Evaluating the Quality of Class Diagrams Created by a Generative

AI: Findings, Guidelines and Automation Options

Christian Kop

University of Klagenfurt, Universitaetsstrasse 65 – 67, Klagenfurt, Austria

Keywords: Class Diagram, ChatGPT, PlantUML, Domain Modelling, Quality Checking.

Abstract: Working with a Generative AI such as ChatGPT to create conceptual models and particularly Class Diagrams

became very popular recently in the modelling community. Therefore, the objectives of this paper are the

following: It analyses the previous scientific work to summarize the findings about the quality of AI-generated

Class Diagrams. Own tests were carried out too. Based on these findings, the paper provides guidelines for

manual quality evaluation. It also discusses automation options for evaluating the quality.

1 INTRODUCTION

Working with a Generative AI became very popular

in the last two years. The driving factor was openAI,

which successfully made ChatGPT (ChatGPT, 2024)

available to the public.

Conceptual modelers also thought about the

benefits of such Generative AI tools for modelling.

They were interested to find scenarios in which such

a support can be used.

Therefore, the first objective of this paper is to

investigate what have already been found out in

previous work with regard to the quality of

automatically created conceptual models. This

literature study was supplemented by own tests in

order to get a better insight regarding the quality of

the created models.

Since possible quality issues in a model make it

necessary to establish guidelines for the evaluation of

a model, such guidelines are the second objective of

this article.

The third objective deals with the question, to

which extent, the quality of the model can be

automatically checked to minimize the manual effort.

In order to better address the above objectives, the

article specialises to several specific aspects:

ChatGPT was solely used to create Class Diagrams in

PlantUML (PlantUML, 2024) for domain modelling.

Prompt engineering was only carried out to the extent

that it can support the generation of such a Class

https://orcid.org/0000-0001-5800-458X

Diagram. Thus, the findings of this papers are only

applicable for these specialised aspects.

To address the objectives, the rest of the paper is

structured as follows. In Section 2 the related work is

listed. Section 3 firstly explains the specific aspects

of how ChatGPT was tested and then it describes the

findings regarding the quality of the AI-generated

Class Diagrams. In Section 4 guidelines for manual

evaluation are given on the basis of the findings.

Afterwards this section focuses on the possibilities as

well as limitations of automatic checking. The paper

is summarized in Section 5.

2 RELATED WORK

Papers already exist, investigating the use of

Generative AI for several aspects of the software

development life cycle. Since this paper is dedicated

on the support of Generative AI and Large Language

Models (LLM) to generate Class Diagrams for

domain modelling, the literature survey is confined to

analyse only literature related to this scope.

(Combemale, 2023) gave a brief overview of the

potentials of Generative AIs and the possibilities it

could have for the future of conceptual modelling.

Some authors focused on the performance of

Generative AI and particularly on ChatGPT to create

Class Diagrams or Entity Relationship Diagrams

(ERD) from textual descriptions.

150

Kop, C.

Evaluating the Quality of Class Diagrams Created by a Generative AI: Findings, Guidelines and Automation Options.

DOI: 10.5220/0013103000003896

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 13th International Conference on Model-Based Software and Systems Engineering (MODELSWARD 2025), pages 150-157

ISBN: 978-989-758-729-0; ISSN: 2184-4348

A detailed analysis of working with ChatGPT was

done in (Cámara, 2023). The authors listed 18

findings after testing ChatGPT to create UML Class

Diagrams. Some of these findings focused on prompt

engineering and how the possible size of the resulting

model can influence the quality of such a generated

model. In other findings, they explained what kind of

modelling language concepts the AI cannot create

properly. The authors also listed some types of errors,

which they recognized, when evaluating the

generated result.

In (Fill, 2023), the authors used textual

descriptions to test how ChatGPT creates an ERD, a

Business Process Diagram, a UML Class Diagram

and the HERAKLIT model. On a general level, they

discussed the system performance to generate these

specific types of models. They also explained what

kind of prompts they used to instruct ChatGPT how

to do this task.

In (Chen, 2023), the authors examined, to which

extend the ChatGPT versions GPT-3.5 and GPT-4.0

can support the automated generation of Class

Diagrams. Therefore, the authors compared the

results with reference models, which were created by

experts. The authors found four categories of how AI

generated model elements matches with model

elements in the reference models: a semantically

exact match, a semantically exact match but not of the

same type, a partial match and no match. Based on the

examinations, the authors concluded, that an

automated generation do not always produce a perfect

result. However, they found out, that the creation of

classes performed better than the creation of

attributes. The creation of attributes performed better

than the creation of relationships. They also achieved

better results with GPT-4.

Another paper (Wang, 2024) examined how well

ChatGPT performed to create three types of UML

diagrams, namely Use Case Diagrams, Class

Diagrams and Sequence Diagrams. They also came

to the conclusion that the Generative AI performed

differently for different types of modelling elements.

The system performed better in recognizing e.g.,

classes and use cases from respective textual

descriptions. However, the system struggled to

recognize relationships.

A set of contributions not only focused on one

Generative AI (e.g., ChatGPT) but compared its

effectiveness with that of other approaches, intended

for creating conceptual models.

In (Omar, 2023), the authors examined how good

ChatGPT can model entity types, relationship types

and multiplicities in ERD with respect to other

modelling tools that use natural language processing

or ontologies. The authors concluded that among all

the tools ChatGPT performed best but also stated, that

human experts should evaluate the generated result

A rule-based approach, a machine learning

approach feature engineered by one of the authors and

ChatGPT were compared in (Bragilovski, 2024). It

turned out that the two machine learning approaches

outperformed the rule-based approach, but none of

them was able to outperform a human expert.

In (Bozyigit, 2023), the authors compared their

own tool with ChatGPT. They came to the conclusion

that on average the own tool performed better.

However, the performance in generating relationships

was low in both tools.

Another type of contributions raised the question

about the role a Generative AI can play in the

educational context of conceptual modelling and

software engineering. For instance, in (Cámara, 2024)

and (Xue, 2024), the authors focused on the question,

how students perform in using ChatGPT. In both

studies, it turned out that Students who used ChatGPT

performed better. In (Xue, 2024) it was stated that the

difference was not significant. In another study

(Saito, 2023) ChatGPT was used to return the

difference between a modelling solution from

students with a given perfect solution. In (Morales,

2023), the authors tested ChatGPT in the task to

explain, if a generalisation relationship between two

notions is appropriate. After a couple of tests, the

authors concluded that ChatGPT cannot be used as an

advisory tool for this specific purpose. Finally, in

(Wang, 2023), the authors also discussed the issue of

plagiarism and how good it can be detected either by

course instructors or specialized AI tools.

The impact of Generative AIs in the software life

cycle were addressed in the following contributions.

Netz et. al, (Netz, 2024) presented an approach,

where ChatGPT transformed natural language text

into a domain specific modelling language for

building web applications. Although the results were

promising for the authors, they also stated that the

detected issues regarding semantic correctness should

be evaluated by a human expert.

In (Kanuka, 2023), ChatGPT was used to create

both a design model (UML Class Diagram) as well as

python code from a textual description. In addition, it

had to establish a traceability between these two

specifications. Regarding traceability, it took several

attempts interacting with the AI until it fulfilled their

expectations.

The use of LLMs for the development of model

and code variants in software product lines was

introduced in (Acher, 2023).

The use of ChatGPT in different early phases of

Evaluating the Quality of Class Diagrams Created by a Generative AI: Findings, Guidelines and Automation Options

151

software development, is presented in (Rouabhia,

2023). The AI created, requirements from an input

document. From these requirements, use cases were

generated. The use cases were in turn the starting

point for the creation of a Class Diagram.

In (Härer, 2023), the author developed a

modelling application, that interacts with Generative

AI APIs. The application then takes the generated

model specification and draws it in the required type

of diagram (e.g., Class Diagram).

Lastly two authors (Conrardy, 2024) (Buchmann,

2024), explored if drawings and sketches of Class

Diagrams can be transformed to a textual

specification of this Class Diagram.

To summarize, authors of previously published

related papers presented general findings like e.g., the

percentage of correctness for different types of model

elements. More detailed findings about some errors

were given in (Cámara, 2023). Overall, the conclusions

in these papers are, Generative AI and particularly

ChatGPT does a good job, however, the quality differs

with respect of the type of modelling element.

This literature analysis raised the question: Do

even more and particularly more concrete quality

issues exist that were not already mentioned?

Furthermore, no explicit guidelines were found in

literature that could guide modelers to evaluate the

quality of the AI-generated Class Diagram. Finally,

no discussion about automation options for this

evaluation task was found.

This paper is therefore dedicated to these open

questions.

3 FINDINGS

This section deals with the testing of ChatGPT for

generating Class Diagrams. It was tested both with

existing examples of input texts given in the literature

as well as new, own text examples.

3.1 General Considerations Regarding

the Tests

ChatGPT was used, because it was frequently used in

the literature analysed. During the interaction with the

AI, an explanation was given about the nature of the

expected output. Namely, it should be a domain

model and it should be a UML Class Diagram in

PlantUML notation. Therefore, the own textual

descriptions started with the following explanation:

“Create a domain model with a UML class diagram

for the text below and output it in PlantUML: ….. “.

Afterwards the text describing the content for the

class diagram followed. In the text examples found in

literature, the introductory and explanatory part of

these texts were adopted, if needed, such that the

purpose of the models and the desired Class Diagram

notation were expressed. No effort was spent to repeat

the interaction with the AI within one chat session by

giving additional text inputs in different, more

detailed variations in order to improve the received

output from the previous interaction. Here, it is

assumed that a modeller should always know what is

right and what is wrong in the AI-generated

conceptual model, before proceeding with any next

step. Thus, checking quality of the resulting Class

Diagram output is important anyway.

PlantUML was taken, since it was frequently used

in literature too. Furthermore, it is a text-based model

specification language that ChatGPT already knows.

Hence, it was assumed that creating a model should

be like creating code for ChatGPT. Although,

PlantUML has advantages, it has a drawback in the

context of domain modelling. PlantUML was

designed for modelling UML diagrams at each phase

of software development. In domain modelling, a lot

of these concepts and notations are not necessary.

However, apart from a few exceptions, many of those

concepts relevant for the implementation phase were

not created by the AI. Therefore, only a subset of

PlantUML had to be considered.

Once the models were created, the quality of these

models then were manually evaluated.

3.2 Test Results

The following was found about the important

concepts in the resulting model.

Classes: ChatGPT created classes from the

textual description but due to missing information in

the textual description, sometimes classes did not

have attributes. Below there is such an example:

class AcademicStaff {

}

In all the tests, classes were involved in

relationships (i.e., association, aggregation,

composition or generalization).

Enumeration Types: ChatGPT created

enumeration types properly, where it could recognize

it in the input text.

Attributes: ChatGPT created attributes that

represent relationships to another class. For example,

in a created class

Sensor the following attribute

appeared referencing to another class

Manufacturer:

manufacturer: Manufacturer

MODELSWARD 2025 - 13th International Conference on Model-Based Software and Systems Engineering

152

Here, the AI did not create an association, the usual

modelling element in domain modelling. This kind of

defect was already mentioned in (Cámara, 2023). In

the following, it will be referred to such an attribute

as a “referencing attribute” to distinguish it from an

attribute that describes the property of a class without

referencing to another class. The AI also sometimes

added attributes to classes that were not part of the

input text, since it used its acquired internal

knowledge.

Finally, if in the input text, names of attributes are

mentioned for different classes, then these attributes

also appear in these different classes in the resulting

model. This is generally okay, but it could also mean

that restructuring is necessary. Take for instance the

following excerpt from a created Class Diagram,

which a modeler can either take as it is or s/he can

think of alternative modelling decisions.

class Owner {

+String firstName

+String surname

+String address

+String telephone

+String email

}

class Customer {

+String firstName

+String surname

+String email

+String telephone

}

Types of Attributes: ChatGPT does a good job

in finding types of attributes even if these types are

not mentioned in the input text.

Associations: The Generative AI created

associations that consists of multiplicities. These

multiplicities however were not always correct.

Sometimes, also association names were missing. In

one case, the association name actually was a role

specification of a participating class. Sometimes, the

AI created associations with a navigation direction

Such associations with navigation direction were also

observed in (Cámara, 2023). In addition, and due to a

lack of sufficient information in the input text, they

did not have multiplicities and association names

either. Here are several examples of associations from

different created models:

WeatherStation --> Location

University "1" -- "0..*" Faculty

Resident "0..*" -- "many" Item

Customer "1" -- "0..*" Account : holder

Institute "1" -- "0..*" Employee :

employs

Sometimes, it also happened that the AI created

associations that were not given in the input text.

In one case, it also created two associations from

two different sentences, although these sentences

only described one association from the perspectives

of each involved class.

Aggregations and Compositions: In (Cámara,

2023) it was complained, that the composite notation

was placed illegally on both ends of a composition.

However, this could not be reproduced during the

tests for this paper. During the tests, it was recognized

that the AI did not generate the multiplicities for

special relationships. It even happened that a

composition was created although it is not needed and

it had an association name. Below, there is a

composition and an aggregation example from

different created models.

Property *-- Newspaper : AdvertisedIn

EBike o-- Battery

Generalizations: The AI often created correct

generalisations but sometimes, it found alternative

constructs for a generalization. It used association

names e.g.,

shippingAddress and

billingAddress to express the role of the class

Address participating in an association. But no

generalization between

shippingAddress and

billingAddress to Address was created.

In one test case it also wrongly generated an

association with a navigation direction and generated

the association name

inherits although a

generalization would be correct in this case. In

another test case, the generalization was expressed

with the keyword

extend.

In a case, it also happened that the AI wrongly

modelled a class as a super class although it was the

subclass in this generalization e.g.,

Lecturer <|-- ScientificEmployee

ScientificEmployee <|-- Employee

Association Classes: They are useful, if for

example, attributes do not belong to only one of the

participating classes. The attribute “mark” is a

common example in the domain of a student

information system, where students can manage, to

which courses they will enrol. A mark belongs neither

to a course nor to a student only. In (Cámara, 2023)

the authors found out, that an association class is not

generated properly. When carrying out the own tests,

it turned out that instead a compensation was created

in the test case of the student information system

scenario. The additional class

Enrolment was

created. This class contained the specific attribute

mark but the two classes Student and Course were

Evaluating the Quality of Class Diagrams Created by a Generative AI: Findings, Guidelines and Automation Options

153

not connected to each other. Instead, each of them

refered to

Enrolment via an association. Hence, the

created PlantUML output did not have the correct

concept and notation for specifying an association

class (e.g.,

(Student, Course) .. Enrolment).

Thus,

Enrolment was only treated as a normal class

in the output.

Methods: In general, methods should not appear

in a domain model focusing on relationships between

notions. However, if ChatGPT already generates

methods in some cases, then they can also be seen as

a chance to get more information about the resulting

model. Methods of a class have in common, that they

operate either on attributes of this class or on an

instance of another class, to which this class has an

association, aggregation relationship or composition

relationship respectively. An example for a method

specification that was created in a test case is:

+ getBranches(): List<Branch>

Therefore, it is worth to take a look at the

signature of the method (i.e., the name of the method

and the parameter of the method as well as the return

parameter of the method if available). If the signature

of the method indicates that the object of another class

is involved, then it can be checked if the class of the

method is directly connected with this other class via

an association, aggregation- or composition

relationship. Otherwise, it can be checked if attributes

appear in this class that are used in the method. The

name of a method is a hint sometimes. During the

tests with the input texts, it was sometimes recognized

that the AI created methods, but from its signature it

could not be concluded, which attributes are involved

if the method does not operate on instances of classes.

This however would be necessary, if the modeler

would like to be sure that the model is complete in

this respect.

4 MANUAL EVALUATION AND

AUTOMATION OPTIONS

Based on the results of the tests, this section provides

guidelines for manual evaluation as well as a

discussion of automation options.

4.1 Guidelines for Manual Evaluation

Although AI often delivers good modelling results,

problems can arise that are not present in manually

generated models. Therefore, a modeler has to

carefully check the resulting model.

Classes: For each class firstly, the modeler should

check if it is necessary in the model according to

his/her domain experience. Afterwards, it has to be

checked if it has attributes. It should be also tested if

a class is at least involved in one relationship

(association, aggregation, composition or

generalization) with another class.

Enumeration Types: Although, enumeration

types were created well, it is also good to check them.

For each enumeration type the modeler should check

if it is necessary. Afterwards, s/he should check if it

has sufficient and correct enumeration values.

Attributes and Types: For each attribute per

class firstly it has to be checked if it is not a

referencing attribute to another class that shall be

better modelled via an association, aggregation or

composition. If it is not a referencing attribute, it has

to be checked if it is relevant or not. If other classes

also have attributes with the same name, the structural

usefulness has to be checked. If a multiplicity is

specified for an attribute, the modeler should also

check if it is correct. Afterwards, the modeler should

check if the type of the attribute is correct.

Associations: For each association firstly, it has

to be checked, if it is necessary in the model and it is

not redundant with respect to another association,

aggregation or composition connecting the same pair

of participating classes. Afterwards, the modeler

should check if the multiplicities are correct, if it does

have an adequate association name and if a created

navigation direction is really necessary.

Aggregations and compositions: For each

aggregation and composition respectively, firstly, it

has to be checked if it is necessary in the model and

it is not redundant with respect to another association,

aggregation or composition connecting the same pair

of participating classes. Afterwards, it has to be

checked if it does have the aggregate/composite

notation only on one end and it does have correct

multiplicities. In case of a composition, it has to be

checked, if the multiplicity at the composite end is

“1”. It should be also evaluated if navigation

directions are necessary.

Generalizations: For each generalization, firstly,

the modeler should check if it is necessary in the

model and is not redundant with respect to another

generalization connecting the same pair of

participating classes. Afterwards, it should be

checked if the role of the super class and sub class is

correctly assigned to the participating classes.

Association Classes: The modeler should evaluate

the model regarding association classes. S/he should

check, if association classes are missing or classes are

wrongly generated as a compensation for an

MODELSWARD 2025 - 13th International Conference on Model-Based Software and Systems Engineering

154

association class. In addition, it has to be checked, if an

attribute is assigned to only one participating class

although it should be part of an association class.

Methods: For each method the modeler should

consider, that it can provide further information. A

method should therefore be checked to determine if it

uses the attributes of its class or instances of another

class. For a method that uses the attributes, it has to

be clarified, which attributes are used and if they

already appear in the class. If instances of another

class are used in a method, then it has to be checked,

if the class of the method also has a direct relationship

(i.e., via an association, aggregation relationship or a

composition relationship) to that other class.

Missing Model Elements: Finally, once all the

elements listed in the created model are evaluated, the

modeler should check if any further necessary

information (e.g., additional classes, enumeration

types, attributes associations, aggregations,

compositions, generalizations, association classes) is

still missing.

4.2 Automation Options

This section discusses, to which extend a modeler can

get tool support to find issues. Both, issues regarding

semantic quality as well as syntactic quality

(Krogstie, 2002) are discussed. According to Krogstie

(Krogstie, 2002), particularly semantic quality is

inter-subjective, i.e., agreed upon the social actors. It

also has to be noted, that many issues are subjective

with respect to the intention of a modeler. What could

be a defect for one modeler could be correct for

another one. The main task of a tool offering

automatic support, is therefore only to draw the

attention of the modeller to a specific section of the

model, where an issue might exist. It is the decision

of the modeler if this is a defect that has to be

corrected. As a proof of concepts, a prototype was

developed. This prototype covers the automation

options explained here.

Classes: Testing if a class might be

underspecified can give the modeler a hint that there

is missing information. Once each class with its

attributes is collected in an internal data structure, it

can be computed, if the class has no attributes, or the

number of its attributes is under a manually defined

threshold. Setting an adequate threshold of course

needs the experience of a modeler.

A class is also underspecified if it is not involved

in any relationship, i.e., if the difference between the

set of all classes and the set of classes participating in

a relationship is not empty, then the elements in the

non-empty set are classes with no relationships.

Enumeration Type: An issue can appear in an

enumeration type, if it does not have sufficient

enumeration values. In general, an enumeration type

should have at least two values, as a general

threshold. But if it has more than two enumeration

values, it remains to the modeler’s experience if s/he

agrees with this number.

Attributes and Types: An attribute can be

automatically tested, if they belong to the category of

referencing attributes. The simplest case is an

attribute name in singular form, which is identical to

a class name other than the class name, in which the

attribute appears. For transforming the plural form of

an attribute’s name to its singular form, though, rules

or a digital dictionary support have to be used. It can

also be tested if the name without a certain suffix

(e.g., “ID”) matches with the name of a class. Lastly,

if the name of the type in the attribute’s specification

is identical to another class, then this also supports the

detection of referencing attributes.

It can also be automatically detected, if an

attribute’s name is listed in multiple classes. If this is

detected, this could indicate that restructuring could

be necessary. As already mentioned in Section 3.2

however, it depends on the context and thus the

design decision of the modeler. Here, an automatic

support only gives the information that it exists.

No automatic support can be given to check, if the

type of an attribute is appropriately chosen. This has

to be done manually by the modeler.

Associations: The check for incompleteness itself

does not need any contextual information and can be

done automatically. An association name and

multiplicities are either available or not. Navigation

directions also can be detected easily by just looking

in association specifications, if they exist.

However, context plays a dominant role in

deciding whether a multiplicity is right or wrong (e.g.,

“*”, is “1..*” or even “1” the correct solution).

Therefore, it cannot be automatically tested, if the

multiplicities are correct. The same holds for

association names. Whether an association should

have an association name or whether existing names

are correct remains the decision of the modeler.

Wrong association names might be detected, if a tool

also manages a list of association names that are

wrong in many contexts but this gives no clue if a

name is wrong or correct in a given context.

Aggregations and Compositions: A wrong

notation as mentioned in (Cámara, 2023) – i.e.,

aggregate / composite symbol on both ends - can be

automatically filtered out as a syntactical error.

Missing multiplicities can also be detected

automatically. Apart from one exception, it is once

Evaluating the Quality of Class Diagrams Created by a Generative AI: Findings, Guidelines and Automation Options

155

again impossible to automatically distinguish

between wrong and correct multiplicities in

aggregations and compositions. The only exception is

the multiplicity at the composite end of a

composition. This multiplicity must be always

“1”

end hence such a violation can be automatically

detected.

It is the decision of the designer, if a name should

be given for an aggregation or composition. Usually,

composition and aggregations already have a

semantic, hence a name is an add-on and it should not

be the wrong name. Therefore, the tool can inform the

modeler about named aggregations and compositions.

Showing such names to the modeler gives him/her the

opportunity to decide if a name for the aggregation or

composition is adequate.

Generalizations: It is difficult to automatically

detect the relevance of a generalisation and

correctness of a generalization specification. But in

two situations, a tool can at least tell the modeler to

take a look.

Regarding relevance of a generalization, let’s

suppose a class G has several subclasses e.g., S1, S2,

S3 and none of these subclasses have attributes as

well as relationships to other classes. Showing such a

case to the modeler gives him/her the chance to think

if restructuring is necessary or not. Both is possible,

it might be correct but it could also be an indicator for

missing information.

Regarding correctness of a generalization

specification, suppose a situation, where the name of

one class is also a substring of the other involved class

name (e.g.,

ScientificEmployee, Employee). In

this example the class

Employee is the superclass in

the generalization. If, however, the generalisation

relationship does not reflect this, but the

generalization arrow is pointing from

Employee to

ScientificEmployee instead, then this

generalisation specification is wrong. This can be

easily detected by comparing the two strings.

Since issues in generalization relationships can

only be recognized under certain conditions, the

modelling expert is particularly in demand here.

Redundant Relationships (associations,

aggregations, compositions, generalizations): An

automatic support can at least inform the modeler that

a pair of classes appears in more than one

relationship. Once again, it depends on the context if

the same pair of classes should really be connected to

each other in more than one association. The modeler

with his/her knowledge should decide if a redundancy

exist in the model. However, it is more unlikely that

the same pair of classes is part of more than one

composition, aggregation or a combination of

composition, aggregation and association. It is also

unlikely that the same pair of classes is part of more

than one generalization relationship.

Association Classes: The evaluation if an

association class exists, also strongly depends on the

context and cannot be done without the experience of

the modeler. If the AI cannot create such a class

properly, then automatic support is only possible, if

the Generative AI uses a specific strategy to

compensate an association class. Particularly, if a

class is created, whose name is a nominalization of a

verb or an adjective. Since some nominalizations

have suffixes like e.g., “ing”, “ment” etc., all classes

could be inspected if their names contain one of those

suffixes. These classes are then shown to modeller.

Admittedly, this is only a minimal support, and does

not guarantee successful detection of association

classes. Neither it can be expected that the AI creates

association classes in this way nor it can be expected,

that a class with a specific suffix is always an

association class.

Methods: As already explained, the signature of

methods can be used to find out, if attributes or

relationships to classes are missing. The idea here is

to analyse the signature in order to find words or

tokens in the method’s name or in a non-empty

parameter list that matches with existing attributes of

the method’s class or other class names. The modeller

has to be informed if this analysis fails. S/he then has

to decide if information is missing. This automatic

support has limitations, since there is no commitment

at all, that the name of a method always has to match

with an attribute’s name or the method has

parameters.

5 CONCLUSION

This paper presented guidelines to evaluate the

quality of AI-generated Class Diagrams. The paper

also discussed if a modeler can be supported in these

evaluation tasks. It was argued that automation is only

possible in co-operation with the modeller. A tool can

just encourage the modeler to have a look at a created

model. It is then up to the modeler do make the right

decision.

Currently, only the performance of ChatGPT for

generating a Class Diagram was tested. Future work

could focus on other Generative AI tools and on other

modelling languages. The presented analysis of the

output are qualitative observations (i.e., what kind of

issues appear). A more extensive study could focus

on quantitative factors like the frequencies of certain

issues in the created models.

MODELSWARD 2025 - 13th International Conference on Model-Based Software and Systems Engineering

156

REFERENCES

Acher, M., Martinez, J. (2023). Generative AI for

Reengineering Variants into Software Product Lines:

An Experience Report, In SPLC '23: Proceedings of the

27th ACM International Systems and Software Product

Line Conference, pp. 57 – 66, https://doi.org/

10.1145/3579028.3609016.

Bozyigit, F., Bardakci, T., Khalilipour, A., Challenger, M.,

Ramackers, G., Babur, Ö, Chaudron, M., R., V. (2023)

Generating domain models from natural language text

using NLP: a benchmark dataset and experimental

comparison of tools, Software and Systems Modeling,

https://doi.org/10.1007/s10270-024-01176-y.

Buchmann, T., Fraas, J.. (2024) AI-Based Recognition of

Sketched Class Diagrams. In Proceedings of the 12th

International Conference on Model-Based Software

and Systems Engineering (MODELSWARD 2024), pp.

227-234

Bragilovski, M., van Can, A. T., Dalpiaz, F., Sturm, A.

(2024) Deriving Domain Models from User Stories:

Human vs. Machines. In IEEE 32nd International

Requirements Engineering Conference (RE), IEEE

Xplore, pp. 1 - 12, DOI: 10.1109/RE59067.2024.00014-

Cámara, J., Troya, J., Burguen

o, Vallecillo, A., (2023). On

the assessment of generative AI in modeling tasks: an

experience report with ChatGPT and UML. In Software

and Systems Modeling Vol. 22, pp. 781 – 793,

https://doi.org/10.1007/s10270-023-01105-5.

Cámara, J., Troya, J., Montes-Torres, J., Jaime, F. J. (2024).

Generative AI in the Software Modeling Classroom: An

Experience Report with ChatGPT and UML. In IEEE

Software, vol 41 (6) pp. 1 – 10.

ChatGPT (2024). https://openai.com/chatgpt/ (last access:

Dec. 2024)

Chen, K., Yang, Y., Chen, B., López, J., H., A. (2023).

Automated Domain Modeling with Large Language

Models: A Comparative Study. In 26th International

Conference on Model Driven Engineering Languages

and Systems (MODELS), IEEE Xplore, pp. 162 – 172.

Combemale, B., Gray, J., Rumpe, B. (2023). ChatGPT in

software modeling. In Software and Systems Modeling.

https://doi.org/10.1007/s10270-023-01106-4.

Conrardy, A., Cabot, J. (2024). From Image to UML: First

Results of Image-based UML Diagram Generation

Using LLMs. In arxiv.org, arXiv:2404.11376v1.

Fill, H.-G., Fettke, P., Köpke, J. (2023), Conceptual

Modeling and Large Language Models: Impressions

From First Experiments With ChatGPT. In Enterprise

Modelling and Information Systems Architectures, Vol.

18, No. 3, pp. 1 – 15, DOI:10.1847/emisa.18,

Härer, F. (2023). Conceptual model interpreter for Large

Language Models. In arxiv.org, arXiv:2311.07605.

Kanuka, H., Koreki, G., Soga, Ryo, Nishikawa, K. (2023).

Exploring the ChatGPT Approach for Bidirectional

Traceability Problem between Design Models and

Code. In arxiv.org, arXiv:2309.14992v2.

Krogstie, J., (2002). A Semiotic Approach to Quality in

Requirements Specifications. In Organizational

Semiotics. IFIP, vol 94. Springer, pp 231–249

Morales, S., Planas, E., Clariso, R., Gogolla, M., (2023).

Generative AI in Model-Driven Software Engineering

Education: Friend or Foe? In International Conference

on Model Driven Engineering Languages and Systems

Companion (MODELS-C), IEEE Xplore, pp. 110 – 113.

Netz, L., Michael, J., Rumpe, B. (2024). From Natural

Language to Web Applications: Using Large Language

Models for Model-Driven Software Engineering. In

Modellierung 2024, Lecture Notes in Informatics

(LNI), pp. 179 – 195.

Omar M.A., (2023). Measurement of ChatGPT

Performance in Mapping Natural Language

Specification into an Entity Relationship Diagram. In

Proceedings of the 2023 IEEE 11th International

Conference on Systems and Control, IEEE Xplore, pp

530 – 535.

PlantUML, (2024). https://plantuml.com/en/, (last access:

Dec. 2024)

Rouabhia, D., Hadjadj, I. (2023). AI as a Co-Engineer: A

Case Study of ChatGPT in Software Lifecycle. In

Research Square, pp 1 – 86,

https://doi.org/10.21203/rs.3.rs-3809973/v1.

Saito, D., Minagawa, T., Hisazumi, K. (2023). Automated

Review Tool for Educational Models Utilizing

Generative AI. In Asia Pacific Conference on Robot IoT

System Development and Platform (APRIS2023), pp.

50 – 51.

Wang, B., Wang, C., Liang, P., Li, B., Zeng, C. (2024) How

LLMs Aid in UML Modeling: An Exploratory Study

with Novice Analysts. In arxiv.org,

arXiv:2404.17739v1

Wang, K., Akins, S., Mohammed, A., Lawrence, R. (2023).

Student Mastery or AI Deception? Analyzing

ChatGPT’s Assessment Proficiency and Evaluating

Detection Strategies. In arXiv.org, arXiv:2311.

16292v1.

Xue, Y., Chen, H., Bai, G. R., Tairas, R., Huang, Y. (2024)-

Does ChatGPT Help With Introductory Programming?

An Experiment of Students Using ChatGPT in CS1. In

46th International Conference on Software

Engineering: Software Engineering Education and

Training (ICSESEET), pp. 331 – 341, https://doi.org/

10.1145/3639474.3640076.

Evaluating the Quality of Class Diagrams Created by a Generative AI: Findings, Guidelines and Automation Options

157
