Word Frequency Statistics Based on Serverless Computing

Zhaoxin

Jia

School of Intelligent Systems Engineering, Sun Yat-sen University, Guangzhou, China

Keywords: Serverless Computing, Word Frequency Statistics, Mapreduce, Cloud Computing.

Abstract: Thanks to the continuous updating of server architectures, serverless computing has gradually become a

research hotspot in the current cloud computing field in recent years because of its agile, scalable, and cost-

effective features. This paper proposes a word frequency statistics method based on the serverless computing

technology and MapReduce framework. Specifically, author add a step of preprocessing based on the basic

method. Then, author adaptively assign tasks to each thread according to the total number of words in each

file, which helps to reduce time waste. The filegroup will be split in the map stage. During the reduce stage,

author further count the word frequency in each thread and store it in a temporary file. The project mainly

achieved multi-threaded parallel task completion. Extensive experimental results successfully demonstrated

the superiority of multi-threaded parallel processing efficiency in dealing with large amounts of data, which

author suppose can bring more new insight for developing serverless computing.

1 INTRODUCTION

With the development of science and technology,

research in the field of computer science gradually

shows a trend: the speed of software development far

exceeds the speed of hardware development. To meet

the increasing computational complexity of software,

most solutions related to hardware involve increasing

the number of hardware devices to meet the high

requirements posted by software. The accompanying

problem is that the hardware is still in short supply.

Serverless computing technology has emerged.

Serverless computing belongs to cloud service

technology and is an emerging paradigm of cloud

computing used to develop various software

application processes (Wen, 2022). Serverless

computing is based on cloud computing infrastructure

and service providers allocate computing resources.

The accuracy and real-time nature of this process

mean that the resources allocated do almost exactly

what the given code does. There is no need to worry

about the cost of resource invocation and the

underlying details of the computing platform.

Serverless computing is like public transportation. To

use it, you only need to pay the corresponding fee for

the resources used, and there is no need to pay for idle

virtual machines or containers (Kumar, 2019). This

https://orcid.org/0009-0006-0265-3357

feature greatly facilitates developers. The client no

longer directly uses cloud infrastructure, but only

uses application process logic without server

provided process execution (Werner, 2018; Shafiei,

2019). However, at the same time, serverless

computing also has some problems that cannot be

ignored, such as the delay caused by platform

function cold start and insufficient resource

utilization (Li, 2021).

MapReduce was originally proposed by Google

as a data parallel programming model for machine

clusters, used to process and generate large datasets

to solve various real-world problems and tasks. It is

also an efficient task scheduling model (Sarkar,

2015). At the beginning of its research, it aimed at

parallel processing of web page data in Google search

engines. The MapReduce model consists of two

functions, which are usually named "map" and

"reduce". Firstly, the "map" function receives data

and processes it into blocks. Each node in the cluster

executes a set of Map tasks in parallel, without

sharing any data with other nodes. Next, the data is

partitioned across all nodes in the cluster. Finally,

each node executes a set of "reduce" tasks in parallel

on the partition it receives(Sarkar, 2015). The

"reduce" function is responsible for accepting and

reducing the intermediate results of the partitioned

100

Jia, Z.

Word Frequency Statistics Based on Serverless Computing.

DOI: 10.5220/0012910600004508

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Engineering Management, Information Technology and Intelligence (EMITI 2024), pages 100-104

ISBN: 978-989-758-713-9

data obtained by the "map" function to obtain the final

result. The main advantages of the MapReduce model

are: first, it can process massive amounts of data in

parallel, greatly improving computational speed.

Second, mask the intricate details of the underlying

implementation, which effectively simplifies the

difficulty of writing parallel structured programs and

improves program efficiency. This allows developers

to focus on the program itself, while issues such as

resource allocation and fault tolerance can be handled

by the platform (Czech, 2017). However, MapReduce

also has some shortcomings. Since MapReduce

improves the fault tolerance of long-term analysis

through frequent checkpoints of completed tasks and

data replication, the frequent input and output

required will reduce efficiency. The goal of a parallel

database management system is to improve efficiency

rather than fault tolerance. It may lead to potential

hazards, that is, in the event of a malfunction, a large

number of operations need to be redone, greatly

increasing the complexity (Lee, 2011).

The advantages of serverless computing and

MapReduce show great complementarity in

functionality, which inspires us to combine them.

This study focuses on applying MapReduce to

perform word frequency statistics on words in

multiple texts, and adds a preprocessing step of

counting the number of words in each text before the

model, which is an optimization in the general

approach. By combining the MapReduce model, this

study provides an effective solution to the problem of

word frequency statistics for large amounts of data

and multiple texts, and provides direction for the

further development and optimization of MapReduce

models.

2 METHOD

2.1 MapReduce

MapReduce is an efficient programming model

proposed by Google that combines task scheduling

and parallel computing. Its main application direction

and one of its obvious advantages is processing large-

scale data. The reason why it is more efficient than

other models is its core idea: divide and conquer. The

"map" section decomposes complex tasks, which are

massive amounts of data that require computation,

into several tasks. The "reduce" section receives

intermediate results from the Map section and

summarizes them. The user specifies a map function

that processes a key-value pair to generate a set of

intermediate key-value pairs, and specifies a reduce

function that merges all intermediate values

associated with the same intermediate key (Dean,

2004).

2.2 Alibaba Cloud OSS and FC

Object Storage Service (OSS) is a cloud storage

service provided by Alibaba Cloud that has high

reliability, security, and service availability. The

stored files can be called in different ways, such as

HTTP, RESTful, API, etc. It has a comprehensive

permission control system. Function Calculate (FC)

is a fully managed computing service provided by the

Alibaba Cloud platform. It does not require

purchasing or managing server computing

infrastructure, and only requires uploading code.

Regarding computing resources, service providers

will prepare computing resources and run tasks

flexibly. This design fully meets the requirements of

serverless computing technology: it is based on cloud

computing infrastructure, and service providers

allocate computing resources.

2.3 Alibaba Cloud OSS and FC

The main calling function of this project, denoted as

final-Copy1, is deployed on the Jupyter Notebook

and is responsible for calling the dispatch, mapper,

and reducer functions deployed on the Alibaba Cloud

platform, which are responsible for evenly allocating

computational tasks, decomposing computational

tasks, and aggregating results. The dispatch function

allocates computational tasks to each thread based on

the number of words in the retrieved file; The mapper

and reducer functions implement parallel execution

of multiple mappers and reducers using a multi-

threaded approach, once again improving

computational efficiency and resource and time

waste. These three functions directly access data files

stored in Alibaba Cloud OSS in the form of HTTP

and Alibaba Cloud secret keys. By applying this

feature, experimenter have achieved the requirement

of MapReduce method: to maintain high efficiency

when processing massive data.

2.4 Alibaba Cloud OSS and FC

In this project, a basic requirement for the parallel

execution of MapReduce was achieved by using a

multi-threaded approach. Multi-threading refers to

the generation of multiple tasks within the same

process, namely threads, which can be executed in

parallel. Next, experimenter will compare the

advantages of multi-threading methods with serial

Word Frequency Statistics Based on Serverless Computing

101

execution. Serialization refers to the execution of

multiple tasks by a single thread in a certain order. In

this method, the previous task must be completed

before proceeding to the next task's process. All tasks

cannot overlap in time. For multi-threaded parallel

execution, it is the simultaneous opening of multiple

threads, which strictly means the same occurrence at

the same time, and multiple tasks overlap in time.

Obviously, the efficiency and speed of parallel

execution achieved by multi-threading are

significantly better than serial execution. In addition,

multi-threaded methods are also a convenient and fast

way to achieve parallel task execution at present.

In addition to the multi-threaded method, another

two points of this project are the dispatch function

deployed on Alibaba Cloud FC. As mentioned in

section 2.3, the dispatch function processes HTTP

requests in an HTTP mode. For the list of files

retrieved from the Alibaba Cloud OSS bucket, they

will be sorted based on the number of words in each

file and distributed to different threads to ensure that

the total number of words allocated to each thread is

as close as possible. This can reduce the time waste

and improve the efficiency and resource utilization.

3 EXPERIMENT

3.1 Experimental Settings

This project aims to solve the problem of word

frequency statistics for multiple files using the

MapReduce method. The platform is the OSS and FC

services provided by Alibaba Cloud. All the codes are

implemented using the Python language and the

Jupyter Notebook. The dataset used is 50 randomly

collected English essays from the experimenter's

middle school period, with a total word count of no

less than 5000 words. It is worth noting that according

to the file name number, the number of words in files

1-20 is relatively small, while in the following 30

files, the number of words in each file is obviously

higher than in the first 20. The evaluation indicators

mainly include the time it takes to sequentially count

the word frequency in 10, 20, 30, 40, and 50 files, and

compare it with the time it takes for a single-threaded

serial execution of the same task, in order to study the

efficiency of the MapReduce method combined with

multi-threaded parallel operations.

3.2 Experimental Environment

There are many implementation methods for the

MapReduce model. Considering the specific research

questions and equipment conditions of this project, as

mentioned above, the project applies the FC and OSS

services provided by Alibaba Cloud for word

frequency statistics, and the experimenter's laptop

serves as the commander of this project. Below are

the parameters of each part of the equipment.

(1)As the commander, the computer is equipped

with the traditional 64 bit processor based x64

Windows operating system and the 12th generation

Intel i7 central processor.

(2)The network connecting the computer to the

Alibaba Cloud platform and Jumper Notebook is a

regular home LAN, with a speed of approximately

8.5MB/s.

(3)Jupyter Notebook, formerly known as IPython

Notebook, is an interactive notebook commonly used

in popular areas in the computer field such as data

simulation, statistical modeling, and machine

learning.

3.3 Experimental Process

Firstly, deploy the dispatch, mapper, and reducer

functions in the Alibaba Cloud, and deploy the client

function as the main calling function on the Jupyter

Notebook. The client function issues instructions and

calls the cloud function to execute the task. After the

dispatch function is executed, the files to be counted

are divided into several groups based on the number

of threads and the number of words in the files

assigned. As introduced earlier, the dispatch function

provides a solution for assigning files to each thread

that will perform word frequency statistics tasks.

However, it is worth noting that the dispatch function

only provides an allocation scheme for the mapper

function below, and the data provided to the mapper

function is only some file numbers. After receiving

the allocation scheme provided by the dispatch

function, the mapper function will group the obtained

files according to the scheme and allocate them to

various threads. Each reducer function is responsible

for the word frequency statistics of a thread. Firstly,

the number of words in each file will be output as key-

value pairs, and each will be written into a temporary

file in json format. Next, by reading the key-value

pairs in these json files, summarizing them again to

obtain a final result, and writing it into another file.

At the same time, the time module of the Python

language was introduced into the code of the Jupyter

Notebook, which records the start time when calling

three cloud functions, the end time after all execution

is completed, and the final running time is the

difference between the two times.

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

102

3.4 Analysis of Experimental Results

According to the experimental method and steps

described above, the experimenter conducts the

experiment and records the experimental results,

namely the program running time and the json format

key-value pairs obtained from each round of the

experiment for word frequency statistics files. At the

same time, to ensure the accuracy and rationality of

the experiment, the experimenter conducted a

sampling check on the correctness of word frequency

in the key-value pair statistical file. The experimental

results are shown in Table 1, and the following points

can be observed:

(1)Under the conditions of this experiment, the

duration is approximately 0.73-1.01 seconds.

(2)According to the experimental process

described in section 3.3 and the special arrangement

of this experiment on the dataset described in section

3.1, it is evident that there is a significant time

difference between the second and third results. This

is consistent with the arrangement of the

experimenter when deploying the test dataset, further

proving the correctness and rationality of this

experiment.

Table 1: Processing time for different lengths of words.

Case Cate

A Cate

1 0.730 0.730

2 0.745 0.747

3 0.885 0.925

4 0.947 0.999

5 1.012 1.090

(3) The results of multi-threaded parallel

processing are also compared with those of single-

threaded serial processing in Figure 1. It can be

observed that in the first few experiments, due to the

small number of words that need to be counted, the

time difference between serial and parallel processing

is extremely small and the time used is basically the

same. In the latter groups of experiments, as the

number of words increased, the difference in time

between the experiments conducted using serial and

parallel processing methods became more

pronounced, with serial processing time gradually

increasing significantly compared to parallel

processing time. From this, it can be seen that in this

project, parallel processing is superior to serial

processing in terms of operational efficiency, and its

advantages will become more apparent as the amount

of data provided increases. This also strongly

demonstrates the efficiency of the Mapreduce method

combined with multi-threaded parallel processing in

processing huge data.

Figure 1: Performance comparison between multi-threaded

and single-threaded processing

(Photo/Picture credit

:Original ).

4 DISCUSSION

This experiment applied the MapReduce method to

solve the problem of counting the frequency of words

in multiple files, and added a data preprocessing step

before the processing step to count the number of

words in each file and distribute it evenly to each

thread. However, there are still many directions for

further development or in-depth research in this

project.

(1) Combining with other algorithms. The

proposed solution in this project can serve as the

fundamental solution for the problem of word

frequency statistics. The object of word frequency

statistics should not be limited to word frequency

statistics in multiple files, which may be too

simplistic. The big language model represented by

ChatGPT has attracted attention from all walks of life

and has been imitated by major companies around the

world. These powerful models have enormous

potential in solving various problems, such as natural

language processing (NLP) tasks and real-world

cases, from natural language understanding (NLU) to

generation tasks, and even paving the way for

Artificial General Intelligence (AGI) (Yang, 2023).

The recently proposed model Sora for video

processing provides a development direction for this

project: applying word frequency statistics to audio

and even video. Speech recognition technology can

be used to recognize and record the textual parts in

recorded videos, and then perform word frequency

statistics.

(2) Test with larger scale data. Due to the limited

hardware equipment of the experimenter, the dataset

did not form a large scale, and the total number of

words in the test files has not yet reached the level of

big data. In the future, equipment may be updated to

support a larger amount of data for testing.

Word Frequency Statistics Based on Serverless Computing

103

5 CONCLUSIONS

This project is based on the MapReduce method in

serverless computing technology, and applies multi-

threaded methods to achieve parallel processing. It

combines the OSS and FC services provided by

Alibaba Cloud, and adds a processing step of evenly

distributing files based on the word size before

entering the thread. Finally, the statistical problem of

word frequency in multiple files was completed. In

the experiment, a comparison is also made between

single threading and multi threading, demonstrating

the efficiency of multi threaded parallel processing.

REFERENCES

Czech, Z. J., 2017. Introduction to Parallel Computing.

Cambridge: Cambridge University Press.

Dean, J., Ghemawat, S., 2004. MapReduce: Simplified

Data Processing on Large Cluster. International

Journal of Research and Engineering, 5, 399-403.

Kumar, M., 2019. Serverless Architectures Review, Future

Trend and the Solutions to Open Problems. American

Journal of Software Engineering, 6(1), 1-10.

Lee, K., H., Lee, Y., J., Choi, H., Chung, Y., D., Moon, B.,

2011. Parallel data processing with MapReduce: A

survey. SIGMOD Record, 40(4), 11-20.

Li, Z., Guo, L., Cheng, J., Chen, Q., He, B., Guo, M., 2021.

The Serverless Computing Survey: A Technical Primer

for Design Architecture. ACM Computing Surveys

(CSUR), 54, 1-34.

Sarkar, A., Ghosh, A., Nath, A., 2015. MapReduce: A

Comprehensive Study on Applications, Scope and

Challenges. International Journal of Advance Research

in Computer Science and Management. 3. 256-272.

Shafiei, H., Khonsari, A., Mousavi, P., 2019. Serverless

Computing: A Survey of Opportunities, Challenges,

and Applications. ACM Computing Surveys, 54, 1-32.

Wen, J., Chen, Z., Liu, X., 2022. A Literature Review on

Serverless Computing. arxiv preprint ArXiv,

abs/2206.12275.

Werner, S., Kuhlenkamp, J., Klems, M., Müller, J., Tai, S.,

2018. Serverless Big Data Processing using Matrix

Multiplication as Example. 2018 IEEE International

Conference on Big Data, 358-365.

Yang, J., Jin, H., Tang, R., Han, X., Feng, Q., Jiang, H., Yin,

B., Hu, X., 2023. Harnessing the Power of LLMs in

Practice: A Survey on ChatGPT and Beyond. ArXiv,

abs/2304.13712.

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

104
