A Framework for Evaluating Integration Testing Criteria in Serverless

Applications

Stefan Winzinger

and Guido Wirtz

Distributed Systems Group, University of Bamberg, An der Weberei 5, 96047 Bamberg, Germany

{stefan.winzinger, guido.wirtz}@uni-bamberg.de

Keywords:

Serverless Computing, FaaS, Integration Testing, Data Flow, Coverage Criteria.

Abstract:

Serverless applications are based on Function-as-a-Service (FaaS) platforms where serverless functions in-

teract with other cloud-speciﬁc services. The integration of these components is crucial for the application’s

functionality and must be adequately tested. Testing criteria can help here by supporting developers in evalu-

ating test suites and identifying missing test cases. This paper presents a framework for evaluating integration

testing criteria in serverless applications by showing the processes needed for evaluating the criteria. The

process deﬁned is shown for some control and data ﬂow criteria and applied to some serverless applications

showing the feasibility of the approach.

1 INTRODUCTION

Serverless computing became popular with the intro-

duction of Amazon’s AWS Lambda in 2014 and is

now also provided by other cloud providers like Mi-

crosoft’s Azure Functions or Google’s Cloud Func-

tions (Baldini et al., 2017).

The serverless functions are the core of serverless

applications and are executed in an instance support-

ing the corresponding programming language where

the function is written. These instances are man-

aged by the cloud platform provider, which can de-

cide whether to create new instances or shut down

old instances after some time of inactivity. There-

fore, developers cannot rely on the instance’s state

between two function calls and have to assume that

the instance is stateless. This statelessness enables

the cloud platform provider to scale the functions au-

tomatically.

However, since the state is not guaranteed to be

kept between serverless function calls, other services

have to be used to keep the state of the application.

These are typically other cloud platform services like

data storage services where data can be stored be-

tween function calls. The combination of serverless

functions with other cloud services builds a serverless

application.

However, the complexity that arises from the com-

https://orcid.org/0000-0002-4526-286X

https://orcid.org/0000-0002-0438-8482

bination of serverless functions and other cloud ser-

vices needs to be tested. Since it is difﬁcult for de-

velopers to know if a test suite is complete, integra-

tion testing criteria can help evaluate test suites and

support the identiﬁcation of missing test cases. By

interviewing experts in the domain of serverless com-

puting, integration testing was identiﬁed as a crucial

problem in (Lenarduzzi et al., 2021). Furthermore,

the need for coverage criteria on the integration level

and the challenge of measuring coverage was identi-

ﬁed in (Lenarduzzi and Panichella, 2021).

In our recent work, we tackled these problems

by introducing a model for serverless applications

in (Winzinger and Wirtz, 2019b) and establishing

testing criteria for integration testing in (Winzinger

and Wirtz, 2019a; Winzinger and Wirtz, 2020). Fur-

thermore, we showed how the testing criteria can

be measured in (Winzinger. and Wirtz., 2021) and

how test cases can be automatically generated in

(Winzinger and Wirtz, 2022). The criteria were ﬁ-

nally evaluated in (Winzinger and Wirtz, 2023).

In this work, we present our framework for eval-

uating integration testing criteria in serverless appli-

cations that summarizes the previous work and con-

tributs the processes needed for the evaluation of the

criteria. In contrast to other work (Frankl and Weiss,

1991; Hutchins et al., 1994), where test criteria were

evaluated at the code level, our approach focuses on

integration test criteria and supports the automatic

generation of test cases.

Winzinger, S. and Wirtz, G.

A Framework for Evaluating Integration Testing Criteria in Serverless Applications.

DOI: 10.5220/0013283100003950

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 15th International Conference on Cloud Computing and Services Science (CLOSER 2025), pages 167-173

ISBN: 978-989-758-747-4; ISSN: 2184-5042

167

2 FRAMEWORK FOR

EVALUATING INTEGRATION

TESTING CRITERIA

We provide an approach for the evaluation of inte-

gration testing criteria in serverless applications. A

rough overview of the creation of test cases and their

evaluation of their fault detection potential is given in

Figure 1 showing the workﬂow.

Source Code

Of Serverless

Functions

Infrastructure

File

Model of

Application

Testing Targets

Instrumented Serverless

Functions for

Measurement of Testing

Targ e ts

Interfaces of

Serverless

Functions

Model of

Application with

Interfaces

Deployed

Instrumented

Application

Automatic

Generated Test

Cases

Mutation

Operators

Deployed

Application with

Injected Faults

Serverless

Functions with

Injected Faults

Evaluation

automatic

Type of Processing:

semi-automatic

manual

Testing

Criteria

Figure 1: Workﬂow of framework.

The testing criteria require certain aspects of an

application to be tested. The aspects required for the

testing criteria can be abstracted away in a model rep-

resenting the application which builds the foundation

of the process. This model should contain all relevant

information required for the identiﬁcation of coverage

criteria and later steps in the evaluation process. By

using the source code of the serverless functions of

the application and the infrastructure ﬁle, the ﬁle can

be created semi-automatically.

Based on the model and testing criteria, testing

targets that need to be covered to meet the correspond-

ing coverage criteria can be identiﬁed. Depending on

the testing criteria, a more or less descriptive model is

required.

These testing criteria are used in the next step to

create test cases, where at least one test case is cre-

ated for each testing target. Ideally, these test cases

are created automatically to support the objectivity of

the created test cases. The automatic creation requires

additionally an instrumented version of the serverless

application which can measure the testing targets cov-

ered and a model of the application which provides

interfaces for the containing serverless functions.

These test cases are evaluated for fault detection

potential using mutation testing. In mutation testing,

mutation operators are needed to deﬁne how a fault

is injected into an application. Such an application

is called a mutant, which is ﬁnally deployed. Test

cases are executed on these mutants to measure the

fault detection potential. Based on the measurement

of the fault detection potential of the single test cases,

the criteria are ﬁnally evaluated.

In the following, the phases and conditions are de-

scribed in more detail.

2.1 Model Creation

In our approach, applications are modeled as a de-

pendency graph where the nodes represent the com-

ponents of the application. These components can be

divided into serverless functions, data storage compo-

nents, and other services provided by the cloud plat-

form. The arcs between the components initialize the

start of the action between a component, e.g., if an arc

from a serverless function is directed to a data storage,

it indicates that the serverless function uses the data

storage. Furthermore, the arcs are annotated with ad-

ditional information when a data storage component

is accessed, indicating the kind of CRUD operation

used.

Additionally, the serverless functions contain in-

formation about their interface since this information

is needed to invoke the serverless functions for test-

ing directly. To support data ﬂow testing, information

about the location where the data are created and used

is also saved in the model.

The creation of such a model can be semi-

automated by reading the infrastructure ﬁle of the ap-

plication and the source code of the serverless func-

tions. While the infrastructure ﬁle can be used to iden-

tify all components of the applications and some rela-

tions between them, the source code has to be parsed

to identify all relations, interfaces, and data ﬂow in-

formation between these components, which can be

supported by a good parser, but not fully automated.

2.2 Test Criteria

Based on the model, both control ﬂow and data ﬂow

criteria were selected.

Taking inspiration from (Linnenkugel and Muller-

burg, 1990), where the criteria are deﬁned at the mod-

ule level, the following coverage criteria focusing on

the control ﬂow are suggested for serverless applica-

tions in (Winzinger and Wirtz, 2019a; Winzinger and

Wirtz, 2020)which can be applied by using the previ-

ously deﬁned model.

• All-resources (AllRes) requires that every re-

source is executed at least once. A resource is the

instance of a service like a serverless function or

a data storage.

• All-resource-relations (AllRel) requires that every

relation between resources is executed (e.g., all

edges between the nodes are covered).

CLOSER 2025 - 15th International Conference on Cloud Computing and Services Science

168

Similarly to the control ﬂow criteria, the data ﬂow

criteria consider interactions where several resources

are involved. Thus, inspired by (Linnenkugel and

Mullerburg, 1990), data ﬂow criteria are suggested in

the following:

If x is a deﬁnition of a value within a serverless

function that is used by another resource, then:

• All-resource-defs (AllDefs) requires that every x

is at least used once in another resource without

being redeﬁned before its usage.

• All-resource-uses (AllUses) requires that every x

is used by all usages of x in other resources with-

out being redeﬁned before its usage.

• All-resource-defuse (AllDefUse) requires that:

– each deﬁnition of a value within a serverless

function that is used by another resource is used

at least once in another resource without being

redeﬁned before its usage.

– each usage of a value deﬁned in another re-

source is used at least once in combination with

any deﬁnition without being redeﬁned before

its usage.

These criteria are the criteria that are investigated

in the approach. If other criteria are selected or pro-

posed, it might be required that the model of the pre-

vious step is adapted to provide all relevant infor-

mation. Furthermore, the following steps might also

need adaptations to produce adequate test cases.

2.3 Measurement of Testing Targets

The coverage of testing targets must be measured

when test cases are executed, which is required both

for the automatic generation of test cases and the ﬁnal

evaluation where the potential of the coverage criteria

is evaluated. Therefore, in (Winzinger. and Wirtz.,

2021) a general approach was introduced to measure

the data ﬂow coverage criteria mentioned above using

serverless functions. In addition to this work, we also

extended our approach to measure control ﬂow crite-

ria. By passing the relevant information between the

components needed for the data ﬂow and the control

ﬂow criteria and evaluating these values, the coverage

can be measured.

Figure 2 shows a box plot with the median ex-

ecution times when a serverless function calls an-

other serverless function synchronously on AWS with

different measurements. In addition to the previous

work and the control ﬂow and data ﬂow measure-

ment, Open-Telemetry, a standardization approach to

effectively observe applications, was measured using

Jaeger as a tracking backend. Also, Amazon’s X-Ray

was additionally used for comparison, which is the

monitoring solution of Amazon that can be applied to

trace and visualize the resources used by a request.

normal defs defuse uses res rel otel xray

20 40 60 80 100

execution time in ms

24.43

25.485

25.645

25.64

25.63

24.54

37.49

26.705

Figure 2: Measurement of coverage.

The measurement was also applied to two other

scenarios in which a data storage service was used.

For all three scenarios and all the criteria imple-

mented, the effect size was calculated indicating how

strong the overhead of the instrumentation was. For

all scenarios and criteria implemented, the effect size

was less than 0.19 which is still small according

to (Cohen, 1992) while the other measurement ap-

proaches showed an effect size of at least 0.35.

2.4 Automatic Generated Test Cases

For the evaluation, test cases are automatically gener-

ated according to (Winzinger and Wirtz, 2022) which

saves time in the generation of numerous test cases

and makes the creation more objective.

For each testing target, a speciﬁc test case is gener-

ated. The approach for the creation of test cases iden-

tiﬁes the ﬁrst potential serverless function that might

have to be invoked to cover the speciﬁc testing tar-

get. This is done statically, by analyzing the model

of the serverless function and analyzing related com-

ponents of the serverless functions where the testing

targets are located. In the second step, the serverless

functions are executed with concrete data which are

generated according to the following heuristics.

• Same Input: Use the value of a key-value pair of

a previous input with the same key.

• Random Input: Use the value of a random key-

value pair of a previous input.

• Same Output: Use the value of a key-value pair

of a previous output with the same key.

• Random Output: Use the value of a random key-

value pair of a previous output.

A Framework for Evaluating Integration Testing Criteria in Serverless Applications

169

• Same Values: Use the same random value for all

values.

Up to ten different input data were generated for each

heuristic and structure of serverless functions that was

identiﬁed for each testing target. Table 1 shows for

three different applications the coverage where for

each application more than 70% of the testing targets

could be covered.

Table 1: Automatic created test cases.

Testing Automatically Manually

Targets Covered Covered

Application 1

All-Resources 17 17 (100%) 0 (0%)

All-Relations 18 18 (100%) 0 (0%)

All-Defs 12 9 (75.00%) 3 (25.00%)

All-Defuse 18 16 (88.89%) 2 (11.11%)

All-Uses 38 24 (64.16%) 14 (36.84%)

∑

103 84 (81.55%) 19 (18.45%)

Application 2

All-Resources 11 10 (90.91%) 1 (9.09%)

All-Relations 15 12 (80.00%) 3 (20.00%)

All-Defs 5 5 (100%) 0 (0.00%)

All-Defuse 11 11 (100%) 0 (0.00%)

All-Uses 14 14 (100%) 0 (0.00%)

∑

56 52 (92.86%) 4 (7.14%)

Application 3

All-Resources 22 22 (100%) 0 (0.00%)

All-Relations 56 48 (85.71%) 8 (14.29%)

All-Defs 14 11 (78.57%) 3 (21.43%)

All-Defuse 57 43 (75.44%) 14 (24.56%)

All-Uses 244 163 (66.80%) 81 (33.20%)

∑

393 287 (73.03%) 106 (26.97%)

For testing targets where no test case was created

automatically, test cases were created manually keep-

ing them as small as possible to avoid unnecessary

coverage of other testing targets.

For each test case created for a testing target, ten

random test cases were also created that contain the

same number of serverless functions that are invoked

directly as the original test case with random input

data. In addition, the input data for the test cases are

generated randomly.

However, this approach produces test cases that

cover the testing targets without having a test case or-

acle indicating how the test case should behave. Just

looking for errors thrown during test case execution is

not enough, since these errors can also be an intended

behavior (Barr et al., 2015). Therefore, a test oracle is

needed to check if the application behaves as intended

when a test case is executed.

The original application is chosen as the test ora-

cle producing the intended behavior since test cases

are needed for the evaluation to detect injected faults.

The results and logs generated by the functions were

recorded for each test case and assigned to the test

case. The dynamic parts of the outputs, such as time

stamps, were identiﬁed and excluded, as the outputs

are not constant when the test case is executed again.

2.5 Measurement of Injected Faults

Since there are rarely enough real faults available that

can be used for the evaluation of the testing criteria,

faults are deliberately injected into the application.

This is done using mutation operators, which deﬁne

how a fault is injected into the application and are

used to predict the effectiveness of test cases and test

suites for real faults (Andrews et al., 2005; Andrews

et al., 2006; Just et al., 2014). The available muta-

tion operators described in (Delamaro et al., 2001a;

Delamaro et al., 2001b; Vincenzi et al., 2001; Ghosh

and Mathur, 2001; Rodr

ıguez-Baquero and Linares-

asquez, 2018) either change or remove the potential

data that are passed between the components. There-

fore, the following mutation operators were deﬁned

by changing the data that are usually transmitted as a

key-value pair in JSON:

• DelKey: Delete key of key-value pair

• DelVal: Delete value of key-value pair

• RepVar: Replace the value of the variable with a

random value

• NegVar: Negate boolean value

• RemRet: Remove return statement

• RemCal: Remove call to other resource

Figure 3 shows the interfaces of serverless

interfaces that we identiﬁed in our previous

work (Winzinger. and Wirtz., 2021).

funcon

parameters

(e.g., data as

JSON)

services

plaorm-specic services

external services

(environment

sengs)

(global variables)

services

plaorm-specic services

external services

return value

(background

processes)

(background

processes)

Figure 3: Data interfaces of serverless functions.

We applied the operators to the function parame-

ters, the return values, and the values passed to and

received from the services.

For each mutant generated by the mutation opera-

tor, a new version of the program is needed and has

to be deployed. By instrumenting the source code

with feature ﬂags that can be activated by environ-

ment variables, a single version of the program was

CLOSER 2025 - 15th International Conference on Cloud Computing and Services Science

170

enough where the faults could be activated individu-

ally. Each test case was run with each mutant to see if

it could detect the injected fault.

Table 2 shows how many mutants could be killed

by all test cases belonging to a certain criterion

where the corresponding randomly generated test

cases killed for most of these suites fewer mutants.

2.6 Evaluation of Integration Testing

Criteria

All automatically and manually generated test cases

for the testing targets and their randomly generated

counterparts were added to a pool to build test suites

that cover a certain target coverage of a speciﬁc test-

ing target.

This test pool was used for the creation of test

suites of different sizes focusing on the fulﬁllment of

the coverage criteria investigated. For each coverage

criterion and each x, where x is a number between 1

and the maximum number of feasible testing targets,

200 test suites were created which cover at least x test-

ing targets of the corresponding coverage criterion to

have a broader space of test suites fulﬁlling a certain

coverage value. The algorithm shown in Algorithm 1

was applied which is adapted from (Andrews et al.,

2006).

Algorithm 1: Test Suite Generation from Test Pool.

Require: Test Pool P, Target Coverage t

suite ←

suiteCoverage ← 0

while suiteCoverage < t do

tc ← random tc of P

P ← P \{tc}

newCoverage ← coverage of suite ∪{tc}

if newCoverage > suiteCoverage then

suite ← suite ∪ {tc}

suiteCoverage ← coverage of suite

end

return suite

A similar test suite with a similar number of test

cases was created for each of the test suites created.

These new test suites were constructed by randomly

selecting test cases from the test pool without reject-

ing any test case to have test suites of equal size and

make them more comparable since the same number

of test cases are used.

Since the number of mutants killed by the test

suites was not normally distributed, the Mann-

Table 2: Coverage of all test cases for criteria (max number

of covered mutants of the best corresponding random suite

in brackets).

All All All All All

Res Rel Defs DefUse Uses

App1

DelKey

136 136 156 178 182

(115) (114) (136) (159) (170)

DelVal

136 136 156 178 182

(115) (114) (136) (159) (170)

RepVar

57 57 123 139 147

(49) (49) (71) (84) (104)

NegVar

15 15 15 18 19

(12) (13) (16) (17) (17)

RemRet

14 14 12 15 16

(12) (12) (14) (15) (15)

RemCal

8 8 13 16 16

(7) (8) (10) (10) (11)

∑

366 366 475 544 562

(308) (306) (367) (443) (487)

App2

DelKey

42 42 37 39 39

(35) (35) (34) (35) (35)

DelVal

45 45 40 42 42

(36) (36) (35) (36) (36)

RepVar

45 47 45 44 44

(27) (30) (27) (31) (31)

NegVar

0 0 0 0 0

(0) (0) (0) (0) (0)

RemRet

9 7 5 6 6

(7) (8) (8) (8) (8)

RemCal

4 4 3 4 4

(3) (3) (3) (3) (3)

∑

145 145 130 135 135

(108) (109) (107) (113) (113)

App3

DelKey

162 265 214 284 314

(130) (168) (162) (169) (195)

DelVal

190 312 253 334 365

(152) (196) (190) (198) (225)

RepVar

172 327 271 361 373

(132) (181) (171) (180) (206)

NegVar

1 10 10 10 10

(1) (1) (1) (1) (1)

RemRet

16 26 15 29 32

(13) (18) (16) (18) (24)

RemCal

18 41 35 45 48

(15) (20) (18) (21) (22)

∑

559 981 798 1063 1142

(440) (583) (558) (585) (672)

A Framework for Evaluating Integration Testing Criteria in Serverless Applications

171

Whitney test was chosen with a signiﬁcance level of

1% to compare them and measure their effect sizes if

the null hypothesis had been rejected.

Figure 4 visualizes the comparison of the test

suites generated for AllUses and their counterparts

generated for an application where the interpolated

lines indicate that AllUses kills more mutants if the

test cases were selected with this criterion.

250

500

750

1000

1250

0 50 100 150

number of test cases of test suite

number of mutants killed

Test Suites

AllUses

Random

Figure 4: Comparison of test Suites for AllUses and random

created suites of an application.

The systematically generated test suites detected

signiﬁcantly more mutations for all applications and

criteria than their randomly generated counterparts.

For the data ﬂow criteria, the effect size was greater

than 0.5, which indicates a strong effect according

to (Cohen, 1992), and supports the hypothesis. How-

ever, only the test suites for App2 and the criterion

AllRel had an effect size greater than 0.5 for the con-

trol ﬂow criteria. For the other applications, the effect

sizes ranged from 0.11 to 0.28, indicating only a small

effect.

In addition to the previous work, a signiﬁcant

advantage of the systematically created test cases

compared to the random ones could also be shown

when the manually generated test cases and their ran-

domly assigned counterpart were excluded from the

test suite.

Furthermore, also when the number of mutants

was reduced to mutants on the interfaces where di-

rect communication to other components occurred,

the criteria-based test suites were signiﬁcantly bet-

ter for the test suites built with and without manually

added test cases.

All criteria are also compared with each other con-

sidering their test suites that fulﬁlled 100% of their

testing targets. Since the data ﬂow criteria build a

subsumption hierarchy, the stricter data ﬂow crite-

ria killed at least as many mutants as their subsumed

ones. There was a strong effect that could be shown

for most of the cases while AllDefUse showed no sig-

niﬁcant improvement compared to AllDefs in App2.

This could be due to the architecture of App2 where

the number of potential uses for each deﬁnition is

lower than in the other applications. Furthermore,

the workﬂow of App2 triggers several serverless func-

tions that cause the coverage of additional testing tar-

gets within a test case. Thus, it is possible to meet the

stricter coverage criteria with a relatively small num-

ber of test cases in App2, in contrast to the other ap-

plications where the more stringent coverage criteria

must execute more test cases to be fulﬁlled, resulting

in a higher coverage.

As a result, it could not be demonstrated that data

ﬂow criteria consistently outperform control ﬂow cri-

teria, since the detection potential is highly dependent

on the application.

3 CONCLUSION AND FUTURE

WORK

This work showed how integration testing criteria can

be measured for serverless applications and applied

the approach to some integration testing criteria on

three serverless applications. The evaluated crite-

ria were shown to be more efﬁcient than random-

generated test cases. However, there is no best crite-

rion among the evaluated criteria. The data or control

ﬂow criteria are more efﬁcient depending on the ap-

plication. Therefore, we recommend not only relying

on a single criterion but combining them with other

criteria and test cases created based on the testers’ ex-

perience.

For future work, more criteria can be evaluated us-

ing the framework introduced. Furthermore, if an ap-

plication is available in which many real-world faults

have already been detected, it would be worthwhile

to evaluate the criteria based on these faults. Also,

microservices pose an interesting area where our ap-

proach can be adapted transferring the criteria and

tooling to this area.

REFERENCES

Andrews, J., Briand, L., Labiche, Y., and Namin, A. (2006).

Using mutation analysis for assessing and comparing

CLOSER 2025 - 15th International Conference on Cloud Computing and Services Science

172

testing coverage criteria. IEEE Transactions on Soft-

ware Engineering, 32(8):608–624.

Andrews, J. H., Briand, L. C., and Labiche, Y. (2005). Is

mutation an appropriate tool for testing experiments?

In Proceedings of the 27th international conference on

Software engineering - ICSE '05. ACM Press.

Baldini, I., Cheng, P., Fink, S. J., Mitchell, N., Muthusamy,

V., Rabbah, R., Suter, P., and Tardieu, O. (2017). The

serverless trilemma: Function composition for server-

less computing. In Proceedings of the 2017 ACM

SIGPLAN International Symposium on New Ideas,

New Paradigms, and Reﬂections on Programming and

Software - Onward! 2017. ACM Press.

Barr, E. T., Harman, M., McMinn, P., Shahbaz, M., and

Yoo, S. (2015). The oracle problem in software test-

ing: A survey. IEEE Transactions on Software Engi-

neering, 41(5):507–525.

Cohen, J. (1992). Statistical power analysis. Current Direc-

tions in Psychological Science, 1(3):98–101.

Delamaro, M., Maidonado, J., and Mathur, A. (2001a). In-

terface mutation: An approach for integration test-

ing. IEEE Transactions on Software Engineering,

27(3):228–247.

Delamaro, M. E., Maldonado, J. C., Pasquini, A., and

Mathur, A. P. (2001b). Interface mutation test ade-

quacy criterion: An empirical evaluation. Empirical

Software Engineering, 6(2):111–142.

Frankl, P. G. and Weiss, S. N. (1991). An experimental

comparison of the effectiveness of the all-uses and all-

edges adequacy criteria. In Proceedings of the sym-

posium on Testing, analysis, and veriﬁcation, TAV-4.

ACM.

Ghosh, S. and Mathur, A. P. (2001). Interface muta-

tion. Software Testing, Veriﬁcation and Reliability,

11(4):227–247.

Hutchins, M., Foster, H., Goradia, T., and Ostrand, T.

(1994). Experiments on the effectiveness of dataﬂow-

and control-ﬂow-based test adequacy criteria. In Pro-

ceedings of 16th International Conference on Soft-

ware Engineering, ICSE-94. IEEE Comput. Soc.

Press.

Just, R., Jalali, D., Inozemtseva, L., Ernst, M. D., Holmes,

R., and Fraser, G. (2014). Are mutants a valid substi-

tute for real faults in software testing? In Proceedings

of the 22nd ACM SIGSOFT International Symposium

on Foundations of Software Engineering - FSE 2014.

ACM Press.

Lenarduzzi, V., Daly, J., Martini, A., Panichella, S., and

Tamburri, D. A. (2021). Toward a technical debt con-

ceptualization for serverless computing. IEEE Soft-

ware, 38(1):40–47.

Lenarduzzi, V. and Panichella, A. (2021). Serverless test-

ing: Tool vendors’ and experts’ points of view. IEEE

Software, 38(1):54–60.

Linnenkugel, U. and Mullerburg, M. (1990). Test data se-

lection criteria for (software) integration testing. In

Systems Integration ’90. Proceedings of the First In-

ternational Conference on Systems Integration. IEEE

Comput. Soc. Press.

Rodr

ıguez-Baquero, D. and Linares-V

asquez, M. (2018).

Mutode: generic JavaScript and node.js mutation test-

ing tool. In Proceedings of the 27th ACM SIG-

SOFT International Symposium on Software Testing

and Analysis. ACM.

Vincenzi, A. M. R., Maldonado, J. C., Barbosa, E. F., and

Delamaro, M. E. (2001). Unit and integration testing

strategies for C programs using mutation. Software

Testing, Veriﬁcation and Reliability, 11(4):249–268.

Winzinger, S. and Wirtz, G. (2019a). Coverage criteria for

integration testing of serverless applications. In 13th

Symposium and Summer School On Service-Oriented

Computing.

Winzinger, S. and Wirtz, G. (2019b). Model-based analysis

of serverless applications. In 2019 IEEE/ACM 11th

International Workshop on Modelling in Software En-

gineering (MiSE). IEEE.

Winzinger, S. and Wirtz, G. (2020). Applicability of cover-

age criteria for serverless applications. In 2020 IEEE

International Conference on Service Oriented Systems

Engineering (SOSE). IEEE.

Winzinger., S. and Wirtz., G. (2021). Data ﬂow testing of

serverless functions. In Proceedings of the 11th In-

ternational Conference on Cloud Computing and Ser-

vices Science - CLOSER,, pages 56–64. INSTICC,

SciTePress.

Winzinger, S. and Wirtz, G. (2022). Automatic test case

generation for serverless applications. In 2022 IEEE

International Conference on Service-Oriented System

Engineering (SOSE). IEEE.

Winzinger, S. and Wirtz, G. (2023). Comparison of inte-

gration coverage criteria for serverless applications.

In 2023 IEEE International Conference on Service-

Oriented System Engineering (SOSE). IEEE.

A Framework for Evaluating Integration Testing Criteria in Serverless Applications

173
