A Data Annotation Approach Using Large Language Models
Carlos Rocha
a
, Jonatas Grosman
b
, Fernando A. Correia
c
, Venicius Rego
d
and H
´
elio Lopes
e
Department of Informatics, PUC-Rio, Marqu
ˆ
es de S
˜
ao Vicente, 225 RDC, 4th floor - G
´
avea, Rio de Janeiro, Brazil
Keywords:
Data Annotation, Large Language Model, Visual Question-Answering, Documents, Machine Learning.
Abstract:
Documents are crucial for the economic and academic systems, yet extracting information from them can be
complex and time-consuming. Visual Question Answering (VQA) models address this challenge using natural
language prompts to extract information. However, their development depends on annotated datasets, which
are costly to produce. To face this challenge, we propose a four-step process that combines Computer Vision
Models and Large Language Models (LLMs) for VQA data annotation in financial reports. This method starts
with Document Layout Analysis and Table Structure Extraction to identify document structures. Then, it uses
two distinct LLMs for the generation and evaluation of question and answer pairs, automating the construction
and selection of the best pairs for the final dataset. As a result, we found Mixtral-8x22B and GPT-4o mini to
be the most cost-benefit for generating pairs, while Claude 3.5 Sonnet performed best for evaluation, aligning
closely with human assessments.
1 INTRODUCTION
Data annotation is essential for developing supervised
machine learning models, especially in Natural Lan-
guage Processing (NLP) and Computer Vision (CV).
The quality of these models relies on large volumes
of labeled data for tasks like document comprehen-
sion and interpretation. Document Visual Question
Answering (DocVQA) exemplifies this by combining
NLP and CV to enable models to interpret document
images, leveraging textual and visual features to allow
interaction with document information through natu-
ral language queries.
Training DocVQA models requires thousands of
carefully reviewed and annotated document pages
(Mathew et al., 2021). This annotation and re-
view process is time-consuming and costly, primar-
ily due to the significant human resources needed. To
meet this demand, the literature often employs non-
expert annotators through crowd-sourcing platforms
like Amazon Mechanical Turk (Mathew et al., 2021;
Mathew et al., 2022). However, using such plat-
forms presents significant challenges and limitations,
including inconsistent annotation quality and the ad-
a
https://orcid.org/0009-0004-9696-330X
b
https://orcid.org/0000-0002-1152-5828
c
https://orcid.org/0000-0003-0394-056X
d
https://orcid.org/0000-0002-7101-4608
e
https://orcid.org/0000-0003-4584-1455
ditional effort required for review and validation, in-
creasing both cost and time (Kittur et al., 2008).
DocVQA models are used in domains like scien-
tific research, insurance, and finance for tasks such
as entity relationship identification, policy compre-
hension, fraud detection, and financial data extrac-
tion. Financial reports, such as those from the Brazil-
ian Stock Market (Brasil Bolsa Balc
˜
ao - B3)
1
, are
a valuable data source. In B3, 2,706 companies
are mandated by the Brazilian Securities and Ex-
change Commission, or Comiss
˜
ao de Valores Mo-
bili
´
arios (CVM),
2
to publish annual balance sheets,
quarterly reports, and other information, reflecting
similar frameworks as the Securities and Exchange
Commission (SEC)
3
in the U.S. and European Secu-
rities and Markets Authority (ESMA)
4
in the EU.
Although these financial reports are public, they
lack structured annotated data, requiring solutions to
the data annotation challenge. One approach is us-
ing Large Language Models (LLMs) as annotators
to generate labels in a zero-shot or few-shot manner.
While promising, this method introduces noise, par-
ticularly in complex, domain-specific tasks (Agrawal
et al., 2022). Given their remarkable capability in text
annotation, LLMs can automate the creation of anno-
1
https://www.b3.com.br/
2
https://www.gov.br/cvm/en
3
https://www.sec.gov/
4
https://www.esma.europa.eu/
748
Rocha, C., Grosman, J., Correia, F. A., Rego, V. and Lopes, H.
A Data Annotation Approach Using Large Language Models.
DOI: 10.5220/0013280100003929
Paper published under CC license (CC BY-NC-ND 4.0)
In Proceedings of the 27th International Conference on Enterprise Information Systems (ICEIS 2025) - Volume 1, pages 748-755
ISBN: 978-989-758-749-8; ISSN: 2184-4992
Proceedings Copyright © 2025 by SCITEPRESS – Science and Technology Publications, Lda.

tated question-answer datasets for DocVQA. Lever-
aging this generalist capability can significantly re-
duce time and cost, leading to our main research ques-
tion: MRQ: How can we use Large Language Models
in data annotation for Document Visual Question An-
swering task?.
To address MRQ, the approach must handle di-
verse document layouts, ensuring readable text repre-
sentation and reliable, high-quality question-answer
pairs for effective model training. This leads to two
sub-questions: RQ1: How can we combine computer
vision models and Large Language Models to gen-
erate questions and answers from documents?, and
RQ2: How can we assess the quality of the questions
and answers generated?.
We propose a three-stage process: (i) Tran-
scription, (ii) Question-Answer Generation, and (iii)
Question-Answer Judgment. First, we transcribe the
document page by recognizing the characters and the
layout’s main points and converting the tables into
a markup language. The transcriptions are then in-
putted into an LLM to generate QA pairs, followed by
a final stage where another LLM evaluates the quality
of these pairs for inclusion in the final dataset.
Our work’s main contributions are the following:
• We present a new approach for generating and
evaluating question-answer pairs in documents
that contain both text and tables.
• We contribute by evaluating different models for
Document Layout Analysis and Table Structure
Recognition to extract information from B3’s fi-
nancial reports.
The remainder of this paper is organized as fol-
lows: Section 2 reviews key works on DocVQA
dataset construction and LLM data annotation. Sec-
tion 3 outlines our method and its stages. Section 4
details the experiments validating the models and ap-
proach. Finally, Section 5 highlights findings, limita-
tions, and future work.
2 RELATED WORK
DocVQA requires a labeled dataset for effective
model training as in any supervised machine learning
task. High-quality data helps models interpret various
textual, structural, and graphical elements in a docu-
ment. (Mathew et al., 2021) introduced a dataset with
complex documents containing 50,000 questions over
12,767 images, curated from the UCSF Industry Doc-
ument Library and annotated through a three-stage
crowdsourced process of question generation, valida-
tion, and review. Our approach is similar to (Mathew
et al., 2021) but with fewer questions per page, ad-
justed validation, and using an LLM to judge the QA
pairs generated.
LLMs have been explored for efficient annota-
tion in NLP. (Wang et al., 2021) showed GPT-3 sig-
nificantly reduced costs in question generation while
maintaining human-like quality. Our work aligns with
theirs, focusing on financial reports in QA annotation
with LLMs. For complex table data, (Nguyen et al.,
2023) converted tables to HTML and dataframes for
QA input. Given LLMs tendency to hallucinate, ques-
tion validity is crucial. (Bai et al., 2024) introduced a
benchmarking framework where LLMs both generate
and evaluate questions, reducing biases via decentral-
ized peer evaluation. Larger models like LLaMA-65B
and GPT-4 showed enhanced accuracy in this setup.
We adopt this evaluation framework using LLMs to
assess annotations, filtering errors and improving au-
tomation without human intervention.
3 METHODOLOGY
As depicted in Figure 1, the process consists of three
stages: (i) Transcription, (ii) Question-Answer Gen-
eration, and (iii) Question-Answer Judgment. The
transcription stage generates a textual representation
of document files and feeds an LLM to generate QA
tuples in the second stage. Finally, the same transcrip-
tion and the generated QA tuples feed another LLM
to select the valid tuples to compose the dataset.
3.1 Transcription
The process begins with the Transcription Stage,
where a document file is received and the desired
pages are extracted as images for subsequent steps.
An OCR tool is then applied to transcribe the textual
content of these images.
Given the importance of OCR and the lack of an-
notated data for training and evaluating open-source
tools, we selected Microsoft OCR V4.
5
This choice
was based on the work of (Santos et al., 2023),
whose evaluation of various OCR tools on diverse
Portuguese text images showed that the Microsoft
model outperformed all other evaluated models, de-
livering solid results even with different backgrounds
and text rotation levels.
The Document Layout Analysis (DLA) step uses
an object detection model for structure recognition.
Object detection models can generally identify which
5
https://azure.microsoft.com/en-us/products/ai-
services/ai-document-intelligence
A Data Annotation Approach Using Large Language Models
749

Figure 1: Proposed process overview.
objects from a known set are present in the image
and provide information about their position. In our
case, the objects are document segments like tables,
images, and section headers, with the DLA model re-
turning the bounding boxes of the segments.
After segmentation, the identified regions were
stored in a data structure containing their bounding
boxes, the detected class, positional information, and
the textual content detected by the OCR tool. The in-
tersection of the text and region bounding boxes was
calculated to determine if the text was within a spe-
cific region. Given the variety of available DLA mod-
els, we selected models from the literature and per-
formed experiments to choose the best one, which we
describe in more detail in Subsection 4.1.
The Table Structure Recognition (TSR) step uses a
second object detection model to segment table struc-
tures, detecting rows and columns as bounding boxes
and defining cells based on the intersections. Next,
a separate algorithm converts these bounding boxes
into HTML. As with the DLA step, multiple models
are available. So, we reviewed models from the lit-
erature and conducted experiments to select the best
one, detailed in Subsection 4.2.
At the end of the Transcription stage, the docu-
ment image transcription is modified to include posi-
tional markers. These markers identify the transcript
regions used to generate a QA pair. For text regions,
we add the paragraph number; for table regions, we
add the table number and the number of each row.
3.2 Question-Answer Generation
The modified document transcription from the pre-
vious step is input into the selected LLM for the
Question-Answer Generation stage, along with gen-
eration instructions.
6
These instructions include the
coherence standards the model should follow, rules
6
Generation instructions available on Github:
https://github.com/carlos-vinicios/DocVQA-Data-
Annotator
for using relative pronouns, the number of desired tu-
ples, the focus area, and the key elements to include
in the output. The prompt also provides positive and
negative examples to guide the generation process.
Finally, the expected output of this stage is a textual
format divided into three parts: QUESTION - AN-
SWER - TEXT REGION. The first two form the QA
tuple, while the third is a positional marker indicating
the text region used for generation.
3.3 Question-Answer Judgment
Finally, the objective of the Question-Answer Judg-
ment stage is to ensure that the generated questions
and answers are coherent and correct, filtering out
possible hallucinations from the generating model
and increasing the quality of the final dataset. This
stage also receives as input the transcript of the doc-
ument, without the positional markers, together with
the evaluation instructions,
7
specifying the criteria
for evaluating the questions and answers.
Each QA tuple judgment uses two calls to the
LLM. The first call evaluates the coherence of the
question, which is considered coherent if the ques-
tions comply with the correct use of the grammatical
rules of the Portuguese language and have only one
answer. The second call evaluates the answer to see if
it answers the question. Since each QA tuple is evalu-
ated individually, the process described is carried out
in 3 iterations per document page. The expected out-
put for each iteration is binary, confirming or denying
the coherence of the question and the validity of the
provided answer.
7
Evaluation instructions available on Github:
https://github.com/carlos-vinicios/DocVQA-Data-
Annotator
ICEIS 2025 - 27th International Conference on Enterprise Information Systems
750

4 EXPERIMENTS
This section describes the experiments conducted fol-
lowing the proposed process. We begin with the ex-
perimentation of the transcription stage, where we
evaluated available DLA models from the literature
using a dataset created during this study. Next, we as-
sessed open-source TSR models, testing them on four
datasets to measure their generalization capabilities.
After the transcription stage, we proceeded to evalu-
ate various LLMs for the QA generation stage. Fi-
nally, we assessed the most robust LLMs for the QA
tuple judgment stage.
4.1 Document Layout Analysis (DLA)
To evaluate the DLA models, we built an annotated
dataset using a process similar to the creation of the
DocLayNet dataset (Pfitzmann et al., 2022). The val-
idation dataset consisted of 990 randomly selected
pages from financial statements, focusing on central
pages that typically contain text, tables, and images.
Two annotators independently annotated each
page, following DocLayNet’s criteria, and reviewed
each other’s work to improve consistency. The Model
evaluation was based on the Mean Average Precision
(mAP), a standard metric for object detection and seg-
mentation. The average Precision (AP) was calcu-
lated for each class as the area under the precision-
recall curve. The model selection followed two main
criteria: it needed to be trained on the DocLayNet
dataset and be open-source, providing access to its
weights for evaluation and modification.
Table 1 shows the mAP performance for each
class. RoDLA achieved the highest overall perfor-
mance, excelling in handling diverse document types
and perturbations. Malaysia-AI performed well in
most classes, especially in detecting tables and text,
benefiting from advanced data augmentation tech-
niques despite using the same architecture as Maik
Thiele. SwinDocSegmenter, although computation-
ally demanding, showed lower performance than
Malaysia-AI, which can run efficiently on a CPU.
In conclusion, RoDLA is the best choice for the
DLA task. While it has a longer execution time, its
superior ability to identify diverse document regions
ensures more accurate layout segmentation,
4.2 Table Structure Recognition (TSR)
Building a specific dataset for TSR model evaluation
is unfeasible due to the high time cost of data anno-
tation and refinement, wich involves marking column
and row bounding boxes, transcribing table text, and
creating the HTML structure. Three datasets were se-
lected for TSR evaluation to address this. The first
is PubTabNet, with around 500,000 table images and
their HTML equivalents for the structural recogni-
tion of tables (Zhong et al., 2020). FinTabNet, which
focuses on financial documents, provides annotated
data for table extraction and conversion to HTML
(Zheng et al., 2021). Finally, the ICDAR 2013 Table
Competition dataset serves as a benchmark for this
task(G
¨
obel et al., 2013).
We used TEDS-Struct, a variant of Tree-Edit-
Distance-based Similarity (TEDS) (Zhong et al.,
2020), to evaluate table extraction model perfor-
mance. Unlike the original TEDS, which assesses
structure and text alignment, TEDS-Struct focuses
solely on the HTML structure, ignoring transcription
errors (Qiao et al., 2021), making it suitable for this
work. For TSR model selection, we identified open-
source models capable of table-to-HTML conversion
from table images. Four models were chosen: Ta-
ble Transformer (TATR) (Smock et al., 2022); MLT-
TabNet (Ly and Takasu, 2023); Table Master (Ye
et al., 2021), and Local and Global Pyramid Mask
Alignment (LGPMA) (Qiao et al., 2021).
Table 2 shows the results for each tested model.
Although no model excelled across all datasets, TATR
All and MLT-TabNet demonstrated the best general-
ization abilities, with TATR All achieving the best
performance on the ICDAR 2013 benchmark dataset.
The findings suggest models trained on the FinTab-
Net dataset exhibit superior generalization, likely due
to the dataset’s complexity and variety of examples
featuring different degrees of customization. In con-
trast, PubTabNet is limited to tables from scientific
publications, offering less diverse training data.
Given its extraction performance, TATR All is the
best model for this work. It showed strong gener-
alization abilities, performing well across all tested
datasets, was the fastest model, and the only one ca-
pable of maintaining a low execution time on CPU.
4.3 Question-Answer Generation
We selected models based on cost-benefit, consider-
ing the token usage required to complete the task.
As this stage generates the most output tokens, it is
the main cost driver. On average, document tran-
scriptions and task instructions use 3, 471(±1080) in-
put tokens, while the question, answer, and positional
marker produce 170(±36) output tokens.
Figure 2 shows the quality and cost (USD per mil-
lion tokens) of the main available models, assuming a
3:1 ratio of input to output tokens. The price format
and quality were based on (Analysis, 2024). In the
A Data Annotation Approach Using Large Language Models
751

Table 1: mAP performance for each class and model on a constructed dataset. The best performance is formatted in boldface.
Class
RoDLA
(Chen et al., 2024)
Malaysia-AI
(Malaysia-AI, 2024)
SwinDocSegmenter
(Banerjee et al., 2023)
Maik Thiele
(Maik Thiele, 2024)
Caption 0.302 0.015 0.067 0.127
List Item 0.860 0.741 0.676 0.642
Picture 0.749 0.413 0.569 0.524
Text 0.979 0.910 0.776 0.901
Footnote 0.735 0.486 0.345 0.254
Page Footer 0.911 0.446 0.621 0.435
Section Header 0.776 0.490 0.391 0.346
Title 0.007 0.015 0.003 0.003
Formula - - - -
Page Header 0.870 0.476 0.485 0.447
Table 0.975 0.955 0.899 0.906
All 0.716 0.495 0.483 0.459
Table 2: TEDS-Struct performance by model on each
dataset. The best performance is formatted in boldface.
Model FinTabNet PubTabNet
ICDAR
2013
TATR All 0.92 0.93 0.94
TATR Fin 0.92 0.88 0.91
MLT-TabNet 0.97 0.90 0.91
TableMaster 0.80 0.97 0.90
LGPMA 0.41 0.96 0.91
Figure 2: Quality vs Price for the main LLM models avail-
able via a pay-per-use API. The price of each model was
collected in August 2024.
Figure, models are grouped into four quadrants: high
quality and high cost, high quality and low cost, rea-
sonable quality and low cost, and lower-performing
models with varying costs.
Based on the average token requirements and the
price-quality balance in Figure 2, we selected models
from the second and third quadrants: GPT-4o mini,
LLaMA 3 70B, Mixtral 8x22B, Gemini 1.5 Flash, and
Claude 3 Haiku. LLaMA 3.1 405B, the best but most
expensive open-source model, was excluded from this
stage and reserved for the third stage of our process.
For the question generation experiments using
LLM, we created a dataset of 300 randomly selected
non-consecutive pages, which feature only text, only
tables or a mixture of both. The tables have different
structures and sizes, so the complexity of interpreting
each one varies, with larger tables being more com-
plex. The information on each page may neither start
nor end within that page.
The first experiment assessed the distribution of
questions based on their initial 3-grams. The goal
was to evaluate the models’ ability to generate di-
verse questions. Figure 3 shows the distribution of
the generated questions, where each level represents
the most frequent words in the natural reading order.
Thus, the first level corresponds to the first word of
the question, the second level to the second word, and
so on. For example, Mixtral 8x22B frequently starts
questions with “Qual foi” (“What was”) or “Qual
´
e
o” (“What is the”), while empty regions at the second
level indicate infrequent words.
Most models used at least five different interrog-
ative pronouns, but Cluade 3 Haiku and Gemini 1.5
Flash showed less variety, favoring a more conser-
vative question phrasing approach. Also, most mod-
els favored using “Qual” (“What”) as the interroga-
tive pronoun, likely due to its adaptability in various
contexts. This pattern aligns with human-generated
questions, as demonstrated by (Mathew et al., 2021).
“Quanto” (“how much” or “how many”) was the
second most frequently used pronoun, linked to the
prevalence of tables in the selected pages. Lastly,
“Quando” (“when”) and “Quem” (“Who”), though
not explored equally by all models, were employed
by GPT-4o mini and Mixtral-8x22B.
Based on the variation, GPT-4o mini and Mixtral-
8x22B showed the most promise for question gen-
eration. Considering the cost-performance trade-off,
Mixtral-8x22B is the optimal choice, being open-
ICEIS 2025 - 27th International Conference on Enterprise Information Systems
752

Figure 3: Distribution of questions by their starting 3-
grams.
source and offering strong performance at a lower
cost. To evaluate the quality of the questions and an-
swers generated by the models, we conducted a hu-
man evaluation with 28 voluntary annotators. They
assessed each QA tuple using a web tool developed
for this research. Annotators evaluated the coherence
of the questions, ensuring they were understandable,
adhered to Portuguese language norms, and were free
of ambiguity. If the question was coherent, they vali-
dated whether the answers were correct based on the
document information. The validation process was
binary: annotators responded ”yes” or ”no” for both
criteria. A question was considered valid if it was co-
herent and the answer was correct.
The evaluation was conducted in batches of 10
pages, with each page containing three QA tuples.
Annotators reviewed each page individually. Some
annotators were responsible for more than one batch
due to the number of annotators and available files.
To maintain consistency, each batch was reviewed by
at least three distinct annotators and inter-annotator
agreement was measured.
The average percent inter-annotator agreement is
0.84 (±0.29) for question coherence and 0.84 (±0.28)
for response accuracy. Based on this high level of
agreement and the number of annotators, we retained
all annotations and used them to validate the models.
Table 3: Question coherence, answer accuracy, and QA tu-
ples valid proportion for each LLM.
Model
Question
Coherence
Answers
Accuracy
QA Tuples
Valid
LLaMA 3 70B 0.89 0.97 0.87
Mixtral 8x22B 0.89 0.95 0.85
Gemini 1.5 Flash 0.93 0.91 0.84
GPT-4o mini 0.83 0.97 0.81
Claude 3 Haiku 0.85 0.94 0.79
Using this dataset, we evaluated the model per-
formance based on the proportion of coherent ques-
tions and correct answers in the QA tuples. Table 3
shows that LLaMA 3 70B generated 0.89 coherent
questions, of which 0.97 had correct answers, yield-
ing 0.87 valid tuples. For all models, the final dataset
included only tuples with coherent questions and ac-
curate answers.
The results showed that LLaMA 3 70B excelled in
coherence and accuracy, while Mixtral-8x22B main-
tained strong performance with higher QA tuple gen-
eration. Gemini 1.5 Flash was less consistent, par-
ticularly in answer accuracy, and Claude 3 Haiku dis-
played the highest variation, indicating randomness in
its generation process. GPT-4o mini was stable with
increased tuple output. Overall, LLaMA 3 70B and
Mixtral-8x22B were the most effective models.
4.4 Question-Answer Judgment
For the QA judgment stage, we prioritized high-
quality models, as this step is crucial for filtering out
invalid questions automatically. To ensure accurate
assessment of the generated QA tuples, we needed
models with strong general task performance and the
ability to understand document transcriptions to en-
sure accurate evaluations and reliable use of the gen-
erated tuples.
At this stage, cost primarily stems from input to-
kens, as the instruction prompt is resent for each
QA tuple evaluation. The average input size was
2261.33 ± 819.75 tokens, while the output averaged
2.67 ± 1.72 tokens. We selected three high-quality
models from the first quadrant: GPT-4o, Claude
3.5 Sonnet, and Gemini 1.5 Pro. Additionally, we
included LLaMA 3.1 405B, a leading open-source
model, to compare commercial and open-source op-
tions.
To evaluate this stage, we used the dataset cre-
ated after a human evaluation during the QA gener-
ation stage, described in Subsection 4.3. We used this
dataset to assess the judgment capabilities of the pro-
A Data Annotation Approach Using Large Language Models
753

Figure 4: Confusion matrix between LLM and human for
the validity of a QA tuple. The human annotation is consid-
ered the true label.
posed approach by comparing the performance of an
LLM and a human annotator. As in the second stage
(Question-Answer Generation), we used Langchain
to normalize the API calls, setting the temperature to
zero and all the other parameters to default. The LLM
judgment of QA tuples followed the same criteria as
the human evaluation, assessing question coherence,
adherence to Portuguese language norms, and clarity.
Models also validated answers accuracy based on the
document transcriptions. The judgment process was
binary, with the LLM responding “yes” or “no”. A
question was deemed valid if it was coherent and the
answer accurate.
After testing all models, we compared their F1
scores and alignment with human judgments for final
dataset use. All four models performed well, with F1
scores above 0.8. The best performance came from
Claude 3.5 Sonnet, which achieved the highest score
at 0.93, followed by Gemini 1.5 Pro and LLaMA 3.1
405B, both at 0.92, while GPT-4o scored 0.90.
The confusion matrix in Figure 4 reveals that all
models struggled to identify false sentences, likely
due to the higher proportion of negative samples in
the dataset, which made detecting invalid tuples more
challenging. To improve judgment performance, we
combined the models into an ensemble. In this ap-
proach, a QA tuple was considered valid only if all
models confirmed both the coherence of the question
and the accuracy of the answer. Table 4 shows the F1
obtained by each ensemble, where we can see that the
combination of models did not improve the metric,
showing a similar performance for all combinations.
Table 4: F1 score between an ensemble of LLMs and hu-
mans for the validity of a QA tuple.
Ensemble
Gemini
1.5 Pro
GPT4-o
LLaMA 3.1
405B
Claude 3.5
Sonnet
F1
1 ✓ ✓ ✓ 0.82
2 ✓ ✓ ✓ 0.82
3 ✓ ✓ ✓ 0.83
4 ✓ ✓ ✓ 0.82
5 CONCLUSION
This paper addresses the research questions by de-
veloping a data annotation process for the DocVQA
task using LLMs. To tackle the first part of RQ1,
we designed a three-step process employing CV mod-
els to extract textual representations from documents.
For the second part, we evaluated five cost-effective
LLMs for generating QA pairs based on document
transcriptions and predefined rules to ensure well-
formed questions and enable human evaluation. To
answer RQ2, we conducted a human evaluation to as-
sess the validity of QA pairs generated by each LLM,
measuring the validity-to-invalidity ratio. Addition-
ally, we evaluated four robust LLMs for automat-
ing the validation process, benchmarking their perfor-
mance against human assessments.
Our findings demonstrate that LLMs can effec-
tively generate QA pairs with a favorable validity-
to-invalidity ratio. Mixtral-8x22B and GPT-4o
mini achieved the best results, generating diverse,
instruction-compliant QA pairs with minimal in-
valid outputs, with GPT-4o mini excelling in cost-
effectiveness. For automatic QA pair validation,
Claude 3.5 Sonnet achieved the highest F1 score
(0.93) but requires further improvements to reduce
false negatives. Ensemble models were tested as an
enhancement but underperformed compared to indi-
vidual models, achieving a maximum F1 score of 0.83
with significantly higher costs, making them imprac-
tical despite a slight reduction in false positives.
5.1 Future Works and Limitations
As discussed earlier, the process occasionally fails in
the validity judgment of QA pairs. To improve the
validity judgment of QA pairs, we plan to introduce a
review score for each generated pair in future works.
This score will help identify questions requiring hu-
man review, minimizing false positives and negatives
while enhancing dataset robustness. Additionally, we
intend to conduct a qualitative assessment of question
relevance and structure, expanding our focus beyond
ICEIS 2025 - 27th International Conference on Enterprise Information Systems
754

validity analysis to ensure alignment with the target
domain.
Given the process’s reliance on document tran-
scription, we also aim to investigate the impact of
transcription errors on question generation. This anal-
ysis will provide insights into model performance un-
der such conditions and inform strategies to mitigate
these effects. Ultimately, we aim to produce a fully
annotated dataset using the proposed process, estab-
lish baselines with state-of-the-art DocVQA models,
and evaluate the process’s strengths and limitations
for further refinement.
ACKNOWLEDGMENTS
This study was supported by the Coordenac¸
˜
ao de
Aperfeic¸oamento de Pessoal de N
´
ıvel Superior -
Brasil (CAPES) - Finance Code 001.
REFERENCES
Agrawal, M., Hegselmann, S., Lang, H., Kim, Y., and
Sontag, D. (2022). Large language models are few-
shot clinical information extractors. In Goldberg, Y.,
Kozareva, Z., and Zhang, Y., editors, Proceedings of
the 2022 Conference on Empirical Methods in Natural
Language Processing, pages 1998–2022, Abu Dhabi,
United Arab Emirates. Association for Computational
Linguistics.
Analysis, A. (2024). Independent analysis of ai models and
api providers. https://artificialanalysis.ai/. Accessed:
2024-08-20.
Bai, Y., Ying, J., Cao, Y., Lv, X., He, Y., Wang, X., Yu,
J., Zeng, K., Xiao, Y., Lyu, H., et al. (2024). Bench-
marking foundation models with language-model-as-
an-examiner. Advances in Neural Information Pro-
cessing Systems, 36.
Banerjee, A., Biswas, S., Llad
´
os, J., and Pal, U. (2023).
Swindocsegmenter: An end-to-end unified domain
adaptive transformer for document instance segmenta-
tion. In International Conference on Document Anal-
ysis and Recognition, pages 307–325. Springer.
Chen, Y., Zhang, J., Peng, K., Zheng, J., Liu, R., Torr, P.,
and Stiefelhagen, R. (2024). Rodla: Benchmarking
the robustness of document layout analysis models.
arXiv preprint arXiv:2403.14442.
G
¨
obel, M., Hassan, T., Oro, E., and Orsi, G. (2013). Icdar
2013 table competition. In 2013 12th International
Conference on Document Analysis and Recognition,
pages 1449–1453. IEEE.
Kittur, A., Chi, E. H., and Suh, B. (2008). Crowdsourcing
user studies with mechanical turk. In Proceedings of
the SIGCHI conference on human factors in comput-
ing systems, pages 453–456.
Ly, N. T. and Takasu, A. (2023). An end-to-end multi-
task learning model for image-based table recogni-
tion. pages 626–634.
Maik Thiele (2024). documentlayoutsegmenta-
tion yolov8 ondoclaynet (revision 25486d5).
Malaysia-AI (2024). Yolov8x-doclaynet-full-1024-42.
Mathew, M., Bagal, V., Tito, R., Karatzas, D., Valveny, E.,
and Jawahar, C. (2022). Infographicvqa. In Proceed-
ings of the IEEE/CVF Winter Conference on Applica-
tions of Computer Vision, pages 1697–1706.
Mathew, M., Kondreddi, V. K., Biten, A. F., Mafla, A.,
Matas, J., Jawahar, C. V., Valveny, E., and Karatzas,
D. (2021). Docvqa: A dataset for vqa on document
images. In Proceedings of the IEEE/CVF Conference
on Computer Vision and Pattern Recognition (CVPR),
pages 2200–2209.
Nguyen, P., Ly, N. T., Takeda, H., and Takasu, A. (2023).
Tabiqa: Table questions answering on business docu-
ment images. arXiv preprint arXiv:2303.14935.
Pfitzmann, B., Auer, C., Dolfi, M., Nassar, A. S., and Staar,
P. (2022). Doclaynet: a large human-annotated dataset
for document-layout segmentation. In Proceedings
of the 28th ACM SIGKDD Conference on Knowledge
Discovery and Data Mining, pages 3743–3751.
Qiao, L., Li, Z., Cheng, Z., Zhang, P., Pu, S., Niu, Y., Ren,
W., Tan, W., and Wu, F. (2021). Lgpma: compli-
cated table structure recognition with local and global
pyramid mask alignment. In International conference
on document analysis and recognition, pages 99–114.
Springer.
Santos, Y., Silva, M., and Reis, J. C. S. (2023). Evaluation
of optical character recognition (ocr) systems dealing
with misinformation in portuguese. In 2023 36th SIB-
GRAPI Conference on Graphics, Patterns and Images
(SIBGRAPI), pages 223–228.
Smock, B., Pesala, R., and Abraham, R. (2022). Pubtables-
1m: Towards comprehensive table extraction from
unstructured documents. In Proceedings of the
IEEE/CVF Conference on Computer Vision and Pat-
tern Recognition, pages 4634–4642.
Wang, S., Liu, Y., Xu, Y., Zhu, C., and Zeng, M. (2021).
Want to reduce labeling cost? GPT-3 can help. In
Findings of the Association for Computational Lin-
guistics: EMNLP 2021, pages 4195–4205, Punta
Cana, Dominican Republic. Association for Compu-
tational Linguistics.
Ye, J., Qi, X., He, Y., Chen, Y., Gu, D., Gao, P., and
Xiao, R. (2021). Pingan-vcgroup’s solution for ic-
dar 2021 competition on scientific literature parsing
task b: table recognition to html. arXiv preprint
arXiv:2105.01848.
Zheng, X., Burdick, D., Popa, L., Zhong, X., and Wang, N.
X. R. (2021). Global table extractor (gte): A frame-
work for joint table identification and cell structure
recognition using visual context. In Proceedings of
the IEEE/CVF winter conference on applications of
computer vision, pages 697–706.
Zhong, X., ShafieiBavani, E., and Jimeno Yepes, A. (2020).
Image-based table recognition: data, model, and eval-
uation. In European conference on computer vision,
pages 564–580. Springer.
A Data Annotation Approach Using Large Language Models
755
