Runtime Veriﬁcation for Deep Learning Systems

Birk Torpmann-Hagen

, Michael A. Riegler

, Pål Halvorsen

and Dag Johansen

UiT The Arctic University of Norway, Tromsø, Norway

SimulaMet, Oslo, Norway

Keywords:

Deep Learning, Runtime Veriﬁcation, Transparency, Distributional Shift, Multimedia.

Abstract:

Deep Neural Networks are being utilized in increasingly numerous software systems and across a wide range

of data modalities. While this affords many opportunities, recent work has also shown that deep learning

systems often fail to perform up to speciﬁcation in deployment scenarios, despite initial tests often indicating

excellent results. This disparity can be attributed to shifts in the nature of the input data at deployment time

and the infeasibility of generating test cases that sufﬁciently represent data that have undergone such shifts. To

address this, we leverage recent advances in uncertainty quantiﬁcation for deep neural networks and outline a

framework for developing runtime veriﬁcation support for deep learning systems. This increases the resilience

of the system in deployment conditions and provides an increased degree of transparency with respect to the

system’s overall real-world performance. As part of our framework, we review and systematize disparate work

on quantitative methods of detecting and characterizing various failure modes in deep learning systems, which

we in turn consolidate into a comprehensive framework for the implementation of ﬂexible runtime monitors.

Our framework is based on requirements analysis, and includes support for multimedia systems and online

learning. As the methods we review have already been empirically veriﬁed in their respective works, we

illustrate the potential of our framework through a proof-of-concept multimedia diagnostic support system

architecture that utilizes our framework. Finally, we suggest directions for future research into more advanced

instrumentation methods and various framework extensions. Overall, we envision that runtime veriﬁcation

may endow multimedia deep learning systems with the necessary resilience required for deployment in real-

world applications.

1 INTRODUCTION

Deep learning is considered the state-of-the-art ap-

proach for a wide variety of tasks and is being uti-

lized in a growing number of software systems. Nev-

ertheless, Deep Neural Networks (DNNs) have been

shown to exhibit several shortcomings in deployment

settings that are not generally observed at the devel-

opment stage (Paleyes et al., 2022; Lwakatare et al.,

2020). In particular, it has been shown that DNNs

readily fail to generalize to data that exhibit proper-

ties that are not well-represented in the training data,

for instance different lighting-conditions (Ali et al.,

2022), demographic stratiﬁcation (Oakden-Rayner

et al., 2020), image-noise (Hendrycks and Dietterich,

2019), or other, more subtle changes (Geirhos et al.,

2020). In addition to this, there are also signiﬁcant

issues with respect to fairness (Holstein et al., 2019),

privacy (Mireshghallah et al., 2020), and security (Liu

et al., 2021). Current state-of-the-art large language

models have also been shown to exhibit severe prob-

lems with respect to reliability (Liu et al., 2024) and

hallucinations (Azamﬁrei et al., 2023). While deep

learning researchers are making strides towards ad-

dressing these shortcomings, DNNs still lack the nec-

essary degree of resilience that would warrant their

implementation in many software systems (Paleyes

et al., 2022). This is of particular relevance to high-

stakes domains such as autonomous vehicles, medical

systems, and algorithmic decision-making, wherein

any of the aforementioned failures could incur sig-

niﬁcant consequences for stakeholders if not imme-

diately recognized and reacted to by a human in the

loop.

Many of these issues can be attributed to the sen-

sitivity of neural networks with respect to shifts in the

nature of the data – i.e. distributional shifts – and

are further complicated by the fact that there is a lack

of testing methodologies capable of uncovering these

shortcomings at the development stage. This means

that these shortcomings are often not identiﬁed until

Torpmann-Hagen, B., Riegler, M. A., Halvorsen, P. and Johansen, D.

Runtime Veriﬁcation for Deep Learning Systems.

DOI: 10.5220/0013195500003928

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 20th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2025), pages 367-377

ISBN: 978-989-758-742-9; ISSN: 2184-4895

367

after they have already manifested in a deployment

scenario. Although it is common development prac-

tice to test neural networks using hold-out datasets

or through cross-validation, this does not generally

constitute a realistic representation of the network’s

accuracy during deployment. Indeed, many of the

shortcomings outlined above can only be discovered

after administering rigorous stress-tests or assessing

the constituent networks on an entirely new, manually

labeled, and curated out-of-distribution dataset (Ali

et al., 2022; Geirhos et al., 2020; Winkler et al., 2019;

D’Amour et al., 2020; Li et al., 2022). While large-

scale testing of this kind already constitutes a signif-

icant improvement over the current standard practice

of simply partitioning the training dataset (Li et al.,

2022), this is often infeasible in production contexts

to the required costs of data-curation and annota-

tion, and is in any case unlikely to account for all

the possible edge-cases that may be encountered in

a deployment scenario (Li et al., 2022; Riccio et al.,

2020). In conventional software systems, such edge-

cases are often identiﬁed through input fuzzing tech-

niques (Myers et al., 2011), but this is not generally

a feasible approach with respect to the testing of neu-

ral networks. Whereas conventional software systems

are generally characterized by a well-deﬁned state-

and input-space from which test-cases can be sam-

pled (Myers et al., 2011), deep learning systems op-

erate on manifolds of high-dimensional data (Brahma

et al., 2016). Sampling inputs that sufﬁciently repre-

sent the scope of variability present in a deployment

scenario thus requires accurately modeling this man-

ifold, a task of equal difﬁculty to training a network

capable of perfect generalization (Li et al., 2022; Ric-

cio et al., 2020).

Current approaches to the veriﬁcation of deep

learning systems are thus not typically successful in

their objective of ascertaining whether or not a given

DNN will perform up to speciﬁcation during deploy-

ment, and deep learning systems often fail in deploy-

ment scenarios as a result. Taking inspiration from

high-stakes systems engineering disciplines (Linde-

mann et al., 2023; Francalanza et al., 2018; Pike

et al., 2012; Falcone et al., 2013), we contend that

these issues can be largely mitigated through the im-

plementation of runtime veriﬁcation (RV) as system

support. This provides an effective safeguard against

insufﬁcient testing at development time, and circum-

vents the problem of representative test-case genera-

tion by simply extracting test-cases as the system is

deployed and executing. While these inputs are nec-

essarily unlabeled, recent advances in DNN uncer-

tainty quantiﬁcation has shown that it is nevertheless

possible to extract meaningful surrogates of system

performance from DNN representations of the input

data alone (Yang et al., 2022; Zhang et al., 2022).

By continuously monitoring these surrogates across

all data sources within the system at runtime, devia-

tions from speciﬁed behavior can be detected and re-

acted upon as they arise, mitigating – and, given suit-

able fall-back measures, possibly preventing – system

failure.

To this end, we introduce a framework for the de-

velopment of RV support for deep learning systems.

Our framework is based on requirements analysis,

and involves the composition of various online test-

ing methods that evaluate surrogates of system prop-

erties, selected in accordance to the system’s require-

ments and data modalities. Our framework is com-

patible with several different data modalities, can ac-

count for the implementation of active-learning, and

can be used to develop RV for complex multimedia

systems. We support our arguments with a review

of suitable online testing methods extracted from dis-

parate work on distributional-shift detection, fairness

in machine learning, adversarial attacks, guardrails

for Large Language Models (LLMs), and more. As

the efﬁcacy of these methods have already been em-

pirically veriﬁed in their respective works, we forego

additional empirical analysis in favor of demonstrat-

ing the potential of our framework through a proof-

of-concept multimedia medical deep learning system

architecture.

We summarize our contributions as follows:

• We outline a general-purpose framework for de-

veloping robust deep-learning systems with RV,

including support for multimedia systems and ac-

tive learning.

• We review, systematize, and unify previous work

on uncertainty quantiﬁcation and veriﬁcation of

deep neural networks, highlighting existing meth-

ods suitable for RV.

• We contextualize our work in terms of an example

system architecture consisting of a medical multi-

media system.

• We propose several avenues of further investiga-

tion and development, including an outline for a

probabilistic risk-assessment framework for deep

learning systems.

We organize our work as follows: in Section 2, we

review shortcomings of deep learning systems, out-

line existing work on the veriﬁcation of deep learning

systems, and relate the concept of RV in conventional

software systems to deep learning systems. In Sec-

tion 3, we outline our proposed framework, including

a review of methods and metrics in the literature that

are suitable for use as runtime monitors. In Section 4,

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

368

we outline an example of a multi-modal medical deep

learning system that implements our framework. Fi-

nally, we discuss the potential of this framework to-

wards endowing deep learning systems with opera-

tional resilience and propose several promising direc-

tions for future research.

2 RELATED WORK

In this section, we outline related work on the short-

comings and veriﬁcation of deep learning systems,

and outline the beneﬁts of RV in other domains.

The shortcomings of DNNs can be understood in

terms of the affected system properties. This often

includes failures with regards of correctness, robust-

ness, fairness, explainability, scalability, privacy, se-

curity, etc. The correctness of a DNN is, for instance,

only guaranteed given that the data is identically dis-

tributed to the data with which it was trained and val-

idated (Goodfellow et al., 2016). Violations of this

assumption results in generalization failure. This has,

for instance, been studied in the polyp-segmentation

domain, where a change in center or lighting con-

ditions was shown to signiﬁcantly reduce polyp de-

tection rates, despite utilizing generalization-oriented

training procedures (Ali et al., 2022). In another study

it was shown that medical systems for skin-cancer di-

agnosis and diabetic retinopathy detection failed to

generalize to underrepresented skin-tones and imag-

ing equipment respectively (D’Amour et al., 2020). In

general, vision-models have been shown to be sensi-

tive to adversarial attacks and natural corruptions such

as additive noise or blurs (Hendrycks and Dietterich,

2019). State-of-the-art LLMs have been shown to

fail to generalize to sentence reversal (Berglund et al.,

2023), often fabricate information in outputs (Azam-

ﬁrei et al., 2023), and readily yield harmful or other-

wise unethical outputs (Yao et al., 2024). They have

also been shown to be prone to generating incorrect

answers when prompted with leading questions or

continued prompt contradiction, a phenomenon often

referred to as LLM-sycophancy (Wang et al., 2023).

It is often argued that these errors can be elucidated

through the use of explanations (Adadi and Berrada,

2018), based on the assumption that incorrect pre-

dictions will yield incongruous explanations. This

view has been challenged by recent work, however,

which has shown that explanations are often mislead-

ing (Rudin, 2019) and can be easily fooled by adver-

sarial perturbations (Heo et al., 2019). DNNs have

also been shown to often lack the fairness necessary

for responsible deployment in domains with socially

salient outcomes (Holstein et al., 2019), as exempli-

ﬁed in a aforementioned study on skin-cancer diag-

nosis. Credit-scoring systems have also been shown

to readily learn biases with respect to gender, race,

and other such variables, despite these variables not

appearing in the training data (Hurlin et al., 2024).

Privacy violations, though somewhat less frequently

studied, are also commonplace in deep learning sys-

tems. It has, for instance, been shown that it is possi-

ble to recover conﬁdential training data using model

inversion (Song and Namiot, 2023) and that it may be

possible to re-identify users from anonymized medi-

cal signal data (Ghazarian et al., 2022).

In the majority of the aforementioned works, sys-

tem failures were only identiﬁed after administering

rigorous stress-tests and testing the system on unseen,

Out of Distribution (OOD) data. Such testing has

been shown to generally not be standard practice in

the industry due to high costs and a general lack of

suitable testing frameworks (Li et al., 2022; Riccio

et al., 2020). The majority of deep learning systems

are instead typically evaluated by computing simple

correctness metrics on hold-out sets, which generally

do not represent the variability present in a deploy-

ment scenario. While synthetic test-input generation,

for instance through generative modeling with OOD

seed data (Pei et al., 2017), offer a partial solution,

the efﬁcacy of these methods has been contested (Li

et al., 2022).

In conventional software engineering and other

systems engineering disciplines, too, the state-spaces

can be so large that conventional testing is consid-

ered insufﬁcient. Where system failures can incur

signiﬁcant consequences, another solution is to use

RV. RV is the study of algorithms, metrics, and meth-

ods for understanding the behavior of an executing

system (Falcone et al., 2013; Falcone et al., 2021).

Implementing these methods in software systems al-

lows increased conﬁdence that the system is working

as speciﬁed at runtime. The RV process is illustrated

in Figure 1, and can be distinguished according to

two distinct components: the monitor, which tracks

the events or states of the system and compares these

against predeﬁned correctness criteria, and the instru-

mentation, which refers to the process or techniques

by which the system’s behaviour is characterized. At

runtime, the monitor reads from the system instru-

mentation and yields a verdict in accordance with the

speciﬁed acceptable range of the observations. The

verdict can, in turn, be used to activate fall-back mea-

sures or generate system-wide alerts.

RV is widely used in high-stakes systems.

NASA’s copilot (Perez et al., 2020), for instance, is

a form of RV designed to detect and react to sys-

tem failures aboard space shuttles. Similar methods

Runtime Veriﬁcation for Deep Learning Systems

369

System

Property

Monitor

Instrumentation

System

Observation

Feedback

Verdict

Figure 1: The RV process.

are also often utilized in aviation (Pike et al., 2012)

and semi-autonomous vehicles (Lindemann et al.,

2023). Decentralized and distributed systems also of-

ten implement some form of RV, typically to ensure

that crashed or faulty nodes do not adversely affect

the overall system or to resolve conﬂicting messages

within the network (Francalanza et al., 2018). RV has

a distinct advantage compared to conventional testing,

precisely in that the system can be veriﬁed on what-

ever data is required at runtime. With conventional

testing, it would be necessary to generate a test case

that represents this data – and, depending on require-

ments, all possible data – but with RV, test cases are

extracted from the execution itself, with the main ob-

stacle being the design of test criteria. Though RV

may be less robust than conventional testing as a re-

sult, it signiﬁcantly mitigates any undesirable behav-

ior from untested inputs, as exempliﬁed in the afore-

mentioned applications.

3 RUNTIME VERIFICATION FOR

DEEP LEARNING SYSTEMS

So far, we have shown that DNNs exhibit a num-

ber of shortcomings that greatly hinder their utility

as components of software systems. We have also

outlined how they are difﬁcult to test sufﬁciently due

to their large input spaces, and how similarly com-

plex systems in other disciplines greatly beneﬁt from

RV. It therefore stands to reason that that deep learn-

ing systems, too, stand to beneﬁt from implement-

ing RV methods as a system support. In this section,

we thus outline a framework for the development of

RV for deep learning systems based on requirements

analysis, and provide an overview of suitable meth-

ods thereto as described in other literature, which we

organize according to data modalities.

The framework is summarized in Figure 2. The

process starts at the requirements speciﬁcation stage.

For the system requirements to be satisﬁed at runtime,

the corresponding properties – e.g. correctness, fair-

ness, safety, etc – must be actively monitored.

Next, it is necessary to identify any parts of the

system that may be prone to failures with respect

to each of the aforementioned requirements, for in-

stance, data sources, intermediate results in pipelined

models, explanations, system outputs, and user in-

puts. We refer to these collectively as data paths.

Increasingly complex systems contain larger amounts

of these data paths, each of which may require moni-

toring. Consider, for instance, a system consisting of

a single model that requires two input data sources.

It is not sufﬁcient to monitor only one of these data

sources, and analyzing both sources simultaneously

requires data fusion (Baltrušaitis et al., 2017; Lahat

et al., 2015), which may introduce additional errors.

Similarly, intermediates in pipelined models – for ex-

ample, where the output of one DNN is used as the

input to another – must be monitored in order to avoid

error propagation (Srivastava et al., 2020). As imple-

menting monitors for each requirement in each data

path is likely to incur signiﬁcant computational costs,

it is, however, necessary to assess what system prop-

erties are at risk at each path according to a threat

model. For example, if it is unlikely that a data source

contains privacy violations, there is no point in imple-

menting a privacy monitor on this path. If a threat

to the system’s ability to meet its speciﬁed require-

ments has been identiﬁed for a given data path, it is

considered a critical data path and is determined to

require monitoring. Distinguishing between threats

across data sources and domains is particularly im-

portant in systems composed of multiple modalities –

i.e. multimedia systems – due to the increased com-

plexity that arises due to cross-modal contexts. It has,

for instance, been shown that state-of-the-art multi-

modal LLMs can be jail-broken if certain images are

provided alongside a prompt that the guardrails would

otherwise deem harmful (Li et al., 2024b). In this

case, monitoring both images and prompts would be

necessary for the attack to be detected.

Once these critical data paths have been identi-

ﬁed, the next step is to implement suitable monitors

for each of them. This requires a means by which the

incidence of system failures can can be characterized.

Whereas this may be fairly straightforward in conven-

tional systems, one cannot generally characterize such

violations precisely in deep learning systems. Instead,

it is necessary to develop sufﬁciently expressive sur-

rogates for each system requirement as part of the in-

strumentation development process. To aid in this, we

provide a brief overview of potential threats to over-

all system performance in terms of system properties

alongside suitable instrumentation algorithms as pre-

sented in other literature in Table 1. To beneﬁt a wide

array of different application domains, we organize

these methods according to data modalities. We note

that this list is by no means comprehensive and that

the development of specialized monitoring methods

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

370

1 2 3 4 5

Define System

Requirements

Identify Critical Data Paths

Input sources, outputs, and

intermediates that may affect system

requirements

Design/Implement Suitable

Monitors

For each critical data path and threat,

implement a suitable monitor

Assess Monitors

Verify that the monitors work as

intended, e.g. through synthetic input

generation. Tune monitors.

Deploy System

Store system traces such that

undetected system failures can be

addressed through updates or redesigns

Figure 2: RV development process for deep learning systems.

may be required in production systems. Moreover,

it is worth noting that the scope of efﬁcacy of these

methods is not yet fully understood. The credibility

of the reported accuracy of many adversarial attack

detectors has, for instance, been contested (Tramèr,

2022).

After suitable monitors have been implemented at

each critical data path, the next step is to verify that

the monitors perform to a sufﬁcient standard. Though

this might appear to counteract the stated beneﬁts of

using RV methods in the ﬁrst place – i.e., not re-

quiring extensive testing – it is nevertheless neces-

sary, as RV are in and of themselves software ar-

tifacts (Falcone et al., 2021). Testing RV methods

is generally easier, however, as monitors can gen-

erally be unit-tested and are characterized by more

well-deﬁned problem statements, as evidenced by

the extensively developed methodologies convention-

ally used to evaluate Distributional Shift Detectors

(DSDs). Generating suitable test cases is also expe-

dited by the fact that the monitors yield a single bi-

nary verdict, and that monitors operate on surrogates

for system properties as opposed to the speciﬁcations

themselves. For instance, verifying that a correctness

monitor works as expected may simply requite testing

whether a given DSD correctly identiﬁes synthetically

augmented data as OOD, rather than testing whether

the DNN yields accuracies within a speciﬁc interval

for all plausible input data.

Finally, it is necessary to continuously collect sys-

tem logs for each critical data path and monitor the

verdict once the system has been deployed. This fa-

cilitates the continued improvement of the monitors

themselves by permitting analysis of system failures

the monitors have failed to detect. If the system im-

plements some form of active learning or other forms

of feedback loops, these logs can then also inform cor-

responding monitor updates. This may, for instance,

be achieved through re-calibration of the monitors at

set intervals and be incorporated as a regular form of

system maintenance.

4 EXAMPLE: RUNTIME

VERIFICATION FOR A

MEDICAL MULTIMEDIA

SYSTEM

To illustrate the potential beneﬁts of RV in production

scenarios, we include an example of a system archi-

tecture that implements our framework for a diagnos-

tic support system for heart disease detection. The

system inputs consist of several data modalities, in-

cluding time-series data in the form of cardiographs,

visual data in the form of echocardidograms and tab-

ular data in the form of patient information such as

medical history, age, etc. The central model in this ar-

chitecture, LLaVA-Med (Li et al., 2023), accepts this

data as input and yields a diagnosis, an initial prog-

nosis, and suggests treatment if required, all in accor-

dance with a clinician’s prompt(s).

In accordance with our framework, we start with

deﬁning some system requirements. Critical data

paths are then identiﬁed, along with suitable moni-

tors for each path. Though we have provided exam-

ples of suitable monitor algorithms, we note that in a

production scenario, these choices should ideally be

informed by prototyping. The results are shown in

Table 2, and the resulting architecture is shown in in

Figure 3.

Though we do not assess this architecture empir-

ically, the results in each of the cited works for each

monitor indicate that this system architecture would,

in a deployment context, exhibit a signiﬁcantly im-

proved degree of robustness, safety, privacy, trans-

Runtime Veriﬁcation for Deep Learning Systems

371

Table 1: Overview of typical threats to deep learning system performance and examples of viable RV monitors, separated

according to data modality. * = survey papers; ? = unable to ﬁnd suitable monitors.

Modality Property Threat(s) Suitable Monitors

Images

& Video

Correctness Generalization Failure (D’Amour

et al., 2020; Geirhos et al., 2020;

Kauffmann et al., 2020)

(Yang et al., 2022)*

Robustness Corruptions, Noise (Hendrycks and

Dietterich, 2019)

(Yang et al., 2022)*

Privacy Model Inversion (Song and Namiot,

2023)

(Song and Namiot, 2024)

Safety Adversarial Attacks (Biggio

et al., 2013), data poison-

ing (Schwarzschild et al., 2021)

(Harder et al., 2021; Zheng and

Hong, 2018; Metzen et al., 2017),

(Paudice et al., 2018; Steinhardt

et al., 2017; Wang et al., 2019)

Explainability Misleading explanations (Zhou et al., 2021)*

Fairness Unfair predictions, model bias, un-

fair performance

(Chen et al., 2024), ?

Compliance Intellectual Property violations ?

Text

Correctness Generalization Failure (Berglund

et al., 2023; Perez-Cruz and Shin,

2024), Misinformation

(Achintalwar et al., 2024; Li et al.,

2024a)*

Robustness Sentence Reversal (Berglund et al.,

2023)

Privacy Model Inversion (Song and Namiot,

2023)

Safety Jail-breaking, unsafe output (Alon and Kamfonas, 2023; Inan

et al., 2023; Yuan et al., 2024; Li

et al., 2024b), (Achintalwar et al.,

2024)*

Explainability Sycophancy(Wang et al., 2023) ?

Fairness Latent Bias (Chu et al., 2024) (Chu et al., 2024)*

Compliance Intellectual Property violations ?

Audio

Correctness Generalization Failure (Yang et al., 2022)

Robustness Noise and Poor Acoustics (Xu et al.,

2021)

Privacy User-identiﬁcation (Williams et al.,

2021)

Safety Adversarial Attacks (Carlini and

Wagner, 2018)

(Ma et al., 2021; Harder et al., 2021)

Compliance Intellectual Property viola-

tions (Blumenthal, 2024)

Signals

Correctness Generalization Failure (Yang et al., 2022)*(Provotar et al.,

2019)

Robustness Sensor Drift (Zheng and Paiva,

2021)

(Yang et al., 2022; Marathe et al.,

2021)

Privacy Re-identiﬁcation (Ghazarian et al.,

2022)

Tabular

Data

Correctness Incomplete/Invalid data (Hynes et al., 2017)

Safety Data Poisoning (Schwarzschild

et al., 2021)

(Steinhardt et al., 2017)

Fairness Algorithmic Bias (Holstein et al.,

2019)

(Chen et al., 2024)

Explainability Misleading Explanations (Heo

et al., 2019)

parency, and trustworthiness over a naive, monitor-

free implementation. A full picture of the value of

such a system architecture does, however, require

integration testing, ideally as part of a ﬁeld study,

though this is beyond the scope of this paper.

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

372

Table 2: System requirements and suitable monitors for a diagnostic support system.

Property Requirement Threat(s)

Critical

Data Paths Monitor

Correctness The system should assign

correct diagnoses at rates

comparable to a trained

clinician

Distributional Shift, incom-

plete data, leading prompts

All data sources OOD-detector (Yang

et al., 2022), data-

lintering (Hynes et al.,

2017), sycophancy-

monitoring (Achintalwar

et al., 2024)

Robustness The model should be robust

to minor perturbations

Noise, blurs, adversarial at-

tacks

Echocardiogram data, EKG

data

Adversarial attack detection

(Harder et al., 2021)

Explainability The factors informing diag-

nosis need to be communi-

cated with respect to each

data stream

Stakeholders do not trust

system/ insufﬁcient regula-

tory compliance

Explanation outputs Explanation quality met-

rics (Zhou et al., 2021)

Safety The system should raise

alerts when yielding diag-

noses with high-impact or

otherwise risky treatment

plans

System suggests treat-

ments that can interact

adversely with patient

history/medication or oth-

erwise exhibit high risks

LLaVA-Med outputs Database check of treat-

ment plans, their side-

effects, and overall risk

assessment

Privacy The patient’s privacy and

the privacy of previous pa-

tients must be maintained,

including training data

Privacy violations in gener-

ated outputs

LLaVA-Med outputs, Ex-

planations

Privacy Guard-rails (Achin-

talwar et al., 2024)

Safety/ Extensibility If monitors indicate im-

peded performance, the

clinician’s manual diagno-

sis and patient data should

be used to update the model

Data sources have been

tampered with or are other-

wise poor quality, clinician

has failed to enter ground-

truth correctly

Clinician diagnosis and

treatment plan, data sources

Data poisoning detec-

tion(Paudice et al., 2018)

Fairness Outputs should be invariant

to non-causal patient prop-

erties, e.g. race, income

System yields unfair out-

comes

LLaVA-Med outputs Fairness tests(Chen et al.,

2024)

Patient

Records

ECG

Cardiogram

Echocardiogram

All

InD?

Prompts

Prompt Guardrails

(Sycophancy

Detection)

Adversarial

Attack/Noise

Detector

OOD-Detector

OOD Detector

(Anomaly

Detection)

Data lintering

Valid?

Manual Diagnosis

Treatment Plan

Output Safety

(Database lookup)

Output Fairness

(Fairness testing)

Output

Clinician

Manual Diagnosis

Treatment Plan

Yes

VQA Response

Guardrails

Diagnosis &

Treatment

Output Privacy

(Guardrails)

PatientInfo

gender = male

age = 53

Does the patient

exhibit any

abnormalities?

Training-Data

Patient

Outcomes,

Monitor Traces

Clinician

Explanation

Quality

Explanation

Privacy

VQA

Explanations

LLaVa-Med

Yes

Data Quality

Monitor

(poisoning

detection)

Clinician

Adversarial

Attack/Noise

Detector

Figure 3: Medical Diagnostic Support System. Green blocks correspond to monitors. For simplicity, we have not speciﬁed

fallback measures for all monitors except where positive verdicts raise the need for further processing.

5 DISCUSSION

As illustrated by the example in Section 4 and the var-

ious suitable monitors reviewed in Section 3, RV al-

ready has the potential to endow deep learning mul-

timedia systems with an increased degree of fault-

tolerance, increasing the feasibility of real-world de-

Runtime Veriﬁcation for Deep Learning Systems

373

ployment of deep learning systems in performance-

critical scenarios. In contrast to the majority of

current implementations of deep learning systems,

wherein system failures manifest silently, our frame-

work permits the detection of system failures at run-

time. Monitor verdicts can then be utilized as signals

to engage fallback measures, for instance in the form

of human intervention or user alerts. In the medi-

cal system illustrated in Section 4, the use of mon-

itors may contribute to more efﬁcient and accurate

diagnoses and treatment of patients, ensure regula-

tory compliance, and expedite any required analysis

should there be a need to troubleshoot or improve the

system.

Beyond medical domains, we also envision that

our framework may greatly beneﬁt systems for au-

tomated journalism and content creation. One may,

for instance, develop and implement monitors that as-

sess the factual accuracy of generated content, iden-

tify potential sources of bias, and/or highlight ethi-

cal considerations, for instance, built on the same al-

gorithmic principles as LLM guardrails. Automated

content ﬁltering and recommendation systems might

also beneﬁt, in particular, given sufﬁcient monitoring

at all critical data paths. Incitements to violence, hate-

speech, deep-fakes, or other undesired content may be

monitored holistically and with respect to both the au-

dio, video, and textual modalities of social media plat-

forms given sufﬁcient algorithmic development. Indi-

vidual monitors may in these cases be easily updated

to adapt to changes in how undesirable content man-

ifests with regards to terminology, imagery, or stake-

holder values, facilitated by monitor trace logging and

the compartmentalization afforded by our framework.

We envision that RV system support can become

as ubiquitous in deep learning systems as it is in other

critical software systems. Further research is required

to this end, however, in particular with regards to the

development of instrumentation that can serve as ef-

fective surrogates for system requirements. A large

majority of existing research in this regard has been

scattered around the development of robustness- and

correctness monitors for image-based systems in the

form of DSDs (Yang et al., 2022) and adversarial at-

tack detectors (Harder et al., 2021; Zheng and Hong,

2018; Metzen et al., 2017). There has, however, been

sparse research towards equivalent methods for large

language models, and sparser still with respect to tab-

ular data and time-series data. Of equal concern is the

scarcity of monitoring methods for more cross-cutting

system properties, such as security, privacy, and fair-

ness. Though this has recently been more extensively

studied in the context of LLMs guard-rails, there is

a need for equivalent efforts for other modalities. To

the best of our knowledge, there are for instance cur-

rently no existing methods of detecting fairness viola-

tions in the form of correctness discrepancies across

sub-populations, nor any methods of monitoring for

privacy violations in image data, such as the detec-

tion of uncensored watermarks, faces, or logos. For

reference, consider the sparsity of citations in certain

entries of Table 1.

Though in this work, we have included a number

of suitable examples of runtime monitors and instru-

mentation, a more extensive survey of instrumenta-

tion methods is warranted. Given sufﬁcient further

development, a library implementing a suite of such

methods may also be useful, both for the purposes of

engineering and for more granular evaluation of deep

neural networks in academic contexts.

Further research into monitor instrumentation is

hindered by a lack of sufﬁcient benchmarks. As men-

tioned in Section 3, test-cases are required in order

to sufﬁciently evaluate runtime monitors. For the de-

tection of distributional shift and adversarial attacks,

generating test cases is fairly simple, often only re-

quiring the synthetic modiﬁcation of training data. On

the other hand, obtaining test cases for other system

properties may be challenging. The development of

a suitable explanation quality monitor, for instance,

would require some notion of what a suitable expla-

nation entails. This requires qualitative assessments

from end-users, which is time-consuming and labour-

intensive. Equivalently, verifying that a fairness mon-

itor correctly detects unfair behaviour requires a test-

bed that contains representative examples of the var-

ious forms of fairness violations that may occur. We

thus also call for the development of datasets and

benchmarks that lend themselves to the development

of RV methods. This could, for instance, entail pack-

aging datasets with two separate model checkpoints

and/or dataset folds, one that satisﬁes some system re-

quirement and one that does not. Proﬁling these meth-

ods with respect to execution time and resource re-

quirements is also warranted. Many multimedia sys-

tems have strict technical requirements, and existing

monitoring methods have not generally been devel-

oped with execution time and resource usage in mind.

In domains where real-time execution is necessary,

there may also be a trade-off with respect to the over-

head introduced by the added monitors and the re-

ductions in the DNN’s parameter counts and auxiliary

processing this overhead would necessitate.

Constructing monitors with other monitor outputs

as instrumentation components may also contribute

to greater insight into the system’s function, in par-

ticular in domains requiring multi-modal data. Fair-

ness with respect to correctness may, for instance,

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

374

be monitored by keeping track of any differences in

prediction rates of distributional-shift detectors with

respect to any pertinent variables. In the system

outlined in Section 4, for instance, one might ver-

ify that the system yields fair outputs by monitor-

ing for disparate distributional-shift detector predic-

tion rates with respect to patient data such as age,

gender, race, etc. The explanation quality monitor

might, in an equivalent manner, be improved by uti-

lizing noise detector and prompt monitor outputs, for

instance, by preventing explanation-affecting adver-

sarial attacks (Heo et al., 2019) or mitigating false ex-

planations due to leading questions in the prompts.

A possible additional beneﬁt of utilizing RV for

deep learning is that it may facilitate the development

of a probabilistic risk assessment framework. Proba-

bilistic risk assessment is common in high-stakes do-

mains (Stamatelatos et al., 2011) and involves statisti-

cal analysis of the rates of system failures. RV meth-

ods can be useful in this regard by providing empiri-

cal probability estimates at each point of failure sim-

ply by recording and analyzing monitor verdicts over

time. In turn, this can be used to quantitatively spec-

ify system risk, increase the overall trustworthiness

of deep learning systems, and inform judicial deci-

sions in the event that these failures incur signiﬁcant

consequences. Given a sufﬁciently rigorous method-

ology, these probability estimates may also constitute

sufﬁcient evidence for a given system’s overall per-

formance and thus assure regulatory compliance and

inform health and safety evaluations.

Overall, we conjecture that the development of RV

methods for multimedia deep learning systems is an

area of signiﬁcant potential with respect to further re-

search. Continued efforts to this end may, in time,

facilitate the operationalization of such systems and

ameliorate many of the shortcomings preventing their

application in production domains.

6 CONCLUSION

In this paper, we have proposed an RV framework

for deep learning systems. We have reviewed recent

work in the ﬁeld on how deep learning systems readily

fail in practical deployment and how existing meth-

ods for testing these systems generally fall short. Im-

plementing deep learning systems with RV methods

can, however, improve the system’s trustworthiness,

transparency, fault-tolerance and overall utility, as ev-

idenced by the recent successes with regard to the

development of methods of detecting distributional

shift. By building monitors for each system require-

ment and at each critical data path, system failures can

be detected and treated, improving the overall trust-

worthiness of the system. We envision that runtime

monitors may, in time, become necessary components

of deep learning systems, similar to how they are crit-

ical components of safety-critical or otherwise high-

stakes systems in other ﬁelds. Continued research

and development of RV methods may, over time, ease

the difﬁculty of regulatory compliance, improve sys-

tem stability and overall performance, and reduce the

risks involved with the real-world deployment of deep

learning systems.

REFERENCES

Achintalwar, S., Garcia, A. A., Anaby-Tavor, A., Baldini,

I., Berger, S. E., Bhattacharjee, B., Bouneffouf, D.,

Chaudhury, S., Chen, P.-Y., Chiazor, L., Daly, E. M.,

de Paula, R. A., Dognin, P., Farchi, E., Ghosh, S.,

Hind, M., Horesh, R., Kour, G., Lee, J. Y., Miehling,

E., Murugesan, K., Nagireddy, M., Padhi, I., Pi-

orkowski, D., Rawat, A., Raz, O., Sattigeri, P., Stro-

belt, H., Swaminathan, S., Tillmann, C., Trivedi, A.,

Varshney, K. R., Wei, D., Witherspooon, S., and Zal-

manovici, M. (2024). Detectors for safe and reliable

llms: Implementations, uses, and limitations.

Adadi, A. and Berrada, M. (2018). Peeking inside the black-

box: A survey on explainable artiﬁcial intelligence

(xai). IEEE Access, 6.

Ali, S., Ghatwary, N., Jha, D., Isik-Polat, E., Polat, G.,

Yang, C., Li, W., Galdran, A., Ballester, M.-A. G.,

Thambawita, V., Hicks, S., Poudel, S., Lee, S.-W., Jin,

Z., Gan, T., Yu, C., Yan, J., Yeo, D., Lee, H., Tomar,

N. K., Haithmi, M., Ahmed, A., Riegler, M. A., Daul,

C., Halvorsen, P., Rittscher, J., Salem, O. E., Lamar-

que, D., Cannizzaro, R., Realdon, S., de Lange, T.,

and East, J. E. (2022). Assessing generalisability of

deep learning-based polyp detection and segmentation

methods through a computer vision challenge.

Alon, G. and Kamfonas, M. (2023). Detecting language

model attacks with perplexity.

Azamﬁrei, R., Kudchadkar, S. R., and Fackler, J. (2023).

Large language models and the perils of their halluci-

nations. Critical Care, 27(1):120.

Baltrušaitis, T., Ahuja, C., and Morency, L.-P. (2017). Mul-

timodal machine learning: A survey and taxonomy.

Berglund, L., Tong, M., Kaufmann, M., Balesni, M., Stick-

land, A. C., Korbak, T., and Evans, O. (2023). The

reversal curse: Llms trained on "a is b" fail to learn "b

is a".

Biggio, B., Corona, I., Maiorca, D., Nelson, B., Šrndi

c, N.,

Laskov, P., Giacinto, G., and Roli, F. (2013). Evasion

attacks against machine learning at test time. Lecture

Notes in Computer Science, page 387–402.

SIGCAS Comput. Soc., 52(3):10–11.

Brahma, P. P., Wu, D., and She, Y. (2016). Why deep learn-

ing works: A manifold disentanglement perspective.

IEEE Transactions on Neural Networks and Learning

Systems, 27(10).

Runtime Veriﬁcation for Deep Learning Systems

375

Carlini, N. and Wagner, D. (2018). Audio adversarial ex-

amples: Targeted attacks on speech-to-text.

Chen, Z., Zhang, J. M., Hort, M., Harman, M., and Sarro, F.

(2024). Fairness testing: A comprehensive survey and

analysis of trends. ACM Trans. Softw. Eng. Methodol.

Just Accepted.

Chu, Z., Wang, Z., and Zhang, W. (2024). Fairness in large

language models: A taxonomic survey.

D’Amour, A., Heller, K., Moldovan, D., Adlam, B., Ali-

panahi, B., Beutel, A., Chen, C., Deaton, J., Eisen-

stein, J., Hoffman, M. D., Hormozdiari, F., Houlsby,

N., Hou, S., Jerfel, G., Karthikesalingam, A., Lucic,

M., Ma, Y., McLean, C., Mincu, D., Mitani, A., Mon-

tanari, A., Nado, Z., Natarajan, V., Nielson, C., Os-

borne, T. F., Raman, R., Ramasamy, K., Sayres, R.,

Schrouff, J., Seneviratne, M., Sequeira, S., Suresh,

H., Veitch, V., Vladymyrov, M., Wang, X., Webster,

K., Yadlowsky, S., Yun, T., Zhai, X., and Sculley,

D. (2020). Underspeciﬁcation presents challenges for

credibility in modern machine learning.

Falcone, Y., Havelund, K., and Reger, G. (2013). A tuto-

rial on runtime veriﬁcation. Engineering dependable

software systems, pages 141–175.

Falcone, Y., Krsti

c, S., Reger, G., and Traytel, D. (2021).

A taxonomy for classifying runtime veriﬁcation tools.

International Journal on Software Tools for Technol-

ogy Transfer, 23(2).

Francalanza, A., Pérez, J. A., and Sánchez, C. (2018). Run-

time Veriﬁcation for Decentralised and Distributed

Systems, pages 176–210. Springer International Pub-

lishing, Cham.

Geirhos, R., Jacobsen, J.-H., Michaelis, C., Zemel, R.,

Brendel, W., Bethge, M., and Wichmann, F. A. (2020).

Shortcut learning in deep neural networks. Nature

Machine Intelligence, 2(11):665–673.

Ghazarian, A., Zheng, J., Struppa, D., and Rakovski, C.

(2022). Assessing the reidentiﬁcation risks posed by

deep learning algorithms applied to ecg data. IEEE

Access, 10.

Goodfellow, I., Bengio, Y., and Courville, A. (2016). Deep

Learning. MIT Press. http://www.deeplearningbook.

org.

Harder, P., Pfreundt, F.-J., Keuper, M., and Keuper, J.

(2021). Spectraldefense: Detecting adversarial attacks

on cnns in the fourier domain. In 2021 International

Joint Conference on Neural Networks (IJCNN).

Hendrycks, D. and Dietterich, T. (2019). Benchmarking

neural network robustness to common corruptions and

perturbations.

Heo, J., Joo, S., and Moon, T. (2019). Fooling neural net-

work interpretations via adversarial model manipula-

tion. In Wallach, H., Larochelle, H., Beygelzimer,

A., d'Alché-Buc, F., Fox, E., and Garnett, R., editors,

NeurIPS, volume 32. Curran Associates, Inc.

Holstein, K., Wortman Vaughan, J., Daumé, H., Dudik, M.,

and Wallach, H. (2019). Improving fairness in ma-

chine learning systems: What do industry practition-

ers need? In Proceedings of the 2019 CHI Confer-

ence on Human Factors in Computing Systems, CHI

’19, page 1–16, New York, NY, USA. Association for

Computing Machinery.

Hurlin, C., Pérignon, C., and Saurin, S. (2024). The fairness

of credit scoring models.

Hynes, N., Sculley, D., and Terry, M. (2017). The data

linter: Lightweight automated sanity checking for ml

data sets.

Inan, H., Upasani, K., Chi, J., Rungta, R., Iyer, K., Mao, Y.,

Tontchev, M., Hu, Q., Fuller, B., Testuggine, D., and

Khabsa, M. (2023). Llama guard: Llm-based input-

output safeguard for human-ai conversations.

Kauffmann, J., Ruff, L., Montavon, G., and Müller, K.-R.

(2020). The clever hans effect in anomaly detection.

Lahat, D., Adali, T., and Jutten, C. (2015). Multimodal

data fusion: An overview of methods, challenges, and

prospects. Proceedings of the IEEE, 103(9).

Li, C., Wong, C., Zhang, S., Usuyama, N., Liu, H., Yang,

J., Naumann, T., Poon, H., and Gao, J. (2023). Llava-

med: Training a large language-and-vision assistant

for biomedicine in one day.

Li, S., Guo, J., Lou, J.-G., Fan, M., Liu, T., and Zhang, D.

(2022). Testing machine learning systems in industry:

an empirical study. In Proceedings of the 44th Inter-

national Conference on Software Engineering: Soft-

ware Engineering in Practice, ICSE-SEIP ’22, page

263–272, New York, NY, USA. Association for Com-

puting Machinery.

Li, T., Pang, G., Bai, X., Miao, W., and Zheng, J. (2024a).

Learning transferable negative prompts for out-of-

distribution detection.

Li, Y., Guo, H., Zhou, K., Zhao, W. X., and Wen, J.-R.

(2024b). Images are achilles’ heel of alignment: Ex-

ploiting visual vulnerabilities for jailbreaking multi-

modal large language models.

Lindemann, L., Qin, X., Deshmukh, J. V., and Pappas, G. J.

(2023). Conformal prediction for stl runtime veriﬁca-

tion. In ICCPS ’23, page 142–153, New York, NY,

USA. Association for Computing Machinery.

Liu, X., Xie, L., Wang, Y., Zou, J., Xiong, J., Ying, Z., and

Vasilakos, A. V. (2021). Privacy and security issues in

deep learning: A survey. IEEE Access, 9.

Liu, Y., Tantithamthavorn, C., Liu, Y., and Li, L. (2024). On

the reliability and explainability of language models

for program generation. ACM Transactions on Soft-

ware Engineering and Methodology.

Lwakatare, L. E., Raj, A., Crnkovic, I., Bosch, J., and Ols-

son, H. H. (2020). Large-scale machine learning sys-

tems in real-world industrial settings: A review of

challenges and solutions. Information and Software

Technology, 127:106368.

Ma, P., Petridis, S., and Pantic, M. (2021). Detecting adver-

sarial attacks on audiovisual speech recognition.

Marathe, S., Nambi, A., Swaminathan, M., and Sutaria, R.

(2021). Currentsense: A novel approach for fault and

drift detection in environmental iot sensors. In IoTDI,

IoTDI ’21, page 93–105, New York, NY, USA. Asso-

ciation for Computing Machinery.

Metzen, J. H., Genewein, T., Fischer, V., and Bischoff, B.

(2017). On detecting adversarial perturbations.

Mireshghallah, F., Taram, M., Vepakomma, P., Singh, A.,

Raskar, R., and Esmaeilzadeh, H. (2020). Privacy in

deep learning: A survey.

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

376

Myers, G. J., Sandler, C., and Badgett, T. (2011). The art of

software testing. John Wiley & Sons.

Oakden-Rayner, L., Dunnmon, J., Carneiro, G., and Ré, C.

(2020). Hidden stratiﬁcation causes clinically mean-

ingful failures in machine learning for medical imag-

ing. In Proceedings of the ACM conference on health,

inference, and learning, pages 151–159.

Paleyes, A., Urma, R.-G., and Lawrence, N. D. (2022).

Challenges in deploying machine learning: A survey

of case studies. ACM Comput. Surv., 55(6).

Paudice, A., Muñoz-González, L., Gyorgy, A., and Lupu,

E. C. (2018). Detection of adversarial training exam-

ples in poisoning attacks through anomaly detection.

Pei, K., Cao, Y., Yang, J., and Jana, S. (2017). Deepxplore:

Automated whitebox testing of deep learning systems.

In SOSP, page 1–18, New York, NY, USA. Associa-

tion for Computing Machinery.

Perez, I., Dedden, F., and Goodloe, A. (2020). Copilot 3.

Technical report.

Perez-Cruz, F. and Shin, H. S. (2024). Testing the cognitive

limits of large language models. BIS Bulletins 83,

Bank for International Settlements.

Pike, L., Niller, S., and Wegmann, N. (2012). Runtime ver-

iﬁcation for ultra-critical systems. In Runtime Veriﬁ-

cation, pages 310–324, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Provotar, O. I., Linder, Y. M., and Veres, M. M. (2019).

Unsupervised anomaly detection in time series using

lstm-based autoencoders. In 2019 IEEE International

Conference on Advanced Trends in Information The-

ory (ATIT).

Riccio, V., Jahangirova, G., Stocco, A., Humbatova, N.,

Weiss, M., and Tonella, P. (2020). Testing machine

learning based systems: a systematic mapping. Em-

pirical Software Engineering, 25(6).

Rudin, C. (2019). Stop explaining black box machine learn-

ing models for high stakes decisions and use inter-

pretable models instead. Nature Machine Intelligence,

1(5).

Schwarzschild, A., Goldblum, M., Gupta, A., Dickerson,

J. P., and Goldstein, T. (2021). Just how toxic is data

poisoning? a uniﬁed benchmark for backdoor and data

poisoning attacks. In Meila, M. and Zhang, T., edi-

tors, Proc. of ICML, volume 139, pages 9389–9398.

PMLR.

Song, J. and Namiot, D. (2023). A survey of the imple-

mentations of model inversion attacks. In Distributed

Computer and Communication Networks, pages 3–16,

Cham. Springer Nature Switzerland.

Song, J. and Namiot, D. (2024). On real-time model inver-

sion attacks detection. In DCCN, pages 56–67, Cham.

Springer Nature Switzerland.

Srivastava, M., Nushi, B., Kamar, E., Shah, S., and Horvitz,

E. (2020). An empirical analysis of backward compat-

ibility in machine learning systems. In Proc. of ACM

SIGKDD, KDD ’20, page 3272–3280, New York, NY,

USA. Association for Computing Machinery.

Stamatelatos, M., Dezfuli, H., Apostolakis, G., Everline,

C., Guarro, S., Mathias, D., Mosleh, A., Paulos, T.,

Riha, D., Smith, C., et al. (2011). Probabilistic risk

assessment procedures guide for nasa managers and

practitioners. Technical report.

Steinhardt, J., Koh, P. W. W., and Liang, P. S. (2017). Certi-

ﬁed defenses for data poisoning attacks. In Guyon, I.,

Luxburg, U. V., Bengio, S., Wallach, H., Fergus, R.,

Vishwanathan, S., and Garnett, R., editors, NeurIPS,

volume 30. Curran Associates, Inc.

Tramèr, F. (2022). Detecting adversarial examples is

(nearly) as hard as classifying them.

Wang, B., Yao, Y., Shan, S., Li, H., Viswanath, B., Zheng,

H., and Zhao, B. Y. (2019). Neural cleanse: Identi-

fying and mitigating backdoor attacks in neural net-

works. In 2019 IEEE Symposium on Security and Pri-

vacy (SP).

Wang, B., Yue, X., and Sun, H. (2023). Can ChatGPT de-

fend its belief in truth? evaluating LLM reasoning via

debate. In Bouamor, H., Pino, J., and Bali, K., ed-

itors, Findings of the Association for Computational

Linguistics: EMNLP 2023, pages 11865–11881, Sin-

gapore. Association for Computational Linguistics.

Williams, J., Yamagishi, J., Noe, P.-G., Botinhao, C. V., and

Bonastre, J.-F. (2021). Revisiting speech content pri-

vacy.

Winkler, J., Fink, C., Toberer, F., Enk, A., Kränke, T.,

Hofmann-Wellenhof, R., Thomas, L., Lallas, A.,

Blum, A., Stolz, W., and Haenssle, H. (2019). Associ-

ation between surgical skin markings in dermoscopic

images and diagnostic performance of a deep learning

convolutional neural network for melanoma recogni-

tion. JAMA Dermatology, 155.

Xu, B., Tao, C., Feng, Z., Raqui, Y., and Ranwez, S. (2021).

A benchmarking on cloud based speech-to-text ser-

vices for french speech and background noise effect.

Yang, J., Zhou, K., Li, Y., and Liu, Z. (2022). Generalized

out-of-distribution detection: A survey.

Yao, Y., Duan, J., Xu, K., Cai, Y., Sun, Z., and Zhang, Y.

(2024). A survey on large language model (llm) se-

curity and privacy: The good, the bad, and the ugly.

High-Conﬁdence Computing, page 100211.

Yuan, Z., Xiong, Z., Zeng, Y., Yu, N., Jia, R., Song, D., and

Li, B. (2024). Rigorllm: Resilient guardrails for large

language models against undesired content.

Zhang, J. M., Harman, M., Ma, L., and Liu, Y. (2022). Ma-

chine learning testing: Survey, landscapes and hori-

zons. IEEE Transactions on Software Engineering,

48(1).

Zheng, H. and Paiva, A. (2021). Assessing machine learn-

ing approaches to address iot sensor drift.

Zheng, Z. and Hong, P. (2018). Robust detection of adver-

sarial attacks by modeling the intrinsic properties of

deep neural networks. In NeurIPS, volume 31. Curran

Associates, Inc.

Zhou, J., Gandomi, A. H., Chen, F., and Holzinger, A.

(2021). Evaluating the quality of machine learning

explanations: A survey on methods and metrics. Elec-

tronics, 10(5).

Runtime Veriﬁcation for Deep Learning Systems

377
