a ﬂexi-

ble, ﬁne-grained authorization policy speciﬁcation for

graph-structured data and datastore-independent en-

forcement. Furthermore, Hofer et al. (2023a,b) pro-

posed an approach to enforce ﬁne-grained access con-

trol by rewriting Cypher queries using an Abstract

Syntax Tree (AST). Bereksi Reguig et al. (2024) re-

cently introduced an approach based on the Neo4j

access control model to apply attribute-based access

control (ABAC). We study the works on conceptual

and technical level by answering the following re-

search questions:

RQ1. What are the current access control approaches

in the context of graph-structured data?

RQ2. How are the authorization policies deﬁned and

enforced in each work?

RQ3. How are the feasibility and applicability of the

proposed approaches proved?

576

Mohamed, A., Auer, D., Hofer, D. and Küng, J.

Comparison of Access Control Approaches for Graph-Structured Data.

DOI: 10.5220/0012861500003767

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 21st International Conference on Security and Cryptography (SECRYPT 2024), pages 576-583

ISBN: 978-989-758-709-2; ISSN: 2184-7711

RQ4. What are the strengths and limitations for each

approach?

The paper is structured as follows. In Section 2,

we describe our method for selecting related works.

In Section 3 to 6, we discuss the conceptual approach,

deﬁnition and enforcement of authorization policy,

and implementation details for the selected works re-

spectively. We compare and analyze the approaches

in Section 7. The paper concludes with a summary

and an outlook on future work in Section 8.

2 SELECTION METHOD

In our SLR of authorization and access control for

different database models (Mohamed et al., 2023b),

we identiﬁed a list of research works related to the

graph database model. We additionally include recent

works as listed in Table 1. For each work, we indi-

cate whether or not it is included according to our se-

lection criteria: protecting property graph-structured

data, ﬁne-grained authorization policy, and applied in

graph datastore.

Table 1: Research works in access control for graphs.

Research works

Protect

property graph

Fine-

grained

Applied

Rizvi and Fong (2018) ✓ ✓ ✓

Morgado et al. (2018) × × ✓

Bertolissi et al. (2019) × ✓ ✓

Jin and Kaja (2019) × ✓ ✓

Mohamed et al. (2020) ✓ ✓ ✓

Valzelli. et al. (2020) ✓ × ✓

Chabin et al. (2021) ×

✓

Clark et al. (2022) ✓ ✓

Hofer et al. (2023a) ✓ ✓ ✓

Bereksi Reguig et al. (2024) ✓ ✓ ✓

Based on the RDF graph model

For vertices but not edges

Morgado et al. (2018) present a model-based

approach using metadata with authorization rules

to control access in applications that use a graph

database. Their security model uses a predeﬁned

schema for the vertices as a plugin in Neo4j. This

approach is not ﬁne-grained, as it only considers pro-

tection on vertex level. The focus is on the meta

model and architecture rather than applying it to pro-

tect graph-structured data.

Bertolissi et al. (2019) introduce an access con-

trol framework for secure data fusion in cooperative

systems. Authorization policies are represented in a

provenance graph, which relates artefacts (vertices) to

depict their provenance through a system. They pro-

vide the formal semantics of the proposed language

and use the extensible access control markup lan-

guage (XACML) to demonstrate provenance-based

access constraints in ABAC policies. Jin and Kaja

(2019) use graphs to represent the XACML authoriza-

tion policy language model. An authorization policy

graph is constructed by parsing XACML policy ﬁles.

In addition duplicates and conﬂicts are handled before

generating the Cypher query statements. XACML re-

quests are processed as queries to Neo4j, which stores

the policy graph. Both approaches do not consider

protecting graph-structured data.

Chabin et al. (2021) propose an access control sys-

tem for graph-based models with schema constraints,

authorization rules to protect the data and user con-

text rules. To enforce the constraints, modules for

rewriting, planning and executing queries in parallel

are provided. Roles can have ﬁne-grained access rules

on vertices, and clearance levels can be associated to

roles and resources. However, each user has only a

single role. Furthermore, only type and direction, but

no attributes can be speciﬁed for edges in rules. This

work is not considered in our comparison as it is not

designed to deal with property graphs, but rather the

resource description framework (RDF) graph model.

Valzelli. et al. (2020) introduce a property graph

model, which combines discretionary access con-

trol, mandatory access control and RBAC to pro-

tect knowledge graphs. Positive and negative autho-

rizations can be speciﬁed using authorization edges

between subjects and resources. RDF concepts are

translated into a property graph query. It is imple-

mented using Tinkerpop. We excluded RBAC ap-

proaches because it is not ﬁne-grained and supported

in many graph databases, such as Neo4j, ArangoDB

and Azure Cosmos DB.

Clark et al. (2022) deﬁne the formal language and

uniﬁed framework ReLOG to encode ReBAC poli-

cies, which can be viewed as graph queries. Although

the work is a ﬁne-grained ReBAC extension, we ex-

cluded it because only the theoretical feasibility of the

approach is investigated. Neither a concrete imple-

mentation nor demo cases are provided.

In the following, we discuss the latest research re-

sults of the remaining works in detail, which are Rizvi

and Fong (2018), Mohamed et al. (2023a), Hofer et al.

(2023a) and Bereksi Reguig et al. (2024).

3 ACCESS CONTROL APPROACH

We identiﬁed two main categories of access control

approaches: permit-deny access and ﬁltered results.

With permit-deny access is requested given the sub-

jects, resources, actions, and other optional condi-

tions. The request is checked against the authorization

policy and a decision is returned indicating whether

the access is authorized or not. This can be used

Comparison of Access Control Approaches for Graph-Structured Data

577

to control the type of actions to be performed on a

speciﬁc resource. The ﬁltered results category refers

to returning authorized data. The result of unautho-

rized access requests is empty. It is commonly used in

databases, where views or query rewriting are applied

to ﬁlter the result according to the policy and retrieve

a list of authorized resources at once. Although there

are currently several works that focus on protecting

data in graph databases, they have different objectives

and use cases. In the rest of this section, we discuss

the conceptual approach for each work with respect to

their access control model and approach category.

AReBAC. The Attribute-supporting ReBAC Model

(AReBAC) (Rizvi and Fong, 2018) is an extension

to ReBAC (Bruns et al., 2012), considering attributes

on vertices and edges along relationships between

subjects and resources to provide ﬁne-grained access

control in property graphs. It relies on a proprietary

graph pattern format to specify queries and access

control policies. A subset of Cypher, called Nano-

Cypher, is deﬁned as an equivalent language. An au-

thorization request is a pair (m, s), with a requested

method m (i.e., a database query with additions) and

subject s. Authorization policies are deﬁned in graph

patterns. For a request (m, s) by a user s, the match-

ing policies for the user’s query m are identiﬁed and

integrated with the query to ﬁlter the results.

XACML4G. The work of Mohamed et al. (2020)

aims to specify and enforce ﬁne-grained, dynamic au-

thorizations for graph-structured data. There can be

several paths from a subject to a resource, but not

all of them are authorized. A subject can only ac-

cess a protected resource through authorized paths

considering the context of resources, as it can re-

veal conﬁdential information. The ABAC model is

extended to specify ﬂexible graph patterns as a path

from the subject to the resource, deﬁning ﬁne-grained

authorization constraints for vertices and edges and

pattern-related conditions to join and compare path el-

ements. The XACML policy language model and ref-

erence architecture are extended as a proof-of-concept

for the proposed approach, which is called XACML

for graphs (XACML4G), to consider speciﬁcation and

evaluation of graph patterns. XACML4G is a permit-

deny access model since the result is a decision.

GQRA

. Hofer et al. (2023a,b) present a graph

query rewriting-based approach (GQRA) to enforce

ﬁne-grained authorizations dynamically for Cypher

queries. Insecure queries are rewritten to include

authorization-speciﬁc ﬁlters. Thus, only authorized

data is returned. The query rewriting algorithm uses

an AST for the source Cypher query. Based on the de-

ﬁned policy, authorization-speciﬁc ﬁlters are added to

the syntax tree and the query is reformulated accord-

ingly. This approach implicitly enforces ABAC in

graph databases, especially Cypher-based datastores,

beyond their supported access control features.

ABAC for Neo4j

. Bereksi Reguig et al. (2024) ex-

tend the RBAC model in Neo4j to support attributes.

In Neo4j, the enterprise edition supports granting and

denying traverse, read and match privileges to node

labels and relationship types along with their proper-

ties. However, the authorization policy rules are asso-

ciated to roles and apply to all nodes or relationships

with the speciﬁed label or type. Therefore, they ex-

tend this access control model to support ﬁne-grained

conditions to ﬁlter out further nodes or relationships

from being traversed or read.

To answer RQ1, we provided an overview and

classiﬁed the selected works into two main categories

(i.e., permit-deny access and ﬁltered results).

4 POLICY DEFINITION

In this section, we explain the authorization policy

language model for the selected works along with an

overview of the access request and response (if any).

AReBAC. Rizvi and Fong (2018) deﬁne authoriza-

tion policy in the context of AReBAC as ”... a

graph pattern used for specifying authorization re-

quirements for accessing resources.”. It can be con-

sidered as a graph restricted by mutual exclusion con-

straints and attribute requirements. AReBAC assumes

an underlying open policy. Database queries are cate-

gorized. Each category has at most one authorization

policy. Categories are used for the request and policy

matching. With graph patterns, a language for declar-

ative authorization policy speciﬁcation is provided, as

an easier to use alternative to logic formulas and regu-

lar expressions (Rizvi and Fong, 2018). A graph pat-

tern contains a set of vertices, a set of edges, mutual

exclusion constraints on vertices, a set of attributes of

vertices and edges, a category, a mapping of selected

vertices and the return values. The graph pattern also

contains placeholders which will be replaced during

request processing and policy matching. To specify

an authorization policy, a Nano-Cypher query with an

associated category and mapping can also be used in-

stead of a graph pattern.

XACML4G. A preliminary policy speciﬁcation is de-

ﬁned in a proprietary JSON format in Mohamed et al.

(2020). Then, the XACML4G elements are deﬁned

using XSD and applied in XACML (Mohamed et al.,

2023a). The meta element deﬁnes vertex labels and

edge types of the source graph relevant for policy

We deﬁned this abbrev. to use throughout our paper.

SECRYPT 2024 - 21st International Conference on Security and Cryptography

578

evaluation. The pattern is a path with composite struc-

ture, consisting of a vertex, an edge, and either an-

other vertex (i.e., the base case) or an entire path.

Each vertex has an identiﬁer, a label, its own cate-

gory URI and a sequence of attributes. Edges addi-

tionally include an optional direction, a type instead

of a label and a range (i.e., minimum and maximum

length) for ﬂexible patterns. The pattern condition el-

ement is structured like the XACML condition, but its

identiﬁer attribute references a vertex or an edge vari-

able in the pattern. Furthermore, the function attribute

should be one of the supported functions. Access re-

quest is extended to additionally include path-related

attributes, specifying vertices and edges as resources.

Based on the input request, the policy is matched and

evaluated, returning an access decision.

GQRA. The authorization policy model deﬁned in

Hofer et al. (2023a) is inﬂuenced by XACML. Autho-

rization requirements are described in a policy hav-

ing a set of rules. The policy speciﬁes the path from

the subject to the resource. The matching elements

can be referenced in conditions and ﬁlter templates,

which require runtime information. Each rule refer-

ences an element of the policy pattern and speciﬁes

one or more boolean combined conditions. A con-

dition checks whether ﬁlter and return properties are

satisﬁed by any element of the policy pattern. The ﬁl-

ter indicates whether the element is ﬁltered according

to its label/type, its properties or not at all, while re-

turn states if it is included in the return clause of the

query (i.e., directly or aggregated).

ABAC for Neo4j. The policy rules in Bereksi Reguig

et al. (2024) are expressed like in Neo4j with an intro-

duced WHERE statement to specify one or more condi-

tions. Each condition consists of an attribute, an op-

erator or a built-in Cypher function, and a value. The

attribute belongs to an entity in the graph, user or con-

text. Thus, the policy extension is ﬁne-grained at the

vertex and edge attributes. Currently, conditions are

only supported with the traverse privilege. The read

rules are speciﬁed without conditions to avoid circu-

lar permissions. The match is not directly supported,

but can be expressed by combining traverse and read.

To summarize, AReBAC, GQRA and ABAC for

Neo4j deﬁne their policies as a query or ﬁlter tem-

plate to restrict the result set. AReBAC uses a cate-

gory with the query to match it with the authorization

policy. XACML4G extends the XACML structure to

deﬁne paths in the graph. XACML4G and ABAC for

Neo4j are based on established policy formats such as

XACML and the Neo4j policy deﬁnition, while ARe-

BAC and GQRA deﬁne their own proprietary formats.

5 POLICY ENFORCEMENT

We now present the policy enforcement approach

for each of the selected works, including processing,

matching and conﬂict resolution (if applicable).

AReBAC. Rizvi and Fong (2018) propose an enforce-

ment based on query rewriting. Nano-Cypher queries

are not directly executed in Neo4j, but the evalua-

tion rather relies on the internal graph pattern for-

mat and the evaluation algorithm GP-Eval. When a

user sends an authorization request, the query is trans-

lated to a graph pattern. The policy is matched using

the method’s category. Categories can be organized

in a hierarchy, which deﬁnes a reﬁnement relation-

ship, e.g., c

≥ c

. Accordingly, the policy for meth-

ods with category c

must be at least as restrictive as

the one for methods with category c

. All graph pat-

terns along the hierarchy are combined into a single

graph pattern. The integrated policy and the query are

merged resulting in a single graph pattern. Rizvi and

Fong (2018) call this process weaving and not query

rewriting. The integrated graph pattern is evaluated

by GP-Eval, which only returns authorized data. As

the AReBAC approach relies on its graph pattern for-

mat, it is datastore-independent, at least at its core.

The database is accessed during the evaluation of the

graph pattern to retrieve candidates for the result set.

XACML4G. In Mohamed et al. (2023a), the XACML

conceptual components are extended to match the re-

quest path with the patterns in policy rules and eval-

uate the pattern conditions. To allow for a source

datastore-independent policy evaluation, a subset of

the overall source data is managed in an indepen-

dent graph, which is called source-subset graph. This

graph is optionally used to evaluate the policy with-

out relying on a speciﬁc datastore and can be con-

structed from multiple data sources. The policy ad-

ministration point (PAP) is extended to process the

XACML4G policy and create the source-subset graph

according to the speciﬁed entities in the meta element.

In the extended context handler, XACML4G requests

are parsed to extract the path attributes. Then, the

extended policy decision point (PDP) adds a speciﬁc

condition for evaluating the pattern if it exists in the

matched policy rule. Based on the pattern and its con-

ditions, a Cypher pattern and a WHERE statement are

dynamically generated and the query is executed to

evaluate path constraints as an extension in the pol-

icy information point (PIP). Conﬂicts are resolved in

XACML at the level of policies and rules using cus-

tom or predeﬁned combining algorithms, such as ﬁrst

applicable and (ordered) deny/permit overrides.

GQRA. Hofer et al. (2023a,b) enforces ﬁne-grained

authorizations by rewriting Cypher queries at run-

Comparison of Access Control Approaches for Graph-Structured Data

579

time. Firstly, the query is processed by mapping each

element in the query to the corresponding one in the

policy based on the pattern structure and the element

label(s). For that, the pattern is mapped to a set of

paths, each one represented as a tuple with start ver-

tex, and optional edge and end vertex. The resulting

comparable structure of the query and policy patterns

are needed for policy matching. A policy is applica-

ble if each path tuple of the insecure query matches

one of its rule patterns and satisﬁes the rule’s condi-

tions. A simpliﬁed AST is built, excluding syntactical

details as well as omitting CREATE and WITH clauses.

It describes the semantics of the query. Filters of the

matched policy rules are added to the WHERE part of

the AST. Nodes without labels could cause ambiguity

when multiple rules are matched. Thus, an optimiza-

tion approach is needed to avoid overlapping ﬁlters

or an empty result, due to non-matching constraints.

Since only positive permissions are supported, no

conﬂicts occur. The extended AST is written to a

Cypher statement and executed in the database to re-

trieve the authorized result set.

ABAC for Neo4j. Bereksi Reguig et al. (2024) pro-

posed an algorithm called SafeCypher to rewrite a

user query according to the deﬁned authorization pol-

icy along with the user role(s) and return a safe one

(if applicable). First, the authorization graph is con-

structed such that each policy component (i.e., role,

privilege, permission and entity) is represented as a

vertex connected by directed edges, e.g., user role to

privilege (i.e., traverse or read), privilege to permis-

sion, and permission to entity (i.e., node label, rela-

tionship type and attribute). A variable is assigned to

each node and relationship in the source query and the

query elements (e.g., MATCH, WHERE and RETURN state-

ments) are extracted. In the case of a nested query, the

subqueries are separately rewritten and the results are

appended to the main query. Then, the corresponding

access conditions are added to the WHERE statement

and the attributes being returned are checked. Con-

ﬂicts are resolved using the authorization policy graph

using the algorithm deny-override like in Neo4j. Fi-

nally, the safe query is optimized before execution.

We answered RQ2 in Section 4 and 5 by dis-

cussing the policy deﬁnition and enforcement mech-

anism for the selected works on the conceptual level.

In the following section, we present the technical de-

tails for each work and the provided use cases (if any).

6 IMPLEMENTATION

In this section, we address how the proposed access

control approaches are feasible and applicable (re-

fer to RQ3). For each work, we demonstrate which

frameworks and graph databases have been used in

addition to where in the architecture it has been im-

plemented, e.g., within the database or an indepen-

dent layer. Furthermore, we give an overview of the

evaluation methods and results.

AReBAC. AReBAC is a proprietary Java implemen-

tation and uses Neo4j

. Graph pattern is an internal

representation of queries and policies. Concerning the

architecture, access control is implemented between

the application and the database. Rizvi and Fong

(2018) use the Census-Income (KDD) Dataset from

the UCI Machine Learning Repository

to demon-

strate the feasibility and performance of AReBAC.

The GP-Eval algorithm implementations provide sig-

niﬁcantly better performance than Neo4j’s Cypher

evaluation engine, but the performance of semanti-

cally equivalent Nano-Cypher queries may differ.

XACML4G. Technically, XACML is an authoriza-

tion service between the datasource and the appli-

cation. Thus, XACML4G (Mohamed et al., 2023a)

is considered as an independent layer. The ap-

proach is implemented in Java as a source-code ex-

tension to Balana

, an open-source framework based

on Sun’s XACML implementation. Furthermore, the

XACML4G policies and requests are validated using

the XML schema for the language extensions. The

optional source-subset graph is created and stored in

an embedded Neo4j database. Currently, two Java

classes are implemented to import graph data for

Neo4j and ArangoDB. Access requests are parsed to

extract relevant attributes for policy matching and pat-

tern evaluation. Then, the PDP evaluates the matched

policy rules to determine the access decision, in-

cluding the XACML4G pattern and its conditions.

A Cypher query is generated from the pattern con-

straints in the policy and path attributes in the ex-

tended request. The pattern evaluation is successful

if the query returns a result. Two demo cases are pre-

sented with various access control scenarios and data

models in different graph database systems. Paths

with different lengths (1 to 5) are evaluated. In con-

trast to previous results, the latest XACML4G pro-

totypical implementation showed better performance

and the constant overhead due to policy processing

is eliminated. The overall overhead is reduced from

≈ 25 (excluding processing overhead) to 21 ms.

GQRA. The query rewriting approach in Hofer et al.

(2023a,b) is implemented in Java as an extension to

the Neo4j Object Graph Mapper (OGM). The class

Session is extended to enforce authorizations not only

https://github.com/szrrizvi/arebac/

https://archive.ics.uci.edu/

https://github.com/wso2/balana

SECRYPT 2024 - 21st International Conference on Security and Cryptography

580

when executing Cypher queries, but also in loading,

saving and deleting objects. A query parser is built

from a subset of Cypher’s grammar using ANTLR.

The function getPaths matches the query pattern

with those of the policy. Authorization-related ﬁlters

are added to the query and placeholders from the tem-

plates are replaced with runtime values. The result-

ing secure query is executed, and authorized resources

are returned. The prototypical implementation is ap-

plied in the research project SyMSpace

. Authoriza-

tion rules are deﬁned in a conﬁguration class. Accord-

ing to the graph model’s structure, permissions can be

assigned directly to users or via roles. Experiments

with representative queries show that the average time

needed for query rewriting is ≈ 0.2 ms.

ABAC for Neo4j. Bereksi Reguig et al. (2024) imple-

mented their proposed concept in Java within Neo4j.

Their Cypher query rewriting algorithm is executed

within the Neo4j browser. The deﬁned authorization

policy is processed from its textual representation to

an access graph and stored in Neo4j. User-deﬁned

procedures and functions are invoked from Cypher to

extend Neo4j using customized Java code. The eval-

uation with respect to efﬁciency and scalability uses

the Stack Exchange dataset. The experiments show

that introducing conditions in authorization rules has

minor performance overhead. It scales well with large

datasets in addition to complex Cypher queries and

authorization policies.

Although all selected works provide proof-of-

concept implementations, they are still research re-

sults. AReBAC is an independent framework with a

proprietary implementation for specifying authoriza-

tion policies in Nano-Cypher and enforcing them us-

ing their GP-Eval algorithm. XACML4G and GQRA

are implemented as extensions to Balana and OGM,

respectively, to prove the feasibility of the concepts

without being limited to these frameworks. Finally,

ABAC for Neo4j is implemented using custom proce-

dures, which can be invoked in Cypher and perform

operations on the database directly.

7 DISCUSSION

After discussing the selected approaches, we compare

them according to the following criteria. The results

are summarized in Table 2.

Access Control Approach. Most of the selected ap-

proaches rely on ﬁltered results to perform access

control close to the database layer, by reducing the

result set to only permitted data. Therefore, the

https://web.symspace.lcm.at

Table 2: Comparison of the selected works.

Criteria AReBAC XACML4G GQRA

ABAC for

Neo4j

Access control

approach

ﬁltered

results

permit-deny

access

ﬁltered

results

ﬁltered

results

Base AC model ReBAC ABAC ABAC RBAC

Open policy ✓ × ✓ ✓

Negative

permissions

× ✓ × ✓

Runtime policy

processing

✓ ✓ ✓ ×

Datastore-

independent

✓ ✓ ✓

Cypher-based datastores only

same access request by different users may return dif-

ferent result sets, depending on their authorizations.

XACML4G belongs to the classic permit-deny ac-

cess, where the access request is checked and a de-

cision is returned.

Base Access Control Model. Fine-grained access

control in the context of graphs is considered in all

approaches, but with different access control models

as a basis. Rizvi et al. (2015) already did research in

ReBAC for relational databases, but without consid-

ering attributes. Even though ReBAC concepts can

be mapped to the graph model, AReBAC was devel-

oped to further support ABAC. The base model of

XACML4G and GQRA is ABAC, which allows ﬂex-

ible, ﬁne-grained authorization policies, but does not

consider restrictions on paths. The XACML4G policy

structure, contains components to deﬁne pattern con-

straints and meta data for policy evaluation. GQRA

supports path-speciﬁc requirements in their ﬁlter tem-

plates. ABAC for Neo4j in contrast is based on RBAC

like access control in the Neo4j Enterprise edition, but

is extended to support ﬁne-grained conditions.

Open/Closed Policy. All ﬁltered results approaches,

i.e., AReBAC, GQRA, and ABAC for Neo4j rely

on an open policy, which authorizes subjects by de-

fault(Samarati and de Vimercati, 2001). Authoriza-

tions limit the result. XACML4G assumes a closed

policy, i.e., only access with positive permission.

Positive and/or Negative Permission Support.

AReBAC and GQRA policies deﬁne ﬁlters to spec-

ify the permitted result set. However, XACML4G

and ABAC for Neo4j policies must explicitly de-

ﬁne, whether matching the policy conditions results

is granting or denying access.

Runtime Policy Processing. This aspect considers

if policies need processing before evaluation. With

ABAC for Neo4j, policies are deﬁned in text and then

transformed into an access graph as a pre-processing

step for query rewriting. All other approaches evalu-

ate policies directly with each authorization request,

even though, pre-processing could enhance perfor-

mance, e.g., translating AReBAC policies deﬁned in

Nano-Cypher to graph patterns in advance.

Comparison of Access Control Approaches for Graph-Structured Data

581

Datastore-Independent Enforcement. The ARe-

BAC concept is datastore independent, as the internal

representation of queries and policies is graph pat-

terns. Thus, any graph pattern-equivalent language

could be used. However, to replace the underlying

Neo4j database, an abstraction layer for the database

access is needed. The query rewriting approach

in Hofer et al. (2023a) can be applied in Cypher-

based datastores, while XACML4G is dynamic, ap-

plies external authorization, and deals with property

graph-compatible datastores. In contrast, the work of

Bereksi Reguig et al. (2024) is datastore speciﬁc, i.e.,

restricted to Neo4j. Although they overcome the limi-

tations of the Neo4j access control model which is not

ﬁne-grained and the rules are statically deﬁned in the

system database, the authorizations are still linked to

roles and are not ﬂexibly assigned to users according

to attribute-based criteria.

Each of the approaches has its strengths and weak-

nesses, and their relevance heavily depends on the

speciﬁc requirements. We summarize the main re-

sults to answer RQ4 in the following. The three

ﬁltered results approaches (AReBAC, GQRA, and

ABAC for Neo4j) share many of the conceptual de-

tails such as an open access control approach, but dif-

fer in the chosen basic access control model. ABAC

for Neo4j supports negative permissions like the au-

thorization model of Neo4j. Furthermore, it follows

the Neo4j policy deﬁnition format unlike AReBAC

and GQRA, which have proprietary formats. GQRA

is restricted to Cypher-based datastores as it enforces

the policies by rewriting Cypher queries, whereas

AReBAC ”weaves” the database query and policies

speciﬁed in the proprietary graph pattern format, and

is thus conceptually independent of the Cypher lan-

guage. XACML4G in contrast differs in fundamen-

tal criteria, as it is a permit-deny access control ap-

proach with a closed policy. However, like GQRA,

it is based on ABAC. Furthermore, XACML4G is

datastore-independent, as it can be enforced on any

property graph-compatible datastore.

8 CONCLUSIONS

To compare and analyze ﬁne-grained access control

approaches to protect property graph-structured data,

we selected Rizvi and Fong (2018), Mohamed et al.

(2020), Hofer et al. (2023a), and Bereksi Reguig et al.

(2024). The proposed access control approaches be-

long to the permit-deny access or ﬁltered results cat-

egory (RQ1). We answered RQ2 and RQ3 by dis-

cussing each work in terms of access control model,

authorization policy deﬁnition, policy enforcement

approach and implementation details. In AReBAC,

the policy is either speciﬁed using their graph pattern

representation or a Nano-Cypher statement, which is

translated to a graph pattern. The enforcement algo-

rithm evaluates graph patterns with a minimal num-

ber of database accesses and amount of data retrieved.

The concept is implemented as an independent layer

on top of Neo4j. XACML4G deﬁnes graph-speciﬁc

authorization constraints on vertices and edges as a re-

cursively structured path pattern. Conditions for com-

paring and joining pattern elements can be speciﬁed

and edges are also considered as resources. Regard-

ing policy enforcement, dynamic queries are gener-

ated for the matched policies, taking additional at-

tribute values from the request, and then executed

in the source database or the one storing the source-

subset graph. The approach is implemented as an ex-

tension to the XACML policy language and architec-

ture. The authorization policy in GQRA is a set of

rules with paths having placeholders to be replaced

with runtime values. To enforce the policy, an AST

equivalent to the source query is generated for adding

authorization-speciﬁc conditions, and then translated

back to a Cypher query. OGM is extended to apply

the proposed query rewriting approach. In ABAC for

Neo4j, the policy has a textual representation based

on the Neo4j access control model, but stored in a

graph after processing. For the policy enforcement,

conditions for each clause are appended to the query,

which is optimized after resolving conﬂicts. A user-

deﬁned procedure is implemented in Neo4j taking the

source query as input to be rewritten and executed.

For the last research question (RQ4), we deﬁned

additional criteria to distinguish between the selected

works, which already satisfy our initial selection cri-

teria (i.e., protect property graph-structured data, ﬁne-

grained, and applied in graph datastores). Only

XACML4G is designed differently with respect to

the permit-deny access control approach and closed

policy, while the rest belongs to the ﬁltered results

category with open policy. Concerning the base ac-

cess control model, XACML4G and GQRA rely on

ABAC, while AReBAC and ABAC for Neo4j rely

on ReBAC and RBAC respectively. XACML4G and

ABAC for Neo4j support negative permissions, un-

like the other works. ABAC for Neo4j is the only

work that supports neither datastore-independent pol-

icy enforcement nor runtime policy processing, as the

approach is speciﬁc to Neo4j and a policy graph needs

to be constructed in advance. The enforcement ap-

proach in XACML4G can work with property-graph

compatible datastores, whereas GQRA is considered

for Cypher-based datastores.

The current work has highlighted further ques-

SECRYPT 2024 - 21st International Conference on Security and Cryptography

582

tions concerning the differences and use cases of the

two categories for access control approaches. For ex-

ample, the ﬁltered results category is typically used in

retrieving authorized resources based on the deﬁned

policy. The permit-deny access category is less com-

monly used in access control for databases, but still

considered in applications to allow authorized users

to perform speciﬁc actions (e.g., edit or delete) on

particular resources and vice versa. A detailed com-

parison of the prototypes (if available) on a common

scenario is considered in the future. Furthermore,

we plan to add more aspects to our comparison and

include other works focusing on protecting property

graph-structured data that have been excluded due to

coarse-grained access control or a lack of application.

ACKNOWLEDGEMENTS

This work has been partly supported by the LIT Se-

cure and Correct Systems Lab funded by the State of

Upper Austria and the Linz Institute of Technology.

This work has also been supported by the COMET-

K2 Center of the Linz Center of Mechatronics (LCM)

funded by the Austrian federal government and the

federal state of Upper Austria.

REFERENCES

Bereksi Reguig, A. A., Mahfoud, H., and Imine, A. (2024).

Towards an effective attribute-based access control

model for neo4j. In Mosbah, M., Kechadi, T., Bella-

treche, L., and Gargouri, F., editors, Model and Data

Engineering, pages 352–366. Springer, Cham.

Bertolissi, C., den Hartog, J., and Zannone, N. (2019). Us-

ing provenance for secure data fusion in cooperative

systems. In Proceedings of the 24th ACM Symposium

on Access Control Models and Technologies, SAC-

MAT ’19, page 185–194. ACM.

Bruns, G., Fong, P. W. L., Siahaan, I., and Huth, M. (2012).

Relationship-based access control. In Bertino, E. and

Sandhu, R. S., editors, Proceedings of the 2nd ACM

conference on Data and Application Security and Pri-

vacy, pages 117–124. ACM.

Chabin, J., Ciferri, C. D. A., Halfeld-Ferrari, M., Hara,

C. S., and Penteado, R. R. M. (2021). Role-based ac-

cess control on graph databases. In Bure

s, T., Dondi,

R., Gamper, J., Guerrini, G., Jurdzi

nski, T., Pahl, C.,

Sikora, F., and Wong, P. W., editors, SOFSEM 2021:

Theory and Practice of Computer Science, pages 519–

534. Springer, Cham.

Clark, S., Yakovets, N., Fletcher, G., and Zannone, N.

(2022). Relog: A uniﬁed framework for relationship-

based access control over graph databases. In Data

and Applications Security and Privacy XXXVI, page

303–315. Springer, Cham.

Hofer, D., Mohamed, A., Auer, D., Nadschl

ager, S., and

ung, J. (2023a). Rewriting graph-db queries to en-

force attribute-based access control. In Strauss, C.,

Amagasa, T., Kotsis, G., Tjoa, A. M., and Khalil, I.,

editors, Database and Expert Systems Applications,

pages 431–436. Springer, Cham.

Hofer, D., Mohamed, A., Nadschl

ager, S., and Auer, D.

(2023b). An intermediate representation for rewriting

cypher queries. In Kotsis, G., Tjoa, A. M., Khalil, I.,

Moser, B., Mashkoor, A., Sametinger, J., and Khan,

M., editors, Database and Expert Systems Applica-

tions - DEXA 2023 Workshops, pages 86–90. Springer.

Jin, Y. and Kaja, K. (2019). Xacml implementation based

on graph databases. In Proceedings of the 34th Inter-

national Conference on Computers and Their Appli-

cations, pages 65–74.

Mohamed, A., Auer, D., Hofer, D., and K

ung, J. (2020).

Authorization policy extension for graph databases.

In Dang, T. K., K

ung, J., Takizawa, M., and Chung,

T. M., editors, Future Data and Security Engineering,

pages 47–66. Springer, Cham.

Mohamed, A., Auer, D., Hofer, D., and K

ung, J. (2023a).

Xacml extension for graphs: Flexible authorization

policy speciﬁcation and datastore-independent en-

forcement. In Proceedings of the 20th Interna-

tional Conference on Security and Cryptography - SE-

CRYPT, pages 442–449. INSTICC, SciTePress.

Mohamed, A., Auer, D., Hofer, D., and K

ung, J. (2023b).

A systematic literature review of authorization and ac-

cess control requirements and current state of the art

for different database models. International Journal

of Web Information Systems.

Morgado, C., Busichia Baioco, G., Basso, T., and Moraes,

R. (2018). A security model for access control in

graph-oriented databases. In 2018 IEEE International

Conference on Software Quality, Reliability and Secu-

rity (QRS), pages 135–142.

Rizvi, S. Z. R. and Fong, P. W. L. (2018). Efﬁcient au-

thorization of graph database queries in an attribute-

supporting rebac model. In Zhao, Z., Ahn, G.-J., Kr-

ishnan, R., and Ghinita, G., editors, CODASPY’18,

pages 204–211. ACM.

Rizvi, S. Z. R., Fong, P. W. L., Crampton, J., and Sellwood,

J. (2015). Relationship-based access control for an

open-source medical records system. In Weippl, E.,

Kerschbaum, F., and Lee, A. J., editors, Proceedings

of the 20th ACM Symposium on Access Control Mod-

els and Technologies, pages 113–124. ACM.

Samarati, P. and de Vimercati, S. C. (2001). Access control:

Policies, models, and mechanisms. In Focardi, R. and

Gorrieri, R., editors, Foundations of Security Analysis

and Design, pages 137–196. Springer Berlin.

Valzelli., M., Maurino., A., and Palmonari., M. (2020).

A ﬁne-grained access control model for knowledge

graphs. In Proceedings of the 17th International Joint

Conference on e-Business and Telecommunications -

SECRYPT, pages 595–601. INSTICC, SciTePress.

Comparison of Access Control Approaches for Graph-Structured Data

583
