AADT: Asset-Driven Attack-Defense Tree

Nan Messe

1 a

and Avi Shaked

2 b

IRIT, CNRS, UT2, France

Department of Computer Science, University of Oxford, Oxford, OX1 3QD, U.K.

Keywords:

Attack Tree, Risk Management, Security Modelling and Assessment, Usable Security.

Abstract:

Attack trees are widely used in threat modelling and risk analysis to describe threats and identify attacks that

realize them. Their extension, attack-defense trees, allows for depicting interactions between attackers and

defenders. However, current graphical representations of attack(-defense) trees focus primarily on threat sce-

narios and do not account for the representation of domain elements and their hierarchical organization. Com-

promised domain elements (e.g., systems, sub-systems, components, etc.) are thus not directly highlighted in

any of these tree representations, which requires additional effort from decision-makers during impact anal-

ysis. To help make impact analysis more explicit and enable stakeholders to assign and evaluate security

controls more effectively, we propose a novel methodology for graphical secure system modelling and as-

sessment, the “Asset-Driven Attack-Defense Tree” (AADT). AADT is an extension of the attack-defense tree,

combining the security and system views for seamless secure system development. AADT’s main contribution

lies in bridging the system and security views while representing domain elements, associated vulnerabilities,

and security controls at different levels of abstraction, which is aligned with the system development lifecy-

cle. This layered representation is especially useful in the fast-evolving cyber threat landscape, where diverse

attack techniques often exploit similar vulnerabilities. By associating vulnerability categories with domain

elements and proposing high-level security controls, AADT helps stakeholders manage a broad spectrum of

attacks targeting similar vulnerabilities, thus enabling a more proactive and structured approach to secure sys-

tem development. We also present a formalism for AADT and illustrate the AADT methodology using a

simple, real-world scenario based on the existing security body of knowledge.

1 INTRODUCTION

Establishing the security of systems is a dynamic

and ongoing effort. The number of cyberattacks

grows, the attackers are active and attack techniques

are sophisticated and diverse. This is exacerbated in

times of stressful, real-world events, such as the war

in Ukraine and the COVID-19 pandemic (Ramadan

et al., 2021). The constant stream of data breaches

and harmful cyberattacks has demonstrated that at-

tack intensity and sophistication will only increase in

the future. Attack tree (Schneier, 1999) is a concep-

tual representation that is widely used for securing

systems. It provides a systematic way of characteriz-

ing diverse system threats and attack scenarios (Gady-

atskaya and Trujillo-Rasua, 2017).

Typically, an attack tree design activity necessi-

tates both system domain expertise and security ex-

https://orcid.org/0000-0002-3766-0710

https://orcid.org/0000-0001-7976-1942

pertise, with the former providing in-depth knowl-

edge of the system and the latter offering secu-

rity knowledge and experience (Gadyatskaya and

Trujillo-Rasua, 2017). However, current graphical

representations of an attack tree focus primarily on

threat scenarios. They do not account for the rep-

resentation of domain elements and their hierarchi-

cal organization. In addition, the standard approach

for attack trees, in which only leaf nodes are anno-

tated with values, can be restrictive, as information for

intermediate nodes are often more readily available

than that of the leaf nodes (Gadyatskaya and Trujillo-

Rasua, 2017).

Attack-defense tree is an extension of attack

tree (Kordy et al., 2014). It allows nodes that repre-

sent defensive measures to appear as leaf nodes of the

tree. This is useful for depicting interactions between

attackers and defenders. However, how can one be

certain that a defensive measure implemented today

will still be effective in the future? How can newly

Messe, N. and Shaked, A.

AADT: Asset-Driven Attack-Defense Tree.

DOI: 10.5220/0013310100003928

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 20th International Conference on Evaluation of Novel Approaches to Software Engineer ing (ENASE 2025), pages 565-572

ISBN: 978-989-758-742-9; ISSN: 2184-4895

565

discovered attacks and defenses be documented in a

systematic and efﬁcient manner? More importantly,

how can stakeholders assign and evaluate the effec-

tiveness of security controls in system designs and

threat scenarios?

To answer these questions, we propose an ex-

tension of attack-defense tree, termed Asset-Driven

Attack-Defense Tree (AADT). This extension in-

cludes information about systems’ assets and their

vulnerabilities, in addition to attack activities and de-

fensive measures. AADT highlights compromised

and protected assets, making impact analysis more

concrete for decision makers.

This paper is structured as follows. In Section 2

we review related work about attack tree, its com-

mon extensions and its integration with risk manage-

ment. In Section 3, we introduce AADT, formalize

AADT and illustrate its graphical representation. A

case study is described in Section 4. In Section 5, we

discuss the signiﬁcance of our work and future work.

Finally, we conclude this paper in Section 6.

2 RELATED WORK

In this section, related works about attack tree, its ex-

tensions and its integration with risk management are

reviewed.

2.1 Attack Trees

Attack trees allow structuring diverse threat scenarios

and reasoning about these scenarios at different lev-

els of abstraction (Gadyatskaya and Trujillo-Rasua,

2017). It was originally proposed by Bruce Schneier

in 1999 (Schneier, 1999). The security community

uses attack trees to model threat scenarios in various

domains, such as Automated Teller Machines (Fraile

et al., 2016), Supervisory Control and Data Acqui-

sition systems (Nielsen, 2011) (Ten et al., 2007)

and Radio Frequency Identiﬁcation systems (Bagnato

et al., 2012).

In an attack tree, the ﬁnal goal of an attacker is

represented by the root of the tree, which is subse-

quently reﬁned and decomposed into sub-goals cap-

tured by child nodes. The actions that can be directly

executed by the attacker are represented by the leaf

nodes.

Research in attack trees mainly focuses on

improving the expressiveness of the formalism

through new operators. Prominent examples include

adding the sequential-AND operator (Jhawar et al.,

2015) (Arnold et al., 2014), designing various quan-

titative assessment methods to prioritize risks (Bag-

nato et al., 2012) (Mauw and Oostdijk, 2006) (Buldas

et al., 2006) (Kordy et al., 2012) (Gadyatskaya et al.,

2016c) and proposing extensions of attack trees, such

as the ones described in the following subsection.

Furthermore, new attack tree semantics are also

being developed, and support the transformation of

attack trees into other formalisms, such as timed

automata (Kumar et al., 2015) (Gadyatskaya et al.,

2016a), stochastic games (Aslanyan et al., 2016) and

Markov chains (Jhawar et al., 2016). These for-

malisms offer advanced computational capabilities

but they do not address the coordination of attack

trees between security experts, system engineers, risk

managers and other decision makers, which remains

a gap.

2.2 Extending Attack Trees to

Incorporate Defenses

Several attack tree extensions have been proposed

in the literature, to introduce the defenders’ view-

point into attack trees. Prominent extensions in-

clude attack-defense tree (ADTree) (Kordy et al.,

2014) (Fraile et al., 2016), attack response tree

(ART), attack countermeasures tree (ACT) (Roy

et al., 2012a) (Roy et al., 2012b) and attack protec-

tion tree (APT) (Ali and Gruska, 2019).

ADTree (Kordy et al., 2014) provides an intuitive

and visually appealing representation of interactions

between an attacker and a defender of a system. In

ADTree, defense measures – alternately security con-

trols – are only applied to leaf nodes. ACT (Roy

et al., 2012a), on the other hand, extends the defense

tree with countermeasures to mitigate attackers’ ac-

tions, where defenses can be applied to any level of

nodes in the tree. ART extends the attacker-defender

interaction to ﬁnd an optimal policy from a list of

countermeasures. However, ART is not popular as

it suffers from a state-space explosion problem (Roy,

2010). APT allows to deﬁne a set of protection ac-

tions at the point in which the attacker interacts with

the system. It is worth noting that all above exten-

sions do not include the domain aspect – i.e., the do-

main elements and their organizational structure – in

the representation of the tree structure. This omission

necessitates additional effort from system engineers

when integrating the security aspect into the system

development, potentially leading to increased com-

plexity, higher risk of errors, and prolonged develop-

ment times.

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

566

2.3 Integration with Risk Management

Research efforts have also been put into the integra-

tion of attack trees with security risk management

methodologies (Pieters and Davarynejad, 2014) (Paul

and Vignon-Davillier, 2014) (Gadyatskaya et al.,

2016b). The security design process and risk manage-

ment life cycle typically include the following main

phases (Force and Initiative, 2013) (Messe, 2021):

• The identiﬁcation of the critical assets to be pro-

tected;

• The analysis of vulnerabilities of the identiﬁed as-

sets;

• The threats that may exploit these vulnerabilities;

• The prioritization of risks relating to threats, vul-

nerabilities and assets;

• The selection and implementation of the security

controls that are needed to protect the identiﬁed

assets;

• The assessment and the monitoring of security

controls in order to verify that they are properly

implemented.

Asset identiﬁcation is fundamental for the success of

secure system development, since its results directly

inﬂuence the subsequent steps in risk management.

The lack of support for asset identiﬁcation in attack-

tree-based methods hinders the ability of pertinent

stakeholders, namely systems engineers, risk man-

agers and decision makers to evaluate the potential

impact of threats on systems. For example, TRADES

Tool (Shaked, 2023) is a research informed open-

source systems security design and assessment tool,

supporting the security design process and risk man-

agement life cycle. While the tool has recently been

extended to support the analysis of assets with respect

to vulnerabilities (Shaked et al., 2024), it does not of-

fer a graphical representation to communicate the de-

sign between stakeholders and support their decision

making.

3 ASSET-DRIVEN ATTACK

DEFENSE TREE (AADT)

In this section, we ﬁrst deﬁne AADT terminologies

and then formalize them. We then illustrate the graph-

ical representation of AADT.

3.1 Terminology

A vulnerable asset is any asset that has vulnerabilities

that can be exploited by attackers. The exploitable

vulnerabilities make the vulnerable asset valuable to

the attackers, who can use it to compromise a sys-

tem. Previous work has shown that common types

of vulnerable assets can be extracted from widely

used security knowledge bases, such as CAPEC

CWE

, CVE

, OWASP

, and ATT@CK

(Messe

et al., 2020). Attack and mitigation information are

also associated with those extracted vulnerable as-

sets. Vulnerable assets extracted from these knowl-

edge bases are independent of a speciﬁc domain and,

thus, reusable. Vulnerable assets that are involved

in domain modelling are annotated as vulnerable do-

main assets.

We deﬁne an Asset-Driven Attack-Defense Tree

(AADT) as a node-labelled tree describing three in-

formation items: (i) the attack measures (strategies

and actions) an attacker might employ to compromise

a vulnerable domain asset; (ii) the defense measures

(strategies and actions) that a defender can use to pro-

tect the vulnerable domain asset; and (iii) the vulner-

able domain asset itself. Accordingly, an AADT has

three types of nodes: attack nodes, defense nodes and

vulnerable domain asset nodes. It is worth noting that

non-vulnerable assets are not considered in this paper,

as we deal exclusively with the security aspect.

The purpose of AADT is to model systems to-

gether with attack-defense scenarios. The ﬁrst two

key features of an AADT are the representation of

reﬁnement and the representation of decomposition.

Each node may have one or more children that either

represent the reﬁnement of the parent node or repre-

sent its decomposition. A leaf-node is deﬁned as a

node that does not have any children.

For attack and defense nodes, the reﬁnement of a

node of an AADT is disjunctive. The goal of a dis-

junctively reﬁned node is achieved when at least one

of its children’s goals is achieved. The decomposi-

tion of a node is conjunctive. The goal of a conjunc-

tively decomposed node is achieved when all of its

children’s goals are achieved.

For vulnerable domain asset nodes, the reﬁnement

of node A into node B means that A is the type or

generalization of B, or B is a specialization of A. The

decomposition from node A into node B means that

A contains B or B is a component of A.

Another key feature of an AADT is the represen-

tation of association, which aims at connecting dif-

ferent types of nodes. Each vulnerable domain asset

node can be associated with attack nodes and defense

https://capec.mitre.org/

https://cwe.mitre.org/

https://cve.mitre.org/

https://owasp.org/

https://attack.mitre.org/

AADT: Asset-Driven Attack-Defense Tree

567

nodes.

As explained shortly, when drawing an AADT,

we depict vulnerable domain asset nodes by trian-

gles, attack nodes by circles and defense nodes by

rectangles, as shown in Figure 1. Reﬁnement rela-

tions are indicated by solid directional lines between

nodes, and decomposition relations are indicated by

dotted directional lines. Association relations con-

necting different types of nodes are described by solid

non-directional lines.

3.2 AADT Formalism

To formalize AADT, we denote an attacker by A and

a defender by D. We represent the set of measures

that can be employed by the attacker as β, and the

set of defense measures as P. We denote by L = {s

, ..., s

} the set of vulnerable domain asset nodes

in the tree. The attack measures are deﬁned on the

attack nodes as a function A : L → 2

, and defense

measures are associated with nodes to block the attack

measures D : L → 2

. This expresses that an attacker

tries to perform attack measure b ∈ A(s) on a given

vulnerable domain asset node s, and that there is a

defense measure assigned by the defender α ∈ D(s)

that will block the malicious activity and protect the

vulnerable domain asset. For simplicity, we denote

this interaction as s

For a vulnerable domain asset node s, if each b ∈

A(s) is associated with a defense measure α ∈ D(s),

then the vulnerable domain asset node is said to be

protected. We denote this as s ⊢ (A, D). For example,

consider a vulnerable domain asset “weak password”

as the root node s

∈ L. This asset is subject to the

attack measure “password brute forcing attack” b ∈

β. A defense measure to protect the s against b can

be “implementing a password throttling mechanism”

α ∈ P. The general syntax of AADT is generated by

the following formula:

T = op(s

(t(s

), t(s

), ..., t(s

))) (1)

Where T is a tree, op = {OR, AND} is either the re-

ﬁnement relation (OR) or the decomposition relation

(AND). Each node except leaf nodes is either AND

or OR node. Each asset node can be associated with

the two other types of nodes. s

is the root vulnerable

domain asset node and t(s

) is a subtree (alternatively,

an intermediate tree) with the root s

. Based on this

syntax, we formalize AADT as follows.

Deﬁnition 1. An Asset-Driven Attack-Defense Tree

(AADT) is a tuple T = (L, E, β, P, A, D), where L is

the set of vulnerable domain asset nodes; E is the set

of links between nodes (either reﬁnement, decompo-

sition or association); β, P are the disjoint attack mea-

sures and the defend measures, respectively; A, D rep-

resent the attacker – A : L → 2

– and the defender –

D : L → 2

– respectively.

The vulnerable domain asset node s

∈ L is said to

be secure if ∀b ∈ A(s

), ∃α ∈ D(s

) : s

. If for each s

we have s

⊢ (A, D), then this means that all vulnerable

domain asset nodes are protected. We denote this as

S ⊢ (A, D).

In the above example of the weak password vul-

nerable domain asset, the attack node “password brute

forcing attack” can be reﬁned by the child attack node

“dictionary-based password attack” b

∈ β. Defend-

ers can perform protection measures such as “lever-

aging multifactor authentication” α

∈ P to defend

against this attack and protect the vulnerable asset

“word-based password” s

∈ L, which is a reﬁnement

of s

3.3 Graphical Representation of AADT

Figure 1: An example of Asset-Driven Attack Defense Tree.

Figure 1 illustrates the graphical representation of an

AADT, with six vulnerable domain asset nodes and

corresponding attack and defense nodes. For sim-

plicity and readability, we only show one-to-one re-

lations, knowing that one-to-many relations are also

possible. s

, s

and s

are leaf nodes. Equation 2

presents the corresponding AADT (T

) construction

that can capture three types of nodes. In T

, s

is the

root vulnerable domain asset node. It is reﬁned by ei-

ther s

or s

, with the latter reﬁned by s

. The node

is decomposed into s

and s

. Each vulnerable do-

main asset node s

is threatened by the attack node b

and protected by the defense node α

= s

, s

), s

)) (2)

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

568

4 EXAMPLE ILLUSTRATION

To illustrate the features of AADT, we consider the

following scenario concerning an anti-spam product,

which can be a system’s component. This scenario is

shown in Figure 2.

To develop a system, a system engineer could re-

quire an anti-spam product as a component of the sys-

tem. This anti-spam product should be modelled as

an architectural element. In this scenario, the system

engineer has chosen the product SpamTitan to play

the role of the anti-spam product. More precisely,

he/she has chosen the version 7.07 of SpamTitan. In

an anti-spam product, such as SpamTitan, conﬁgura-

tion ﬁles are available. One of the conﬁguration ﬁles

in SpamTitan 7.07 is snmpd.conf, which allows con-

trolling the Net-SNMP agent’s operation and the man-

agement information provided.

Figure 2: Using AADT to capture attack scenario for an

anti-spam product.

From the attacker’s point of view, there is a pos-

sibility of injecting unexpected items (CAPEC-152

)

into a vulnerable anti-spam product, as shown in Fig-

ure 2. As an anti-spam product contains conﬁguration

ﬁles, the attacker could carry out command injection

attack (CAPEC-248

). In the case of SpamTitan 7.07,

which contains the conﬁguration ﬁle snmpd.conf, a

remote attacker could perform SNMP command in-

jection in the ﬁle snmpd.conf through the page snmp-

x.php, which alters the system’s behavior from its in-

tended operation

. For that, the attacker has to get

access to snmp-x.php ﬁle, input strings that contain a

malicious command and execute the command to ob-

https://capec.mitre.org/data/deﬁnitions/152.html

https://capec.mitre.org/data/deﬁnitions/248.html

https://nvd.nist.gov/vuln/detail/CVE-2020-11698

tain a privilege or capability that the attacker would

not otherwise have. The success of this attack is based

on the fact that snmpd.conf allows unsanitized user

input constructing all or part of a command.

Figure 3: Using AADT to capture attack scenario and de-

fense measures for an anti-spam product.

From the defender’s point of view, to neutral-

ize special elements that could modify the intended

command, all input information should be validated

(NIST SP 800-53 SI-10) (Group, 2020) and ﬁltered

for potentially unwanted characters. Untrusted data

injections may be prevented using a parameterized in-

terface or output escaping (also known as output en-

coding). This is shown in Figure 3. Parameterized

interfaces keep data and code separate, ensuring that

malicious or unintended data cannot alter the meaning

of commands. Output escaping marks speciﬁc char-

acters to signal the interpreter’s parser about the trust

level of the data.

5 DISCUSSION

Asset is an essential concept in threat modelling, as

the attackers’ aim is to compromise assets and the de-

fenders’ aim is to protect them. Until now, the con-

cept of asset was absent in attack-trees-based secu-

rity modelling. Here, we propose a novel extension –

Asset-Driven Attack-Defense Tree (AADT) – which

incorporates the fundamental Asset concept into the

attack-trees-based security modelling. We demon-

strated the novelty using a simple scenario. From our

demonstration, it is clear that for any elaboration of

the scenario, the speciﬁc AADT in Figure 3 could

be easily extended with new system assets, attacks

and defenses. Future research should provide a more

in-depth evaluation of AADTs, exploring additional,

more complex scenarios and applications.

AADT: Asset-Driven Attack-Defense Tree

569

As time passes, attack techniques become more

and more diverse and defense measures have to evolve

to follow the fast-changing pace of attackers. In

comparison, assetsare relatively stable due to their

domain-speciﬁc nature and could therefore be rele-

vant underpinning elements (Uzunov and Fernandez,

2014; Messe et al., 2020). Adding and focusing

on the vulnerable asset perspective as an anchor ad-

dresses the current limitations of the attack-defense

tree, which concentrates on concrete actions without

fully integrating domain elements. We plan to elab-

orate the AADT formalism with a notion of time as

well as relate to information ﬂows within the system.

In contrary to attack-defense tree, which annotates

concrete attack and defense actions, AADT offers a

novel, multi-level approach. This approach allows de-

picting nodes in different levels of abstraction. Us-

ing the reﬁnement relation in AADT, it is possible to

mix abstract assets with concrete ones. This allows

to explicitly capture corresponding attack and defense

categories as well as actions. This characteristic is

particularly useful in architectural design, which can

be performed in several system development stages

and therefore involves domain elements in different

levels of abstraction. Capturing asset/attack/defense

categories promotes the ability to mitigate newly-

discovered attack techniques of existing categories.

For example, a newly-discovered attack about Poetry

Argument Injection has been discovered

, as its ab-

straction – Command Injection – has already been in-

cluded in the current AADT in Figure 3. Accordingly,

in our example scenario, the relevant defense mea-

sures were already incorporated into the design, and,

therefore, the anti-spam product is secured against

this speciﬁc attack. By organizing vulnerabilities into

abstraction layers, AADT enables the deployment of

adaptable, category-level defenses that remain effec-

tive as new threats emerge within existing vulnerabil-

ity classes. This approach helps ensure that defensive

measures implemented today maintain their relevance

and robustness in the face of future, unanticipated at-

tacks.

Like ART, ADTree and APT, AADT faces the

state-space explosion problem, which hampers its

comprehensibility. It is thus necessary to provide

means for visualizing large AADT, such as the one

proposed by the REsPASS project (Probst et al.,

2015) (Lenin et al., 2016). By structuring the tree in

a circular pattern, linearizing complex attack-defense

scenarios, and allowing zooming in and out, the vi-

sualization can disguise the tree’s complexity to re-

duce the cognitive effort needed to process a com-

https://www.cve.org/CVERecord?id=CVE-2022-

36069

plex AADT. We intend to explore the adaptation of

this visualization technique for AADT. We also plan

to experiment with formal veriﬁcation of AADTs, us-

ing a model checker (e.g. UPPAAL (Behrmann et al.,

2006)).

Creating the AADT representations is labor inten-

sive. We are working towards automating the gener-

ation of AADTs. For example, one of the concrete

methods we are exploring is the automatic extrac-

tion of assets from the CAPEC attack pattern descrip-

tion, which is in natural language. Another direction

we are currently attempting is automatically identi-

fying vulnerabilities/attacks using the Common Plat-

form Enumeration (CPE)

as an identiﬁer for assets.

Future work can integrate the new AADT repre-

sentation into security modelling tools. Speciﬁcally,

we are considering extending TRADES Tool with

AADT representations. TRADES Tool already sup-

ports the relevant concepts in its models, namely at-

tack and defense measures, assets and relations be-

tween them. TRADES also supports extraction and

association of CVEs with assets based on their CPEs.

We intend to rely on those to automate the genera-

tion of AADT representations. This would also make

sure that the derived AADTs are synchronized with

the models that represent the systems’ design and se-

curity posture. In addition, this would help to mini-

mize the effort of creating AADTs.

6 CONCLUSION

In this paper, we introduce an extension of attack-

defense trees, the Asset-Driven Attack-Defense Tree

(AADT), which focuses on vulnerable asset infor-

mation as a novel type of node. Unlike traditional

attack-defense trees, which center on threat scenarios

and defensive measures, AADT addresses the need

for representing domain elements and their hierar-

chical structure. By explicitly incorporating vulner-

able assets, such as systems, sub-systems, and com-

ponents, AADT provides decision-makers with a co-

hesive view of system architecture and security, en-

hancing impact analysis and supporting the strategic

design of security controls.

AADT also improves on traditional models by

representing security controls and vulnerabilities at

multiple levels of abstraction. This layered ap-

proach aligns with system development stages, allow-

ing stakeholders to implement adaptable security con-

trols that target both general and speciﬁc attack cate-

gories, such as high-level defenses against command

https://cpe.mitre.org/

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

570

injection rather than focusing only on individual vul-

nerabilities.

Additionally, the explicit representation of com-

promised assets and associated vulnerabilities allows

stakeholders to evaluate potential threats more effec-

tively and assign security controls with minimal ef-

fort. By associating vulnerability categories with as-

sets, AADT facilitates proactive, category-level miti-

gation strategies that can address future attacks within

the same vulnerability class. We formalize AADT

and demonstrate its unique strengths in reﬁnement

and impact analysis through a case study. Future in-

tegration of the AADT representation into security

modelling tools can facilitate security experts’ under-

standing of systems designs and security posture as

well as their active role in designing trustworthy sys-

tems.

ACKNOWLEDGEMENTS

This work is supported by ICO, Institut Cybers

ecurit

Occitanie, funded by R

egion Occitanie, France, and

by Innovate UK, grant number 75243.

REFERENCES

Ali, A. T. and Gruska, D. P. (2019). Attack protection tree.

In CS&P.

Arnold, F., Guck, D., Kumar, R., and Stoelinga, M. (2014).

Sequential and parallel attack tree modelling. In Inter-

national Conference on Computer Safety, Reliability,

and Security, pages 291–299. Springer.

Aslanyan, Z., Nielson, F., and Parker, D. (2016). Quanti-

tative veriﬁcation and synthesis of attack-defence sce-

narios. In 2016 IEEE 29th Computer Security Foun-

dations Symposium (CSF), pages 105–119. IEEE.

Bagnato, A., Kordy, B., Meland, P. H., and Schweitzer, P.

(2012). Attribute decoration of attack–defense trees.

International Journal of Secure Software Engineering

(IJSSE), 3(2):1–35.

Behrmann, G., David, A., Larsen, K. G., H

akansson, J., Pet-

tersson, P., Yi, W., and Hendriks, M. (2006). Uppaal

4.0.

Buldas, A., Laud, P., Priisalu, J., Saarepera, M., and

Willemson, J. (2006). Rational choice of security

measures via multi-parameter attack trees. In Inter-

national Workshop on Critical Information Infrastruc-

tures Security, pages 235–248. Springer.

Force, J. T. and Initiative, T. (2013). Security and privacy

controls for federal information systems and organi-

zations. NIST Special Publication, 800(53):8–13.

Fraile, M., Ford, M., Gadyatskaya, O., Kumar, R.,

Stoelinga, M., and Trujillo-Rasua, R. (2016). Using

attack-defense trees to analyze threats and counter-

measures in an atm: a case study. In IFIP Working

Conference on The Practice of Enterprise Modeling,

pages 326–334. Springer.

Gadyatskaya, O., Hansen, R. R., Larsen, K. G., Legay, A.,

Olesen, M. C., and Poulsen, D. B. (2016a). Modelling

attack-defense trees using timed automata. In Interna-

tional Conference on Formal Modeling and Analysis

of Timed Systems, pages 35–50. Springer.

Gadyatskaya, O., Harpes, C., Mauw, S., Muller, C., and

Muller, S. (2016b). Bridging two worlds: reconciling

practical risk assessment methodologies with theory

of attack trees. In International Workshop on Graphi-

cal Models for Security, pages 80–93. Springer.

Gadyatskaya, O., Jhawar, R., Kordy, P., Lounis, K., Mauw,

S., and Trujillo-Rasua, R. (2016c). Attack trees for

practical security assessment: ranking of attack sce-

narios with adtool 2.0. In International Conference on

Quantitative Evaluation of Systems, pages 159–162.

Springer.

Gadyatskaya, O. and Trujillo-Rasua, R. (2017). New direc-

tions in attack tree research: catching up with indus-

trial needs. In International Workshop on Graphical

Models for Security, pages 115–126. Springer.

Group, J. T. F. T. I. I. W. (2020). Security and pri-

vacy controls for information systems and organiza-

tions. Technical Report NIST Special Publication (SP)

800-53, Rev. 5, Includes updates as of September,

2020, National Institute of Standards and Technology,

Gaithersburg, MD.

Jhawar, R., Kordy, B., Mauw, S., Radomirovi

c, S., and

Trujillo-Rasua, R. (2015). Attack trees with sequen-

tial conjunction. In IFIP International Information

Security and Privacy Conference, pages 339–353.

Springer.

Jhawar, R., Lounis, K., and Mauw, S. (2016). A stochastic

framework for quantitative analysis of attack-defense

trees. In International Workshop on Security and Trust

Management, pages 138–153. Springer.

Kordy, B., Mauw, S., Radomirovi

c, S., and Schweitzer, P.

(2014). Attack–defense trees. Journal of Logic and

Computation, 24(1):55–87.

Kordy, B., Mauw, S., and Schweitzer, P. (2012). Quanti-

tative questions on attack–defense trees. In Interna-

tional Conference on Information Security and Cryp-

tology, pages 49–64. Springer.

Kumar, R., Ruijters, E., and Stoelinga, M. (2015). Quanti-

tative attack tree analysis via priced timed automata.

In International Conference on Formal Modeling and

Analysis of Timed Systems, pages 156–171. Springer.

Lenin, A., Gadyatskaya, O., Ionita, D., Pieters, W., Tanner,

A., Saraiva, S., Muller, C., Willemson, J., Ford, M.,

and Muller, S. (2016). Technology-supported risk es-

timation by predictive assessment of socio-technical

security.

Mauw, S. and Oostdijk, M. (2006). Foundations of attack

trees, information security and cryptology-icisc 2005.

In 8th international conference, Seoul, Korea, pages

186–198.

Messe, N. (2021). Security by Design: An asset-based ap-

proach to bridge the gap between architects and secu-

rity experts. PhD thesis, Universit

e de Bretagne Sud.

AADT: Asset-Driven Attack-Defense Tree

571

Messe, N., Chiprianov, V., Belloir, N., El-Hachem, J.,

Fleurquin, R., and Sadou, S. (2020). Asset-oriented

threat modeling. In 2020 IEEE 19th International

Conference on Trust, Security and Privacy in Comput-

ing and Communications (TrustCom), pages 491–501.

IEEE.

Nielsen, J. R. (2011). Evaluating information assurance

control effectiveness on an air force supervisory con-

trol and data acquisition (scada) system.

Paul, S. and Vignon-Davillier, R. (2014). Unifying tradi-

tional risk assessment approaches with attack trees.

Journal of Information Security and Applications,

19(3):165–181.

Pieters, W. and Davarynejad, M. (2014). Calculating ad-

versarial risk from attack trees: Control strength and

probabilistic attackers. In Data Privacy Management,

Autonomous Spontaneous Security, and Security As-

surance, pages 201–215. Springer.

Probst, C. W., Willemson, J., and Pieters, W. (2015). The at-

tack navigator. In International Workshop on Graphi-

cal Models for Security, pages 1–17. Springer.

Ramadan, R. A., Aboshosha, B. W., Alshudukhi, J. S.,

Alzahrani, A. J., El-Sayed, A., and Dessouky, M. M.

(2021). Cybersecurity and countermeasures at the

time of pandemic. Journal of Advanced Transporta-

tion, 2021.

Roy, A. (2010). Attack countermeasure trees: A non-state-

space approach towards analyzing security and ﬁnd-

ing optimal countermeasure sets. PhD thesis, Duke

University.

Roy, A., Kim, D. S., and Trivedi, K. S. (2012a). Attack

countermeasure trees (act): towards unifying the con-

structs of attack and defense trees. Security and com-

munication networks, 5(8):929–943.

Roy, A., Kim, D. S., and Trivedi, K. S. (2012b). Scal-

able optimal countermeasure selection using implicit

enumeration on attack countermeasure trees. In

IEEE/IFIP International Conference on Dependable

Systems and Networks (DSN 2012), pages 1–12.

IEEE.

Schneier, B. (1999). Attack trees. Dr. Dobb’s journal,

24(12):21–29.

Shaked, A. (2023). A model-based methodology to support

systems security design and assessment. J. Ind. Inf.

Integr., 33:100465.

Shaked, A., Messe, N., and Melham, T. (2024). Modelling

tool extension for vulnerability management. In Pro-

ceedings of the ACM/IEEE 27th International Con-

ference on Model Driven Engineering Languages and

Systems (MODELS Companion ’24), New York, NY,

USA. ACM.

Ten, C.-W., Liu, C.-C., and Govindarasu, M. (2007). Vul-

nerability assessment of cybersecurity for scada sys-

tems using attack trees. In 2007 IEEE Power Engi-

neering Society General Meeting, pages 1–8. IEEE.

Uzunov, A. V. and Fernandez, E. B. (2014). An extensible

pattern-based library and taxonomy of security threats

for distributed systems. Computer Standards & Inter-

faces, 36(4):734–747.

ENASE 2025 - 20th International Conference on Evaluation of Novel Approaches to Software Engineering

572
