Conceptual Model Detection in Business Web Applications Within the

RPA Context

Dora Moraru, Adrian Sterca

, Virginia Niculescu

, Maria-Camelia Chis

alit¸

a-Cret¸u

and Cristina-Claudia Osman

Babes¸-Bolyai University, Cluj-Napoca, Romania

Keywords:

Web Automation, Robotic Process Automation, Data Model Extraction, Entity Detection in Web Applications.

Abstract:

Robotic Process Automation (RPA) platforms target the automation of repetitive tasks belonging to business

processes, performed by human users. Web automation is a part of RPA that deals with the automation of web

applications. In our previous work, we introduced a web automation tool in the form of a browser plugin that is

able to discover simple processes on a target business web application and is able to later execute these simple

processes automatically without human intervention. Our web automation tool relies on a description of the

data model used by the target web application. This data model must be manually speciﬁed by the human user

in advance. In our current work, we propose a new method for discovering this data model automatically from

the target web application itself. We also performed some experiments in the paper that show that our method

is viable.

1 INTRODUCTION

Companies operating in different business areas often

share the same economic and human objectives while

performing speciﬁc business processes. Economic

objectives involve reducing costs, increasing produc-

tivity, improving efﬁciency, and service quality. Hu-

man objectives indicate practices that allow employ-

ees to feel valued and supported in the working area,

which frequently means reducing the amount of repet-

itive and manual work.

Usually, business processes require interaction be-

tween various business applications (e.g., Customer

Relationship Management (CRM) systems, Enter-

prise Resource Planning (ERP) software).

Robotic Process Automation (RPA) is the appli-

cation of speciﬁc methodologies and technologies

that aim to automate business process-related repet-

itive tasks achieved by human users (Hofmann et al.,

2020).

Existing RPA tools provide capabilities for devel-

oping software robots (or bots) that mimic the actions

performed by humans to execute the steps of a partic-

ular business process.

https://orcid.org/0000-0002-5911-0269

https://orcid.org/0000-0002-9981-0139

https://orcid.org/0000-0002-1414-0202

https://orcid.org/0000-0002-9706-2915

Automation includes a wide range of actions

(Hartley and Sawaya, 2019), such as data entering,

simple calculations, data reading and extraction from

ERP systems, PDF ﬁles, or images, form ﬁll out,

e-mail reply, attachments opening or saving, partic-

ular application features execution, operations over

ﬁles and folder, data scraping from web pages, etc.

More, multiple technologies such as optical charac-

ter recognition (OCR), natural language processing

(NLP), and various artiﬁcial intelligence (AI) meth-

ods are used for data extraction (Hegde et al., 2018).

Software robots automate rule-based processes

using high-volume and well-deﬁned structured data

processed in a deterministic context (Willcocks and

Lacity, 2016).

Current RPA platforms (e.g., UiPath

, Automa-

tion Anywhere

, Blue Prism

, Microsoft Power Au-

tomate

, etc.) help increase work efﬁciency and accu-

racy by automatizing business processes and execut-

ing them more robustly by avoiding possible human

errors.

RPA refers to those tools that operate on the user

interface (UI) aiming to perform automation tasks us-

ing an ”outside-in” approach (Van der Aalst et al.,

https://www.uipath.com/

https://www.automationanywhere.com/

https://www.blueprism.com/

https://powerautomate.microsoft.com/en-us/

Moraru, D., Sterca, A., Niculescu, V., Chis

ali¸t

a-Cre¸tu, M. and Osman, C.

Conceptual Model Detection in Business Web Applications Within the RPA Context.

DOI: 10.5220/0012864100003753

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 19th International Conference on Software Technologies (ICSOFT 2024), pages 519-526

ISBN: 978-989-758-706-1; ISSN: 2184-2833

519

2018). RPA is not an invasive technology, based on

existing systems, without being constrained to de-

velop or replace costly platforms (Willcocks and Lac-

ity, 2016).

RPA projects usually follow an automation pro-

cess consisting of task identiﬁcation, process redef-

inition from AS-IS to TO-BE, actual bot develop-

ment, testing, deployment, and monitoring (Huang

and Vasarhelyi, 2019), (Gex and Minor, 2019).

RPA developers identify UI components of a soft-

ware application like buttons, text input controls,

drop-down lists, and tables, and then customize activ-

ities by writing code snippets in a programming lan-

guage to act on these UI controls (e.g. clicking the se-

lected button, writing data in the text input, select all

data from a table or a drop-down list, etc.). The code

referencing the selected UI controls forms the auto-

mated business process which can be executed many

times later with different input parameters.

This paper emphasizes a complementary ap-

proach, where we automatically navigate over the

web application and aim to identify a conceptual

model employed throughout the executed business

processes.

The original contributions presented in the paper

can be summarized as follows. In previous work

(Sterca et al., 2023) we developed a web automation

tool in the form of a browser plugin that is able to dis-

cover simple processes in a target business web appli-

cation and it can later execute these simple processes

automatically without human intervention; an exam-

ple of such a simple process which we call a concep-

tual operation is the operation of adding an account

in a CRM business application. In our previous work,

we relied on a description of the data model used by

the target web application (i.e. the concepts and en-

tities used by the web application together with their

properties). This data model must be created manu-

ally by the human user either from the ofﬁcial doc-

umentation of the target web application or from the

UI of the target web application itself. This manual

labour is tedious and takes time. In our current work,

we propose a new method for the automatic discov-

ery of this data model of the target business web ap-

plication, keeping the human user intervention to the

lowest degree possible.

The rest of the paper is structured as follows: Sec-

tion 2 provides related work about business processes

in the context of RPA. Section 3 offers details about

our web automation tool developed in previous work.

Our algorithm for the automatic discovery of the data

model of the target web application is described in

detail in Section 4, while Section 5 describes some

evaluation tests that we performed in order to show

that our method of automatic detection of the data

model of a business web application is viable. The pa-

per concludes with the ﬁnal remarks and future work

ideas.

2 RELATED WORK

The software development cycle (SDC) starts with a

high-level design that gets translated into source code.

Reverse engineering ﬂips this process around, taking

the source code or the software product and identi-

fying the original design intent. Reverse engineering

allows the extraction of ER models (Hainaut, 1991) or

UML models (Iftekhar et al., 2019), (Abb and Rehse,

2022) from schema or schema-less databases.

RPA is a cutting-edge technology that allows com-

panies to automate repetitive ofﬁce tasks. Utilizing

software robots programmed to execute speciﬁc in-

structions, RPA imitates human actions by interacting

with various web and desktop applications (Van der

Aalst et al., 2018). On the other hand, Process Mining

(PM) represents a set of techniques that extracts mod-

els based on human behaviour recorded as event logs

(Van Der Aalst, 2016). The intersection of these ﬁelds

is described as Robotic Process Mining (RPM) (Leno

et al., 2021). RPM instruments aim to create RPA

scripts from UI logs. Nevertheless, there are some

differences between event logs (input for PM) and UI

logs (input for RPM) (Leno et al., 2021). Firstly, the

level of abstraction is different: UI logs are gener-

ated at GUI level, while event logs are generated at

the business process task level. Therefore, a business

process task may consist of several UI actions. Event

logs ask for a case ID, while a unique identiﬁer for

each case is not required at UI log level. The data pro-

duced/consumed within an event is not mandatory to

be stored at the event log level, while UI logs need this

data. The fourth difference mentioned by (Leno et al.,

2021) refers to the missing events that in some situa-

tions are ignored if they are not recorded by the infor-

mation systems used by the involved participants.

A method for analyzing UI logs with the aim of

identifying sequences of actions is depicted by (Bosco

et al., 2019). The focus is on discovering routines

that can be automated to improve the user experience

or streamline processes. The limitations of their re-

search refer to routines involving loops (when the exit

condition is not identiﬁable) and noise (the presence

of an event that does not belong to the current rou-

tine). There are also approaches that discover candi-

date routines from unsegmented UI logs in the pres-

ence of noise (Leno et al., 2020). Application logs

are also analysed with the aim of extracting the most

ICSOFT 2024 - 19th International Conference on Software Technologies

520

frequent user tasks. Usually frequent pattern mining

techniques and sequential pattern mining techniques

(Mannila et al., 1997), (Agrawal and Srikant, 1995)

are used, but (Dev and Liu, 2017) propose a rank pat-

tern based on membership based cohesion.

A reference data model for process related UI logs

is proposed by (Abb and Rehse, 2022). This model

is described as an extension of the standard used for

event logs, XES (G

unther and Verbeek, 2013). Our

plugin browser maps the UI operations to conceptual

operations in a database, the main idea being focus-

ing on the connection of UI actions to database oper-

ations.

Web scraping techniques are used to automati-

cally extract information from websites. These tech-

niques have diverse applications, including gathering

contact information, monitoring and comparing price

changes, collecting product reviews, compiling real

estate listings, tracking weather data, detecting web-

site changes, and integrating web data (Zhao, 2017).

Three phases are needed for web scraping projects:

site analysis, data analysis and design, and produc-

tion (ten Bosch et al., 2018). Our approach is differ-

ent than web scraping as the plugin browser identiﬁes

the conceptual operations and it can execute these op-

erations. Furthermore, the data model is discovered

based on the identiﬁcation of the conceptual opera-

tions.

In a systematic mapping study, Sepulveda et. all

(Sepulveda et al., 2017) summarizes the methods and

techniques to obtain the data model from business

process models. In the RPA context, our method ex-

tracts the data model by examining the Graphical User

Interface (GUI) components and the Document Ob-

ject Model (DOM) structure. None of the approaches

presented earlier focus on extracting conceptual data

models based on the GUI/DOM structure.

3 WAPlugin FOR WEB

AUTOMATION

WAPlugin is a web automation tool implemented as

a browser plugin that automatically translates hu-

man user operations on the UI of a target web appli-

cation onto conceptual operations in the underlying

database. We consider conceptual operations as being

CRUD (i.e. Create, Retrieve, Update, Delete) oper-

ations on concepts; the term concept refers to a data

type stored in a database table, while an entity refers

to a row/record of a database table. A concept always

describes a set of entities; e.g. an ‘Account concept‘

is stored in an ‘Account‘ table in the database, while

each entry/record from this table represents an ‘Ac-

count entity‘.

This web automation tool is developed as a

browser plugin, and so it bears the advantages of this

kind of applications. The usage of this tool involves

two stages:

• one stage through which the tool discovers the

speciﬁc conceptual operations

• and another stage in which the tool is able the au-

tomatically executes these operations.

In the ﬁrst stage, the human user guides the tool by

navigating in the target business web application (i.e.

clicking through the various buttons, links and other

clickable elements of UI of the target web applica-

tion), so that the plugin discovers what we call pri-

mary blocks for process automation - which is another

name for a conceptual operation. The user has to fol-

low on the UI all the steps that are needed to each

conceptual operation; all these operations assisted by

the user form the stage that we may call the learn-

ing stage. Based on this guidance, the plugin discov-

ers and extract these primary blocks, and then on a

further stage, it can automatically execute such pri-

mary blocks on the target web application or it can

form complex processes with the discovered primary

blocks and it can execute those too. The human user

speciﬁes to the browser plugin which primary block

(i.e. conceptual operation) to execute and he/she can

also provide parameters for the respective conceptual

operation; for example, if the user wants to execute an

‘Add New Account‘ automatically, he/she must spec-

ify which conceptual operation should be executed to

the browser plugin (in this case its an ‘INSERT Ac-

count‘ conceptual operation) and then the user must

provide the parameters for this conceptual operation

(e.g. the name of this new account, its address, de-

scription and other properties described in the data

model of the business web application).

For further details, please see (Sterca et al., 2023).

The WAPlugin automation tools requires up front

a description of the data model of the target business

web application. This data model is just a list of all

the concepts used by the target web application. Each

concept is deﬁned by a list of properties and is equiv-

alent to a database table in the underlying database

used by the target web application. This data model

is an input parameter for all functionalities offered by

our browser plugin (together with the root URL of the

target web application and the access credentials to

the application). In our previous work, we specify

this data model of the target web application manu-

ally in the form of a long JSON string. The purpose

of our current work is to determine this data model (or

an approximation of it that will be further reﬁned by

a human expert) automatically by browsing through

Conceptual Model Detection in Business Web Applications Within the RPA Context

521

the web pages generated by the target business appli-

cation. This automatic discovery of the data model

of the target business web application would reduce

the amount of labour required from the human user

who otherwise needs to consult the technical docu-

mentation of the application or he/she needs to browse

through the webpages of the UI of the application in

order to manually describe the data model of the ap-

plication in JSON format.

4 DETECTING THE DATA

MODEL OF THE TARGET WEB

APPLICATION

The basic idea of our method for detecting the under-

lying data model of a business web application is that

as long as the business web application exposes the

Update functionality for its entities (and most, if not

all, business applications offer this kind of functional-

ity to its human users; otherwise, all the entities would

be read-only in the application), a browser plugin can

detect these entities by discovering html input ﬁelds

(like ”<input type=text >,<select >,<textarea >”)

in the web pages generated by the application and can

associate these input ﬁelds to textual labels from the

UI of the application. These textual labels will form

the properties/ﬁelds of entities in the data model. As

long as the web application offers update function-

ality, it has to use html input ﬁelds in order to get

values from the human user (the web application can,

of course, implement its own custom input ﬁelds, but

this involves complex javascript code which is inef-

ﬁcient as long as html tags described by the HTML

standard language are available and were especially

created for this purpose - to get the input from the hu-

man user).

The algorithm used for automatically browsing

through the web pages generated by the business web

application, algorithm which is implemented in our

browser plugin, works by running a depth-ﬁrst traver-

sal on the entire web application. The various web

pages of the application are traversed through click-

able elements. This algorithm is described in code

listing 1.

In the ﬁrst lines of the algorithm, lines 1-

3, we perform initializations of various structures

used in the algorithm: the stack and the current

clickableElements present on the web page. The al-

gorithm assumes that the starting HTML document of

the web application is already loaded in the browser

(this means the access credentials were already input

by the human user before running the algorithm). The

Algorithm 1: The algorithm that navigates automatically

through a business web application.

The AutomaticBrowsing algorithm is:

1: Stack = [] ; newPath = [];

2: clickableElements = GetClickableElements()

3: Stack.push(newPath, clickableElements)

4: while (Stack is not empty) do

5: clickableElementsSet = Stack.top()[1]

6: if cl ickableElementsSet == NULL then

7: continue

8: end if

9: ClickElem =

10: GetFirstUnvisitedClickableElement(clickableElementsSet)

11: ClickElem.state = visited

12: if cl ickElem is not in the current DOM then

13: Navigate(Stack.top()[0])

14: end if

15: remaining = GetUnseenClickableElements()

16: Stack.push(newPath, remaining)

17: entity = DetectEntity()

18: if entity! = NULL then

19: DataModel.add(entity)

20: Stack.pop()

21: GoBackOneStep()

22: end if

23: end while

algorithm retrieves the clickableElements from this

HTML document in line 2. An element of the stack is

formed by the clickableElementsSet found on the web

page and a list (newPath) formed by the XPATHs of

the clicks that led to the current webpage (in line 3,

newPath is an empty list).

Following, lines 4-23 deﬁne the main cycle of the

iterative depth-ﬁrst traversal algorithm. The Stack

stores all the clickableElements that need to be tra-

versed/visited. An element is removed from the stack

when all its clickable elements are visited by our tool

or when an entity for the data model is found. On

lines 5-14 we take the ﬁrst element from the top of the

stack, get its ﬁrst unvisited (i.e. unclicked) clickable

element and check if it is present in the current DOM;

if not, the plugin navigates to the path of ClickElem,

using the ﬁrst list from the element retrieved from the

stack (Stack.top()[1]). Each element of the stack is a

pair element containing at index 0 the path - sequence

of clickable elements that got us to this webpage and

at index 1 the webpage - deﬁned by a set of clickable

elements. Reaching the web page that contains our

current clickable element, the browser plugin clicks it,

the DOM is expected to change, and in the following

steps (lines 15-16) we get the new clickable elements,

that have not been seen until now by the plugin, and

store them into the stack in order to be visited later.

Next, on line 17, we try to detect if an entity

is present on the current web page (DetectEntity()).

Lines 18-22 are for the case when an entity from the

ICSOFT 2024 - 19th International Conference on Software Technologies

522

data model is present in the loaded HTML document.

In this scenario, we store this entity in the data model,

remove the last element from the stack because we are

no longer interested in the current web page (since we

have found the entity), and go back a step (there’s a

higher probability that the next unvisited clickable el-

ement is situated on the previous page than others).

The algorithm for detecting an entity for the data

model is based on the premise that a label associ-

ated with an input is situated on its North-West side.

Therefore, we ﬁrstly detect the inputs (<input>, <se-

lect>, <textarea>) present on the HTML web page

and then try to ﬁnd for each input the closest textual

label that is positioned in the North-West quarter of a

circle with the centre in the middle of the input. If for

more than one input we have found a pair in the list of

labels, it means that the plugin has found an entity for

the data model of the page, and the associated textual

labels are the properties/ﬁelds of the entity of the data

model.

5 VALIDATION

We conducted an experiment in which we tried to de-

termine the data model for a business web application.

The application we used to test our browser plugin is

Microsoft Dynamics 2016 CRM. This business appli-

cation has more than 150 distinct types of web pages

generated (i.e. more than 150 functionalities). We

let the plugin discover entities for 30 minutes, time in

which it found 21 different entities out of 21 possibili-

ties (apparent 100% precision; also the plugin did not

detect any false entity - an entity that does not exist

in the application). This precision of 100% is appar-

ent because although the plugin detected all the avail-

able entities in the time frame of the experiment (30

minutes), occasionally some of the properties/labels

of the detected entities were not properly detected.

We realize that it would have been better to let the

plugin run for a signiﬁcantly longer period of time, so

that it discovers all entities in the data model of the

Microsoft Dynamics 2016 CRM application, but the

web pages generated by this application are similar

and we consider that running the data model detec-

tion algorithm of our plugin for about 30 minutes is

statistically relevant for the whole Microsoft Dynam-

ics 2016 CRM application. After running the browser

plugin for 30 minutes, we report the entities it has

found. Some of these entities were found multiple

times because of their numerous occurrences in the

web pages of the application. Being a complex ap-

plication, it has a variety of buttons and features, such

as generating reports or downloading ﬁles. Therefore,

the plugin had to traverse these steps with the aim of

discovering an entity.

Running the data model discovery algorithm for a

longer time period would, of course, allow the plugin

to discover more entities from the data model of the

target business web application.

In screenshot Fig. 1, we can see how the plugin

detected the clickable elements and bordered them in

red. We compute the XPATH of these HTML ele-

ments and push them into a stack, in order to be later

clicked one by one in a depth-ﬁrst search manner.

In Fig. 2 and Fig. 3, the plugin ﬁrstly detected the

input ﬁelds present on this web page and then associ-

ated the closest textual label to each input. Therefore,

the labels which are associated with an input, repre-

sent the properties of an entity, or more exactly, the

column’s names of an entity in a database. In rare

cases, where the wrong labels are closer to an input,

the associations are incorrect.

The list of entities that make up the model is saved

by the browser plugin in JSON format due to the ubiq-

uitous support for this format in web applications.

Each entity is described by its name and a list of at-

tributes/ﬁelds (which are equivalent to column names

in a database table). For example, a small snippet of

the entities from the Microsoft Dynamics 2016 CRM

application identiﬁed by our browser plugin tool is the

following :

[ "Invoice" :

["Invoice ID", "Name", "Currency",

"Price list", "Prices locked",

"Opportunity", "Order", "Customer",

"Description", "Date delivered",

"Due date", "Shipping method",

"Payment terms", "Bill to address",

"Ship to address"],

"Order" :

["Order ID", "Name", "Currency",

"Price list", "Prices locked",

"Opportunity", "Quote", "Potential

Customer", "Description", "Requested

delivery", "Date fulfilled",

"Shipping method", "Payment terms",

"Freight Terms", "Bill to address",

"Ship to address"]

]

We should also note that the detected model of

the application is just an approximation of the data

model of the database used by the target web appli-

cation. The actual data model of the database used

by the web application is hidden from the human user

(i.e. the human user does not have direct access to the

underlying database of the web application). The de-

tected data model is the one imprinted in the UI of the

web application (i.e. it is comprised from the labels

Conceptual Model Detection in Business Web Applications Within the RPA Context

523

Figure 1: Detection and highlight of clickable elements from a web page.

Figure 2: Detecting an entity in Ms Dynamics 2016 CRM - example 1.

used in the UI of the web application). But this ap-

proximate data model is the one we need if we want

to automate the usage of the target web application as

explained in Section 3.

6 CONCLUSIONS AND FUTURE

WORK

In this paper, we introduced a method for automatic

discovery of the data model used by a target busi-

ness web application. Our method is implemented

in a browser plugin and is based on automatic navi-

gation through the web pages generated by the target

business web application. It identiﬁes speciﬁc DOM

elements (i.e. html input tags) and associates these

to properties of concepts in the data model to be dis-

covered. We note that this data model is just an ap-

proximation of the actual data model of the underly-

ing database used by the target web application (this

database is hidden from the human user). But this ap-

proximate data model is all we need in order to imple-

ment a web automation tool in the form of a browser

plugin (i.e. a tool that is able to discover business pro-

cesses - with or without the help of the human user -

ICSOFT 2024 - 19th International Conference on Software Technologies

524

Figure 3: Detecting an entity Ms Dynamics 2016 CRM - example 2.

in a target business web application and is later able

to execute these processes automatically.

We performed some evaluation tests on a business

web application, namely Microsoft Dynamics 2016

CRM in order to show that our method is viable. Our

method indeed discovered entities from the underly-

ing data model used by the target web application.

Of course, our work has limitations. In future

work, we intend to perform evaluation tests on other

business web applications, not just on Microsoft Dy-

namics 2016 CRM.

Also, our current work is not able to detect refer-

ences/links between concepts in the data model (i.e.

the equivalent of foreign keys in database tables).

And this would be a good starting point for future

work.

REFERENCES

Abb, L. and Rehse, J.-R. (2022). A reference data model for

process-related user interaction logs. In International

Conference on Business Process Management, pages

57–74. Springer.

Agrawal, R. and Srikant, R. (1995). Mining sequential pat-

terns. In Proceedings of the eleventh international

conference on data engineering, pages 3–14. IEEE.

Bosco, A., Augusto, A., Dumas, M., La Rosa, M., and

Fortino, G. (2019). Discovering automatable routines

from user interaction logs. In Business Process Man-

agement Forum: BPM Forum 2019, Vienna, Austria,

September 1–6, 2019, Proceedings 17, pages 144–

162. Springer.

Dev, H. and Liu, Z. (2017). Identifying frequent user tasks

from application logs. In Proceedings of the 22nd in-

ternational conference on intelligent user interfaces,

pages 263–273.

Gex, C. and Minor, M. (2019). Make your robotic process

automation (rpa) implementation successful. Armed

Forces Comptroller, 64(1):18–22.

unther, C. W. and Verbeek, E. (2013). Xes standard deﬁ-

nition. 2014. BPMcenter. org.

Hainaut, J.-L. (1991). Database reverse engineering: Mod-

els, techniques, and strategies. In ER, pages 729–741.

Hartley, J. L. and Sawaya, W. J. (2019). Tortoise, not the

hare: Digital transformation of supply chain business

processes. Business Horizons, 62(6):707–715.

Hegde, S., Gopalakrishnan, S., and Wade, M. (2018).

Robotics in securities operations. Journal of Securi-

ties Operations & Custody, 10(1):29–37.

Hofmann, P., Samp, C., and Urbach, N. (2020). Robotic

process automation. Electronic Markets, 30(1):99–

106.

Huang, F. and Vasarhelyi, M. A. (2019). Applying robotic

process automation (rpa) in auditing: A framework.

International Journal of Accounting Information Sys-

tems, 35(C).

Iftekhar, N., Warsi, M. R., Zafar, S., Khan, S., and

Biswas, S. S. (2019). Reverse engineering of rela-

tional database schema to uml model. In 2019 In-

ternational Conference on Electrical, Electronics and

Computer Engineering (UPCON), pages 1–6. IEEE.

Leno, V., Augusto, A., Dumas, M., La Rosa, M., Maggi,

F. M., and Polyvyanyy, A. (2020). Identifying can-

didate routines for robotic process automation from

unsegmented ui logs. In 2020 2nd International Con-

ference on Process Mining (ICPM), pages 153–160.

IEEE.

Conceptual Model Detection in Business Web Applications Within the RPA Context

525

Leno, V., Polyvyanyy, A., Dumas, M., Rosa, M. L.,

and Maggi, F. M. (2021). Robotic process min-

ing: Vision and challenges. Business & Information

Systems Engineering: The International Journal of

WIRTSCHAFTSINFORMATIK, 63(3):301–314.

Mannila, H., Toivonen, H., and Inkeri Verkamo, A. (1997).

Discovery of frequent episodes in event sequences.

Data mining and knowledge discovery, 1:259–289.

Sepulveda, C., Cravero, A., and Cares, C. (2017). From

business process to data model: A systematic mapping

study. IEEE Latin America Transactions, 15(4):729–

736.

Sterca, A., Niculescu, V., Chis

alit¸

a-Cret¸u, M.-C., and Os-

man, C.-C. (2023). Primary building blocks for web

automation. In Zhang, F., Wang, H., Barhamgi, M.,

Chen, L., and Zhou, R., editors, Web Information Sys-

tems Engineering – WISE 2023, pages 376–386, Sin-

gapore. Springer Nature Singapore.

ten Bosch, O., Windmeijer, D., van Delden, A., and van den

Heuvel, G. (2018). Web scraping meets survey design:

combining forces. In Big Data Meets Survey Science

Conference, Barcelona, Spain.

Van Der Aalst, W. (2016). Data science in action. Springer.

Van der Aalst, W. M. P., Bichler, M., and Heinzl, A. (2018).

Robotic process automation. Business and Informa-

tion Systems Engineering, 60:269–272.

Willcocks, L. P. and Lacity, M. (2016). Service automation

robots and the future of work. SB Publishing.

Zhao, B. (2017). Web scraping. Encyclopedia of big data,

ICSOFT 2024 - 19th International Conference on Software Technologies

526
