the upper limbs separately from all effects of natural
hypergravity, which also includes acceleration that
has a strong effect on the cardiovascular system by its
own. Introducing forces by active exoskeletons could
be used to analyze whether the effects seen in HR and
HRV are caused by the increased force or by the
acceleration acting on the cardiovascular system. This
would make it possible to differentiate between the
effects of force exposure and force exposure
including circulatory stress (e.g., blood displacement
due to acceleration in SAHC). On the other hand, this
could also be a limitation since it could also be helpful
to train the cardiovascular system and all other organs
to be in hypergravity, which is not possible by using
an active upper body exoskeleton.
5 CONCLUSIONS
In this paper we analyzed the current state on research
investigating the effects of hypergravity on the human
body and in particular on cognition, cardiovascular
activity, muscle activity and fine motor skills
analyzing cognitive (EEG, ECG) and motor
performance (EMG, aiming accuracy). Our survey
shows that all parameters are changing under
hypergravity conditions. It is important to further
investigate how and, above all, why the
aforementioned parameters change in hypergravity,
as there are currently only a few studies on this. In our
future work, we want to test an active exoskeleton for
the upper limbs to simulate hypergravity as a novel
training method for astronauts to prepare them for the
different gravity conditions already during training on
Earth. Such intensive training could reduce the
workload under real hypergravity and the adaptation
time to it, which could make working in safety-
critical environments safer from the start.
ACKNOWLEDGEMENTS
The work is supported by the German Federal
Ministry for Economic Affairs and Climate Action
(BMWK) under the grant number FKZ 50RP2340A
in the project VASKuM.
REFERENCES
Aoyama, T., & Kohno, Y. (2020, July 20). Temporal and
quantitative variability in muscle electrical activity
decreases as dexterous hand motor skills are learned.
PlosOne.
Artiles, A. D., Schor, D., & Clément, G. (2018). Effects of
inverted vision on hand-pointing performance in altered
gravity during parabolic flight. IEEE Xplore. USA.
Badalì, C., Wollseiffen, P., & Schneider, S. (2023,
September). Under pressure-the influence of
hypergravity on electrocortical activity and
neurocognitive performance. xp Brain Res.
Bock, O., Arnold, K., & Cheung, B. (1996, February).
Performance of a simple aiming task in hypergravity: I.
overall accuracy. Aviat Space Environ Med.
Bütefür, J., Trampler, M., & Kirchner, E. (2024).
Evaluation of Gel and Dry Electrodes for EEG
Measurement to Compare Their Suitabiloty for
Multimodal Worklaod Detection in Humans.
Proceedings of the 17th International JOint Conference
on Biomedical Engineering Systems and Techologies -
Volume 1, ISBN 978-989-758-688-0, pp. 747-754.
Bütefür, J., Trampler, M., & Kirchner, E. (2024,
Decemeber). Technical Test of a Dry Electrode Headset
for EEG Measurement in Microgravity. In M. Guarino,
Biomedical Engineering Systems and Technologies.
BIOSTEC 2024. Communications in Computer and
Information Science. Springer (to be published).
Chen, Y., Mori, S., Koga, K., Ohta, Y., Wada, Y., &
Tanaka, M. (1999, June). Shift in arm-pointing
movements during gravity changes produced by aircraft
parabolic flight. Biol Sci Space.
Clark, T., Newman, M., Merfeld, D., & Young, L. (2014).
Pilot control and stabilization of a rate-controlled
vehicle in hyper-gravity. IEEE Xplore.
Debie, E., Rojas, R., Fidock, J., Barlow, M., Kasmarik, K.,
Anavatti, S., . . . Abbass, H. (2021). Multimodal Fusion
for Objective Assessment of Cognitive Workload: A
Review. IEEE Transactions on Cybernetics, No. 51,
Vol. 3, pp. 1542 - 1555.
Frett, T., Petrat, G., van Loon, J. J., Hemmersbach, R., &
Anken, R. (2016, June). Hypergravity Facilities in the
ESA Ground-Based Facility Program – Current
Research Activities and Future Tasks. Spinger Nature.
Habenicht, J., & Kirchner, E. A. (2024). Preliminary
Results on the Evaluation of Different Feedback
Methods for the Operation of a Muscle-Controlled
Serious Game. 17th International Conference on Bio-
inspired Systems and Signal Processing. Rom.
Habenicht, J., Tabie, M., Will, N., & Kirchner, E. A. (2022).
Survey on studies investigating the effect of simulated
microgravity on the musculoskeletal system.
International Anstronautical Congress. Paris.
Honkanen, T., Oksa, J., Mäntysaari, M., Kyröläinen, H., &
Avela, J. (2017, February). Neck and Shoulder Muscle
Activation Among Experienced and Inexperienced
Pilots in +Gz Exposure. Aerosp Med Hum Perform.
Kirchner, E., Will, N., Simnofske, M., Benitez, L.,
Bongardt, B., Krell, M. M., . . . Kirchner, F. (2016).
Recupera-Reha: Exoskeleton Technology with
Integrated Biosignal Analysis for Sensorimotor
Rehabilitation. . Conference: 2. Transdisziplinäre
Konferenz "Technische Unterstützungssysteme, die die
