VBSF: A Visual-Based Spam Filtering Technique for Obfuscated Emails
Ali Hossary
a
and Stefano Tomasin
b
Dept. of Information Engineering (DEI), University of Padova, Italy
Keywords:
Spam Email Detection, Hidden Text Salting, Obfuscated Words, Email Rendering, Machine Learning, Optical
Character Recognition (OCR) Convolutional Neural Networks (CNN) and Ensemble Learning.
Abstract:
Recent spam email techniques exploit visual effects in text messages, such as poisoning text, obfuscating
words, and hidden text salting techniques. These effects were able to evade spam detection techniques based
on the text. In this paper, we overcome this limitation by introducing a novel visual-based spam detection
architecture, denoted as visual based spam filter (VBSF). The multi-step process mimics the human eye’s
natural way of processing visual information, automatically rendering incoming emails and capturing their
content as it appears on a user screen. Then, two different processing pipelines are applied in parallel. The
first pipeline pertains to the perceived textual content, as it includes optical character recognition (OCR) to
extract rendered textual content, followed by na
¨
ıve Bayes (NB) and decision tree (DT) content classifiers. The
second pipeline focuses on the appearance of the email, as it analyzes and classifies the images of rendered
emails through a specific convolutional neural network. Lastly, a meta classifier integrates text- and image-
based classifier outputs exploiting the stacking ensemble learning method. The performance of the proposed
VBSF is assessed, showing that It achieves an accuracy of more than 98%, which is higher than the compared
existing techniques on the designed dataset.
1 INTRODUCTION
Emails have witnessed an overwhelming global vol-
ume exceeding 200 billion messages daily. However,
a staggering 80-90% of this flow comprises spam,
which both annoys users and fuels malicious activi-
ties like phishing, fraud, and malware dissemination.
Conventional anti-spam methods like blacklists and
heuristics struggle against this onslaught, prompting
the development of scalable and adaptive techniques.
Machine learning is the leading approach, with state-
of-the-art classifiers achieving over 90% accuracy.
The prominence of machine learning in spam defense
is driven by factors such as the massive scale of global
spam, evolving spam tactics, and ongoing algorithmic
advancements tailored for text analysis. Moreover,
the exponential growth in computational resources
enhances the effectiveness of spam filtering models.
Among advanced spam techniques, visual effects
on text messages are particularly challenging for
spam detectors, since they defeat text-based detec-
tion systems. Such approaches go under the names
poisoning text, obfuscated words, and hidden salt-
a
https://orcid.org/0009-0002-9227-2662
b
https://orcid.org/0000-0003-3253-6793
ing (Bergholz et al., 2008). Recently, (Sokolov et al.,
2020) has shown that spam detection techniques can
be evaded by replacing some characters with others
that look very similar but come from a different alpha-
bet. For a review of hidden salting tricks see (J
´
a
˜
nez-
Martino et al., 2023).
This paper proposes new techniques to detect
spam messages, including hidden salting and other
visual attack strategies. The introduced solution is a
VBSF and it emulates the human visual perception of
emails, thus aiming at reading the text as perceived
by the human reader. Therefore, visual tricks such as
fainted colors and small text used to hide part of the
text and letting the reader see hidden spam content
will also affect our detection technique that will be
able to see the spam content and predict it exploiting
multiple diverse classifiers.
The findings underscore the importance of model
composition and the value of incorporating diverse
classifiers to achieve superior results. Our enhanced
VBSF represents a promising advancement in predic-
tive modeling, offering a pathway for further refine-
ment and optimization of our approach. The resulting
decision-making mechanism is robust and provides a
final classification accuracy of the meta-classifier sur-
Hossary, A. and Tomasin, S.
VBSF: A Visual-Based Spam Filtering Technique for Obfuscated Emails.
DOI: 10.5220/0013133700003899
Paper published under CC license (CC BY-NC-ND 4.0)
In Proceedings of the 11th International Conference on Information Systems Security and Privacy (ICISSP 2025) - Volume 2, pages 299-305
ISBN: 978-989-758-735-1; ISSN: 2184-4356
Proceedings Copyright © 2025 by SCITEPRESS – Science and Technology Publications, Lda.
299

passing the accuracy of all the base models, exceeding
98%.
The rest of this paper is organized as follows. In
Section II we review the existing literature with a fo-
cus on works related to our proposed VBSF solution.
Section III presents the VBSF technique in detail. We
then design its implementation in Section III. The per-
formance results of the proposed solution and existing
approaches are presented and discussed in Section V.
Lastly, Section VI provides the main conclusions of
this work.
2 RELATED WORK
Several works have addressed the problem of detect-
ing spam when hidden text salting is used. In many
cases, machine learning techniques are employed, as
they are well known to be effective in several security-
related applications (Shaukat et al., 2020).
In (Moens et al., 2010), the rendering process is
tapped into. The rendering commands are analyzed to
identify sections of the source text (plaintext) that will
be invisible to human readers, based on criteria such
as text character and background colors, font size,
and overlapping characters. Furthermore, the visi-
ble text (cover text) is reconstructed from rendering
commands, and the character reading order is identi-
fied, which may differ from the rendering order. In
our study, we also render emails as images to ana-
lyze how they are perceived by the human eye. In-
stead of exploiting rendering commands, we render
the whole content and then operate on the rendered
image, thus being more flexible and independent of
the specific rendering process. Moreover, we exploit
powerful tools such as OCR and image analysis by
neural networks that have proven to be effective in
detection processes.
In (Nam et al., 2022) it has been proposed to use
three sub-models to extract three features from im-
ages. In particular, two sub-models for text process-
ing extract topic-based features (to identify the main
subject of the message) and word-embedding-based
features (to capture the meaning and relationships be-
tween words in the message) using the text contained
in the images extracted by OCR. Then, a convolution-
based sub-model extracts convolution-based features
from images. Lastly, text and image features ex-
tracted from each sub-model are input into the clas-
sifier model that decides on the spam nature of the
email. Thus, (Nam et al., 2022) proposes a technique
for classifying spam images using image and text fea-
tures extracted from images, which is related to our
approach. We use instead three classifiers, each with
its feature extraction method, followed by a stacking
meta classifier to consolidate the predictions of sub-
models, additionally. Moreover, the focus of (Nam
et al., 2022) was on spam images included in emails,
while we generated the images from the incoming
emails.
In (Biggio et al., 2007) the focus is on detecting
spam techniques that hide the real content of the im-
age. The proposed approach aims at identifying a
specific characteristic of spam images with embedded
text - the presence of content obscuring techniques.
The underlying rationale is that images containing
embedded text, which are deliberately obscured to
render OCR ineffective, are likely to be spam.
In (Naiemi et al., 2019), a method based on the
histogram of oriented gradients, HOG, and a support
vector machine (SVM) has been used for OCR in im-
ages contained in emails. One of the limitations faced
by the HOG feature extraction method is its lack of
resistance against character variations on scales and
translations. The proposed enhanced HOG feature ex-
traction method has been used so that the OCR sys-
tem of spam has been enhanced by using the HOG
feature extraction method in such a way to be both
resistant against the character variations on scale and
translation and to be computationally cost-effective.
Our work focuses on text emails with hidden salting
tricks, rather than on emails containing spam images.
Other approaches for spam detection using ma-
chine learning approaches include a bio-inspired tech-
nique (Gibson et al., 2020), such as particle swarm
optimizations and genetic algorithms which are used
to optimize the performance of classifiers: it turned
out that multinomial NB with the genetic algorithm
outperforms the other. Still, no visual tricks were con-
sidered in (Gibson et al., 2020).
In (Karim et al., 2021), an unsupervised frame-
work for spam detection is proposed, that resorts
to a clustering approach including multiple algo-
rithms. A suitable feature reduction is applied to ob-
tain seven features that represent impactful analyti-
cal email characteristics from a multiangular point of
view. However, this solution primarily uses the email
content (body) and the subject header and does not
properly deal with visual tricks.
In our work, we also apply a convolutional neu-
ral network (CNN) directly to an image rendering an
email. Such an approach has been adopted in other
contexts (not related to spam detection). For exam-
ple, in (Rizky et al., 2023) a CNN is used to recognize
text in images. Several modifications of the images
have been investigated and the best model turned out
to be the VGG-16 architecture along with specific im-
age transformations. The model architecture used in
ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy
300

Figure 1: The proposed VBSF solution.
this study could be a valuable resource for developing
future text detection systems.
3 VISUAL-BASED FILTERING
TECHNIQUE
Spammers often use hyper text markup language
(HTML) techniques such as hidden or invisible text,
HTML comments, or misleading formatting to trick
traditional text-based classifiers. At the same time, to
convey the spam message, such tricks should provide
a final image of the email that is clearly readable to
the human reader. The basic idea of VBSF is to first
render the email as an image, then perform spam de-
tection on the image: this enables the spam detector
to operate on the same input as provided to the hu-
man reader. This approach enhances the classifier’s
ability to detect spam accurately, as it considers the
visual presentation of the email, uncovering potential
malicious elements that might be hidden in the HTML
code.
In detail, first, the email is rendered as an im-
age: this includes interpreting HTML commands (on
fonts, colors, and page layout), adding attached im-
ages, etc. Then, two spam detection techniques are
applied in parallel on the obtained image, each de-
noted as a pipeline. The first pipeline is based on the
perceived content, obtained through an OCR: the ex-
tracted text content is then fed to a content-based clas-
sification system based on NB and DT classifiers. The
latter pipeline is based on the visual appearance and
classifies images of the email content by using aCNN.
Lastly, a meta classifier combines the outputs of
both text- and image-based classifiers by a stacking
ensemble learning method. Through experiments, we
observed a remarkable increase in testing accuracy.
Integrating the DT classifier proved to be particularly
impactful, contributing to a significant enhancement
in predictive performance.
Fig. 1 shows the workflow of the proposed VBSF,
which is composed of the following elements:
• Rendering of the email as an image
• First pipeline: text extraction using OCR, fol-
lowed by content-based filters
• Second pipeline: image-based classifier (by a
CNN model), applied to the email image
• Meta classifier, utilizing stacking ensemble
method, as an ensemble learning technique
Each element of the VBSF solution is described in
detail below.
3.1 Email Rendering
The email rendering step generates the image of the
email, as it would be shown to the end human reader.
This includes the formatting of text and page accord-
ing to the HTML format, the inclusion of images,
etc. Hidden salting tricks are also exploiting such for-
matting parts so that once the email is shown to the
reader, it shows content (such as sentences or images)
that are hard to identify in the original HTML docu-
ment (Bergholz et al., 2008). The rendering can be
easily obtained with one of the several tools that al-
low the conversion of an HTML file into an image (as
it was rendered in a browser or email reader). The
obtained image is then processed in the forthcoming
steps.
VBSF: A Visual-Based Spam Filtering Technique for Obfuscated Emails
301

3.2 First Pipeline: OCR Engine and
Textual-Based Classificarion
The first pipeline aims at detecting spam by first con-
verting the image of the email with OCR and then
applying spam detectors on the obtained text. Noting
that this step is not the inverse of email rendering, as
the text captured by the OCR is very close to what the
human eyes perceive, and can be very different from
the textual content of the HTML files, due to the hid-
den salting tricks.
3.2.1 NB and DT Classifiers for Spam Filtering
Once the image has been converted into the perceived
text, we apply text-based spam classifiers to detect the
presence of spam. In particular, we consider the NB
classifier as one of the most renowned and effective
content-based spam filters. We also use a DT classi-
fier which operates in a different manner and is also
very effective.
3.3 Second Pipeline: Image-Based
Classification with CNN
The second pipeline aims to detect spam directly from
the appearance of the email as rendered in the image,
including colors and other visual objects. Here we
use a specific computer vision CNN model as a very
effective tool for image classification in similar con-
texts. The CNN, serves as a visual perception model,
learns patterns and features crucial for distinguishing
between the images of spam and ham emails.
Figure 2: Stacking classifier architecture.
3.4 Final Classification
Since we have two pipelines aiming at providing a
classification of an email, and to consolidate the clas-
sification predictions from both pipelines, which are
predictions of baseline models, we incorporated a
meta-classifier (Wolpert, 1992) utilizing the stacking
ensemble method, as depicted in Fig. 2. The stacking
classifier architecture elements are as follows:
• Baseline classification models: the NB, DT and
CNN models.
• Predictions of the base models: the training pre-
dictions of the models in binary form, also called
stacking features, which are fed as input training
data for the meta classifier
• Meta classifier: a logistic regression (LR) classi-
fier is chosen, trained on the training predictions
of the base classifiers, in its output the final binary
prediction of the whole architecture.
The LR classifier is fed with the predictions gener-
ated by the CNN classifier, DTclassifier, and the NB
classifier, the use of a diverse set of base classifiers,
leveraged their diverse nature to improve final predic-
tive accuracy.
The utilization of Logistic Regression classifier
as the stacking classifier further refines the inte-
gration process, providing a well-balanced synthe-
sis of the predictions from baseline models, ensur-
ing a more comprehensive and nuanced analysis of
the input data, leading to a more reliable and in-
formed final classification outcome. Interestingly,
we experimented with various models as potential
stacking meta-classifiers, such as SVM, DT, and ran-
dom forests. However, after rigorous evaluation, LR
emerged as the best fit.
4 VBSF ENVIRONMENT SETUP
In this section, we describe our dataset and the Envi-
ronment of the VBSF technique including fine tuning
the Neural Network model process and its setup used
for performance evaluation in the next section.
4.1 Dataset Collection and Preparation
A mix of publicly available datasets has been used to-
gether with a dataset of hand-crafted emails for spe-
cific testing purposes. In particular, we considered
the Enron 1 and Enron 4 and pre-processed Spam As-
sasin email corpus. The combination of parts of the
three datasets was the best fit for our proposed model
and led to better generalization: indeed, Enron 1 and
4 have enough textual features, while they lack colors
and visual features, while Spam Assasin is rich in col-
ors and visual emails but alone was not big enough.
The combined dataset had imbalanced class dis-
tributions (40% spam and 60% ham emails), so we
increased the number of spam emails to balance the
dataset and prevent overfitting toward the majority
class. As a result, we have 4009 benign emails (ham)
ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy
302

Table 1: Accuracy of VBSF-Pipeline 1 (after applying OCR) vs
existing normal Text-Based Detection (without OCR).
ML Model
Accuracy
Text-based spam detector VBSF - Pipeline 1
NB 94 % 96 %
DT 95 % 97 %
LR 96 % 97 %
SVM 80 % 96 %
AdaBoost 96 % 96 %
KNN 89 % 91 %
Table 2: VBSF Accuracy With Different Meta Classifiers.
Meta Classifier Model VBSF final False Positive False Negative
used for VBSF test accuracy Rate Rate
LR 98.3% 1.2% 0.5%
Random Forest 97.3% 1.7% 1.0%
DT 96.6% 2.3% 1.1%
and 3800 spam emails. Additionally, a few sam-
ples have been minimally modified by applying some
spam tricks, trying to emulate an adversary behavior,
such as spam word spacing using HTML comments,
ham and spam word injection, and modification of
the size and bold effects. Most of these samples suc-
ceeded in misleading existing classifiers.
4.2 VBSF Setup
For the OCR of the obtained image, we resort to
Google Tesseract (Smith, 2007) (PyP, ).
For the second pipeline that classifies the image
into the two spam and ham classes, we resort to
the CNN VGG-19 neural network that utilizes small
3 × 3 filters across all convolutional layers, result-
ing in optimal performance reflected in its low error
rate (Zheng et al., 2018). We fine-tuned the VGG-
19 model through various settings to attain optimal
predictive performance. Several key hyperparameters
were precisely adjusted, including the learning rate,
the number of training and fine-tuning epochs. Ad-
ditionally, we incorporated data augmentation tech-
niques to further enhance the model’s ability to gen-
eralize patterns from our dataset. Choosing an appro-
priate learning rate was a critical step in achieving the
best results. Fig. 3 shows the classification accuracy
heatmap for the VGG19 model. We note that through
a systematic exploration of various learning rates and
epoch numbers, we identified the spot that led to a
remarkable accuracy and low validation loss, without
overfitting or underfitting the data.
Figure 3: Classification accuracy heatmap for the VGG19
model.
5 NUMERICAL RESULTS
We first assess the accuracy of the first pipeline with-
out the DT branch and with different classifiers on the
OCR output. In particular, we consider the NB, DT,
LR, SVM, AdaBoost (Freund and Schapire, 1997),
and k-nearest neighbor (KNN) classifiers. For com-
parison purposes, we also apply the same classifiers
directly to the original HTML text file, thus without
passing through the visual representation and OCR.
Table 1 shows the accuracy of both the VBSF and
text-based detectors for the various classifiers. In-
terestingly, when applied to the raw emails (source
etext) in our new dataset, the performance of con-
ventional NB and DT classifiers did not match those
on well-known email datasets. However, when we
VBSF: A Visual-Based Spam Filtering Technique for Obfuscated Emails
303

used the NB and DT classifiers on emails that went
through the OCR after rendering and capturing, both
classifiers demonstrated a remarkable performance
improvement. The adaptation of OCR technology
appeared to enhance the classifier’s ability to dis-
cern spam characteristics within the text, showcas-
ing the versatility of the NB and DT classifiers in
the context of our VBSF’s first pipeline. This nu-
anced observation underscores the importance of tai-
loring spam filters to the unique characteristics of the
dataset at hand, optimizing their performance for di-
verse sources and formats of email content.
Now, we assess the performance of the VBSF
solution. Table 2 shows the test accuracy of the
meta classifier after augmenting the first pipeline of
the VBSF. Several meta-classifiers underwent test-
ing, again, among which LR produced superior per-
formance compared to others reaching more than
98% accuracy, hence it was selected as the preferred
choice.
Through experimentation and evaluation, we ob-
served a remarkable increase in testing accuracy. The
integration of the DT classifier proved to be par-
ticularly impactful, contributing to a significant en-
hancement in predictive performance. These find-
ings underscore the importance of model composi-
tion and the value of incorporating diverse classifiers
to achieve superior results. Our enhanced variant of
VBSF represents a promising advancement in predic-
tive modeling, offering a pathway for further refine-
ment and optimization of our approach.
6 CONCLUSIONS
We have proposed a new approach to detect emails
that use visual tricks (or hidden salting tricks)and
HTML-related tricks, to convey spam messages to
end users. By employing a multi-step process imitat-
ing the natural processing of visual information by the
human eye, alongside text extraction of email snap-
shots using OCR followed by textual content classi-
fication using an NB classifier, augmented by a DT
classifier, our system efficiently cleans and analyzes
email text content. Moreover, integrating a CNN as
a visual perception classification model enhances the
system’s ability to discern between spam and legiti-
mate emails based on visual features and cues.
A remarkable strength of our proposed solution
lies in its adaptability to the dynamic nature of spam-
ming techniques, especially the visual ones. The pro-
posed model includes parsing all HTML tags and for-
matting the content according to their specifications.
Whether it’s normal content, known spam content
hiding tricks, or crafty spam tactics, all elements are
visually visible and ready for further investigation. By
integrating text-based and image-based classifiers in a
meta-classifier using stacking ensemble learning, our
system achieves a very good final classification accu-
racy exceeding 98%. This holistic approach enhances
both the accuracy and the resilience against evolving
spam tactics.
REFERENCES
Bergholz, A., Paass, G., Reichartz, F., Strobel, S., Moens,
M.-F., and Witten, B. (2008). Detecting known and
new salting tricks in unwanted emails. In Proc. Fifth
Conference on Email and Anti-Spam (CEAS), vol-
ume 9.
Biggio, B., Fumera, G., Pillai, I., and Roli, F. (2007). Im-
age spam filtering using visual information. In Proc.
Int. Conf. on Image Analysis and Processing (ICIAP
2007), pages 105–110.
Freund, Y. and Schapire, R. E. (1997). A decision-theoretic
generalization of on-line learning and an application
to boosting. Journal of Computer and System Sci-
ences, 55(1):119–139.
Gibson, S., Issac, B., Zhang, L., and Jacob, S. M. (2020).
Detecting spam email with machine learning op-
timized with bio-inspired metaheuristic algorithms.
IEEE Access, 8:187914–187932.
J
´
a
˜
nez-Martino, F., Alaiz-Rodr
´
ıguez, R., Gonz
´
alez-Castro,
V., Fidalgo, E., and Alegre, E. (2023). A review of
spam email detection: analysis of spammer strategies
and the dataset shift problem. Artificial Intelligence
Review, 56(2):1145–1173.
Karim, A., Azam, S., Shanmugam, B., and Kannoorpatti, K.
(2021). An unsupervised approach for content-based
clustering of emails into spam and ham through multi-
angular feature formulation. IEEE Access, 9:135186–
135209.
Moens, M.-F., De Beer, J., Boiy, E., and Gomez, J. C.
(2010). Identifying and resolving hidden text salt-
ing. IEEE Trans. on Info. Forensics and Security,
5(4):837–847.
Naiemi, F., Ghods, V., and Khalesi, H. (2019). An ef-
ficient character recognition method using enhanced
HOG for spam image detection. Soft Computing,
23(22):11759–11774.
Nam, S.-G., Jang, Y., Lee, D.-G., and Seo, Y.-S. (2022). Hy-
brid features by combining visual and text information
to improve spam filtering performance. Electronics,
11(13).
Rizky, A. F., Yudistira, N., and Santoso, E. (2023). Text
recognition on images using pre-trained CNN. arXiv.
Shaukat, K., Luo, S., Varadharajan, V., Hameed, I. A., and
Xu, M. (2020). A survey on machine learning tech-
niques for cyber security in the last decade. IEEE Ac-
cess, 8:222310–222354.
ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy
304

Smith, R. (2007). An overview of the Tesseract OCR en-
gine. In Proc. Int. Conf. on Document Analysis and
Recognition (ICDAR 2007), volume 2, pages 629–
633.
Sokolov, M., Olufowobi, K., and Herndon, N. (2020). Vi-
sual spoofing in content-based spam detection. In
Proc. Int. Conf. on Security of Information and Net-
works, page 3–3.
Wolpert, D. H. (1992). Stacked generalization. Neural net-
works, 5(2):241–259.
Zheng, Y., Yang, C., and Merkulov, A. (2018). Breast can-
cer screening using convolutional neural network and
follow-up digital mammography. In Proc. Computa-
tional Imaging III, SPIE Commercial and Scientific
Sensing and Imaging.
VBSF: A Visual-Based Spam Filtering Technique for Obfuscated Emails
305
