Study of IoT Layers Vulnerabilities and Attack Surfaces

Mr. Karan Tamboli

, Dr. Vanita Mane

, Mrs. Namita Pulgam

and Dr. Tabassum A. Maktum

Department of Computer Engineering, Ramrao Adik Institute of Technology,

Dr. D. Y. Patil Deemed to be University, Nerul, Navi Mumbai, India

Keywords: IoT, Security, Protocols, Cyber Security, Attacks.

Abstract: The rapid surge in the adoption of Internet of Things (IoT) devices and their use in many areas has

revolutionized the way humans interact with technology such as embedding connected devices into the diverse

aspects of our lives. However, this adoption has also opened up a portal for cyber security threats as IoT

security vulnerabilities and attack surfaces have become a critical concern. This study is towards the view of

landscape of IoT security, exploring the various vulnerabilities present in the IoT devices, networks and

overall ecosystems, examines the overall view of most pre-known vulnerabilities, such as weak

authentications, encryption, protocols and attacks con-ducted over IoT infrastructure such as Botnet, Man in

the Middle (MIM) and many more. The analysis of Layers and Protocols used in IoT and it’s summarizing

aims towards research, raise awareness and to promote the development of adequate security measures to

prevent the rapidly evolving IoT.

1 INTRODUCTION

The Internet of Things (IoT) which has seen massive

developments in past years is revolutionizing the way

we interact with the devices and the surrounding

environment. a network of physical components,

systems and the devices that are connected with each

other can communicate and share or exchange data

over the Internet is known as the Internet of Things

(IoT). The Automation and convenience could be

increased by IoT technology in many different

industries, including smart cities, transportation,

healthcare, and agriculture but despite the potential

for revolutionary advancements in technology, IoT

poses security risks and attack surfaces that

compromise the confidentiality, availability, and

integrity of data and services. This study aims to

explore the architecture of IoT systems, towards into

their various layers of an IoT and comprehensively

examines the vulnerabilities within these layers and

the protocols [1] that can potentially lead to attacks

and also user privacy threats [2] in evolving nature.

While studying the vulnerabilities with possible

https://orcid.org/0009-0008-7646-0448

https://orcid.org/0000-0002-4303-4089

https://orcid.org/0000-0001-7725-0997

https://orcid.org/0000-0002-8797-2894

attacks and the causes referenced to each of

significant layers of IoT and protocols [26] used and

conclusively propose the possible mitigation

measures to prevent and secure the IoT environment.

This comprehensive study is towards the expansive

landscape of IoT security, aiming to the multifaceted

vulnerabilities of IoT devices, networks and the

ecosystems they create. Goal of this exploration is to

highlight awareness and action. By deeper under-

standing of these rapidly evolving IoT landscape

vulnerabilities, this research aims to prompt the

development of robust, adaptive security measures.

The Wider layers of IoT has been explained

differently from basic Layered of IoT and the

Protocols[3] used to make this IoT system work and

their potential demerits or concern factors which

invokes a summarized form of input to deal with and

possible mitigation has been discussed in classified

form. The aim of study is to enhance awareness and

understanding of the security challenges in IoT

architecture among stakeholders, including

developers, policymakers and end-users. To identify

and categorize the various security vulnerabilities

present in IoT systems and assess their potential risks.

Tamboli, K., Mane, V., Pulgam, N. and Maktum, T.

Study of IoT Layers Vulnerabilities and Attack Surfaces.

DOI: 10.5220/0013264000004646

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 1st International Conference on Cognitive & Cloud Computing (IC3Com 2024), pages 76-84

ISBN: 978-989-758-739-9

By Examining the attack surfaces [18] related to these

vulnerabilities and the potential attack ways and

malicious methods and to improve the overall

security of IoT ecosystems and possibly to propose

the mitigation methods to IoT security vulnerabilities,

best practices and study possible strategies are being

mentioned.

The objective of this study is to review various

studies conducted before in IoT architecture layers

and security and form a detailed layered structure

from it and envelope an table with layers and their

protocols as well as Vulnerabilities in it, and suggest

possible mitigation Strategies in one shell from those.

2 LITERATURE SURVEY

In an examination while study of IoT Security an

author Abid [1] provide a comprehensive analysis of

the challenges linked with the IoT security including

the device and their constraints and also the absence

of standardized protocols in the vast landscape of

Security. While The Muhammad Guezzaz [2]

underscores the role of robust authentication

mechanisms and encryption techniques for miti-

gating of vulnerabilities within IoT ecosystems while

also discussing potential drawbacks such as resource

overheads etc. Author H.J Felcia [3] discusses about

traditional internet of things infrastructure and

proposing for the integration of innovative

countermeasures and mentioned both the merits and

limitations of existing solutions while the Selvakumar

Manickam [4] directs an attention to the security of

the MQTT protocol and highlighting resource

constraints as a barrier to its widespread adoption and

discussing potential trade-offs in security measures.

P. Goyal [5] discuss the scope by addressing security

threats across various layers of the IoT architecture,

discusses for the implementation of security solutions

like blockchain and machine learning and

acknowledging the complexity and potential

integration and challenges. Author Forhad et al. [6]

studies the security needs of IoT devices and about

the importance of approach to ad-dressing

vulnerabilities across various OSI layers along with

the challenges in the implementing those measures

effectively. T. Lestable [7] focuses on safeguarding

privacy within smart homes and the concerns over

manufacturers to prioritizing market share over

security measures but talks about necessitating the

development of robust security frameworks to protect

the user data and discussing potential trade-offs in

usability of IoT systems. A. Murali Rao [8] provides

the perspective on IoT's interconnected systems

underscoring the role of ongoing re-search efforts in

IoT systems against emerging threats and

vulnerabilities and also discussing the challenges in

rapid technological advancements. The authors [9]

reviews IoT security patterns and architectures,

identifying areas for improvement and inputs for

enhanced collaboration between academics and

industry stakeholders to secure the IoT security.

Authors O. Toutsop, S. Das and K. Kornegay [10]

studies into the threat modelling methodologies and

on potential security pitfalls within home-based IoT

devices and proposing strategies to enhance system

resilience and integrity, while also discussing

potential challenges in implementing and maintaining

such methodologies effectively. A. Majid [12]

discusses security prerequisites which are critical for

safeguarding Smart City IoT systems while utilizing

the STRIDE framework to identify and address

potential security vulnerabilities across the IoT

deployments and also discusses potential challenges

in implementing and maintaining such type of

measures effectively in IoT.

3 BACKGROUND

IoT (Internet of Things) architecture is a framework

that defines the structure and components of a system

designed to connect and manage a multiple node

objects and devices through the Internet. It contains

the hardware, software and communication protocols

necessary for data exchange and to control over the

internet-connected devices[5]. The Figure 1 Shows

Basic Architecture of IoT Ecosystem widely

discussed in section 3.1

Figure 1: IoT Architecture[15].

3.1 Basic Layers of IoT Architecture

Perception Layer is the lowest layer in the IoT

architecture and involves the physical ‘things” or

devices that collect data from the real world these

Study of IoT Layers Vulnerabilities and Attack Surfaces

devices can include sensors, actuators, cameras,

RFID tags and many more devices the sensors gather

data from the environment such as temperature,

humidity, light, motion etc and actuators are takes the

actions based on the data received, such as turning

on/off a light etc[9].

Network Layer is used for transmitting data

from the perception layer to higher layers of the IoT

system. It involves various communication protocols

and technologies[21][26] including wired (e.g.,

Ethernet) and wireless (e.g., Wi-Fi, Blue-tooth,

Zigbee, cellular) connectivity options an Gateways be

used for communication between different types of

devices and protocols[21].

Middleware Layer acts as an intermediary

between the network layer and the application layer

handles the tasks such as data processing, data

transformation, and the protocol translation the

Middleware include computing for real-time data

analysis and decision-making at the device level

itself.

Application Layer is the topmost layer where

IoT applications and services are developed and

deployed. The IoT applications can be from simple

data monitor-ing and reporting to analytics of

automation and control systems. An data from

sensors and devices are processed, analysis and used

to do actions or generate insights.

3.2 Wider Layers of IoT Architecture

Sensors and Devices Layer: Foundation of IoT

interfaces directly with the physical environment to

collect data from diverse sensors and devices.

Security vulnerabilities include weak authentication,

sensor spoofing and physical tampering, which

compromise data integrity and system functionality,

in recent due to weak authentication the Numerous

incidents in 2020 showed that Ring door-bells[30]

were hacked due to many users did not change the

default passwords which allows unauthorized access

to video feeds in another sensor spoofing in 2021

research demonstrated how Autopilot system[31]

could be tricked by spoofing sensor data while the key

protocols used such as MQTT [16][29] and CoAP.

Connectivity Layer: This layer used for

communication, channelling in be-tween IoT devices

and the network and has options like Wi-Fi, cellular

and other connectivity solutions while the Security

vulnerabilities in this layer are insecure network

protocols, device spoofing and eavesdropping which

poses risks to data confidentiality and system

security, examples in recent like Insecure Network

Protocol in 2020 vulnerabilities in the Z-Wave

protocol which is widely used by smart home devices

were exposed which allows attackers to intercept and

alter device communications in CVE-2019-9494 and

Device Spoofing vulnerability in Apple's Air-Drop to

devices and access person-al information reported in

CVE-2019-8615, the protocols like

HTTP/HTTPS[16] and DTLS for communication

[24] used.

Middleware Layer: Acts as an intermediary

manages data processing, protocol translation and

seamless communication between IoT devices and

applications. Vulnerabilities include insecure data

handling, message spoofing and unauthenticated

access, which compromise system integrity and

expose sensitive information in recent times the

Insecure Data Handling at 2021 a vulnerability was

identified in the implementation of the MQTT

protocol across several IoT plat-forms making it

possible to intercept and manipulate messages

reported in CVE-2019-11779 while the Message

Spoofing in 2020 the Philips Hue smart lights were

found to be susceptible to Zigbee protocol exploits to

allowing attackers to spoof messages and control the

lights in reported CVE-2020-6007 as the Key

protocols such as MQTT and AMQP used within the

middleware [19].

Application Layer: It is central to IoT which

processes and analyses data for insights. Security

vulnerabilities includes in this layer is data breaches,

vulnerabilities in machine learning algorithms and

inadequate access controls poses the risks to data

confidentiality and system reliability context to a

significant breach in 2021 involved Verkada security

cameras[32] which exposes live feeds from thousands

of cameras in various sensitive locations due to poor

application security and Vulnerabilities in Machine

Learning Algorithms[33] attacks on facial

recognition systems used by smart security cameras

were causing them to misidentify individuals the

Protocols like RESTful APIs and gRPC which

facilitate data exchange are used [26] [21].

Integration Layer: Used for seamless

integration of IoT data into existing IT systems and

external services across diverse platforms. The

Vulnerabilities include insecure APIs, data leaks and

inadequate data mapping, leading to data

IC3Com 2024 - International Conference on Cognitive & Cloud Computing

inconsistencies and breaches during integration in

recent times examples Inse-cure APIs was found that

Peloton's API[34] which exposed private user

information such as age, gender and location due to

inadequate authentication while the Data Leaks in

smart meter integrations with utility systems in the

UK led to the exposure of personal user data, the

Protocols like HTTP/HTTPS and Web-Socket

[23][28] which used.

Business Layer: It shows the IoT's impact on

operational efficiency, revenue generation and

innovation in business models Security, the

vulnerabilities include data monetization risks,

financial data security concerns and subscription

fraud which poses threats to revenue streams and

customer trust such as Financial Data Security In

2019, smart payment systems used in vending

machines were found to have vulnerabilities that

allowed unauthorized transactions and Subscription

Fraud in 2021 a vulnerability in the subscription

models of certain IoT services allowed attackers to

bypass payments and access premium features

without authorization while the protocols

HTTP/HTTPS and MQTT [5] [19] are used.

Security Layer: It is a foundational for IoT

security which implements measures like

authentication, authorization and data encryption to

protect system integrity and confidentiality. The

Vulnerabilities include weak authentication, lack of

data encryption and inadequate access controls,

exposing systems to un-authorized access and data

breaches Weak Authentication In 2020 leads to

vulnerabilities in authentication mechanisms of

several smart home hubs were al-lowing

unauthorized access and control over devices

reported in CVE-2020-16136 while due to the Lack

of Data Encryption In 2021, some IoT medical de-

vices were found to be transmitting patient data

without encryption exposes sensitive information, the

protocols used such as TLS/SSL and OAuth[17].

Management and Monitoring Layer: Used

as device monitoring, maintenance and firmware

updates to ensure the health and security of IoT

devices and systems. An Vulnerabilities include

insecure device management, unsecured firm-ware

updates and unauthorized access to IoT platforms,

compromising system security and functionality such

as Insecure Device Management attracts

vulnerabilities in the management platforms of

various smart camera systems allowed unauthorized

access and control and incident in Unsecured

Firmware Updates In 2021 a flaw in the firmware

update process of some IoT routers was discovered

which enabling attackers to install malicious

firmware. CVE-2020-28592 while protocols like

HTTP/HTTPS and MQTT [12] used.

User Interface Layer: This used as interfaces

for users to interact with IoT data, enhancing user

experience and decision-making the Security

vulnerabilities include insecure user authentication,

data exposure and cross-site scripting, posing risks to

user privacy and system integrity into the protocols

like HTTP/HTTPS and WebSockets enable secure

communication and real-time data exchange in user

interfaces [25].

Regulatory and Compliance Layer: This

layer addresses legal and aspects of IoT operations

ensuring compliance with data privacy regulations

and industry-specific standards while Vulnerabilities

include data privacy violations, non-compliance with

regulations and ethical concerns regarding data

collection and usage, examples such as Data Privacy

Violations In 2021 data privacy violation was

discovered when a smart toy company was found to

be collecting and storing children's data without

parental consent and violating COPPA regulations

and Non-Compliance with Regulations in 2020,

several smart medical devices were found to be non-

compliant with HIPAA, risking patient data exposure

while the most used protocols like HTTP/HTTPS[12]

and TLS/SSL [18].

4 KEY FINDINGS AND ANALYSIS

4.1 Concerns and Findings in Layers

and Protocols

In the IoT architecture, different layers utilize specific

protocols to enable communication, each facing

distinct privacy and security challenges. For in-

stance, at the a Sensors and Devices Layer MQTT and

CoAP are used where the main concern is

unauthorized access to sensitive sensor data as seen

in example of them, In the Connectivity Layer the

HTTP/HTTPS and DTLS protocols used for data data

transmission but concerns are eavesdropping and

privacy breaches. The Middleware Layer MQTT and

AMQP have risks like data tampering and

unauthorized access which can potentially

compromising data integrity. Likewise the

Application Layer where RESTful APIs and gRPC

Study of IoT Layers Vulnerabilities and Attack Surfaces

are used the vulnerabilities like SQL injection poses

a threats to stored user data security. The Integration

Layer utilizes protocols like HTTP/HTTPS and

WebSocket has risks such as data leak-age through

APIs or intercepted communication. In the Business

Layer where the HTTP/HTTPS and MQTT protocols

are used there are unauthorized access potentially

leads to the data theft and compromising sensitive

business information. while, the Security Layer uses

TLS/SSL and OAuth protocols face issues such as

weak authentication and unauthorized access so

safeguarding user data from breaches is important. In

the Management and Monitoring Layer where the

HTTP/HTTPS and MQTT protocols are used has

concerns about unauthorized access to device

management systems is important to use secure

device management practices, In the User Interface

Layer protocols are HTTP/HTTPS and Web-Sockets

which face the risks like unauthorized access and data

leakage which needs security measures to implanted

properly. In the end layer Regulatory and Compliance

Layer which uses HTTP/HTTPS and TLS/SSL

protocols needs compliance with data privacy

regulations to avoid legal consequences and protect

user data and the privacy.

The Table 1 outlines various attack surfaces

and types of attacks within the context of IoT

(Internet of Things) environments. This table consists

of view of the threat landscape, including the

potential impacts on both end users and the IoT

ecosystem, The study is being conducted from the

various segregated previous research and maps in

overall context to different layers we have discussed

in wider study of IoT layers.

In Table 1 we referenced vulnerabilities with

respect to specific protocols and layers of the IoT

architecture, security threats within this rapidly

evolving domain. The Attack Types gives view of

various types of attacks performed over the various

layers of IoT and their possible impact on end users

and on IoT environment and also the protocol which

is used in that specific layer or has vulnerability

which is used to perform such attack is referred with

specific protocol is discussed widely.

Table 1. Attack Types and Impact Table.

SR Attack Type Impact on End

User and IoT

Environment

Protocols

and Layers

(References)

1 Data

Tampering

End User:

Data integrity

com

romised.

MQTT

(Sensors and

IoT: Misleading

data.

Devices

Layer) [3][4]

2 Man-in-the-

Middle

(MitM)

End User:

Confidential

data exposure.

IoT: Data

compromise.

MQTT

(Sensors and

Devices

Layer),

WebSocket

(Integration

Layer)[3][5]

3 Unauthorized

Access

End User:

Privacy

invasion.

IoT:

Unauthorized

control.

CoAP

(Sensors and

Devices

Layer),

HTTP

(Connectivity

)

[5][9]

4 SQL Injection End User: Data

leaks.

IoT: Database

corruption.

RESTful

APIs

(Application

Layer)[5][6]

5 Data Leakage End User:

Privacy breach.

IoT: Sensitive

data ex

osure.

HTTP

(Integration

Layer),(User

Interface

)

[3][4]

6 Subscription

Fraud

End User:

Financial losses.

IoT: Revenue

loss.

MQTT

(Business

Layer)[3]

7 Firmware

Tampering

End User:

Device

malfunctions.

IoT: Security

com

romise.

MQTT

(Management

and

Monitoring

)

[5]

8 XSS Attacks End User:

Browser-based

attacks.

IoT: Web

interface

compromise.

WebSockets

(User

Interface

Layer)[5][6]

9 Regulatory

Non-

compliance

End User:

Privacy

violations.

IoT:Legal

ercussions.

TLS/SSL

(Regulatory

Compliance

Layer)[4][6]

10 Ethical

Violations

End User:

Ethical concerns.

IoT: Reputation

damage.

TLS/SSL

(Regulatory

Compliance

Layer) [3][4]

11 Denial of

Service (DoS)

End User:

Service

unavailability.

IoT: Network

con

estion.

MQTT

(Middleware

Layer)[3][4]

12 Device

Spoofing

End User:

Unauthorized

access.

IoT: Security

breach.

CoAP

(Sensors and

Devices

Layer), DTLS

(Connectivity

Layer)

IC3Com 2024 - International Conference on Cognitive & Cloud Computing

4.2 Importance and Need of

Implications of Data and Privacy in

the IoT

Compliance with the data privacy regulations boards

such as GDPR, CCPA and HIPAA is important, as

failure to comply with these regulations can result in

legal issues[17] and can leads to the fines and legal

actions against the organizations or development

companies, to build and maintain an user trust is

important and should be main objective for

businesses and institutions. The Instances such as the

data breaches can break the trust of user which leads

to non recover damage to organization's reputation

and credibility also the financial implications of data

breaches are significantly large which consist of

expenses like legal fees, compensations to affected

individuals and costs relating to recover the breach,

these kind of breaches can cause in large financial

losses for an organization.

The IoT often involves the collection of

sensitive data like personal and financial information

and health related data, Safeguarding this data isn't

just a legal problem but also a moral and ethical issues

with it. while ensuring safe operation with it is crucial

as security breaches can disturb regular operations

which are leads to downtime of system that can

impact on overall productivity and services which

affects an organization's efficiency also the

Unauthorized access of user data can be results in

identity theft, which has the severe consequences for

individuals, so protecting user data is critical to

prevent such instances.

Fail to comply with data privacy regulations

not just pose legal risks but it can also lead to

regulatory penalties and imposing financial issues on

organizations and potentially affecting their

sustainability in market, so to collaborate with the

above concerns, vulnerabilities and causes it needs to

look into a generalized solution to protect the attacks

caused in various layers of IoT, The Possible

Mitigation section gives a generalized view of

suggested measures for attack vector type and layers

and their protocols.

4.3 Protective Measures

Safeguarding the integrity of IoT landscapes needs a

multi-faced approach which incorporating in various

pre-known protective strategies. The below

mentioned measures consist generalized

authentication methods, data encryption practices and

access controls which aimed at pre-defences against

unauthorized access and potential data breaches.

Integrating these protective strategies throughout the

lifecycle of IoT projects establishes a sturdy security

foundation, mitigating vulnerabilities and enhancing

overall security standards across the IoT.

The Measures such as Implementing Strong

Authentication, Encrypting Data in Transit and at

Rest, Applying Access Controls and Role Based

Permissions, Regular Firmware and Software

Updates, Ensuring Network Security[22] with Fire-

walls and Regular Assessments, Prioritizing

Privacy[26] Considerations from Design Stage,

Educating Users and Employees on Security Best

Practices, Utilizing Established IoT Security

Frameworks and Guidelines, Securing Device

Lifecycle from Manufacturing to Disposal,

Promoting Ethical Data Collection and Usage,

Deploying Real-Time Monitoring for Suspicious

Activities, Developing and Testing Incident

Response Plans, Assessing Security Practices of IoT

Vendors, Providing User-Configurable Privacy[25]

Settings, Ensuring Regulatory Compliance with Data

Privacy Laws, Conducting Regular Security Audits

and Assessments, Implementing Secure End-of-Life

Processes for Devices, Segregating IoT Networks for

Minimized Impact, Adopting Zero Trust Security

Model, Collaborating with IoT Security Experts and

Industry Groups for Threat Awareness and Best

Practices.

4.4 Mitigation Strategies

The Mitigation strategies are essential for addressing

vulnerabilities and enhancing the security of IoT

systems across various layers and the protocols, the

user may adopt this security approaches and monitor

the IoT ecosystem to prevent from threats and

vulnerabilities.

Generalized suggested strategies are implementing

Message Integrity Checks for tampering detection,

Implementing Role-Based Access Control (RBAC)

for restricted user access, Implementing Robust

Authentication Mechanisms,[27] Encrypting Data in

Transit for traffic protection, Utilizing Public Key

Infrastructure (PKI) for secure authentication,

Implementing Rate Limiting to mitigate DoS at-

tacks[18], Enforcing Input Validation to prevent SQL

Study of IoT Layers Vulnerabilities and Attack Surfaces

injection and XSS attacks, Encrypting Sensitive Data

both in transit and at rest, Employing Secure

Communication Protocols[26] for data security,

Ensuring Digitally Signed Firmware Up-dates for

authenticity, Enforcing Strict Access Controls for

devices and applications, Maintaining Regular

Updates for machine learning models[20] and firm-

ware, Implementing API Security Best Practices for

secure APIs, Ensuring Secure WebSocket

Implementation for communication security,

Establishing Ethical Data Usage Guidelines for

responsible practices, Implementing Strong Data

Privacy Controls for user data protection, Conducting

Regulatory Compliance Checks for adherence to data

privacy regulations.

The layers such as Management and

Monitoring uses (HTTP,MQTT) like protocols poses

to Unauthorized Device Control manageable with

possible mitigation like Secure device management,

[24] an vulnerability such as Firmware Tampering,

Unauthorized Access can be mitigate if uses

mitigation strategies like Digitally signed firmware

updates, Strong access controls.[9][14]

A User Interface Layer uses protocols such as

(HTTP/HTTPS, WebSockets) is fronted towards the

attacks such as Unauthorized Access, Data Leakage

which can be mitigate using measures such as Strong

authentication, [24] Data encryption, Input

validation[9]

Regulatory Compliance layer which commonly

uses the (HTTP/HTTPS,TLS/SSL) layer may front

to attacks and breach things such as Data Breach,

Regulatory Non-compliance can be mitigate in some

extent using the strategies like Data privacy controls,

Regulatory compliance checks[12][27], Ethical

Violations Ethical data usage guidelines, Strong

authentication[12][24][27].

The Table 2 is a study of various attack types and

their associated concerns, including specific

protocols that may be vulnerable. The table is a

reference for understanding the landscape of

cybersecurity threats and it consists of suggestions of

possible solutions to security by mentioning

mitigation strategies for each attack type, these

strategies are for organizations and individuals with

the knowledge needed to safeguard their digital assets

and infrastructure effectively in once to focus on

various layers of IoT from past different researches

conducted.

Table 2. Layer (Protocol) wise Attack Vector table and

Possible Mitigation.

Layer Attack Vectors Possible

Mitigation

Strate

ies

Sensors and

Devices

(MQTT,

CoAP)

Data Tampering,

Man-in-the-

Middle

Message integrity

checks, RBAC,

Strong

authentication [14]

Unauthorized

access,

Device

tampering.

Strong

authentication,

Physical security

measures[9][14]

Connectivity

(HTTP /

HTTPS,

DTLS)

Man-in-the-

Middle,

Eavesdropping

Use DTLS for

secure

communication,

PKI for

authentication[8]

Packet Sniffing,

Device Spoofing

Traffic

encryption,[14]

Strong

authentication

mechanisms.

Middleware

(MQTT,

AMQP)

Data Tampering,

Man-in-the-

Middle

Message

integrity checks,

RBAC, Secure

communication

[14]

Message

Spoofing,

Unauthenticated

Access

Role-based

access control,

Rate

limiting[9][14]

Application

(RESTful APIs,

gRPC)

SQL Injection,

Data

Manipulation

Input validation,

Data encryption,

Strong

Authentication

[9][14]

Algorithm

Attacks,

Unauthorized

Access,

API

Exploitation,

Data Leakage

Access controls,

Regular updates,

Strong

authentication,

[8][14]

API security

measures, [14]

Data encryption,

Access controls

Integration

(HTTP /

HTTPS,

WebSocket)

Man-in-the-

Middle (MitM)

Secure

WebSocket

implementation,

Encryption[14]

[26]

Business

(HTTP /

HTTPS,

MQTT)

Data Theft,

Financial Data

Breaches

Data access

controls, [24]

Encryption,

Strong

authentication

IC3Com 2024 - International Conference on Cognitive & Cloud Computing

Subscription

Fraud

Strong user

authentication,

Access

controls[9][14]

Security

(TLS/SSL,

OAuth)

Data

Interception,

Brute Force

Attacks

Strong

authentication,

[4][9]

Data

encr

tion.[14]

4 CONCLUSIONS

The Internet of Things (IoT) has the potential to

revolutionize industries, offering an increase in

efficiency. However, this transformative power

comes with significant security challenges. This

comprehensive study shows depth layers of IoT

architecture, vulnerabilities, communication

protocols, potential threats and strategies to mitigate

these security challenges. Furthermore, IoT

architecture is multifaceted, consists of various

layers, each with its unique functions and security

considerations. In the study we have discussed about

the various layers of IoT architecture and their

demerits which leads to exploit protocols and attacks,

in which we have discussed and proposed mitigation

strategies to secure the future of IoT, users and

organizations must adopt protective measures. These

include implementing robust authentication,

encrypting data during transit and storage, enforcing

stringent access controls, ensuring regulatory

compliance with an emphasis on transparency and

user consent, prioritizing ethical data collection and

usage, educating users and employees about IoT

security risks, securing the future of IoT requires a

forward approach that encompasses technological

advancements, regulatory notes, ethical

considerations and proactive security measures. By

following these guidelines, users and organizations

can harness the immense potential of IoT while

safeguarding data privacy and security in an evolving

digital landscape

ACKNOWLEDGEMENTS

I express my deepest gratitude towards my guide and

mentor Dr. (Mrs.) Vanita Mane, Prof. Dr. Vidhate

Amarsinh (Head of the Department of Computer

Engineering), Dr. Mukesh D. Patil (Principal RAIT)

and the faculty members of the Department of

Computer Engineering at RAIT, Dr. DY Patil

University, Nerul, India for their inspiration and

cooperation to do this research study.

REFERENCES

Ahmed J. Hintaw1 , Selvakumar Manickam1 , Shankar

Karuppayah1 and Mohammed Faiz Aboalmaaly 2, “A

Brief Review on MQTT’s Security Issues within the

Internet of Things (IoT)”,Journal of Communications

Vol. 14, No. 6, June 2019.

Abid, Muhammad, “IoT Security Challenges and

Mitigations: An Introduction”, Re-searchgate, Oct

2022.

Mourade Azrour , 1 Jamal Mabrouki , 2 Azidine Guezzaz ,

3 and Ambrina Kanwal4 , “ Internet of Things Security:

Challenges and Key Issues”, Hindawi Security and

Com-munication Networks Volume 2021.

H.J. Felcia Bel, S. Sabeen, “A Survey on IoT Security:

Attacks, Challenges and Coun-termeasures ”,

Webology, Volume 19, Number 1, January, 2022.

Hassija, V. Chamola, V. Saxena, D. Jain, P. Goyal and B.

Sikdar, ”A Survey on IoT Se-curity: Application Areas,

Security Threats and Solution Architectures,” in IEEE

Ac-cess, vol. 7, pp. 82721-82743, 2019, doi:

10.1109/ACCESS.2019.2924045.

Rabbi, Md. Forhad et al. “Vulnerabilities to Internet of

Things and Current State of the Art of Security

Architecture.” (2019).

A. Aldahmani, B. Ouni, T. Lestable and M. Debbah,

”Cyber-Security of Embedded IoTs in Smart Homes:

Challenges, Requirements, Countermeasures and

Trends,” in IEEE Open Journal of Vehicular

Technology, vol. 4, pp. 281-292, 2023, doi:

10.1109/OJVT.2023.3234069.

A Murali M Rao Year: 2021 IoT: Security Issues and

Challenges ICIDSSD EAI DOI: 10.4108/eai.27-2-

2020.2303127 60

Rajmohan, T., Nguyen, P.H. & Ferry, N. A decade of

research on patterns and architec-tures for IoT security.

Cybersecurity 5, 2 (2022).

https://doi.org/10.1186/s42400- 021-00104-7

O. Toutsop, S. Das and K. Kornegay, ”Exploring The

Security Issues in HomeBased IoT Devices Through

Denial of Service Attacks,” 2021 IEEE SmartWorld,

Ubiquitous Intelligence Computing, Advanced Trusted

Computing, Scalable Computing Communi-cations,

Internet of People and Smart City Innovation (Smart-

World/SCALCOM/UIC/ATC/IOP/SCI), Atlanta, GA,

USA, 2021, pp. 407-415, doi:

10.1109/SWC50871.2021.00062.

Altulaihan, E.; Almaiah, M.A.; Aljughaiman, A.

Cybersecurity Threats, Countermeas-ures and

Mitigation Techniques on the IoT: Future Research

Directions. Electronics 2022, 11, 3330. https://

doi.org/10.3390/electronics11203330

Majid, A. (2023) Security and Privacy Concerns over IoT

Devices Attacks in Smart Cit-ies (2022). Journal of

Study of IoT Layers Vulnerabilities and Attack Surfaces

Computer and Communications, 11, 26-42.

https://doi.org/10.4236/jcc.2023.111003

Ankit Dhatrak, Anshuman Sarkar; ”Cyber Security Threats

and Vulnerabilities in IoT” IRJET;Volume: 07 Issue:

03 — Mar 2020.

N. Mishra and S. Pandya, ”Internet of Things Applications,

Security Challenges, At-tacks, Intrusion Detection and

Future Visions: A Systematic Review,” in IEEE

Access, vol. 9, pp. 59353-59377, 2021, doi:

10.1109/ACCESS.2021.3073408.

https://content.altexsoft.com/media/2020/08/iot-


Khan, Muhammad Almas Khattak, Muazzam Jan, Sana

Ullah Ahmad, Jawad Jamal, Sajjad Shaukat Shah,

Awais Pitropakis, Nikolaos Buchanan, William.

(2021). A Deep Learning-Based Intrusion Detection

System for MQTT Enabled IoT. Sensors. 21.

10.3390/s21217016.

Y. al-Hadharni and F. K. Hussain, “DDoS attacks in IoT

networks: A comprehensive systematic literature

review,” World Wide Web,Jan. 2021. 61

K. Doshi, Y. Yilmaz and S. Uludag, “Timely detection and

mitigation of stealthy DDoS attacks via IoT networks,”

IEEE Trans. Dependable Secure Comput., early access,

Jan. 8, 2021, doi: 10.1109/TDSC.2021.3049942.

S. E. Belanda, C. F. M. Foozy, A. Mustapha, P. S. S.

Palaniapan and Z. Abdullah, “De-tecting botnet attack

in Internet of Things (IoTs) environment by using

machine learn-ing technique: A review,” J. Crit. Rev.,

vol. 7, no. 8, 2020.

H. Wu, H. Han, X. Wang and S. Sun, “Research on artificial

intelligence enhancing In-ternet of Things security: A

survey,” IEEE Access, vol. 8, 2020.

A. Munshi, N. A. Alqarni and N. A. Almalki, “DDOS attack

on IoT devices,” in Proc. 3rd Int. Conf. Comput. Appl.

Inf. Secur. (ICCAIS), Mar. 2020,

C. V. Mart´ınez and B. Vogel-Heuser, “Towards industrial

intrusion prevention sys-tems: A concept and

implementation for reactive protection,” Appl. Sci., vol.

8, no. 12,2018.

R. Panigrahi, S. Borah, A. K. Bhoi and P. K. Mallick,

“Intrusion detection systems (IDS)—An overview with

a generalized framework,” Adv. Intell. Syst. Comput.,

vol. 1040

F. Meneghello, M. Calore, D. Zucchetto, M. Polese and A.

Zanella, “IoT: Internet of threats? A survey of practical

security vulnerabilities in real IoT devices,” IEEE

Internet Things J., vol. 6, no. 5, Oct. 2019.

P. Anand, Y. Singh, A. Selwal, M. Alazab, S. Tanwar and

N. Kumar, “IoT vulnerability assessment for

sustainable computing: Threats, current solutions and

open challenges,” IEEE Access, vol. 8, 2020.

Q.-D. Ngo, H.-T. Nguyen, L.-C. Nguyen and D.-H.

Nguyen, “A survey of IoT malware and detection

methods based on static features,” Opt. Commun.,

2020.

Carratù, M., Colace, F., Lorusso, A., Pietrosanto, A.,

Santaniello, D., Valentino, C. (2023). Data Mining

Techniques for Intrusion Detection on the Internet of

Things Field. International Conference on Cyber

Security, Privacy and Networking (ICSPN 2022).

ICSPN 2021Springer, Cham.

https://doi.org/10.1007/978-3-031-22018-0_1

Ling, Z., Hao, Z.J.: Intrusion detection using normalized

mutual information feature se-lection and parallel

quantum genetic algorithm. Int. J. Semant. Web Inf.

Syst. (IJSWIS) 18(1), 1-24 (2022).

Zarpelão, B.B., Miani, R.S., Kawakani, C.T., de Alvarenga,

S.C.: A survey of intrusion detection in internet of

things. J. Netw. Comput. Appl. 84 (2017).

https://doi.org/10.1016/j.jnca.2017.02.009.

ARNAR PÉTURSSON, Ethical Hacking of a Ring

Doorbell, https://www.diva-

portal.org/smash/get/diva2:1751192/FULLTEXT01.p

Xu, Yuan & Han, Xingshuo & Deng, Gelei & Li, Guanlin

& Liu, Yang & Li, Jiwei & Zhang, Tianwei. (2022).

SoK: Rethinking Sensor Spoofing Attacks against

Robotic Ve-hicles from a Systematic View.

Verkada Security Incident Report :

https://docs.verkada.com/docs/Security_Incident_Rep

ort_Version1.2.pdf

Vakhshiteh, Fatemeh & Nickabadi, Ahmad &

Ramachandra, Raghavendra. (2021). Adversarial

Attacks Against Face Recognition: A Comprehensive

Study. IEEE Access. PP. 1-1.

10.1109/ACCESS.2021.3092646.

Peloton's API exposes riders' private data.

https://www.securitymagazine.com/articles/95146-

pelotons-api-exposes-riders-private-data.

IC3Com 2024 - International Conference on Cognitive & Cloud Computing
