Cybersecurity Risk Assessment Through Analytic Hierarchy Process:

Integrating Multicriteria and Sensitivity Analysis

Fernando Rocha Moreira

1 a

, Edna Dias Canedo

1 b

, Rafael Rabelo Nunes

2 c

Andr

e Luiz Marques Serrano

3 d

, Cl

audia Jacy Barenco Abbas

4 e

, Marcelo Lopes Pereira J

unior

4 f

and F

abio L

ucio Lopes de Mendonc¸a

4 g

University of Bras

ılia (UnB), Department of Computer Science, Bras

ılia–DF, Brazil

UniAtenas University Center, Paracatu-MG, Brazil

University of Bras

ılia (UnB), Professional Postgraduate Program in Electrical Engineering - PPEE, Bras

ılia–DF, Brazil

University of Bras

ılia (UnB), Department of Electrical Engineering, Bras

ılia–DF, Brazil

Keywords:

Cybersecurity Risk Management, NIST Cybersecurity Framework, Analytic Hierarchy Process, Multicriteria

Decision-Making, Public Sector Cybersecurity.

Abstract:

Context: Cybersecurity is increasingly critical for public institutions, particularly as digital transformations

expose them to a wide range of cybersecurity risks. Managing these risks effectively requires a structured

approach that aligns with recognized standards and frameworks. Methods: This study presents the process of

cybersecurity risk management within a Brazilian public agency, utilizing the cybersecurity incident detection

controls proposed by the NIST Cybersecurity Framework (NIST-CSF). To assess and prioritize these controls,

the Analytic Hierarchy Process (AHP) was applied as a multicriteria decision-making method. Expert judg-

ments were collected and integrated into the AHP model to determine the relative importance of each control.

Results: The application of the AHP method resulted in a prioritized list of cybersecurity controls. This list

outlines the sequence in which controls should be implemented, enabling decision-makers to direct resources

effectively and make informed choices in mitigating cybersecurity risks. Conclusion: The ﬁndings underscore

the value of adopting multicriteria methods like AHP in cybersecurity risk management. This paper con-

tributes to the literature by encouraging the use of such methods as best practices for improving cybersecurity

risk assessment and management in public sector organizations.

1 INTRODUCTION

Technology has played a critical role in the daily lives

of citizens and public services. It has facilitated and

provided increasingly efﬁcient services to the pop-

ulation. Moreover, technological evolution assumes

great importance in achieving the strategic objectives

of public agencies (Alves et al., 2023). However,

along with the beneﬁts brought by the use of tech-

nology, new risk factors also emerge (Canedo et al.,

https://orcid.org/0000-0003-3100-7128

https://orcid.org/0000-0002-2159-339X

https://orcid.org/0000-0002-1538-4276

https://orcid.org/0000-0001-5182-0496

https://orcid.org/0000-0002-6939-172X

https://orcid.org/0000-0001-9058-510X

https://orcid.org/0000-0001-7100-7304

2021), among them, cybersecurity risk (Moreira et al.,

2021).

Brazil has faced growing cyberattacks, with ap-

proximately 357,422 attacks reported in the second

half of 2023 (CNN Brasil, 2023). A signiﬁcant exam-

ple of a cyberattack and data breach in the public sec-

tor occurred with the ConecteSUS Platform, the ofﬁ-

cial application of the Ministry of Health. The plat-

form was targeted in an invasion and hacked, result-

ing in its temporary shutdown. Approximately 50 ter-

abytes of personal data were compromised, with some

data being withheld and others altered in the system

(Divino and Campos, 2024).

To improve the efﬁciency and effectiveness of

public agencies, the Brazilian government created

the Privacy and Information Security Program (PPSI)

(BRASIL, 2023). The PPSI establishes privacy and

Moreira, F. R., Canedo, E. D., Nunes, R. R., Serrano, A. L. M., Abbas, C. J. B., Pereira Júnior, M. L. and Lopes de Mendonça, F. L.

Cybersecurity Risk Assessment Through Analytic Hierarchy Process: Integrating Multicriteria and Sensitivity Analysis.

DOI: 10.5220/0013197300003929

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 27th International Conference on Enterprise Information Systems (ICEIS 2025) - Volume 2, pages 117-128

ISBN: 978-989-758-749-8; ISSN: 2184-4992

117

information security controls to support best prac-

tices in mitigating cyberattacks and managing risks

(BRASIL, 2023).

However, managing cybersecurity risks is no triv-

ial task. Good risk management involves a well-

deﬁned process for assessing an institution’s cyber-

security controls. Available security frameworks in-

volve many controls that need to be assessed and

prioritized (Moreira et al., 2021). For example, the

Cybersecurity Framework (CSF) from the National

Institute of Standards and Technology includes 108

subcategories of cybersecurity, while ISO 27.001 in-

cludes 93 controls to be assessed and prioritized

(NIST, 2018), (ISO/IEC, 2022).

Given this situation, information security man-

agers face the problem of prioritizing security con-

trols for risk management. ISO 31010 (ISO/IEC,

2018) presents several risk assessment and prioritiza-

tion tools, which can help managers deal with the pri-

oritization of security controls and risk management

in their daily activities (ISO/IEC, 2018).

Among the tools proposed by ISO 31010

(ISO/IEC, 2018) are MCDM – Multi-Criteria De-

cision Methods. These methods are known to as-

sist in decision-making processes and can produce a

ranking of alternatives based on the selected criteria

(ISO/IEC, 2019). One of the most widely used meth-

ods in the literature is the Analytic Hierarchy Process

(AHP), which uses mathematical calculations to gen-

erate the ﬁnal result (Saaty, 1980).

In this research, we applied the AHP multicriteria

method within a federal public administration agency

(APF), utilizing the Cybersecurity Framework (CSF)

as a guide to prioritize the controls to be adopted. Due

to conﬁdentiality concerns surrounding the agency,

we created a hypothetical scenario as the focus for the

practical case study.

The study produced several ﬁndings, two of which

we highlight here: 1) We evaluated the application of

the AHP in the risk management process, ensuring

that all its principles were addressed. 2) We analyzed

and discussed the decisions made by managers and

cybersecurity risk specialists, emphasizing the major

concerns faced by professionals in this ﬁeld today.

This study contributes to the existing literature by

demonstrating the practical application of AHP in the

context of cybersecurity risk management within pub-

lic institutions, providing valuable insights into the

decision-making process of risk prioritization. The

study also discusses the main cybersecurity detection

controls that should be prioritized by information se-

curity managers in the Brazilian public sector.

This paper is divided as follows: Section 2 con-

tains the Related Work and the Background of the re-

search, in which the similarities and differences in re-

lation to the work in question will be presented and

the concepts used to solve the problem in question

are discussed; Section 3 will present the Study Set-

tings; Section 4 will present the results obtained from

solving this problem; Finally, section 5 discusses the

conclusions of this study.

2 BACKGROUND AND RELATED

WORK

2.1 Risk Management

The risk management process should be an interac-

tive activity that supports organizations in developing

strategies to achieve their objectives and in decision-

making (ISO/IEC, 2018). This process is part of gov-

ernance and leadership and should involve all organi-

zational activities, including all stakeholders (Moreira

et al., 2021). Furthermore, one of the objectives of a

well-implemented Risk Management is the creation

and protection of value, improved performance, en-

couragement of innovation, and support in achieving

organizational goals (Canedo et al., 2021).

When it comes to cybersecurity risks, it is no dif-

ferent. This category of risks is crucial for the orga-

nization’s objectives, considering that the impact of

such failures on the business can lead to severe conse-

quences, especially for organizations with high strate-

gic dependence on ICT (Canedo et al., 2021).

To efﬁciently manage risks, it is essential to ﬁrst

establish the context and then proceed with the risk

assessment process. The result of this process is then

evaluated to verify whether the obtained information

is adequate to deﬁne the necessary actions to reduce

the risk to an acceptable level (ISO/IEC, 2018). A

well-designed risk management process should in-

volve eight principles (ISO/IEC, 2018):

• Integrated. Risk management should involve all

parts of the organization.

• Structured and Comprehensive. The risk man-

agement process should be approached in a struc-

tured manner, contributing to consistent and com-

parable results.

• Customized. Risk management should be tai-

lored to adjust to external and internal contexts

and the organization’s objectives.

• Inclusive. The risk management process should

involve all stakeholders, ensuring that different

viewpoints and perceptions are considered.

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

118

• Dynamic. New risks may arise, change, or dis-

appear as the organization’s external and internal

contexts evolve; therefore, the risk management

process must be dynamic.

• Best Available Information. The data entry pro-

cess should be clear, based on both past and future

considerations, and should account for limitations

and uncertainties. All information should be clear

and available to stakeholders.

• Human and Cultural Factors. This principle

must be considered, as it directly inﬂuences all

risks at every strategic level.

• Continuous Improvement. The risk manage-

ment process should be continuously improved

and reviewed based on the learning and experi-

ences gained.

2.2 Analytic Hierarchy Process

One way to support the risk management process and

decision-making is to use a Multi-Criteria Decision

Making (MCDM). These methods aim to generate a

preference ranking among the available options (Mor-

eira et al., 2021). They use a matrix of options and

criteria, rated based on a score for each option, ide-

ally aligning with the risk management process rec-

ommended by ISO 31.000 (ISO/IEC, 2018).

The main objective is to establish a preference or-

der among the available options. This involves an

analysis that consists of constructing a matrix com-

posed of options and criteria. These criteria are evalu-

ated and ranked, and subsequently aggregated to gen-

erate a ﬁnal score for each option (ISO/IEC, 2019).

(ISO/IEC, 2019) states that when applying an

MCDA, the risk management process is followed,

considering the steps: Risk Identiﬁcation, Risk Anal-

ysis, and Risk Evaluation. It is classiﬁed as ”Appli-

cable” for the Risk Identiﬁcation and Risk Evaluation

phases. Regarding the Risk Evaluation phase, from

the perspective of Consequences and Risk Levels,

MCDA is considered ”Strongly Applicable,” while

from the perspective of ”Probability,” it is deemed

”Applicable.”

The Analytic Hierarchy Process (AHP) is a multi-

criteria decision-making method derived from the

American school, where the main objective is the pre-

cision of calculations and the result, producing a pri-

ority list of the alternatives being evaluated (Saaty,

1980). This method ﬁts perfectly into the risk man-

agement process. The AHP has seven phases, as pre-

sented in Figure. 1 :

1. Problem Identiﬁcation. In this phase, it is neces-

sary to identify the problem, understand it, as well

Analytic Hierarchy Process - Steps

Problem Identiﬁcation

Hierarchical Structure

3 Pairwise Matrix

Eigenvector normalization

Repeat step 3 and 4 for subcriteria

Consistency Ratio

Rank

Figure 1: Steps of the Analytic Hierarchy Process (AHP).

as identify the real needs for its solution.

2. Hierarchical Structure. In this phase, the prob-

lem must be understood and transformed into a

hierarchical tree. This tree should contain the cri-

teria and alternatives to be judged, as indicated by

the method’s creator (Saaty, 1980).

3. Pairwise Matrix. This phase involves the evalu-

ation and judgment of specialists involved in the

decision-making process. The evaluation is con-

ducted in a paired manner, where one alternative

is evaluated against another concerning a speciﬁc

criterion, using a scale proposed by the author

(Saaty, 1980). Table 1 illustrates Saaty’s scale.

4. Eigenvector Normalization. In this phase, the

method normalizes the calculation vectors to en-

able the calculation of the consistency index,

which will be done in phase 6.

5. Repeat Step 3 and 4 for Subcriteria. In this

phase, steps 3 and 4 should be repeated for all al-

ternatives and subcriteria concerning the criteria

until all possible judgments within the hierarchi-

cal structure are completed (Siregar et al., 2024).

6. Consistency Ratio. In this phase, the consis-

tency index is calculated. This index can indicate

whether the judgments provided by the experts

are meaningful and consistent. This is possible

thanks to the pairwise comparison system using

Saaty’s scale. The index is calculated after the ex-

perts complete their evaluation of the alternatives

against a criterion. If the consistency index ex-

ceeds 10

Cybersecurity Risk Assessment Through Analytic Hierarchy Process: Integrating Multicriteria and Sensitivity Analysis

119

Table 1: Saaty’s Scale. (Saaty, 1980).

Numerical

Scale

Conceptual

Scale

Description

1 Equal The two elements con-

tribute equally to the

criterion

3 Moderate The compared element

is slightly more impor-

tant than the other

5 Strong Experience and judg-

ment strongly favor the

element over the other

7 Very

Strong

The compared element

is much stronger than

the other, and such im-

portance can be ob-

served in practice

9 Absolute The compared element

presents the highest

possible level of evi-

dence in its favor

2,4,6,8 Intermediate

values

When the evaluator has

difﬁculty choosing be-

tween two levels of un-

derlying importance

7. Rank. Finally, the method globally calculates the

priority list, providing the contribution each ele-

ment has concerning the objective. The AHP uses

matrix calculations to obtain this result (Saaty,

1980).

Some software tools implement this process and

facilitate the application of AHP. To address this prob-

lem, the Super Decision software was used to imple-

ment the project. This software, which implements

the AHP method, was developed by the team of the

method’s creator, Thomas Saaty. Its development and

maintenance are sponsored by the Creative Decisions

Foundation. (Creative Decision Foundation, 2012).

2.3 NIST Cybersecurity Framework

The Cybersecurity Framework (CSF) is a cybersecu-

rity framework that contains 108 controls called se-

curity subcategories, which companies and organiza-

tions can adopt for their internal cybersecurity risk

management process. This guide was created in 2013

in the United States under Executive Order 13636,

titled “Improving Critical Infrastructure Cybersecu-

rity” (NIST, 2018).

Subsequently, the Cybersecurity Enhancement

Act was created in 2014, assigning NIST the role of

identifying and developing cybersecurity risk guide-

lines, encouraging critical infrastructure operators to

voluntarily adopt the guide (NIST, 2018).

This guide was designed to combat and manage

cybersecurity risks aimed at the economy, and it is

also based on the business and organizational needs

of companies. It has no regulatory nature for orga-

nizations. It provides guidance for organizations to

incorporate cybersecurity risk management processes

as part of the organization’s overall risk management

process (NIST, 2018).

The framework assists critical infrastructure man-

agers in developing cybersecurity risk guidelines for

their companies. Critical infrastructure refers to es-

sential systems and assets whose disruption could

cause severe impacts on economic security, health,

and public safety. The CSF follows a tree structure,

where the ﬁrst level consists of functions, the second

contains categories, the third includes subcategories

representing cybersecurity controls, and the fourth

comprises the references from which these controls

were derived (NIST, 2018). The ﬁgure 2 illustrates

the tree structure of the CSF for the Detect function.

The Detect function was utilized in this study. Its

controls aim to develop and implement guidelines to

identify the occurrence of cybersecurity events. This

function includes the following categories: Anoma-

lies and Events (DE.AE), Security Continuous Mon-

itoring (DE.CM), and Detection Processes (DE.DP).

Each category comprises speciﬁc activities relevant to

cybersecurity detection.

In addition to the Detect function, the CSF in-

cludes other important functions that were not utilized

in this paper. The controls of the Identify function are

associated with the organizational understanding re-

quired to manage security risks. This function focuses

on identifying systems, people, assets, and resources.

The Protect function is responsible for developing and

implementing the necessary protections to ensure the

continued operation of services, aiming to limit cyber-

security incidents. The Respond function implements

activities to take appropriate actions when a cyberse-

curity incident is detected. Finally, the Recover func-

tion aims to carry out activities and maintain plans to

restore services that became inoperative due to a cy-

bersecurity incident.

2.4 Related Work

There are some works in the literature that have used

multicriteria methods to support risk management.

(Brigido et al., 2022) used the AHP multicriteria

method together with the Technique for Order of Pref-

erence by Similarity to Ideal Solution (TOPSIS) to

create a risk mitigation model for the allocation of

human resources in a law ﬁrm. The authors argued

that AHP can validate human criteria judgments while

TOPSIS prioritizes alternatives through risk similarity

(Brigido et al., 2022).

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

120

DETECT

Anomalies and

Events (DE.AE)

Security Contin-

uous Monitoring

(DE.CM)

Detection Pro-

cesses (DE.DP)

DE.AE-1: A base-

line of network

operations and ex-

pected data ﬂows

for users and sys-

tems is established

and managed

DE.AE-2: De-

tected events are

analyzed to under-

stand attack targets

and methods

DE.AE-3: Event

data are collected

and correlated

from multiple

sources and sen-

sors

DE.AE-4: Impact

of events is deter-

mined

DE.AE-5: Incident

alert thresholds are

established

DE.CM-1: The

network is mon-

itored to detect

potential cyberse-

curity events

DE.CM-2: The

physical environ-

ment is monitored

to detect poten-

tial cybersecurity

events

DE.CM-3: Per-

sonnel activity is

monitored to de-

tect potential cy-

bersecurity events

DE.CM-4: Mali-

cious code is de-

tected

DE.CM-5: Unau-

thorized mobile

code is detected

DE.CM-6: Ex-

ternal service

provider activity

is monitored to

detect potential cy-

bersecurity events

DE.CM-7: Mon-

itoring for unau-

thorized personnel,

connections, de-

vices, and software

is performed

DE.CM-8: Vulner-

ability scans are

performed

DE.DP-1: Roles

and responsibilities

for detection are

well deﬁned to en-

sure accountability

DE.DP-2: De-

tection activities

comply with all

applicable require-

ments

DE.DP-3: Detec-

tion processes are

tested

DE.DP-4: Event

detection informa-

tion is communi-

cated

DE.DP-5: Detec-

tion processes are

continuously im-

proved

Figure 2: Hierarchical structure of the DETECT framework

showing the three main categories.

(Ru et al., 2016) evaluated the inﬂuence of cy-

berattacks on the Electric Cyber-Physical System

(ECPS). The authors created a model to perform a

quantitative risk assessment, using AHP to model the

problem as well as to quantify the impact of the attack

on the ECPS. The authors conducted a practical case

study, and the results indicated that applying the pro-

posed method can support organizations in assessing

risks in ECPS systems.

(Bitton et al., 2021) conducted an analysis of the

threats to a Machine Learning (ML) system using

AHP. As a reference, the authors used the NIST threat

ontological model. Thus, the NIST model was used

to assess the security risks of enterprise networks and

ML-based systems. AHP was used to classify var-

ious attributes of cyberattacks through the judgment

of security experts. As a result, the authors supported

practitioners in the ﬁeld of information security with a

methodological and practical tool to assist in the exe-

cution of the cybersecurity risk quantiﬁcation process

in production systems using ML (Bitton et al., 2021).

(Moreira et al., 2021) used the Constructivist Mul-

ticriteria Decision Support Methodology (MCDA-C)

to develop a cybersecurity risk assessment plan for

a ﬁnancial bank. The authors used the cybersecu-

rity controls from the CSF as a reference. The con-

trols were assessed, and unlike AHP, which produces

a list of priorities, MCDA-C demonstrated the perfor-

mance point of each cybersecurity control when com-

pared to the points of maximization and minimization

of each one. Through this approach, the authors con-

tributed to a better understanding of risk management,

using MCDA-C as a good practice in risk manage-

ment (Moreira et al., 2021).

Multicriteria methods have been used to manage

risks in various ﬁelds of knowledge, such as in the

management of human resource allocation risks and

in cybersecurity risk management. Unlike previous

works, this study uses AHP with the CSF controls,

aiming to support organizational managers in creating

the risk management plan and developing a priority

list of controls to be implemented to help risk man-

agers mitigate cybersecurity risks. Thus, this work

proposes a practical approach, using AHP based on

the structure of the controls proposed by the CSF to

improve the process of cybersecurity risk manage-

ment.

This paper stands out for its innovative applica-

tion of multicriteria methods in cybersecurity risk

management, using CSF controls combined with the

AHP method. Unlike previous studies that focused

on areas such as human resource allocation multicri-

teria methods to support risk management. (Brigido

et al., 2022), electric cyber-physical systems (Ru

et al., 2016), and machine learning-based systems

(Bitton et al., 2021), this work adopts a broad and

practical approach, applicable to various organiza-

tions. Furthermore, in contrast to the MCDA-C-based

approach used by (Moreira et al., 2021), which as-

sessed the performance of cybersecurity controls in a

ﬁnancial bank, this study employs AHP to generate a

prioritized list of CSF controls, facilitating decision-

making and resource allocation. This unique integra-

tion of AHP with CSF controls provides a practical

and structured tool for organizational managers, en-

abling efﬁcient risk mitigation aligned with the cur-

rent needs of cybersecurity.

Cybersecurity Risk Assessment Through Analytic Hierarchy Process: Integrating Multicriteria and Sensitivity Analysis

121

3 STUDY SETTINGS

This research has an applied nature as it evaluates and

prioritizes cybersecurity controls for an organization,

a bank of the Brazilian Government. Based on this

evaluation, the bank will identify gaps in its infor-

mation security management process and will deﬁne

measures to mitigate them.

Regarding data collection, it can be characterized

as primary and secondary. The primary is justiﬁed as

data was collected, raised, and analyzed through the

judgment of decision-makers concerning the evalua-

tion of cybersecurity controls. The secondary is jus-

tiﬁed as the cybersecurity controls were derived from

the CSF along with its structure to be evaluated by the

judges (NIST, 2018).

The work has a dual approach in terms of its

methodology. It has quantitative characteristics con-

sidering the mathematical model with matrix calcu-

lations and consistency index used by AHP (Saaty,

1980). It also has a qualitative approach by utilizing

the structure of Detection from the CSF being evalu-

ated under the light of Saaty’s scale, which has quali-

tative degrees of assessment.

The research presents itself in a mixed manner due

to the phases of AHP application. The ﬁrst phase

is considered inductive because it adopted the struc-

ture and controls of the Detect function from the CSF

(NIST, 2018). As the main concern of decision-

makers is the processes for detecting cybersecurity in-

cidents, the subcategories of the Detect function from

the CSF were used. The second phase has a deductive

character due to the paired judgments of each con-

trol concerning a criterion using Saaty’s scale (Saaty,

1980). Finally, the phase of evaluating the cyberse-

curity controls presented itself inductively as it was

based on the priority list of controls generated by

AHP (Saaty, 1980).

In this paper, the structure of the Detect function

from the CSF was used so that it could later be judged

by decision-makers. As a result, a prioritized list of

cybersecurity controls was generated, assisting in the

creation of a cybersecurity risk assessment plan that

complies with all risk management principles.

As the ﬁnal priorities of the alternatives demon-

strate a strong dependence on the weights assigned

to the main criteria, small variations in the relative

weights can result in signiﬁcant changes in the ﬁnal

ranking, given that these weights are often derived

from subjective judgments (Chang et al., 2007). Thus,

it was essential to test the robustness of the priority list

and the choices of experts by performing a sensitivity

analysis against different weight assignments to the

categories.

4 RESULTS

In this section, the results obtained through the

evaluation of the cybersecurity controls contained

in the CSF using AHP will be described. First,

three research participants were selected, who are the

decision-makers. These individuals hold representa-

tive positions in their respective areas within the orga-

nization, whose roles can be cited as shown in Table

2 :

The selection of a diverse proﬁle among the

judges was intentional, addressing human and cul-

tural factors, integration, and inclusion, principles ad-

dressed by risk management. These specialists were

chosen because they hold power and inﬂuence in the

company’s decision-making process.

Next, the controls from the Detect function of the

CSF were selected, which, as required by the AHP ap-

plication, already has a predeﬁned tree structure. This

structure is important because it addresses the prin-

ciples of a comprehensive, customized, and dynamic

framework outlined in the risk management process

contained in ISO 31.000. In Figure 2, the structure

is characterized such that the ﬁrst level represents the

main node, which is the Detect function of the CSF.

The second level contains the categories that will be

evaluated by AHP. The third level consists of the ac-

tual cybersecurity controls, which will be evaluated,

prioritized, and where decision-makers or specialists

should focus their efforts to implement risk mitigation

solutions.

In the next phase, a brainstorming session was

conducted with the specialists where the cybersecu-

rity controls of the CSF were evaluated. For the eval-

uation, the Saaty scale, proposed by the method it-

self, was used. During this evaluation, each cate-

gory/subcategory was subjected to a pairwise compar-

ison with another category/subcategory. The question

asked for the evaluation was as follows: In terms of

importance criteria, how much could subcategory X

contribute to the institution compared to category Y?

Table 3 presents the evaluation performed by spe-

cialists using the Saaty scale for the categories of the

Detect function. For example, the category DE.CM

- Security Continuous Monitoring received a score of

5, indicating strong importance compared to DE.AE -

Anomalies and Events, predominantly shown in red.

Scores of 1, in black, indicate categories considered

”Equal” by specialists. The consistency index was

5%, below the 10% recommended by the method.

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

122

Table 2: Demographics Information of the Participants.

ID Age group Highest Degree Experience Current Occupation Team Size

(in years old) (in years) (people number)

P1 41-50 Postgraduate 15-20 Senior IT Development Analyst <= 10

P2 31-40 Postgraduate 8-15 Senior IT Infrastructure Analyst <= 10

P3 31-40 Postgraduate 8-15 IT Integration Manager <= 10

Table 3: Judgment of the Categories of the Detect Function.

Controls DE.AE DE.CM DE.DP

DE.AE X 5 2

DE.CM X X 5

DE.DP X X X

The results of the judgment of the categories, with

DE.CM receiving 71%, DE.AE 18%, and DE.DP

11%, indicate that DE.CM (Security Continuous

Monitoring) was considered the most critical priority

for detecting cybersecurity threats. This focus on con-

tinuous monitoring reﬂects the importance of quickly

detecting anomalous behaviors and malicious activi-

ties, ensuring a swift response to threats.

The DE.AE (Anomalies and Events) category,

with a lower weight, is still relevant, highlighting the

need to detect and respond to cybersecurity events.

Meanwhile, DE.DP (Detection Processes), with 11%,

although less prioritized, suggests that detection pro-

cesses are in place and considered important but less

critical than continuous monitoring and anomaly de-

tection. When comparing the results obtained in this

study with (Moreira et al., 2021) paper a similarity in

ﬁndings is observed.

The Figure 3 illustrates the results of the experts

evaluation of the categories using the AHP method.

0 20 40

80 100

DE.DP

DE.AE

DE.CM

Figure 3: Detection - Categories.

Table 4 shows the evaluation performed by the

specialists regarding the controls of Category 1:

Anomalies and Incidents. The evaluation achieved a

consistency index of 7.38%, which remained below

the 10% threshold as indicated by Saaty.

Table 4: Table showing the judgment of specialists regard-

ing the Anomalies and Events Subcategory (DE.AE).

Subcategories DE.AE-

DE.AE-

DE.AE-1 X 1 2 2 3

DE.AE-2 X X 1 4 7

DE.AE-3 X X X 2 5

DE.AE-4 X X X X 4

DE.AE-5 X X X X X

The results presented under the Anomalies and

Events criterion highlight DE.AE-2 as the highest

priority, with 34 points, followed by DE.AE-3 with

28 points, DE.AE-4 with 17 points, DE.AE-1 with

16 points, and DE.AE-5 with 5 points. These val-

ues demonstrate a clear emphasis on the detection of

anomalous behaviors and critical incidents.

These results suggest that proactive anomaly de-

tection and event correlation are essential components

of the organization’s cybersecurity strategy, as shown

in the Figure 4.

0 20 40

80 100

DE.AE-5

DE.AE-1

DE.AE-4

DE.AE-3

DE.AE-2

Figure 4: DE.AE - Anomalies and Events - Subcategories.

When comparing the results obtained in this study

with those of other papers, a similarity in ﬁndings is

observed. (Moreira et al., 2021) study presents the

following order for the categories: DE.AE-2, DE.AE-

1, DE.AE-3, DE.AE-4, and DE.AE-5. The common

result highlights the concern for the DE.AE-2 subcat-

egory, reinforcing the necessity and priority of detect-

ing events to understand attack methods. However, it

is evident that the DE.AE-5 subcategory is not con-

sidered signiﬁcant by managers.

Cybersecurity Risk Assessment Through Analytic Hierarchy Process: Integrating Multicriteria and Sensitivity Analysis

123

Table 5: Table containing the experts’ evaluation regarding the Subcategory of Security Continuous Monitoring (DE.CM).

Controles DE.CM-

DE.CM-

DE.CM-1 X 5 2 3 3 3 5 1

DE.CM-2 X X 3 5 5 2 2 6

DE.CM-3 X X X 4 4 1 1 5

DE.CM-4 X X X X 1 5 5 1

DE.CM-5 X X X X X 5 5 1

DE.CM-6 X X X X X X 1 5

DE.CM-7 X X X X X X X 5

DE.CM-8 X X X X X X X X

Regarding the evaluation of the other subcate-

gories, differences are observed in the obtained prior-

ity order and their relative importance. These differ-

ences can be attributed to variations in judgments dur-

ing the application process and the application pro-

tocols of MCDA-C compared to AHP. In MCDA-C,

weights are determined through percentages agreed

upon during a brainstorming session with decision-

makers (Moreira et al., 2021), while in AHP, weights

are derived using the Saaty scale, which, after appli-

cation, generates percentage weights while ensuring

a consistency index for the judgments (Saaty, 1980).

Regarding the subcategories of the DE.CM - Security

Continuous Monitoring category, the specialists per-

formed the evaluation, as shown in Table 5. The eval-

uation achieved a consistency index of 2.738%, also

below the 10% threshold as indicated by the method.

The evaluation result of the DE.CM - Security

Continuous Monitoring category highlighted the sub-

categories DE.CM-4: Malicious code is detected and

DE.CM-5: Unauthorized mobile code is detected as

the most important and critical within this category.

Figure 5 illustrates this scenario.

0 20 40

80 100

DE.CM-2

DE.CM-7

DE.CM-6

DE.CM-3

DE.CM-1

DE.CM-8

DE.CM-5

DE.CM-4

Figure 5: DE.CM - Security Continuous Monitoring - Sub-

categories.

When comparing the results obtained with those

of other studies, a strong similarity is observed. (Mor-

eira et al., 2021) presents the following priority order

for the subcategories: DE.CM-5, DE.CM-4, DE.CM-

8, DE.CM-1, DE.CM-3, DE.CM-6, DE.CM-7, and

DE.CM-2. This order is almost identical to the results

obtained in this paper, as there was a tie in priorities

between DE.CM-5 and DE.CM-4. This indicates the

concern of managers regarding the detection of mali-

cious mobile code that can compromise an organiza-

tion’s outcomes.

In this scenario, it is possible to observe that in

the category with the highest weight, the order of im-

portance of the controls remained unchanged, unlike

what occurred in the previous category. This indicates

that, despite different methods of application, the re-

sults were consistent.

Table 6 illustrates the evaluation performed re-

garding the controls of the DE.DP - Detection Pro-

cesses category. The evaluation achieved a consis-

tency index of 3.096%, also below 10%.

Table 6: Table containing the experts’ judgment regarding

the Detection Processes Subcategory (DE.DP).

Controls DE.DP-1 DE.DP-2 DE.DP-3 DE.DP-4 DE.DP-5

DE.DP-1 X 4 5 2 6

DE.DP-2 X X 1 3 2

DE.DP-3 X X X 5 1

DE.DP-4 X X X X 3

DE.DP-5 X X X X X

The judgments of the controls in the DE.DP -

Detection Processes category highlighted DE.DP-1:

DE.DP-1: Roles and responsibilities for detection are

well deﬁned to ensure accountability is communi-

cated as the most important control in this category.

Figure 6 shows this scenario.

0 20 40

80 100

DE.DP-3

DE.DP-2

DE.DP-5

DE.DP-4

DE.DP-1

Figure 6: DE.DP - Detection Processes - Subcategories.

When comparing the evaluation of this study with

other works on the DE.DP category, both similarities

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

124

and differences are observed. (Moreira et al., 2021)

presents the following order of priorities: DE.DP-1,

DE.DP-2, DE.DP-4, DE.DP-5, DE.DP-3.

This demonstrates that both the most priori-

tized subcategory, DE.DP-1, and the least important,

DE.DP-3, held similar positions. However, the re-

maining subcategories appeared in different orders.

This same phenomenon was also observed in the eval-

uation of the DE.AE category.

After completing all alternative evaluations by the

experts, the global result was obtained through the

AHP calculation, reﬂecting the prioritization of sub-

categories based on the assigned weights and evalu-

ated criteria. This result was then analyzed in detail,

enabling the identiﬁcation of the most relevant sub-

categories within the Detect function of the CSF. The

global analysis, calculated using the AHP method,

consolidated the decisions made during the prioriti-

zation process, highlighting the critical controls that

should be implemented to strengthen the organiza-

tion’s cybersecurity.

The global scale result provided a list prioritiz-

ing the cybersecurity controls for the organization.

The list indicates which controls should be priori-

tized. Highlighted are controls DE.CM-4: Malicious

code is detected and DE.CM-5: Unauthorized mo-

bile code is detected. This suggests that the ability to

detect threats involving malicious code and unautho-

rized mobile code is a critical priority for ensuring the

early identiﬁcation of potential attacks. This empha-

sis is crucial, as failures in these areas may compro-

mise system security, allowing attacks to occur with-

out timely detection.

Subsequently, the DE.CM-8 subcategory, ”Vul-

nerability scans are performed,” achieved a score of

15%. This result highlights that the detection of

known vulnerabilities and potential system ﬂaws is

considered a critical area. The prioritization of ac-

tions aimed at conducting vulnerability scans under-

scores the importance of identifying and mitigating

weaknesses before they can be exploited, reinforcing

a proactive approach to cybersecurity.

Speciﬁcally for the categories DE.CM-1 (10%)

and DE.AE-2 (6%), which ranked fourth and ﬁfth re-

spectively, provide important insights into their rela-

tive priorities in the context of threat detection. The

10% weight of DE.CM-1 indicates that continuous

network monitoring to detect cybersecurity events is

highly relevant, though not the top priority. This

suggests that while network monitoring is crucial for

identifying incidents, other controls, such as mali-

cious code and vulnerability detection, are considered

more critical for providing immediate defense against

speciﬁc threats.

Conversely, the ﬁfth position of DE.AE-2, ac-

counting for 6%, highlights the importance of ana-

lyzing detected events not only to understand their

potential impacts but also to identify the speciﬁc tar-

gets and methods employed in the attack. Such in-

depth analysis is essential for the development of ef-

fective response and mitigation strategies. However,

despite its critical role, this aspect is assigned a com-

paratively lower priority within the broader detection

framework, relative to other mechanisms.

These rankings highlight that organizations may

focus more on direct defensive actions against known

or high-risk threats, while practices like network

monitoring and behavioral analysis provide crucial

support but are not the frontline of defense.

Among the controls with intermediate scores,

DE.DP-1 (5%) and DE.AE-3 (5%) stand out. The

control DE.DP-1, which addresses the deﬁnition of

roles and responsibilities to ensure accountability in

detection, indicates that the organization considers it

essential to clearly establish responsibilities, although

this is not a primary focus of action.

Similarly, DE.AE-3, related to the collection and

correlation of event data from multiple sources and

sensors, also scored 5%, reﬂecting the importance of

consolidating information for security event analysis.

Both controls are crucial for effective incident man-

agement, but their intermediate score suggests that the

organization has prioritized other, more critical areas,

such as the detection of malicious code.

Controls with slightly lower scores, such as

DE.CM-3 (4%), DE.CM-6 (3%), DE.CM-7 (3%),

DE.DP-4 (3%), DE.AE-4 (3%), and DE.AE-1 (3%),

also represent relevant areas. DE.CM-3, which in-

volves monitoring personnel activity, and DE.CM-

6, which concerns monitoring external service

providers’ activity, indicate that the organization ac-

knowledges the importance of overseeing human and

third-party activities, though these areas received

lower priority.

The control DE.CM-7, which relates to monitor-

ing unauthorized connections, devices, and software,

along with DE.AE-4, which determines the impact of

events, were also rated at 3%. This reﬂects that while

these activities are recognized, the organization may

be focusing on actions more directly related to threat

detection, such as those concerning malicious code

and vulnerabilities. Figure 7 illustrates the prioritiza-

tion of controls and provides a visual representation

of the scenario previously described.

Sensitivity analysis is essential for verifying the

robustness of the results obtained after applying the

AHP method, ensuring that security control decisions

are consistent and reliable. After obtaining the results,

Cybersecurity Risk Assessment Through Analytic Hierarchy Process: Integrating Multicriteria and Sensitivity Analysis

125

0 20 40

80 100

DE.AE-5

DE.DP-3

DE.DP-2

DE.DP-5

DE.CM-2

DE.AE-1

DE.AE-4

DE.DP-4

DE.CM-7

DE.CM-6

DE.CM-3

DE.AE-3

DE.DP-1

DE.AE-2

DE.CM-1

DE.CM-8

DE.CM-5

DE.CM-4

Figure 7: Scores obtained and preference order calculated

by AHP at the global level of the subcategories within the

Detect function of the NIST CSF, based on the previous

weights and judgments provided by the decision-makers.

the researchers conducted a sensitivity analysis to as-

sess how variations in the weightings of criteria could

affect the prioritization of controls. This procedure

is critical for identifying whether small changes in

decision-makers’ preferences could cause signiﬁcant

impacts on the order of control prioritization, which

would indicate an excessive sensitivity in the model.

Figure 8 shows that the DE.CM subcategories be-

gin to lose relevance when their weight is reduced to

50% of the total ”Detect” function. For the DE.AE

subcategories to become predominantly prioritized,

their weight would need to reach 84%, as indicated

by the dashed line in Figure. This contrasts with the

18% obtained in the assessment, demonstrating the

consistency and reliability of the weights assigned by

the experts. This result highlights the robustness of

the analysis and the conﬁdence in the decisions made

during the prioritization process.

Figure 9 performs the sensitivity analysis of the

weight of DE.CM - Security Continuous Monitoring

against DE.DP - Detection Processes. The analy-

sis shows a similar scenario, with a sharp decline in

the DE.CM subcategories when the weight reaches

Figure 8: Sensitivity Analysis of the Subcategories of

DE.AE - Anomalies and Events.

around 50%. For the DE.DP categories to gain promi-

nence, their weight would need to reach around 88%,

as indicated by the dashed line, compared to the 11%

obtained. These values also demonstrate the certainty

of the specialists’ choices, as the weight would need

to increase signiﬁcantly for the subcategories to gain

prominence.

Figure 9: Sensitivity Analysis of the Subcategories of

DE.DP - Detection Processes.

The sensitivity analyses of DE.CM against the

other two categories, DE.AE and DE.DP, conﬁrm the

robustness and certainty of the experts’ choices. Both

analyses show a clear and consistent pattern, with

DE.CM subcategories losing relevance only when

their weight is signiﬁcantly reduced, while DE.AE

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

126

and DE.DP would need a substantial increase in

their weights—84% and 88%, respectively—to gain

prominence. This demonstrates that the data and eval-

uations were consistent, providing a solid foundation

for the prioritization process and reinforcing the re-

liability of the experts’ judgments in the decision-

making process.

All stages of the AHP methodology were success-

fully completed, from deﬁning the problem and struc-

turing the hierarchy of criteria to conducting the pair-

wise comparisons and synthesizing the results. The

successful execution of each phase, supported by con-

sistent and robust outcomes from the sensitivity anal-

yses, conﬁrms that the AHP approach was effectively

implemented. This ensures a reliable framework for

prioritizing cybersecurity controls, providing valu-

able guidance for decision-making in the manage-

ment of cybersecurity risks.

The prioritized list of controls for the ”Protect”

function of the NIST Cybersecurity Framework, pre-

viously applied using the AHP method, adheres to the

principle of Best Available Information in risk man-

agement. By employing AHP, the decisions regarding

control prioritization are based on a thorough and sys-

tematic analysis of the most relevant and up-to-date

information available concerning the organization’s

security environment.

It is essential to regularly perform the AHP ap-

plication procedure to ensure effective management

of cybersecurity risks and maintain adherence to the

principle of Continuous Improvement. Cybersecu-

rity threats, both internal and external, are constantly

evolving, requiring ongoing adjustments to defense

strategies. By periodically reapplying AHP, the orga-

nization can reassess and update its control priorities,

ensuring they remain aligned with the current threat

landscape. This process enables a swift and efﬁcient

response to emerging risks, optimizes resource alloca-

tion, and strengthens the organization’s cybersecurity

resilience in the face of evolving security challenges.

Through the information gathered and the created

list, a new principle of risk management was also ad-

dressed, which is the principle of the best available

information. It is important to emphasize that, for an-

other principle to be addressed—the principle of Con-

tinuous Improvement—this process must always be

repeated as the internal and external factors of the or-

ganization inﬂuence the company’s objectives.

5 CONCLUSIONS

The proposed model effectively developed a risk as-

sessment based on the cybersecurity controls outlined

in the CSF. By applying the AHP method, a prior-

itized list was generated based on expert judgment,

with the goal of supporting public managers in their

decision-making processes. This list is crucial in de-

termining the order in which cybersecurity controls

should be implemented, optimizing resource alloca-

tion and ensuring that critical risks are addressed ﬁrst.

The simulation using the AHP method revealed

that the ﬁve most critical CSF subcategories for the

organization are those related to the detection and

monitoring of malicious codes and vulnerabilities.

This highlights the major concerns of both experts and

managers, indicating a clear focus on proactive threat

detection and vulnerability management. These re-

sults demonstrate the alignment of the experts’ prior-

ities with the current cybersecurity landscape, where

early threat detection and mitigation are essential for

organizational resilience.

Moreover, the AHP method proved to be a power-

ful decision-making tool, allowing managers to conﬁ-

dently allocate resources and prioritize cybersecurity

actions based on a structured, data-driven approach.

The ability of AHP to reduce biases and provide a

consistent framework for evaluating expert judgments

reinforces its value in ensuring that decisions are

made transparently and systematically. The applica-

tion of AHP, as recommended by ISO 31000, adhered

to the eight principles of risk management—ensuring

a balanced, thorough, and reliable risk assessment

process. These principles include context establish-

ment, structured decision-making, stakeholder en-

gagement, and continuous improvement, all of which

were successfully addressed by the AHP model.

Additionally, AHP demonstrated that it is partic-

ularly valuable for public sector information security

managers in Brazil. In conjunction with other security

frameworks, such as PPSI, AHP can assist public ad-

ministrators in prioritizing cybersecurity controls that

are most relevant to their speciﬁc context. This ca-

pability makes AHP a versatile tool that can be tai-

lored to ﬁt various risk management frameworks, pro-

viding a strong foundation for effective cybersecurity

risk management in government institutions. Thus,

the continuous use of this approach can contribute to

the development of more robust and dynamic security

policies, capable of keeping up with the rapid changes

in the technological and threat landscape. In this way,

AHP can establish itself as an essential tool for the ef-

ﬁcient management of cybersecurity risks in the pub-

lic sector.

Cybersecurity Risk Assessment Through Analytic Hierarchy Process: Integrating Multicriteria and Sensitivity Analysis

127

ACKNOWLEDGMENTS

The authors would like to thank the technical

and computational support provided by the LATI-

TUDE Laboratory of the University of Bras

ılia, TED

01/2021 of the National Secretariat for Social As-

sistance – SNAS/DGSUAS/CGRS, TED 01/2021 of

the General Coordination of Information Technology

(CGTI) of the Attorney General’s Ofﬁce of the Na-

tional Treasury – PGFN, the SISTER City Project –

Secure and Real-Time Intelligent Systems for Smart

Cities (Grant 625/2022), the Project Control and

Uniﬁcation System of Projects for the Federal Dis-

trict Government – Sispro-DF (Grant 497/2023), the

Project Research, Development and Application –

Methodology to Support the Elicitation of Ethical and

Privacy Requirements (Grant 514/2023), the Dean’s

Ofﬁce of Research and Innovation – DPI/UnB and

FAP/DF.

REFERENCES

Alves, R. S., Georg, M. A. C., and Nunes, R. R. (2023).

Judici

ario sob ataque hacker: riscos de neg

ocio para

seguranc¸a cibern

etica em tribunais brasileiros. Revista

erica de Sistemas e Tecnologias de Informac¸

ao,

(E56):344–357.

Bitton, R., Maman, N., Elovici, Y., Shabtai, A., Singh, I.,

and Momiyama, S. (2021). Evaluating the cyberse-

curity risk of real-world, machine learning production

systems. ACM Computing Surveys (CSUR).

BRASIL (2023). PORTARIA SGD/MGI Nº 852, DE 28 DE

MARC¸ O DE 2023. Brazilian legislation.

Brigido, W. J. H., Miranda, J. P. C. T. D., and Monteiro, S.

B. S. (2022). Risk-based resource allocation apply-

ing ahp-topsis. In 2022 17th Iberian Conference on

Information Systems and Technologies (CISTI), pages

1–6.

Canedo, E. D., do Vale, A. P. M., Gravina, R. M., Patr

ao,

R. L., de Souza, L. C., dos Reis, V. E., de Mendonc¸a,

F. L. L., and de Sousa Jr., R. T. (2021). An applied

risk identiﬁcation approach in the ICT governance

and management macroprocesses of a brazilian

federal government agency. In Filipe, J., Smialek,

M., Brodsky, A., and Hammoudi, S., editors, Pro-

ceedings of the 23rd International Conference on

Enterprise Information Systems, ICEIS 2021, Online

Streaming, April 26-28, 2021, Volume 1, pages 272–

279, https://doi.org/10.5220/0010475902720279.

SCITEPRESS.

Chang, C.-W., Wu, C.-R., Lin, C.-T., and Chen, H.-C.

(2007). An application of ahp and sensitivity analy-

sis for selecting the best slicing machine. Computers

& Industrial Engineering, 52(2):296–307.

CNN Brasil (2023). Ataques hackers aumentam 88% no

brasil, e pa

ıs segue como 2º mais atacado do mundo.

Accessed: August 17, 2024.

Creative Decision Foundation (2012). Super decision soft-

ware for decision making. [Online]. Available: http:

//www.superdecisions.com.

Divino, S. B. S. and Campos, B. (2024). Comunicac¸

de incidentes de seguranc¸a na lei geral de protec¸

de dados: A deﬁnic¸

ao do prazo mediante an

alise de

impacto regulat

orio como instrumento indispens

avel

ao enforcement da autoridade nacional de protec¸

ao de

dados. Revista Direitos Sociais e Pol

ıticas P

ublicas

(UNIFAFIBE), 12(1):84–104.

ISO/IEC (2018). ISO/IEC 31000:2018: Risk management

— Guidelines.

ISO/IEC (2019). ISO 31010:2019 - Risk Management

— Risk Assessment Techniques. Available at https:

//www.iso.org/standard/72140.html.

ISO/IEC (2022). Information Security, Cybersecurity and

Privacy Protection (ISO/IEC 27002:2022).

Moreira, F. R., Filho, D. A. D. S., Nze, G. D. A.,

de Sousa J

unior, R. T., and Nunes, R. R. (2021). Eval-

uating the performance of nist’s framework cyberse-

curity controls through a constructivist multicriteria

methodology. IEEE Access, 9:129605–129618.

NIST (2018). Cybersecurity Framework V1.1 - Frame-

work for Improving Critical Infrastructure Cyberse-

curity (Version 1.1). Technical report, National Insti-

tute of Standards and Technology, Gaithersburg, MD,

USA.

Ru, Y. et al. (2016). Risk assessment of cyber attacks in

ecps based on attack tree and ahp. In 2016 12th Inter-

national Conference on Natural Computation, Fuzzy

Systems and Knowledge Discovery (ICNC-FSKD),

pages 465–470.

Saaty, T. L. (1980). The Analytic Hierarchy Process.

McGraw-Hill, New York, NY, USA.

Siregar, I. M., Putri, L. W. B., and Sugihartono, T. (2024).

Sensitivity analysis of various ahp process: A case

study on consumption ﬁsh farming. Jurnal Sisfokom

(Sistem Informasi dan Komputer), 13(2):216–223.

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

128
