Multiple GPUs-Based Distributed Learning for Classification of

Breast Cancer Images

Tengfei Luo

Computer Science (Artificial Intelligence), University of Nottingham, Nottingham, U.K.

Keywords: Distributed Machine Learning, GPUs, Deep Learning, Breast Cancer.

Abstract: The study focuses on the classification of breast cancer images using deep learning techniques, particularly

emphasizing the role of multi-GPU setups to handle the demanding computational needs of this task. Breast

cancer, notorious for its high misdiagnosis rate, poses a significant challenge in medical diagnostics, where

Computer-aided Diagnosis (CAD) systems can play a pivotal role. This study experiments with various

convolutional neural network models including ResNet and MobileNet. These models are tested on a dataset

divided into three categories—normal, benign, and malignant images—sourced from ultrasound scans. The

dataset used comprises a substantial number of images, which are then processed and augmented to fit the

model requirements. The study evaluates the models' performance based on accuracy and efficiency metrics,

revealing that while multiple Graphics Processing Units (GPUs) theoretically increase computational speed,

they do not always correspond to better model performance due to potential issues in data synchronization and

parallel processing inefficiencies.

1 INTRODUCTION

With the recent advances in deep learning, computers

are able to take a step forward from humans to

perform complex tasks that have a high misdiagnosis

rate. In medicine, Computer-aided Diagnosis (CAD)

is becoming increasingly important, especially in

diseases with high misdiagnosis rates, such as breast

cancer, nonspinal fractures, and spinal fractures

(Jeremy, 2013; Qiu, 2019; Qiu, 2022).

Among these diseases, breast cancer has the

highest misdiagnosis rate due to its difficult diagnosis

and detection (Ma, 2020), posing a serious threat to

women's health as the second leading cause of death

among women. Early diagnosis can significantly

reduce the mortality rate (40 per cent or more). There

are two ways to detect breast cancer. The first is

mammography (Gøtzsche, 2013), which has a high

resolution and is highly standardised, but it is costly,

can lead to overdiagnosis and carries a risk of

radiation exposure. The second method is ultrasound

(Guo, 2018), which is radiation-free and has high

sensitivity in detecting solid masses, but it has low

resolution and is dependent on the experience and

skill of the operator. Ultrasound images do not have

https://orcid.org/0009-0000-2766-8519

any distinctive features compared to other medical

images. Ultrasound features of breast cancer may

include irregular shape, blurred borders, uneven

internal echoes, etc. However, in benign lesions, there

are no distinctive features that can be detected.

Benign lesions (such as cysts or fibroadenomas) can

sometimes show similar features, which can lead to

diagnostic uncertainty. Ultrasound is healthier for

people who have regular testing, but it is a condition

that relies heavily on the experience and skill of the

doctor, and therefore has a higher rate of

misdiagnosis. Given deep learning's proficiency in

learning from past experiences, the application of it

can be considered in reducing the rate of misdiagnosis

of breast cancer.

The technique being used in breast cancer

detection is commonly known as machine learning.

Machine learning is characterised by the researcher

finding a filter or feature that makes the results clearer

and then learning to find the values of the relevant

features in an image to make a final judgement. Yali

proposed the use of H-Scan image, in this ultrasound

image there is a big difference in the result of benign

and malignant tumours, benign breast tumours have

more red areas and malignant tumours have more

Luo, T.

Multiple GPUs-Based Distributed Learning for Classiﬁcation of Breast Cancer Images.

DOI: 10.5220/0012937700004508

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Engineering Management, Information Technology and Intelligence (EMITI 2024), pages 333-336

ISBN: 978-989-758-713-9

333

blue areas, so it is good to classify them (Yali, 2019).

But deep learning doesn't need humans to do feature

extraction, the machine will analyse the image from a

higher dimensional perspective. Because deep

learning can learn some abstract features that are

difficult for humans to understand. These features

may be more useful for image classification. Zhantao

proposed a supervised learning method that uses

trained textures to classify breast tissue into different

categories (Zhantao, 2019). Some researchers have

tried to use deep learning models for training,

Boukaache tried to use pre-trained convolutional

neural network models such as VGG16, ResNet18

and ResNet50 for breast cancer image classification.

(Boukaache, 2024) And got good results (97.8%). But

the general training is done on a high-performance

Graphics Processing Unit (GPU). The trained texture

is not very easy to get in practical situation,

ultrasound image is a more three-dimensional image,

the picture is the same for different angles at the same

position, in some angles the picture is very noisy and

thus a good texture cannot be obtained.

So the main purpose of this research is to attempt

to classify breast cancer images using multiple GPUs.

This paper will use ResNet 18 and MobileNetV2,

which are simpler models that can be trained on

smaller machines. This paper also tried to compensate

for the lack of performance of a single GPU by using

multiple GPUs.

2 METHOD

2.1 Dataset Preparation and

Preprocessing

This data utilized medical images of breast cancer

based on ultrasound scans. The breast ultrasound

dataset is divided into three categories: namely

normal, benign and malignant images. Firstly, the

dataset is medical images of breast cancer scanned

with ultrasound (Al-Dhabyani W). The source of the

dataset is downloaded from Kaggle (Kaggle, 2021).

The original dataset classifies the images into three

categories, benign tumours, malignant tumours and

normal (no tumour) and is accompanied by images of

the tumour location and its shape. There are 891

images of benign tumours, 421 images of malignant

tumours and 266 images of normal. Figure 1 provides

sample images on the dataset.

The raw data can be used for target recognition,

so each image has not only the classification

information but also the coordinates of the target. In

this experiment, this paper only focuses on

classification, so the location information contained

in the data will be removed. After processing the

images, the data is divided into a training set and a

test set. The data is then enhanced. For different sizes

of images, the images are firstly resized to 256x256

and then cropped in the centre by taking a square of

length 224x224 with the centre as the origin. Then,

the data is normalised. This paper also converted the

pixel values from 0 to 255 to around 0 to 1. Finally,

the image data was divided into a training set and a

test set using 5-fold cross validation to evaluate and

improve the generalisation of the model.

Figure 1: Breast image Malignant (Left) benign(middle)

normal (right) (Photo/Picture credit: Original).

2.2 Model Establishment

In this study, MobileNet V2 is used to deal with an

image classification task that is prone to overfitting

(Sandler, 2018). MobileNet V2 is a simple deep

learning model for very simple image classification

tasks. If a complex model is prone to overfitting, it is

common to choose a simple model in addition to

tuning the parameters.

MobileNetV2 is a lightweight deep learning

model optimised for mobile devices, with the core

advantage of Depthwise Separable Convolution. This

technique reduces the number of parameters and

computational cost of the model, while providing

efficient performance. The model also introduces

Inverted Residual Blocks and Linear Bottlenecks to

further improve efficiency. The last layer in these

blocks usually does not use the ReLu activation

function to prevent information loss.

The model was implemented using the PyTorch

framework, and the accelerate library was used to

support training in a multi-GPU environment. The

accelerate library allows for parallel processing of

data and training of the model in a multi-GPU

environment, which theoretically improves the

efficiency of training. At the end of the epoch, the

study evaluates the model's calibration by its

accuracy and saves the model when it finds a higher

accuracy in a test.

This study used Resnet 34. Firstly, pretrained was

set to false. To reduce overfitting, dropout

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

334

Table 1: The performance of various models based on different parameters.

Batch size Time GPU number Train accuracy Test accuracy

ResNet34 64 771 2 0.99 0.42

ResNet34 128 840 2 0.99 0.46

ResNet34 128 1588.14 4 0.93 0.53

ResNet34(Dropout= 0.8) 64 771 2 0.88 0.43

ResNet 18 128 799 2 0.82 0.45

ResNet 50 64 770.45 2 0.7 0.45

ResNet 50 128 865 2 0.7 0.42

MobileNet V2 128 801 2 0.99 0.4

MobileNet V2(cross-validation) 128 801 2 0.99 0.83

MobileNet V2(cross-validation) 128 2200 4 0.99 0.63

regularisation was added by setting the dropout rate

to 0.5. The optimiser was defined as stochastic

gradient descent with a learning rate of 0.001 and

momentum of 0.9. The model then uses a learning

rate scheduler, which stops at the validation loss, and

a learning rate scheduler, which stops at the validation

loss, and a learning rate scheduler, which stops at the

validation loss. The model then uses a learning rate

scheduler to reduce the learning rate when the

verification loss stops improving.

For this paper, ResNet34 which is a deep residual

network that belongs to the ResNet of deep learning

architectures was chose, proposed by He et al.

proposed in 2015. The main idea of ResNet is to solve

the degradation problem in the training process of

deep neural networks through residual learning.

Before the emergence of ResNet, if the number of

layers increases there may be problems such as

gradient disappearance, and the performance of the

network will be saturated or even decline, rather than

continue to improve.

ResNet34 is composed of 34 convolutional layers.

The innovation of this network is the introduction of

residual modules, each of which consists of two or

three convolutional layers and is connected by jumps.

The minnow connection allows the gradient to flow

directly through multiple layers, thus increasing the

efficiency of gradient propagation during training and

allowing the network to learn deeper features.

A 3080x4 GPU was used for this study. After

configuring the distributed model, they used the same

dataset with batch sizes set to 64 and 128 to compare

the results. The epoch is also set to 10, 50, 100 to

compare the correctness rate. The highest accuracy of

the training batch is then used as the final accuracy of

the training.

The methodology and dataset used in this study

are described above, and the experiments are

conducted while controlling all other variables, in

order to investigate the difference between running on

a single GPU and running on multiple GPUs at the

same time. The experiments are then quantified by

two metrics: runtime and accuracy.

3 RESULTS AND DISCUSSIONS

As shown in Table 1, the best accuracy of this

experiment is 0.83, using MobilNet V2 with a batch

size of 128. In this experiment, four models, Resnet

18, Resnet 34, Resnet 50 and MobileNet V2, were

tested. The batch size was set to 64 and 128, and the

number of GPUs was set to 2 or 4.

From the experiments, it can be concluded that the

batch size has little effect on the correctness rate in

the case of overfitting, and cannot change the status

quo of overfitting. In terms of time, as the depth of

the model increases, the training time increases

slightly, and when the number of GPUs is set from 2

to 4, the time increases to 3 times of the original one,

which may be due to the inefficiency of data

transmission and synchronisation. This suggests that

the communication between GPUs may cause the

training parallelisation to be inefficient.

Since the initial training with ResNet 34 resulted

in a high rate of correct model training, the next

experiments were conducted to make the model more

generalisable by other methods. First, this paper tried

using Dropout. All models were given a default

Dropout value equal to 0.5, and then the paper tried

expanding the value to 0.8 or 0.9. This did reduce the

correctness of the training ensemble, but there was no

significant increase in the generalisation ability.

When using ResNet50, the training results

became even worse and did not increase the

correctness of the test set, so the only way to solve the

overfitting problem is to make the model as simple as

possible. Next, the MobileNet V2 model was used in

this study. Firstly, the amount of data is not very

large, so this study uses cross-validation for random

segmentation, which allows the model to learn more

Multiple GPUs-Based Distributed Learning for Classiﬁcation of Breast Cancer Images

335

features. The model is then trained on different

numbers of GPUs. When the number of GPUs is

equal to 4, the experiment doesn't have excellent

performance, which may be due to the improper

configuration of the model parallelisation or the

uneven distribution of the data and other problems.

The best results are obtained on two GPUs.

However, a problem common to all models is that

the best test set results tend to occur within 10 training

runs, and as the number of runs increases, the

correctness of the test set decreases. The training set

basically reaches 99% around 80 times. The test set

does not increase with training. This may also require

reducing the complexity of the model.

In conclusion, the use of cross-validation

significantly improves the test accuracy of

MobileNetV2, demonstrating its importance for

improving generalisation. ResNet18 is not yet

proficient enough, and a cleaner model is needed to

improve the accuracy. Furthermore, increasing the

number of GPUs did not always reduce training time

or improve accuracy, suggesting the need to optimise

multi-GPU training strategies.

4 CONCLUSION

The purpose of this study is to investigate whether

parallel computing on GPUs increases the

performance of the trained model. From the results, it

does not, because GPU training also needs to take into

account the transfer of data between GPUs, and the

integration time of the weights across GPUs increases

as the number of GPUs increases. The results do not

get better as the number of GPUs increases, and

overfitting reappears as the number of training

sessions increases. This model is characterised by the

fact that the data is very easy for the model to overfit,

and the increasing complexity of the model is not

friendly to the extraction of features from simple

images. Currently, there is no good classification for

data that is overfitted because of the simplicity of the

images. In the future, further study will try to find out

which part of the model is slowing down the training

process and try to improve the accuracy of the model

by using libraries that allow multi-GPU training or

algorithms that integrate the parameters of different

GPUs. Further study will also try to get a model that

can solve the problem of overfitting images easily.

REFERENCES

Boukaache, A., Benhassıne, N. E., & Boudjehem, D. 2019.

Breast cancer image classification using convolutional

neural networks (CNN) models. International Journal

of Informatics and Applied Mathematics, 6(2), 20-34.

Cao, Z., et al. 2019. An experimental study on breast lesion

detection and classification from ultrasound images

using deep learning architectures. BMC Medical

Imaging, 19, 1-9.

Guo, R., Lu, G., Qin, B., & Fei, B. 2018. Ultrasound

imaging technologies for breast cancer detection and

management: a review. Ultrasound in medicine &

biology, 44(1), 37-70.

Gøtzsche, P. C., & Jørgensen, K. J. 2013. Screening for

breast cancer with mammography. Cochrane database

of systematic reviews, (6).

He, K., et al. 2016. Deep residual learning for image

recognition. Proceedings of the IEEE Conference on

Computer Vision and Pattern Recognition.

Kaggle. 2021. Breast ultrasound images dataset. Retrieved

from https://www.kaggle.com/datasets/aryashah2k/bre

ast-ultrasound-images-dataset/code, last accessed time:

April 13, 2024

Ma, Y. 2020. Diagnosis of Benign and Malignant Breast

Lesions in Rats by MRI Plain Scan Combined with

Diffusion-Weighted Imaging. Revista Científica de la

Facultad de Ciencias Veterinarias, 30(5), 2464-2473.

Ouyang, Y., et al. 2019. Classification of benign and

malignant breast tumors using h-scan ultrasound

imaging. Diagnostics, 9(4), 182.

Qiu, Y., Chang, C. S., Yan, J. L., Ko, L., & Chang, T. S.

2019. Semantic segmentation of intracranial

hemorrhages in head CT scans. In 2019 IEEE 10th

International Conference on Software Engineering and

Service Science (ICSESS) (pp. 112-115). IEEE.

Qiu, Y., Wang, J., Jin, Z., Chen, H., Zhang, M., & Guo, L.

2022. Pose-guided matching based on deep learning for

assessing quality of action on rehabilitation

training. Biomedical Signal Processing and

Control, 72, 103323.

Sandler, M., Howard, A., Zhu, M., Zhmoginov, A., & Chen,

L. C. 2018. Mobilenetv2: Inverted residuals and linear

bottlenecks. In Proceedings of the IEEE conference on

computer vision and pattern recognition (pp. 4510-

4520).

Whang, J. S., et al. 2013. The causes of medical malpractice

suits against radiologists in the United States.

Radiology, 266(2), 548-554.

EMITI 2024 - International Conference on Engineering Management, Information Technology and Intelligence

336
