Deep Learning and Machine Learning Based Facial Expression

Recognition Employed in Mental Health

Hanyu Lin

Computer Science and Technology, Beijing Information Science & Technology University, Beijing, China

Keywords: Machine Learning, Deep Learning, Facial Expression Recognition, Mental Health.

Abstract: Facial expressions play an important role in human communication, conveying a wide range of emotions

without the need for verbal communication. In recent years, Facial Expressions Recognition (FER) has found

applications in various domains, particularly in the medical field. The technology was originally developed,

using mostly machine-learning model algorithms, including Support Vector Machine (SVM) etc. However,

as the dimension of the characteristics increases, it is difficult to obtain more feature samples. To solve

problem, a framework for Principal Components Analysis (PCA)+Latent Dirichlet Allocation (LDA) is

proposed. After a few years, the development of deep learning gave the FER experiments many large models

to use, such as Convolutional Neural Network (CNN). However, the complexity of facial expressions,

compounded by factors such as illumination, posture, and occlusion, poses challenges for accurate recognition

using traditional methods, the Long-Short-Term-Memory (LSTM) layer structure is added to the CNN, and

it developed into a new model called LSTM-CNN. Deep learning excels in handling complex data and large-

scale datasets, making it the preferred choice for FER due to its adaptability and end-to-end learning capability.

However, its lack of interpretability and challenges with complex data can hinder accuracy and trust in results,

especially in medical applications like mental health diagnosis. Preprocessing data and refining identification

algorithms are crucial steps to improve accuracy in FER projects.

1 INTRODUCTION

The expression on the face is really complex that

through the control of eye muscles, face muscles and

oral muscles, people can make more than 20 species

expressions, such as ‘happy’, ‘sad’, ‘fear’. Those

expressions are usually used in people’s daily life to

correctly express their feelings at the time without

saying any words. Due to the complexity of facial

expressions and the effects of illumination, posture

and occlusion, traditional methods can’t accurately

identify the features of expressions to judge which

expression is it. Identifying emotions based solely on

the eyes is particularly prone to inaccuracies. Deep

learning, on the other hand, offers a robust solution

by using large datasets for model training in many

domains (Liu, 2021; Liu, 2023, Qiu, 2020). It can

pick up more elaborate characteristic and learn the

complexity relationship between different

expressions. After the training, it can give a higher

accuracy in identification, and cut down time

https://orcid.org/0009-0004-0303-3163

required, which can be considered as an effective

solution.

In recent years, Facial Expressions Recognition

(FER), as a new technique, has been employed in

many areas, especially in medical treatment field. It

can sequence specific features of expressions from a

given live videos or images. For instance, Hearst et

al. proposed Support Vector Machine (SVM) and

soon applicable in FER to solve the data classification

problems by finding an optimal decision hyperplane

(Hearst, 1998). In addition, many researchers

proposed a series of more efficient feature extraction

algorithms, like Principal Components Analysis

(PCA), Latent Dirichlet Allocation (LDA), Local

Binary Patterns (LBP), combined with SVM,

Artificial Neural Network (ANN) to improve the

accuracy of recognition. As time progresses, fast-

paced life brings kinds of mental disease to many

people, and those who are living with mental disease

are getting younger. Mental health has actually

become an important globalization social issue. This

Lin, H.

Deep Learning and Machine Learning Based Facial Expression Recognition Employed in Mental Health.

DOI: 10.5220/0012936800004508

In Proceedings of the 1st International Conference on Engineering Management, Information Technology and Intelligence (EMITI 2024), pages 285-288

ISBN: 978-989-758-713-9

285

issue has allowed for the rapid development of

technical means of mental treatment in recent years.

The identification of facial expressions is an

important technique used in treatment to identify the

inconspicuous expressions changes. By analysing the

features of expressions which are captured by facial

expressions recognition technology, it can be

understood the emotions state of patients more

accurately. With deep learning came into a new step

that had been get a great development. The

application of CNN in FER is considered. Breuer et

al. use CNN to calculate the relationship between the

facial action coding system and action units. Then,

they use the Extended Cohn-Kanade (CK+),

NovaEmotions and FER2013 datasets to prove their

findings, identified the micro-expressions based CNN

models. And they introduce a basic LSTM Recurrent

Neural Network (RNN) to achieve most state-of-the-

art accuracy (Breuer and Kimmel, 2017). Peng also

proposed to introduce the LSTM model into CNN to

improve CNN models, and made a comparison in

SVM, CNN and novel CNN (Peng, 2021).

This paper focuses on facial expressions

identification which is used in the treatment of mental

diseases. The content of several other parts of the

paper is as follows. First of all, the details of some

existing methods will be introduced in section 2.

Then, this paper will discuss the shortcoming and

development direction in the existing methods in

section 3. And the last section is to summarize the

first three sections, conclude and reorganize the result

from the paper.

2 METHODS

2.1 Traditional Machine-Learning

Based Facial Expressions

Recognition Models

2.1.1 SVM

As a traditional machine learning model, SVM is a

kind of classification algorithm which has been used

in FER to classify different expressions from images

(Bellamkonda, 2015; Tsai and Chang, 2018). Because

the data is usually images data, each facial expression

is treated as a data point and the features of those data

points were extracted from images. To classify the

expressions, this algorithm can find a hyperplane in

the vector space of features. The hyperplane can put

the expression into two sides, one is healthy emotion,

the other is unhealthy emotion (Peng, 2021). The

advantage is the ability to handle the high-

dimensional space of feature and to do well with the

nonlinear classification problem with suitable kernel

functions.

2.1.2 PCA

PCA has no explicit model structure, it’s a kind of

linear transformation method, can put the data into a

new coordinate like a projector (Abdulrahman, 2014).

When PCA using in FER, it can compress the

expression features data to solves the problem from

identifies the similarities and differences in those

data. By calculating the expressions eigenvalues and

the expressions eigenvectors of the covariance

matrix, then the eigenvector corresponding to the

largest eigenvalues was selected as the principal

components to project the raw data onto the principal

components. It’s a kind of technique that can achieve

dimension reduction from 3D to 2D even through

there are N expression images (Deng, 2005). It can

reduce the amount of expression features while

retaining most of the information, reducing redundant

information between data at the same time.

2.1.3 LBP

LBP has no explicit model structure, it’s a kind of

method that can extract the expression features from

images, it can transform the facial image into a

grayscale image. The original LBP operator is

defined in the 3×3 traditional neighbourhood model,

with the centre of the neighbourhood as a threshold.

Compared the grey value of the 8 pixels with the grey

value of centre. If the surrounding pixel is greater

than the central pixel value, the position of the pixel

is marked as 1, otherwise 0 (Bellamkonda, 2015). By

describing the local texture of the image, it can

capture the characteristics of texture, which is benefit

for texture recognition.

2.1.4 FER Based on SVM with LBP and

PCA and PCA+LDA

Muzammil Abdulrahman proposed a model using

with LBP and PCA with SVM for FER

(Abdulrahman, 2017). Using PCA and LBP

algorithms to extract expression features, and SVM

are used for classification.

PCA is a supervised learning algorithm that is

mainly used for feature dimension reduction and

classification. The goal is to find an optimal

projection, so that the data of different categories can

be separated in the new feature space, while the data

within the same category are clustered as closely as

possible (Deng, 2005). LDA differs from PCA. PCA

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

286

aims to maximize the variance of the data, while LDA

aims to maximize differences between classes and

minimize differences within classes.

Deng proposed that as the dimension of the

characteristics increases, it is difficult to obtain more

feature samples. To solve this significant problem, the

author proposed a new framework PCA+LDA. This

framework can describe that PCA maps the original

t-dimensional feature acquisition to the f-dimensional

feature as an intermediate space, and then LDA

projects the PCA output onto the new g-dimensional

feature vector (Deng, 2005).

2.2 Deep-Learning Based Facial

Expressions Recognition Models

2.2.1 CNN

The Neural Network is a mathematical model or

computational model that mimics the structure and

function of the biological neural network. The

structure of CNN can be divided into three large

layers: input layer, hidden layer and output layer (Li,

2021; Qiu, 2024). In the hidden layer, there are three

layers: Convolutional Layer for extracting the

expression features, Pooling Layer for down

sampling without damage identification results, Fully

Connected Layer for classification.

When the convolution step is 1, the convolution

core scans the elements of the feature map one by one.

As an image of 16×16 input into the input layer, after

a convolution kernel with a unit step size and no full

of 5×5, it will output a feature map image which size

of 12 × 12. After the data is convolved by the

convolution kernel in the convolutional layer to

extract the expression features. The pooling layer had

a size of 2×2 polling box means that the length of the

moving step was 2, which just like to the compression

of the image. This process is performed repeatedly

until the number of times the operational

requirements are met (Peng, 2021).

2.2.2 LSTM-CNN

X. L. Peng then proposed to introduce LSTM into

CNN. The LSTM as a layer can reduce the impact of

the background colour, because the algorithm can

make features more prominent which are continuous

changes when people change the expression. This

layer was configured with 64 hidden neurons, weights

initialized using glorot_normal initialization, the bias

initialized to 0 (Peng, 2021). The structure of LSTM

can be put into three parts: input gate, forget gate and

output gate. The input gate, calculated by the tanh

function, is utilized to extract expression features

from the candidate state. Then in the next gate by

forgetting the old information and adding newly

information to updates the old cell. In the last, the

output gate will output the new cell (Yang, 2023).

This combination takes advantage of the ability of

LSTM to process sequence data and the advantages

of the CNN in extracting spatial features, allowing the

model to perform better in tasks such as face emotion

recognition.

3 DISCUSSIONS

To compare the deep learning models with machine

learning, deep learning has better performance on

processing complex data and solving different

problems. The main reason why FER chooses deep

learning is that it can better handle complex features

and large-scale data sets of face data, and can realize

end-to-end learning process. Also, deep learning

models are more adaptable and generalized, they can

be better able to handle large-scale data and complex

patterns, and also have good predictive power for the

data which has never been seen before.

However, there are still some disadvantages for

deep learning models. The interpretability of AI is

that although these models can run completely, but

there hardly have any explanation for why specific

features over other specific features are selected

during training, or how the correlation in the trained

data is represented in the selection of features

(Chakraborty, 2017). For example, in the medical

scenario, due to the interpretability of AI, the reasons

for the formation of facial expressions provided by

patients are not explained, which may lead to doctors

and patients to distrust the results from deep learning

model, that will affect the doctor’s judgment of the

condition, and then affect the application and

development of mental health.

Another reason for the low accuracy of deep

learning models is because the original data is too

complex and unique, so it is hindered when using

some feature extraction algorithms. S. Li et al.

proposed that different illumination, background and

head posture can have a large impact on the data

images, thus affecting the performance of FER (Li

and Deng, 2020). When conducting the FER project,

if the accuracy of the result is low, experimental

group can choose to preprocess the data and adjust the

identification algorithm. Reduce the number of

expressions first, after ensuring a steady accuracy

rate, then add to the type quantity. Here are some

ways to preprocess the data by adjusting the image to

a uniform size, scaling the pixel value of the image to

a fixed range (usually [0,1] or [-1,1]), and

standardizing the pixels and pose or angle values.

Deep Learning and Machine Learning Based Facial Expression Recognition Employed in Mental Health

287

In the future, FER is expected to become an

important tool in the field of mental health, helping to

identify people’s emotional changes. Combining

deep learning and emotional intelligence, more

accurate expression recognition can be realized to

assist the diagnosis of mental health problems such as

depression and anxiety. This technology may be

combined with advanced biosensing hardware

technology to provide a more comprehensive

assessment of emotion (Deng, 2019; Sugaya, 2019).

In the future, the development of these technologies

may lead to more mental health AIDS and improve

the mental health status of individuals.

4 CONCLUSIONS

In this paper, a review of machine learning and deep

learning in FER was provided. This paper discussed

models in methods of machine learning and deep

learning. In machine learning, there are several

models like SVM, LBP, PCA and PCA+LDA. In

deep learning, there are several models like CNN and

CNN-LSTM. Overall, machine learning is less

accurate than deep learning in FER. But deep learning

also has problems such as the inability to handle

complex data and interpretability. This paper there

are only limited models and algorithms about

machine learning and deep learning. In the future the

further study plans to increase the exploration of the

usage scenarios and the method exploration of how

the data are processed.

REFERENCES

Abdulrahman, M., Gwadabe, T. R., Abdu, F. J., & Eleyan,

A. 2014, April. Gabor wavelet transform based facial

expression recognition using PCA and LBP. In 2014

22nd signal processing and communications

applications conference (SIU) (pp. 2265-2268). IEEE.

Abdulrahman, M., & Eleyan, A. 2015, May. Facial

expression recognition using support vector machines.

In 2015 23nd signal processing and communications

applications conference (SIU) (pp. 276-279). IEEE.

Breuer, R., & Kimmel, R. 2017. A deep learning

perspective on the origin of facial expressions. arXiv

preprint arXiv:1705.01842.

Bellamkonda, S., & Gopalan, N. P. 2018. A facial

expression recognition model using support vector

machines. IJ Mathematical Sciences and Computing, 4,

56-65.

Chakraborty, S., Tomsett, R., Raghavendra, R., Harborne,

D., Alzantot, M., Cerutti, F., ... & Gurram, P. 2017,

August. Interpretability of deep learning models: A

survey of results. In 2017 IEEE smartworld, ubiquitous

intelligence & computing, advanced & trusted

computed, scalable computing & communications,

cloud & big data computing, Internet of people and

smart city innovation (pp. 1-6). IEEE.

Deng, H. B., Jin, L. W., Zhen, L. X., & Huang, J. C. 2005.

A new facial expression recognition method based on

local Gabor filter bank and PCA plus

LDA. International Journal of Information

Technology, 11(11), 86-96.

Deng, X., Li, L., Enomoto, M., Kawano, Y., 2019.

Continuously frequency-tuneable plasmonic structures

for terahertz bio-sensing and spectroscopy. Scientific

reports, 9(1), p.3498.

Hearst, M. A., Dumais, S. T., Osuna, E., Platt, J., &

Scholkopf, B. 1998. Support vector machines. IEEE

Intelligent Systems and their applications, 13(4), 18-28.

Li, S., & Deng, W. 2020. Deep facial expression

recognition: A survey. IEEE transactions on affective

computing, 13(3), 1195-1215.

Li, Z., Liu, F., Yang, W., Peng, S., & Zhou, J. 2021. A

survey of convolutional neural networks: analysis,

applications, and prospects. IEEE transactions on

neural networks and learning systems, 33(12), 6999-

7019.

Liu, Y., Liu, L., Yang, L., Hao, L. and Bao, Y., 2021.

Measuring distance using ultra-wideband radio

technology enhanced by extreme gradient boosting

decision tree (XGBoost). Automation in

Construction, 126, p.103678.

Liu, Y. and Bao, Y., 2023. Intelligent monitoring of

spatially-distributed cracks using distributed fiber optic

sensors assisted by deep learning. Measurement, 220,

p.113418.

Peng, X. 2021. Research on Emotion Recognition Based on

Deep Learning for Mental Health. Informatica, 45(1).

Qiu, Y., Hui, Y., Zhao, P., Cai, C. H., Dai, B., Dou, J., ... &

Yu, J. 2024. A novel image expression-driven modeling

strategy for coke quality prediction in the smart

cokemaking process. Energy, 130866.

Qiu, Y., Yang, Y., Lin, Z., Chen, P., Luo, Y., & Huang, W.

2020. Improved denoising autoencoder for maritime

image denoising and semantic segmentation of

USV. China Communications, 17(3), 46-57.

Sugaya, T., Deng, X., 2019. Resonant frequency tuning of

terahertz plasmonic structures based on solid

immersion method. 2019 44th International Conference

on Infrared, Millimeter, and Terahertz Waves, p.1-2.

Tsai, H. H., & Chang, Y. C. 2018. Facial expression

recognition using a combination of multiple facial

features and support vector machine. Soft

Computing, 22, 4389-4405.

Yang, W. 2023. Extraction and analysis of factors

influencing college students’ mental health based on

deep learning model. Applied Mathematics and

Nonlinear Sciences.

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

288
