Virtual Try on Application and Parameter Analysis Based on

Clothing Warping and Masking Technology

Chunbo Feng

Data Science and Big Data, South China University of Technology, Guangzhou, China

Keywords: Virtual Fitting, DCI-VITON, Masking Techniques, Visual Quality.

Abstract: Virtual Fitting represents a pivotal application of technology, facilitating seamless online clothing purchases

by enabling users to visualize garments on their bodies. As a focal point within the image generation domain,

it holds immense commercial value, garnering substantial attention. This paper delves into the examination

of parameters and training sessions' impact on Diffusion-based Conditional Inpainting for Virtual Try-ON

(DCI-VITON), elucidating the efficacy of individual blocks and the overall model. Leveraging garment

warping and masking techniques, the method preserves coarse character image structures while harnessing

the potent generative capabilities of diffusion models to refine results. Experimental findings highlight the

nuanced effects of various parameters on model performance, showcasing its superiority over alternative

virtual fitting methods, particularly in capturing clothing details and styles. The model's ability to produce

realistic, intricately detailed morphed garments with consistent visual quality underscores its significance.

This project serves as a crucial reference for future virtual fitting techniques grounded in diffusion models.

1 INTRODUCTION

Along with the growing community of users shopping

online, the commercial value of image-generated

virtual try-on is increasing. Virtual fitting allows

users to very visually see the effect of goods on the

body instead of going to a physical store to try on

clothes. This reduces the cost of fitting and greatly

improves the user's online shopping experience.

Virtual fitting technology is based on images of

people as well as images of clothing to generate the

final effect. It is ideal for online platforms as it is able

to edit and replace the content of clothing images

directly online (Song, 2023).

Virtual Try-on based on image generation

presents several challenges. First of all, the image

should retain the original pose and the original shape

of the body in a complete and natural way. Secondly,

in order to achieve a better effect, the costume should

be naturally deformed so that the posture of the

costume can fit more closely with the original posture

and body shape of the character. In addition, the parts

of the body that are initially covered by the clothing

should be rendered appropriately. Satisfying these

https://orcid.org/0009-0001-9835-3431

requirements was challenging due to the initial

mismatch between the clothing and character images.

Generative adversarial networks (GANs) have

underpinned most previous virtual try-on techniques.

Nikolay et.al. Bergmann proposed Conditional

Analogical GAN (CAGAN) which suggested a U-

NET-based GAN (Jetchev, 2017). However, the

convergence of GAN's generator is heavily dependent

on the choice of hyperparameters and parameters,

making it unrealistic and imperfectly detailed. In

2018, VITON has innovatively proposed an image-

based virtual try-on network that does not make use

of any 3D information (Han, 2017). Subsequently, the

proposal of VITON-HD (Choi, 2021) and HR-

VITON (Lee, 2022) further advanced the

development of virtual try-on, which is no longer

limited to low resolution. Recently, as the capabilities

of diffusion models have been tapped in the field of

generative models, more and more people have begun

to investigate virtual try-on techniques based on

diffusion models. In 2023, Aiyu CUI utilized the

diffusion model for the first time to provide virtual

fittings to passersby on the street, expanding the

direct beneficiaries of virtual fittings from merchants

to every one of us (Cui, 2023). TryOnDiffusion (Zhu,

328

Feng, C.

Virtual Try on Application and Parameter Analysis Based on Clothing Warping and Masking Technology.

DOI: 10.5220/0012937600004508

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Engineering Management, Information Technology and Intelligence (EMITI 2024), pages 328-332

ISBN: 978-989-758-713-9

2023) and StableVITON (Kim, 2023), launched by

Google based on the diffusion model, have achieved

the best performance so far in 1024x1024 single-

piece top fitting.

Enhancing clothing quality post-deformation by

adjusting parameters in the deformation network and

optimizing clothing details constitute the primary

objectives of this study. Furthermore, this research is

dedicated to improving the visualization of generated

clothing on the human body in virtual fitting tasks. To

achieve this, a multi-step approach is employed.

Firstly, a morphing network predicts the clothes to be

tried on and the models wearing them, facilitating

accurate clothing morphing. Secondly, Diffusion

models refine initial synthetic results. Thirdly,

various models' predictive performance is analyzed

and compared. Additionally, the optimal model is

determined through iterative training sessions,

hyperparameter adjustments, and latent space

downsampling. Experimental findings elucidate the

impact of different parameters on model performance.

2 METHODOLOGIES

2.1 Dataset Description and

Preprocessing

This study utilizes the High-Resolution VITON-

Zalando Dataset (VITON-HD), specifically designed

for high-resolution virtual try-on tasks (Choi, 2021).

VITON-HD comprises original images featuring

female characters adorned in various garments,

alongside associated agnostic masks, cloth masks,

densepose images, and more, derived from these base

images. The dataset is meticulously divided into

distinct training and test sets, with the test set

containing 11,647 pairs and the training set

comprising 2,032 pairs. This extensive dataset serves

as a comprehensive resource for training and

evaluating the performance of the proposed methods

in virtual fitting tasks. The sample is shown in the

Figure 1.

Figure 1: Images from VITON-HD dataset

(Picture credit:

Original).

2.2 Proposed Approach

This virtual try-on approach comprises two main

components. Firstly, clothes are warped and merged

with a masked image of the individual using a

warping network. Secondly, the results from the

initial step are refined using a diffusion model. Prior

to this, the author preprocesses the individual's image

to obtain segmentation results, dense pose, and

clothes-agnostic data. To ensure compatibility

between the clothing and the target individual, the

deformation network predicts the appearance flow

field, facilitating pixel-level matching between the

clothing and the individual's torso image.

Subsequently, the deformed clothing is integrated

with the distorted character image, yielding an initial

result. Following the addition of noise, the coarse

output from the first step undergoes refinement

through the diffusion model, resulting in an enhanced

outcome after denoising. This method leverages the

robust generative capabilities of the diffusion model,

in conjunction with garment warping and masking

techniques. The integration of these methodologies

yields a seamless synthesis of the individual and the

garment, thereby yielding excellent performance in

virtual try-on tasks. The system's architecture is

illustrated in Figure 2 below.

Figure 2: The pipeline of study

(Picture credit: Original).

2.2.1 Warping Networks

There are two types of warping methods used for

garment deformation, Thin Plate Spline deformation

and appearance flow-based deformation. Thin Plate

Spline (TPS) is one of the interpolation methods,

which is a commonly used 2D interpolation method

(Bookstein, 1989). TPS is often used in applications

related to the deformation of image key points and so

on. It will offset the control points of an image to

achieve a specific deformation of the image through

the control points.

Appearance flow-based deformation is based on

the concept of appearance flow. Appearance flow

refers to the difference in appearance between two

Virtual Try on Application and Parameter Analysis Based on Clothing Warping and Masking Technology

329

images, which can be understood as the pixel-level

correspondence between two images, as a way to

deform and align images with each other (Gou, 2023).

For this method, first, features are extracted from the

two input images. Next, the correspondence between

the two images is determined by calculating the

difference in appearance between the two images.

Using the estimated obtained appearance flow,

feature points in one image are mapped to

corresponding positions in the other image. In this

way, as shown in Figure 4, the deformation between

the images is realized. The process is shown in the

Figures 3. and Figure 4.

Figure 3:

The process of warping network

(Picture credit:

Original).

Figure 4: Warped clothes after passing through the warping

network

(Picture credit: Original).

2.2.2 Diffusion Model

Denoising Diffusion Probabilistic Models (DDPM)

(Ho, 2020) is a method that changes the input image

into pure Gaussian noise and then recovers it back to

the image, utilizing the forward process and Gaussian

distribution variance to generate the image.

However, because the Denoising Diffusion

Probabilistic Model itself is a Markov chain process,

it is impossible to avoid the iterative process, thus

leading to its inference being too slow. Therefore,

Robin Rombach proposed the latent space diffusion

model (LDM). This model is a good combination of

diffusion process and latent variable model, aiming at

capturing the underlying structure and dynamic

evolution in the data, which greatly improves the

efficiency and quality of the generation (Rombach,

2021). By modeling latent variables and the diffusion

process, the latent diffusion model can be used to

learn structures and patterns in the data and used to

generate new data samples.

In this approach, the diffusion model generates

more refined results based on the initial results

generated in the first part to make the clothing fit the

portrait better and to process the details of the

clothing to make the overall effect more realistic.

There are two main parts to the training process for

this module: the reconstruction and the refinement

(Gou, 2023). In the reconstruction part, the model

first performs forward diffusion processing on the

target image, and then gradually adds noise to

improve the robustness and generalization ability of

the model. The model uses a latent space diffusion

model to reduce computation time and improve

model performance. The image is first inserted into

the latent space with a pre-trained encoder. Then the

image is reconstructed by the pre-trained decoder. In

the refinement part, the model improves the similarity

between the model predictions and the results

generated by the deformation network by adding

noise to the inputs. The training process of the model

is done by optimizing the objective function of both

branches while optimizing both parts of the model.

2.2.3 Loss Function

For the appearance flow, the total variation loss

function is optimal because it should be regularized

to ensure the smoothness of the appearance flow.

Total-variation (TV) loss is a loss function commonly

used in image processing and computer vision tasks.

It is used to smooth an image to avoid excessive noise

or discontinuities in the image. TV loss is often used

as a regularization term in tasks such as image

reconstruction, denoising, and super-resolution to

help maintain the smoothness and continuity of an

image. Given a 2D image I, the TV loss can be

expressed as:

1, , , 1 ,

() ( )

i j ij ij ij

TV I I I I I

=−+−



(1)

where

𝐼



denotes the pixel value at position (i, j)

in image I. This formula calculates the differences

between adjacent pixels in the image and smoothes

the image by minimizing these differences

In addition, the L1 loss and the perceptual loss are

used to minimize the distance between the warped

cloth and the pose of the person in the feature space.

L1 loss is a loss function commonly used in

regression models to achieve feature selection using

L1 loss to simplify the model and improve

generalization. The L1 loss is defined as:

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

330

()

Lii

yfx

=−



(2)

Where the true value represented by

𝑦



is the

deformation mask and the predicted value

represented by

𝑓



𝑥





is the deformed cloth.

Perceptual loss utilizes the ability of the

convolutional layer to abstract high-level features to

approximate the human eye's perception of image

quality thereby comparing the similarity of the

generated image to the target image. This loss

function better captures the semantic content and

structure of the image, not just pixel-level differences.

Perceived loss is also applied to the diffusion model.

The Perceptual loss can be defined as:

() ()

vgg

φφ

=−



(3)

3 RESULTS AND DISCUSSION

For evaluating the performance of the model, this

study uses measures that are commonly used in the

field of image generation: structural similarity index

(SSIM), perceptual distance (LPIPS). In addition to

this Frechette's Perceptual Distance (FID) is also

used. By comparing with other virtual try-on

methods, as shown in Table 1, it is found that the

improved method achieves good results for all

evaluation criteria. The SSIM evaluation criteria

show that the generated image has a very high

similarity to the original image. The value of LPIPS

reaches 0.092, which also indicates that the two

images are very similar. Overall, the improved

method generates more realistic and better images

and compares well with other SOTA methods.

Table 1: Quantitative comparison with baselines.

Resolution 512*384

Method

SSIM↑

LPIPS↓

FID↓

PF-AFN

0.885

0.082

11.3

HR-VITON

0.8623

0.1094

16.21

CP-VITON

0.791

0.141

30.25

DCI-VITON

0.896

0.043

8.09

This method turns down the learning rate of the

Adam optimizer compared to the original DCI-

VITON model. Compared to the default learning rate

of 0.001, problems such as gradient explosion or

gradient vanishing can be avoided, although the

model takes longer to converge. In addition to the β_1

of the Adam optimizer is adjusted to 0.5, which

prevents the gradient decay rate from being too high

and making it difficult to jump out of the local

minimum.

Figure 5: The comparison between the original garment and

the deformed garment

(Picture credit: Original).

As can be seen from the images generated in

Figure 5, the first and second columns of clothing

retain the original details (patterns and stripes) of the

garments intact. There are no color differences and

the style of the garments is consistent with the

original garments. At the same time, the style of the

deformed garment fits very well with the human body

posture, structure and form. In terms of the color and

pattern of the garment, although there are some

deviations, the expected effect is generally achieved

and the final effect is very realistic.

4 CONCLUSIONS

This study primarily focuses on analysing the

structure of DCI-VITON and the impact of various

parameters on its performance. The model's main

innovation lies in the integration of the warping and

refinement modules. The warping module combines

warped clothing with masked characters to produce

coarse results, while the refinement module employs

the robust generative capabilities of the diffusion

model to enhance image details after noise addition.

The diffusion model training process involves two

key stages: reconstruction and refinement, which

collectively contribute to improved model

performance. Additionally, adjustments to epochs

and hyperparameters are made to compare

performance effectively. The authors specifically

concentrate on deformation networks, fine-tuning

Virtual Try on Application and Parameter Analysis Based on Clothing Warping and Masking Technology

331

parameters to achieve accurate, realistic, and detail-

preserving deformed clothing. Extensive experiments

have been conducted to optimize the proposed

method. Moving forward, the next phase of research

will focus on implementing and enhancing diffusion

models to generate complete virtual try-on figures.

Furthermore, attention will be directed towards

human accessories such as scarves, bracelets, and

headbands, expanding the scope of virtual try-on

applications.

REFERENCES

Song, D., Zhang, X., Zhou, J., Nie, W., Tong, R., & Liu, A.

(2023). Image-Based Virtual Try-On: A Survey. arXiv,

2311.04811.

Jetchev, N., & Bergmann, U.M. (2017). The Conditional

Analogy GAN: Swapping Fashion Articles on People

Images. 2017 IEEE International Conference on

Computer Vision Workshops (ICCVW), pp: 2287-2292.

Han, X., Wu, Z., Wu, Z., Yu, R., & Davis, L.S. (2017).

VITON: An Image-Based Virtual Try-on Network.

2018 IEEE/CVF Conference on Computer Vision and

Pattern Recognition, pp: 7543-7552.

Choi, S., Park, S., Lee, M.G., & Choo, J. (2021). VITON-

HD: High-Resolution Virtual Try-On via

Misalignment-Aware Normalization. IEEE/CVF

Conference on Computer Vision and Pattern

Recognition (CVPR), pp: 14126-14135.

Lee, S., Gu, G., Park, S.K., Choi, S., & Choo, J. (2022).

High-Resolution Virtual Try-On with Misalignment

and Occlusion-Handled Conditions. European

Conference on Computer Vision.

Cui, A., Mahajan, J., Shah, V., Gomathinayagam, P., &

Lazebnik, S. (2023). Street TryOn: Learning In-the-

Wild Virtual Try-On from Unpaired Person Images.

arXiv, 2311.16094.

Zhu, L., Yang, D., Zhu, T.L., Reda, F.A., Chan, W., Saharia,

C., Norouzi, M., & Kemelmacher-Shlizerman, I. (2023).

TryOnDiffusion: A Tale of Two UNets. 2023

IEEE/CVF Conference on Computer Vision and

Pattern Recognition (CVPR), pp: 4606-4615.

Kim, J., Gu, G., Park, M., Park, S.K., & Choo, J. (2023).

StableVITON: Learning Semantic Correspondence

with Latent Diffusion Model for Virtual Try-On. arXiv,

2312.01725.

Gou, J., Sun, S., Zhang, J., Si, J., Qian, C., & Zhang, L.

(2023). Taming the Power of Diffusion Models for

High-Quality Virtual Try-On with Appearance Flow.

Proceedings of the 31st ACM International Conference

on Multimedia.

Bookstein, F. L. (1989). Principal warps: Thin-plate splines

and the decomposition of deformations. IEEE

Transactions on pattern analysis and machine

intelligence, vol. 11(6), pp: 567-585.

Ho, J., Jain, A., & Abbeel, P. (2020). Denoising Diffusion

Probabilistic Models. arXiv, 2006.11239.

Rombach, R., Blattmann, A., Lorenz, D., Esser, P., &

Ommer, B. (2021). High-Resolution Image Synthesis

with Latent Diffusion Models. 2022 IEEE/CVF

Conference on Computer Vision and Pattern

Recognition (CVPR), pp: 10674-10685.

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

332
