DynaSchema: A Library to Support the Relational Data Schema

Evolution for the Self-Adaptive Software Domain

Gabriel Nagassaki Campos

and Frank José Affonso

Department of Statistics, Applied Mathematics and Computation, São Paulo State University – UNESP,

PO Box 178, Rio Claro, São Paulo, 13506-900, Brazil

Keywords:

Self-Adaptive Software, Data Schema Evolution, Reference Architecture.

Abstract:

The development of self-adaptive software (SaS) represents a signiﬁcant challenge, as this type of software

enables structural, behavioral, and context changes at runtime. Among the range of SaS, this paper focuses

on a speciﬁc type of SaS that enables data schema evolution (DSE) at runtime. This type of SaS requires

data storage while preserving the integrity between the logical model (i.e., SaS) and the data model (i.e., data

schema). Regarding DSE, a solution must encompass not only the migration of the original data model to a

new one but also the migration of data from the old schema to the new one without affecting the SaS regarding

incompatibility and/or lack of data integrity. Although relevant to the SaS domain, DSE is a research topic

that still needs further investigation to develop a comprehensive and robust solution. The objective of this

paper is to contribute to this research topic by presenting DynaSchema, a library that enables the evolution of

relational data schemas at runtime through a non-intrusive approach. To demonstrate the applicability of the

DynaSchema library, a case study was conducted. The ﬁndings suggest that the library has the potential to

make a signiﬁcant and efﬁcient contribution to the SaS domain.

1 INTRODUCTION

The role of software systems in modern society has

been of essential importance, facilitating the automa-

tion of tasks across numerous areas. These include

public and private institutions, communication sys-

tems, airports, entertainment media, and other appli-

cation areas. Therefore, it is of the utmost importance

that these software systems possess the capacity to

address uncertainties that may originate from a mul-

titude of sources, including alterations in their oper-

ational environment or changes in the requirements

of their users. In this regard, self-adaptive software

(SaS) represents a special type of software system,

distinguished by its capacity to respond to changes

in a dynamic environment. This encompasses the ca-

pacity to adapt to evolving user requirements or to au-

tonomously adjust in response to alterations in the ex-

ecution environment, including instances of degraded

quality, overloaded operations, and other forms of ad-

versity (Salehie and Tahvildari, 2009; Weyns, 2019).

From another perspective, reference architectures

(RA), a special type of software architecture, have be-

https://orcid.org/0000-0001-9737-0734

https://orcid.org/0000-0002-5784-6248

come an important element in the systematic reuse

of architectural knowledge. Consequently, a variety

of software systems domains, including SaS, have

recognized the necessity of encapsulating knowledge

(i.e., experiences and best practices) for the purpose

of disseminating and reusing this knowledge in the

development of systems (Bass et al., 2012). To illus-

trate, Camargo et al. (2024) designed an RA for the

self-adaptive cyber-physical system, named RA4Self-

CPS, Affonso et al. (2019) developed an RA for

self-adaptive, service-oriented mobile applications,

called RA4Self-MobApps, and Affonso and Naka-

gawa (2013) proposed a RA for SaS, named RA4SaS.

Regarding the last architecture, Affonso et al. (2024)

presented a second release, in which they highlighted

a tool for SaS modeling through a domain-speciﬁc

language (DSL) named eLanguage. Concerning de-

sign, it is notable that, although the aforementioned

architectures were originally conceived to serve a spe-

ciﬁc purpose, they have been developed in a way that

allows them to be adapted for use in a variety of dif-

ferent systems. This is achieved through the integra-

tion of three key principles: (i) modular organization;

(ii) an external adaptation approach; and (iii) the use

of computational reﬂection. The modular organiza-

722

Campos, G. N. and Affonso, F. J.

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain.

DOI: 10.5220/0013349000003929

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 27th International Conference on Enterprise Information Systems (ICEIS 2025) - Volume 2, pages 722-733

ISBN: 978-989-758-749-8; ISSN: 2184-4992

tion enables the reuse of knowledge, or modules, be-

tween such architectures. The external adaptation ap-

proach provides a means of designing adaptive soft-

ware independently of the speciﬁc adaptation mecha-

nisms involved. Finally, computational reﬂection has

been demonstrated to be a valuable resource for dis-

covering SaS information at runtime.

Among the SaS that can be found in both

academia and industry, this paper focuses on a type

of SaS that requires data storage while preserving the

integrity between the logical model (i.e., SaS) and the

data model (i.e., data schema) during execution and

adaptation cycles. As argued by Störl et al. (2020),

Hillenbrand et al. (2022) and Campos (2024), a solu-

tion for data schema evolution must encompass both

the schema and data migration in a way that does not

affect the software, either in terms of incompatibility

or lack of data integrity. As evidenced by the study

conducted by Campos (2024), data schema evolution

remains a research topic that requires further inves-

tigation within the SaS domain, as there is currently

no comprehensive and robust solution. Based on this

context, the objective of this paper is to present Dy-

naSchema, a library that enables the evolution of re-

lational data schema at runtime. To do so, this library

was designed to act as a middleware layer between

SaS (i.e., software entities designed by RA4SaS) and

the relational databases through a non-intrusive ap-

proach. In order to evaluate the applicability of Dy-

naSchema, a case study was conducted using a seller

system via the Internet. As a result, the library pro-

posed in this paper offers promising potential for con-

tributing to SaS, providing a feasible alternative for

addressing data schema evolution at runtime.

Based on the presented scenario, the library pro-

posed in this paper aims to consolidate itself as a

means to facilitate the data schema evolution at run-

time. In short, the main contributions of DynaSchema

can be summarized as follows: (i) design indepen-

dence, as it does not interfere with the SaS develop-

ment. In other words, the software engineer can con-

centrate on designing software entities without con-

cern for injecting cross-cutting interests into them to

ensure the functioning of the DynaSchema library;

(ii) modular organization, as it tends to facilitate the

expansion of its capacity to accommodate other types

of databases (e.g., NoSQL); and (iii) ease of cou-

pling, as it was designed based on a request and no-

tiﬁcation system. In essence, the adaptation engine

(e.g., RA4SaS) must be responsible for forwarding a

request for adaptation in the database to the library.

Next, the DynaSchema library must then notify the

adaptation engine, providing the result of the afore-

mentioned request. Besides contributions related to

the library, this paper also provides a set of require-

ments in Section 4.1, which may serve as a robust and

solid foundation for guiding the development or en-

hancement of new solutions for data schema evolu-

tion for SaS or other software domains. Thus, it is

expected to create a favorable scenario for the devel-

opment of SaS, since the DynaSchema provides an

easy means to deal with data schema evolution while

enabling the SaS side to evolve and scale.

The paper is organized as follows: Section 2 intro-

duces the essential concepts related to SaS, RA4SaS,

data schema evolution, and an overview of related

work; Section 3 addresses a running example; Sec-

tion 4 presents the DynaSchema, a library for the

evolution of relational database schema for SaS; Sec-

tion 5 describes a case study to show the applicability

of DynaSchema; Section 6 shows a brief discussion

of results; and Section 7 summarizes the conclusions

and perspectives for future work.

2 BACKGROUND AND RELATED

WORK

This section presents the background and related

work that contributed to the development of this pa-

per. First, the concepts of SaS, RA4SaS, and data

schema evolution are introduced. Next, related work

on the research topic of this paper is addressed.

Self-Adaptive Software. SaS is a special type of soft-

ware system that is capable of automatically modi-

fying itself in response to changes in its operating

environment (Krupitzer et al., 2015). As evidenced

by Salehie and Tahvildari (2009), the modiﬁcation of

the internal dynamics of SaS can be achieved through

changes in its various artifacts or attributes, which

can be executed with minimal human intervention or

without any human involvement whatsoever. Accord-

ing to Weyns et al. (2013), changes in the execution

environment of SaS may arise due to failures, ﬂuctu-

ations in available resources, shifts in user priorities,

and other factors. To overcome such challenges, SaS

includes speciﬁc features known as “self-properties”,

which provide ﬂexibility within the application and

help mitigate anticipated variations during its opera-

tional phase (Salehie and Tahvildari, 2009).

RA4SaS. This RA was designed to facilitate the de-

velopment of general-purpose SaS (Affonso and Nak-

agawa, 2013) based on three main concepts: (i) the

MAPE-K (Monitor, Analyze, Plan, Execute over a

shared Knowledge) adaptation loop (IBM, 2005),

which enables the management of SaS at runtime;

(ii) computational reﬂection (Maes, 1987), which pro-

vides the means to modify software entities at run-

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain

723

time; and (iii) the external adaptation approach (Sale-

hie and Tahvildari, 2009) proposes an adaptation logic

organization comprising two layers: (1) supervisor,

which contains the adaptation logic, and (2) super-

vised, which contains the SaS. Moreover, it is essen-

tial to underscore that this architecture operates with a

controlled adaptation modality, wherein the developer

must specify the adaptation level of each software en-

tity. In its most recent release, RA4SaS enables soft-

ware engineers to design software entities within a

tool designated as DSLModeler4SaS through a DSL

namely eLanguage. According to the RA4SaS’s fea-

tures, engineers can use adaptation and persistence

annotations to deal with these development concerns

(Affonso et al., 2024).

Data Schema Evolution. According to an investiga-

tion conducted by Campos (2024), the evolution of

data schema is a complex and broad subject that en-

compasses a multitude of concepts. Given the limi-

tations in terms of space and scope, this section will

focus on the principal concepts of data schema and

data migration.

As stated in Elmasri and Navathe (2019), a data

schema represents a formal description of the struc-

ture of a database, typically delineated during (or as

part of) the software design process. In the view of

Roddick (1995), schema modiﬁcation occurs when a

database system enables modiﬁcations to the schema

deﬁnition of a populated database.

According to Störl et al. (2020), the process of

data migration typically occurs subsequent to the

evolution of the underlying schema. In the existing

literature, a variety of strategies have been proposed,

including eager, lazy, incremental, and predictive ap-

proaches (Hillenbrand et al., 2022). In the ﬁrst strat-

egy, upon the detection of a change in the data model,

all entities are migrated to the new model. The sec-

ond strategy may be the opposite of the ﬁrst, where

data is lazily migrated as it is accessed in the new

data model release. The third strategy represents an

intermediate between the ﬁrst and second. It treats

changes in the data model as a lazy migration, grad-

ually accumulating migration debt that is addressed

by eager migration periods. The fourth strategy aims

to monitor historical access to data and its constituent

entities, ensuring the timely updating of data deemed

“hot” by the system.

As related work, a synthesis of the investigation

conducted by Campos (2024) is addressed, which

served as the foundation for the design of Dy-

naSchema. It is noteworthy that all studies presented

here addressed initiatives related to the evolution of

data schema and the migration of data. Next, the main

studies of this investigation are presented, categorized

by solution type.

A Database Management System (DBMS) rep-

resents a solution type that proposes the creation of

a DBMS that implements data schema evolution as a

native feature. In this direction, Neamtiu et al. (2013)

developed a solution that represents a modiﬁed ver-

sion of the SQLite database. In short, this solution en-

ables the introduction of new SQL commands to cre-

ate new data schema versions. To do so, it exploits the

march-forward nature of many database applications,

providing on-the-ﬂy updates while ensuring consis-

tency and transparency to database clients. Further-

more, the proposed solution eliminates the need to

support old schema versions after the schema update.

Solutions classiﬁed as Tool address the implemen-

tation and use of a tool to facilitate the evolution of the

data schema in a software system. JAVADAPTOR is

a solution developed by Pukall et al. (2013) that en-

ables the updating of the data schema of a Java ap-

plication. To do so, the solution combines schema al-

teration through class replacement by class renaming

and caller updates with Java HotSwap, utilizing con-

tainers and proxies. These operations are compatible

with all major standard Java virtual machines.

Solutions that introduce an intermediate layer be-

tween a software system (e.g., SaS) and its database

were classiﬁed as Middleware. In this regard,

de Jong et al. (2017) developed a middleware solu-

tion that allows multiple versions of an application to

store their schemas and share common data in a re-

lational database. To achieve this, the solution em-

ploys a mixed-state approach for each schema change

set, maintaining a set of synchronized “ghost tables”.

Hillenbrand and Störl (2023) proposed a manager that

enables the management of schema evolution and data

migration from a non-relational database. This solu-

tion uses heuristics to estimate the impact of schema

evolution when the migration situation can be elicited.

In contrast, schema migration strategies are used in

order to comply with service-level agreements (SLA).

Finally, Framework represents a solution type

based on a reusable infrastructure of components de-

signed to facilitate the evolution of the data schema

in a software system. To illustrate, Beurer-Kellner

et al. (2023) has proposed a framework that facili-

tates data sharing between web services subject to fre-

quent evolution. In short, this framework provides

a version-aware interface deﬁnition language (IDL)

for API (Application Programming Interface) design.

This comprises a typed JavaScript-based language for

deﬁning migration functions using the IDL deﬁnition

and a runtime environment for executing migrations.

Despite the signiﬁcant initiatives mentioned, no

solution has yet emerged that adequately supports

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

724

SaS development and addresses data schema evolu-

tion comprehensively and robustly. The studies pre-

sented in this section address the data schema evolu-

tion in particular approaches, focusing on the solution

in a speciﬁc type of target application. However, it is

observed that the authors did not consider the mini-

mum essential requirements (see Sections 2 and 4.1)

that this type of solution must implement.

3 RUNNING EXAMPLE

This section presents a running example that illus-

trates the evolution of data schema and data migration

related to a software entity undergoing an adaptation

process, as shown in Figure 1. In short, the purpose of

this example is to facilitate an understanding of how

the integrity of software entities can be maintained

throughout the adaptation process at runtime. The

maintenance of integrity aims to ensure that the goals,

domain requirements, database schema, and data of

each entity can be accommodated by the changes

made during the life cycle of these entities. More-

over, it is also important to note that although this ex-

ample has been developed with relational databases,

the fundamental concept behind it can be applied to

non-relational databases as well. Next, a description

of this example is addressed.

Access

Goals (G) / Domain (D)

SEntity

+ field: type

+ method(type): type

DBEntity

Schema

+ column: type

Data

Entity adaptation

Access

Goals (G') / Domain (D')

SEntity'

+ field: type

+ method(type): type

DBEntity'

Schema'

+ column: type

Data'

Data Migration

Schema adaptation

Self-adaptive Software (SaS)

Database

Adaptation

Engine

Figure 1: Running example.

In order to illustrate the proposed adaptation sce-

nario, the example was organized into two layers.

The top layer represents the software entities (i.e.,

SEntity and SEntity’), which is a generic term

used to refer to SaS. The bottom layer symbolizes

database entities (i.e., DBEntity and DBEntity’),

which are represented by a table in a relational

database and its data. In short, the objective is to

design an entity that meets a set of speciﬁed goals

(G) and operates within a designated software domain

(D). To illustrate this adaptation scenario, the entity

designated as SEntity must be adapted, and a new

entity named SEntity’ must be created.

As illustrated, the Adaptation Engine compo-

nent intercepts the entity’s adaptation, facilitating the

process through an external adaptation approach. In

essence, the Adaptation Engine changes the adapt-

able software, referred to as SEntity, to introduce,

update, or remove features and/or behaviors in the

new entity that will be generated (i.e., SEntity’).

This enables the new entity with the capacity to align

with the shifting goals (G’) or domain (D’) of its

stakeholders. This may result in a schema adapta-

tion from DBEntity to DBEntity’, as well as data

migration from Data to Data’. Regarding the adap-

tation process, three steps can be conducted, namely:

(i) software entity adaptation; (ii) data schema adap-

tation; and (iii) data migration. From an operational

viewpoint, the adaptation scenario presented in this

example encompasses two distinct scenarios, namely:

(A) When it is necessary to maintain the two enti-

ties in operation. Here, it is necessary to maintain

the functionality of both entities (i.e., SEntity and

SEntity’). This entails the preservation of the data

schemas associated with these entities, which must

remain active and accessible to facilitate data shar-

ing. It can thus be stated that only two adaptation

steps (i and ii) were executed. (B) When there is no

longer any reference to the original entity. Here, it is

determined that there are no longer any requests for

the original entity (i.e., SEntity), with all executions

pertaining solely to the new entity (i.e., SEntity’).

Consequently, the data belonging to the original en-

tity’s data schema can be migrated to the new entity’s

data schema. Therefore, it can be stated that all three

steps (i, ii, and iii) were executed.

4 DynaSchema

This section presents the DynaSchema, a library de-

signed to facilitate the evolution of relational data

schema for the SaS domain. To do so, this library im-

plements a ﬂexible data persistence mechanism based

on the JPA (Java Persistence API) speciﬁcation. Thus,

this mechanism enables the use of object-relational

mapping (ORM) for the development of software en-

tities. In order not to interfere with the SaS develop-

ment (i.e., software entities designed by RA4SaS (Af-

fonso et al., 2024)), the library was designed through

a non-intrusive approach, implemented as a middle-

ware layer between SaS and the underlying database.

Regarding the design, the DynaSchema library was

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain

725

developed based on a set of requirements gathered

through a literature mapping conducted by Campos

(2024). Section 4.1 provides an overview of such re-

quirements, and Section 4.2 presents the architectural

view for the DynaSchema library in a model orga-

nized in six modules.

4.1 DynaSchema Requirements

This section presents the requirements that were gath-

ered from the study conducted by Campos (2024) and

that served as the fundamental base of the design of

the DynaSchema library. Next, a description of each

requirement is addressed.

R1. A solution for data schema evolution must be de-

signed to facilitate the transformation of SaS’s inter-

nal structure while maintaining access to the data pre-

viously stored in a relational database. A process for

this solution type entails two distinct schemas: (1) an

object-oriented schema that reﬂects the SaS struc-

ture, speciﬁcally the software entities (Mitrpanont and

Fugkeaw, 2006); and (2) a database schema that re-

ﬂects the structure of the columns and tables utilized

for data storage (Santos et al., 2011). To illustrate

the complexity of these operations, two scenarios will

be presented, namely: the decomposition of classes

and the breaking of relationships. The ﬁrst requires

the creation of a new table for each newly deﬁned

subclass, besides the deﬁnition of foreign keys to

facilitate the relationship between these tables (i.e.,

columns that store attribute data). The second aims

to remove the tables representing the subclasses and

insert their columns into the table representing the su-

perclass (Götz and Kühn, 2015).

R2. A solution for data schema evolution should fa-

cilitate the migration of the application’s data schema

to be conducted at runtime. The investigation con-

ducted by Campos (2024) revealed that the schema

migration process becomes increasingly costly and

may impose some form of downtime on the data alone

as the volume of data increases signiﬁcantly. To

overcome these adversities, it is recommended that

asynchronous mechanisms must be adopted for the

migration of the application’s data schema together

with notiﬁcation messages. Therefore, SaS can re-

quest a schema migration, and the solution notiﬁes

the user when this process begins and ends. Solutions

based on the runtime concept facilitate the execution

of insert, update, and delete operations by SaS while

schema migration is in progress. To do so, such solu-

tions must implement a queue, where the migration is

only complete when all queue actions are completed.

However, the data query operation requires the solu-

tion to inform SaS when the migration process has

ended, preventing the system from recovering partial

data (Marks and Sterritt, 2013; Hillenbrand and Störl,

2023).

R3. During the SaS’s life cycle, it may be possible

that it has to alter the structure of an internal com-

ponent itself and, next, insert it into the operational

environment. Therefore, it can be stated that there is

a transient state in which parts of the system may uti-

lize the previous version of the data schema, while

the migrated components may operate with the most

recent iteration of this schema. In order to meet this

requirement, the solution must facilitate SaS’s inter-

action with its data, even in a mixed state that re-

quires interaction with both the old and new versions

of the data schema (de Jong et al., 2017). To do so,

the solution must incorporate a data synchronization

mechanism to ensure that changes made to the old

schema version are reﬂected in the new version and

vice versa (Wang et al., 2012).

R4. As previously stated in Section 2, SaS must

prompt the alteration of the data schema in accor-

dance with the adaptation executed in the software en-

tities. In some cases, it may be necessary to map data

between software entities and their corresponding ta-

bles in the database. To illustrate this scenario, a table

that contains a numeric column for data categoriza-

tion will be considered, where each category is repre-

sented by a positive integer number. In order to opti-

mize the semantics of this information, the new data

schema requires that this column be of the text type,

with each category being labeled by a name. There-

fore, SaS must establish a mapping between the old

numerical category and its equivalent label (Namdeo

and Suman, 2021).

R5. As outlined in Section 2, the development of SaS

is a challenging task due to the numerous issues that

must be addressed with the objective of enabling the

software to execute modiﬁcations at runtime. Ana-

lyzing relational databases available in the literature,

it was noted that these databases have different SQL

dialects. For instance, an auto-increment column in

Microsoft SQL Server database must be deﬁned as

IDENTITY, and the same feature is deﬁned in the

MariaDB database as AUTO_INCREMENT. Therefore, it

can be stated that a solution capable of handling dif-

ferent types of relational databases would be advanta-

geous (Namdeo and Suman, 2021). To do so, a solu-

tion must be designed based on a ﬂexible design capa-

ble of allowing new SQL dialects to be inserted with-

out signiﬁcant changes in its source code (Beurer-

Kellner et al., 2023).

R6. During the evolution of a software entity (i.e.,

SaS), the database schema may also undergo changes,

as may the data associated with it. It is thus possible to

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

726

have both old and new entities running concurrently,

each with its own database schema. The functional-

ity that emerges from this scenario is the ability of a

SaS to recognize and deﬁne the trigger for migrating

data from the old schema to the new one. Therefore,

the solution for data schema evolution must also pro-

vide notiﬁcation to the SaS regarding the status of the

schema evolution and data migration. This is neces-

sary for the SaS to recognize that the old entity has

evolved into a new one and that there are no users

connected to it, allowing for the deﬁnitive schema and

data migration to be performed. Otherwise, an incom-

plete schema migration could cause the SaS to break

or execute with inconsistent data (Wang et al., 2012).

4.2 DynaSchema Architecture

Figure 2 illustrates the DynaSchema architectural de-

(R1 to R6) outlined in Section 4.1. As can be ob-

served, the DynaSchema library (dotted line) was de-

signed as a data persistence mechanism, acting as a

middleware layer between SaS and the database. This

design option enables the library to behave as a non-

intrusive solution concerning other layers, speciﬁcally

the database and the SaS layer. Moreover, the library

was structured into a modular format to provide a vi-

able option for stakeholders seeking to design SaS

that requires data schema evolution at runtime. From

an operational viewpoint, the Middleware layer re-

ceives a request from the adaptation process (i.e., SaS

layer) and performs the data schema evolution based

on a well-deﬁned sequence process. The SaS layer

must be notiﬁed in relation to the changes made in

the Database layer so that the software entities can

handle their schema properly. Next, a description of

each module is addressed.

State Manager. The objective of this module is to fa-

cilitate the storage of metadata that will be utilized by

other modules within the DynaSchema library for the

purpose of coordinating their respective functionali-

ties [R3]. To illustrate, this metadata comprises data

regarding the current data schema, the status of on-

going schema migrations, the status of ongoing data

migrations, a list of schema and data migration his-

tories, information about database connections, and a

list of ﬂags for identifying the status of each schema

and data migration. The aforementioned ﬂags facil-

itate the identiﬁcation of whether the activities were

correctly executed or require rollback. To enable

such operations, this module provides a local data

repository (e.g., database, XML (eXtensible Markup

Language) or JSON (JavaScript Object Notation) text

ﬁles) to store the aforementioned metadata of each ap-

plication during the data schema evolution process so

that other modules can manage them without conﬂict-

ing access.

Persistence Manager. The principal objective of this

module is to address the issue of data persistence in

relational databases for each application (i.e., SaS)

[R1]. To perform the ORM, this module must have

access to the metadata contained in the Schema Man-

ager module. This is necessary for it to be able to

determine the appropriate mapping type to be con-

ducted, namely: (1) the current data schema or (2) the

candidate data schema (mixed state). To facilitate

such operations, this module implements reﬂection-

based mechanisms for discovering and generating in-

formation at runtime, which is then used for persisting

objects in the database and vice versa. Moreover, the

mapping strategy incorporated into this module repre-

sents a notable distinction from existing conventional

ORM solutions documented in the literature. In such

solutions, the mapping between classes and tables is

typically conﬁgured at the outset of the software de-

velopment phase. On the other hand, this module

enables runtime mapping following the current data

schema of the Schema Manager module.

Schema Manager. The objective of this module is

to ensure the effective management of data schema

versions (i.e., current and candidate) utilized by an

application (i.e., SaS) [R3] throughout the migra-

tion process. To this end, the module implements

a strategy capable of handling both schemas simul-

taneously, preventing an incorrect mapping between

classes and tables. In essence, the modiﬁcation ac-

tions of the current data schema must be performed

independently in a candidate schema, thus prevent-

ing any disturbance to the application that owns the

current data schema. Furthermore, this module must

also be responsible for storing a list of actions for

modifying data schemas, enabling the user to request

new modiﬁcations throughout the application’s exe-

cution cycle. Once the aforementioned actions have

been successfully applied, they can be utilized to fa-

cilitate future data schema migration requests, as the

sequence of steps has already been deﬁned.

Migration Manager. The principal objective of this

module is to facilitate the management of the database

schema migration process [R1]. It is important to note

that this process encompasses alterations to both the

application (object-oriented) and the database schema

(relational). To this end, this module coordinates the

migration process following three steps: (i) the data

schema must be migrated, with the Schema Migrator

module assuming responsibility for this task; (ii) the

data must be migrated [R4], with the Data Migra-

tor module assuming responsibility for this task; and

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain

727

Goals (G') / Domain (D')Goals (G) / Domain (D)

Access

Data

SEntity

+ field: type

+ method(type): type

DBEntity

Schema

+ column: type

Data

SEntity'

+ field: type

+ method(type): type

DBEntity'

Schema'

+ column: type

Data'

SaS

Database

Persistence Manager

Complete

Notification

Request

Schema

State Manager

Map

Entities

Schema Manager

Candidate/Current Schema

Access

Data

Map

Entities

Candidate/Current Schema

Old Schema

New Schema

Metadata

Adaptation

Process

Notification Manager

Migration Manager

Schema

Migrator

Data

Migrator

Notifications

Dialect

Entity

Mapping

Entity

Mapping

Figure 2: DynaSchema architecture.

(iii) the context must be changed to the current data

schema [R6], which requires coordination between

the modules Schema Manager to change the cur-

rent schema and State Manager to save the changes.

Furthermore, the Migration Manager module uses

the State Manager module to store a list of database

schema modiﬁcation actions, thereby enabling the

user to request additional modiﬁcations. Upon the

initiation of a data migration request, the actions ac-

cumulated in the Schema Manager module can be

immediately applied via Migration Manager mod-

ule. In addition, the State Manager module is em-

ployed to store metadata regarding the ongoing mi-

gration process, which is analyzed in three key activ-

ities: (1) the completion status of the schema migra-

tion, including the identiﬁcation of any errors, (2) the

completion status of the data migration, including the

identiﬁcation of any errors, and (3) the completion

status of both the schema and data migrations, en-

abling the context to be switched to the most current

schema version and data.

Notiﬁcation Manager. This module is responsible

for notifying the SaS of the actions being performed

by the DynaSchema library [R2]. An increase in the

quantity of data stored in the database may result in

delays in the data schema migration process. For

this reason, the migration must be performed asyn-

chronously to prevent the execution of SaS from be-

ing compromised and/or interrupted. To overcome

this adversity, SaS must be informed of the start and

end of this task to prevent the migration process from

becoming faulty. Thus, it is of essential importance

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

728

the capacity to ascertain when a migration process is

complete, as partial information may otherwise be re-

covered if the migration process is still in progress.

Furthermore, SaS can also be informed about the pro-

cess of removing the old version of the data schema,

enabling a self-adaptation cycle to be completed.

Dialect. This module is responsible for deﬁning the

SQL statements executed by the DynaSchema library

[R5]. The software engineer can choose a relational

DBMS that best aligns with the requirements of the

application domain in question (i.e., SaS). It is im-

portant to note that the syntax of an SQL statement

can vary signiﬁcantly between different DBMSs. To

address this issue, this module must implement sup-

port for SQL dialects to facilitate compatibility with

the various DBMSs. Additionally, the software engi-

neer must conﬁgure SaS in conjunction with the Dy-

naSchema library to operate with a speciﬁc dialect

that aligns with their requirements. This conﬁgura-

tion must be performed within the metadata stored by

the State Manager module.

5 CASE STUDY

This section presents a case study conducted to evalu-

ate the applicability, strengths, and weaknesses of the

DynaSchema library proposed in this paper. The sub-

ject application for this empirical analysis is a web

system that manages the sales of a book distributor,

referred to from this point on as SallesSys. Next, a

description of this system and the empirical strategies

adopted for conducting this case study are presented.

Subject Application. The SallesSys system was de-

veloped with the objective of streamlining the process

of selling books. To do so, this system has an online

catalog that enables customers to access a comprehen-

sive catalog of available titles. With regard to opera-

tional procedures, the purchase of these books is per-

mitted only to customers duly registered in SallesSys,

which can be either individuals or legal entities. To

make a purchase, these customers must contact one

of the system’s salespersons to place an order. In the

initial purchase, the salesperson must ﬁrst register the

customer in the system based on the following infor-

mation: personal data, contact information, and deliv-

ery and billing addresses. Next, the salesperson must

create a new order comprising the books requested by

the customer. After the service, the salesperson must

verify the order information with the customer, com-

plete the incorporation of this sales order into Sal-

lesSys, and transfer the customer to the ﬁnance de-

partment for the payment of the order.

As illustrated in Figure 3, the development of the

SallesSys system can be summarized in two distinct

phases: (1) architectural design; and (2) development

activity. Regarding architectural design (Phase 1),

SallesSys was organized in three layers: presentation,

application, and database. For reasons of space and

scope, this section will focus on the design, devel-

opment, and adaptation of the software entities (i.e.,

SaS) within the application layer. At this phase, the

software engineer concentrates their efforts on the ar-

chitectural design of the system, which is based on

design patterns, architectural patterns, and architec-

tural decisions. As a result, a set of templates must

be developed for automatic code generation, as evi-

denced by the presence of the .ftl ﬁles in each layer

of the application layer.

Concerning the development (Phase 2), the soft-

ware engineer can utilize the DSLModeler4SaS tool

to facilitate the development of software entities for

the SallesSys system. Thus, the software engineer

can design software entities and utilize the automated

process of RA4SaS to generate source code in a tar-

get programming language (i.e., Java). As may be

observed in the SallesSys project, the engineer cre-

ates a “.entity” ﬁle within the sallessys.entity

package for each software entity of the SallesSys sys-

tem. Following this phase, the templates developed in

Phase 1 for the code generation can be imported to

Templates section. Moreover, it is worth mentioning

that the conﬁguration of these templates in relation to

the software entities is an essential task for generating

the source code. To do so, the DSLModeler4SaS tool

provides a template conﬁguration wizard that facili-

tates the speciﬁcation of the desired conﬁguration in

relation to the software entities. Due to the limitations

of space and scope, the details of the conﬁguration

wizard will not be reported in this paper. However, a

more comprehensive understanding of this wizard can

be seen in the study by Affonso et al. (2024).

Empirical Research Strategy. To demonstrate the

functionalities of the DynaSchema library, it is as-

sumed that the SallesSys system was properly imple-

mented and deployed in the execution environment,

as described in Section 3. As illustrated in Figure 3,

the Contact and Person entities (see .entity ﬁles)

have ORM annotations for mapping of the software

entities to database, besides the adaptation annota-

tions (e.g., @ClassAnnotation – Line 1). Based on

the RA4SaS persistence module

, the following an-

notations are used: @Entity (Line 3), @Id (Line 5),

and @Relationship (Lines 8 and 10). Moreover,

both entities have been annotated with the adaptation

According to Affonso et al. (2024), RA4SaS has a per-

sistence annotation module based on the JPA, which will

not be presented in this paper because of space limitations.

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain

729

(Phase 1) Architectural design

Software

Engineer

Design Patterns

Architectural Patterns

Architectural Decisions

Application Layer

serviceentity

Database layer

entity.ftl

dao

provider

daoFactory.ftl

genericDAO.ftl

genericDAOImpl.ftl

entityDAO.ftl

entityManagerProvider.ftl

serviceProvider.ftl

serviceFactory.ftl

entityService.ftl entityServiceImpl.ftl

config

persistenceUnity.ftl

Presentation layer

(Phase 2) Development activity

1. @ClassAnnotation(...,

2. adaptationLevel=CLASSES, ...)

3. @Entity()

4. public entity Contact {

5. @Id(strategy = IDENTITY)

6. private long idContact;

7. private TString phoneNumber;

8. private TString email;

9. }

Contact.entity

1. @ClassAnnotation(...,

2. adaptationLevel=CLASSES, ...)

3. @Entity(inheritanceType = SINGLE_TABLE)

4. entity Person {

5. @Id(strategy = IDENTITY)

6. private int id;

7. private TString name;

8. @Relationship(type=ONE_TO_ONE, fetch=LAZY)

9. private Contact contact;

10. @Relationship(type=ONE_TO_MANY, fetch=LAZY)

11. private TList<Address> address;

12. }

Person.entity

Figure 3: Architectural design and entity development.

level CLASSES (RA4SaS adaptation module), indicat-

ing that they can undergo structural and behavioral

modiﬁcations.

As outlined in Section 4.2, the adaptation of a

software entity is controlled by an adaptation pro-

cess (i.e., RA4SaS), which triggers events to the Dy-

naSchema library containing instructions for modify-

ing the application’s data schema. As highlighted in

bold in the code listings of the Contact and Person

entities (Figure 3 – Line 7), the phoneNumber and

name attributes will be used to characterize the adap-

tation of a software entity (i.e., SaS) and exemplify

how an entity of the data schema, associated with

these entities, can be modiﬁed to accommodate the

new adaptation concerns. In short, such modiﬁca-

tions can be summarized in two scenarios: (A) The

addition of attributes: the phoneNumber attribute of

the Contact entity must be removed and two new at-

tributes (i.e., homePhone and businessPhone) will

be created; and (B) The breaking of attributes: the

lastName attribute will be created in the Person en-

tity, allowing it to handle both name and lastName

attributes simultaneously. To illustrate the behavior

of the DynaSchema library, it is sufﬁcient to consider

the ﬁrst scenario, as it encompasses the operations of

both scenarios and is the most complex in terms of

the number of operations. Figure 4 illustrates the se-

quence of steps and the source code generated by Dy-

naSchema.

The SaS is initiated in its execution environment

(Step 1), and an adaptation activity is triggered fol-

lowing the interests of the application (i.e., SaS). Fol-

lowing the previous step, the adaptation process (i.e.,

RA4SaS) must coordinate the calls to the data schema

evolution activities provided by the DynaSchema li-

brary. To do so, the SaS adaptation process must reg-

ister itself with the library (Line 1), becoming aware

of the notiﬁcations triggered by the asynchronous ac-

tions taken by the DynaSchema library (Step 2).

Steps 3 to 5 represent the changes to the entity, as

one attribute is being removed and two attributes are

being added. In Line 3, the phone attribute is removed

from the Contact entity, thus allowing for the inser-

tion of the homePhone and businessPhone attributes

(Lines 5 to 9 and Lines 11 to 15). The following code

snippets illustrate the declaration of the aforemen-

tioned attributes, their designation as either “name”

and “type”, the deﬁnition of their names as database

columns, and their assignment to the Contact soft-

ware entity.

In Step 6, the mapping of attributes is executed

so that the migration process can be achieved. The

phone attribute is mapped to homePhone (Lines 17

to 20) to facilitate the transfer of existing data to the

new entity within the database. All structural changes

to the Contact entity and its attributes mapping are

committed to the candidate data schema (Line 21).

Upon completion of the schema migration

(Step 7), the data can be migrated from the old

schema to the new one (Step 8) so that the library can

remove the old schema and designate the new one as

the current schema for the software entity (Step 9).

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

730

SaS DynaSchema

SaS adaptation

(1)

(3)

Notification

configuration

(4)

Remove field

(5)

Add field

Source code

(6)

Add field

(7)

Field Mapping

(8)

Schema migration

(11)

SaS adaptation

1. DynaSchema.attachObserver(this);

3. DynaSchema.removeEntityField(Contact.class, "phone");

5. DSField homePhone = new DSField();

6. homePhone.setName("homePhone");

7. homePhone.setType(String.class.getCanonicalName());

8. homePhone.setColumnName("homePhone");

9. DynaSchema.addEntityField(Contact.class, homePhone);

10.

11. DSField businessPhone = new DSField();

12. businessPhone.setName("businessPhone");

13. businessPhone.setType(String.class.getCanonicalName());

14. businessPhone.setColumnName("businessPhone");

15. DynaSchema.addEntityField(Contact.class, businessPhone);

16.

17. FieldMapping homePhoneMapping =

18. new FieldMapping(Contact.class, "homePhone");

19. homePhoneMapping.setSourceField("phone");

20. DynaSchema.addFieldMapping(homePhoneMapping);

21. DynaSchema.saveState();

22.

23. DynaSchema.migrateSchema();

24.

25. DynaSchema.migrateData();

26.

27. DynaSchema.switchSchema();

(9)

Data migration

(2)

Schema switch

(10)

Figure 4: Sequence of steps for data schema evolution.

Upon switching to the new schema, DynaSchema

must notify SaS that the activity has been completed

(Step 10) so that the software entity (i.e., SaS) can

utilize the new data schema (Step 11).

6 DISCUSSION OF RESULTS

This section summarizes the main ﬁndings and dis-

cusses the relevance of the DynaSchema library to

the SaS and Software Engineering communities. The

main ﬁndings and results are listed as follows.

Independent and Reusable Design. DynaSchema

is a middleware-type solution that is capable of han-

dling data schema evolution for SaS. To do so, the

library operates as an intermediary between SaS and

its database, offering the following functionalities:

(i) migration of the relational data schema; (ii) data

persistence in the database; and (iii) data migration

between schemas. Moreover, its modular organiza-

tion allows the library to be an extensible solution,

capable of supporting other types of databases, and

reusable, serving as a reference for the design of new

solutions.

Support for Different Data Models. The process

of migrating data schemas within the DynaSchema li-

brary can be classiﬁed into two primary categories:

object-oriented and database schemas. The ﬁrst refers

to the structural conﬁguration of the software enti-

ties (i.e., SaS), which can be classiﬁed as classes

of the object-oriented paradigm within the context

of RA4SaS. The second is related to the database

schema, which represents the structure of the tables

(in the case of relational databases) for the storage of

SaS data. In this sense, it can be stated that the Dy-

naSchema library may operate with two distinct data

models: (i) the database model, which is associated

with the operations to evolve the database schema;

and (ii) the object-relational model, which is linked to

the ORM approach implemented by the DynaSchema

library to address data persistence.

Segmentation of Operations. The data schema evo-

lution process was structured into discrete stages in

the DynaSchema library, separately delineating the

migration of the database schema and the data con-

tained in such schema. This segmentation enables the

library, in conjunction with SaS, to identify the opti-

mal temporal window for the data migration process,

thereby avoiding potential issues associated with sys-

tem interruption or data inconsistency.

Schema Versioning. The DynaSchema library was

developed with the objective of providing a solu-

tion that could handle the versioning of the SaS data

schema over time to avoid any disruption to the SaS

execution process. This feature incorporates inter-

nal operational mechanisms that safeguard against

failures in the SaS data schema evolution process,

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain

731

thereby preventing adverse impacts on application

performance and minimizing instances of downtime.

Furthermore, this feature offers a viable method for

monitoring SaS during the initiation of a schema evo-

lution operation. The stakeholders of this SaS can

trace the evolution process, thereby facilitating any

manual reversion process.

Learning Curve. The library proposed in this paper

was designed to facilitate the preservation of develop-

ers in their native development environment, specif-

ically in the SaS domain. To this end, the cognitive

effort required to learn to use DynaSchema is reduced

by the presence of a facilitator (i.e., middleware layer)

situated between SaS and the database. Therefore,

they can focus their attention on the development of

the software entities without concern for the injection

of source code to address data schema evolution is-

sues.

As detailed in this paper (see Section 4), while the

library design incorporated aspects such as design in-

dependence and reusability, two considerations war-

rant particular attention. Firstly, despite adherence to

the proposed requirements (see Section 4.1), the li-

brary proposed in this paper cannot be considered a

comprehensive solution that can address all the needs

required by a real-world SaS. Secondly, although Dy-

naSchema was evaluated in a development and execu-

tion context associated with RA4SaS (see Section 5),

the gathered evidence suggests that this library can be

easily adapted for other software domains.

7 CONCLUSIONS

This paper presented DynaSchema, a library that en-

ables dealing with data schema evolution at runtime

through a non-intrusive approach. This type of ap-

proach enables the integration of DynaSchema with

SaS as an intermediary layer between the database

and SaS. As presented in Section 4.2, the proposed li-

brary addresses all the requirements reported in Sec-

tion 4.1, which were established based on the study

conducted in Campos (2024). The aforementioned re-

quirements provide a robust and solid foundation for

guiding the development or enhancement of new so-

lutions addressing data schema evolution in the SaS

domain or other software domains. Based on the pre-

sented context, the principal contributions of this pa-

per are as follows:

• for the SaS area, by providing a library that facil-

itates the development of SaS that requires data

schema evolution at runtime;

• for the software engineering area, by presenting a

set of requirements that served as a solid base for

DynaSchema design, and that may be utilized as

a reference for the development of new solutions

or enhancement of existing solutions; and

• for different development areas, by providing a

solution based on modular organization-based and

reusable design. This feature enables the potential

extension of Dynachema to cover other database

types (e.g. NoSQL databases).

Regarding future work on DynaSchema, at least

three activities are intended: (i) conduction of more

case studies or proof of concepts intending to com-

pletely evaluate the proposed library, including dif-

ferent adaptation scenarios and databases; (ii) instan-

tiation of DynaSchema for other programming lan-

guages to evaluate its structures and respective el-

ements, behavior, and relationships between them

when a new homogeneous or heterogeneous compu-

tational environment is utilized; (iii) use of this li-

brary in the industry to evaluate its behavior when it

is applied in a larger real environment of development

and execution. Therefore, based on the evidence pre-

sented in this paper, a favorable research scenario can

be delineated, as it is expected that the proposed li-

brary may prove to be an effective contribution to both

the software engineering and SaS communities.

ACKNOWLEDGMENTS

This study was ﬁnanced in part by the Coordenação

de Aperfeiçoamento de Pessoal de Nível Superior

- Brasil (CAPES), under Grant 88887.670715/2022-

00; and in part by the São Paulo Research Foun-

dation (FAPESP), Brazil, under Grant 2017/01703-6

and Grant 2019/21510-3.

REFERENCES

Affonso, F. J., Nagassaki Campos, G., and

Guiguer Menaldo, G. (2024). A reference architec-

ture based on reﬂection for self-adaptive software: A

second release. IEEE Access, 12:97476–97499.

Affonso, F. J. and Nakagawa, E. Y. (2013). A reference

architecture based on reﬂection for self-adaptive soft-

ware. In The 7th Brazilian Symposium on Software

Components, Architectures and Reuse (SBCARS’ 13),

pages 129–138.

Affonso, F. J., Passini, W. F., and Nakagawa, E. Y. (2019).

A reference architecture to support the development

of mobile applications based on self-adaptive services.

Pervasive and Mobile Computing, 53:33 – 48.

Bass, L., Clements, P., and Kazman, R. (2012). Soft-

ware Architecture in Practice. Addison-Wesley Pro-

fessional, 3rd edition. Published:05 October 2012.

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

732

Beurer-Kellner, L., von Pilgrim, J., Tsigkanos, C., and

Kehrer, T. (2023). A transformational approach to

managing data model evolution of web services. IEEE

Transactions on Services Computing, 16(1):65–79.

Camargo, M. P. d. O., Pereira, G. d. S., Almeida, D.,

Bento, L. A., Dorante, W. F., and Affonso, F. J.

(2024). Ra4self-cps: A reference architecture for self-

adaptive cyber-physical systems. IEEE Latin America

Transactions, 22(2):113–125.

Campos, G. N. (2024). Dynaschema: uma biblioteca

para evolução de banco de dados relacional para o

domínio de software autoadaptativo. Master thesis

(in Portuguese), São Paulo State University (Unesp),

Institute of Geosciences and Exact Sciences (IGCE),

Rio Claro. Unesp’s Graduate Program in Computer

Science (PPGCC), Avaliable in https://hdl.handle.net/

11449/255063, Acessed on: March 21, 2025.

de Jong, M., van Deursen, A., and Cleve, A. (2017). Zero-

downtime sql database schema evolution for continu-

ous deployment. In Proceedings of the 39th Interna-

tional Conference on Software Engineering: Software

Engineering in Practice Track, ICSE-SEIP ’17, page

143–152, Buenos Aires, Argentina. IEEE Press.

Elmasri, R. and Navathe, S. B. (2019). Sistemas de banco

de dados. Pearson Education do Brasil, 7 edition.

Götz, S. and Kühn, T. (2015). Models@run.time for object-

relational mapping supporting schema evolution. In

CEUR Workshop Proceedings, volume 1474, page 41

– 50.

Hillenbrand, A., Störl, U., Nabiyev, S., and Klettke, M.

(2022). Self-adapting data migration in the context

of schema evolution in nosql databases. Distributed

and Parallel Databases, 40(1):5–25.

Hillenbrand, A. and Störl, U. (2023). Managing schema

migration in nosql databases: Advisor heuristics vs.

self-adaptive schema migration strategies. Communi-

cations in Computer and Information Science, 1708

CCIS:230 – 253.

IBM (2005). An architectural blueprint for au-

tonomic computing. [On-line], World Wide

Web. Avaliable in https://drive.google.com/ﬁle/

d/1ZY5wMBsugcCoeMCn2GxrX1ZNAr7dUHHT/

view?usp=sharing, Acessed on: March 21, 2025.

Krupitzer, C., Roth, F. M., VanSyckel, S., Schiele, G.,

and Becker, C. (2015). A survey on engineering ap-

proaches for self-adaptive systems. Pervasive and Mo-

bile Computing, 17:184–206.

Maes, P. (1987). Concepts and experiments in compu-

tational reﬂection. In Conference Proceedings on

Object-Oriented Programming Systems, Languages

and Applications, OOPSLA ’87, page 147–155, New

York, NY, USA. Association for Computing Machin-

ery.

Marks, R. M. and Sterritt, R. (2013). A metadata

driven approach to performing complex heteroge-

neous database schema migrations. Innovations in

Systems and Software Engineering, 9(3):179 – 190.

Mitrpanont, J. L. and Fugkeaw, S. (2006). Direct access

versioning for multidimensional database schema cre-

ation. In The Sixth IEEE International Conference

on Computer and Information Technology (CIT’06),

pages 17–17.

Namdeo, B. and Suman, U. (2021). A model for relational

to nosql database migration: Snapshot-live stream db

migration model. In The 7th International Conference

on Advanced Computing and Communication Systems

(ICACCS), volume 1, pages 199–204.

Neamtiu, I., Bardin, J., Uddin, M. R., Lin, D.-Y., and

Bhattacharya, P. (2013). Improving cloud availabil-

ity with on-the-ﬂy schema updates. In Proceedings of

the 19th International Conference on Management of

Data, COMAD ’13, page 24–34, Mumbai, Maharash-

tra, IND. Computer Society of India.

Pukall, M., Kästner, C., Cazzola, W., Götz, S., Grebhahn,

A., Schröter, R., and Saake, G. (2013). Javadaptor -

ﬂexible runtime updates of java applications. Software

- Practice and Experience, 43(2):153 – 185.

Roddick, J. F. (1995). A survey of schema versioning is-

sues for database systems. Information and Software

Technology, 37(7):383–393.

Salehie, M. and Tahvildari, L. (2009). Self-adaptive soft-

ware: Landscape and research challenges. ACM

Transactions on Autonomous and Adaptive Systems,

4(2).

Santos, R. J., Bernardino, J., and Vieira, M. (2011). 24/7

real-time data warehousing: A tool for continuous ac-

tionable knowledge. In The 35th Annual Computer

Software and Applications Conference, pages 279–

288.

Störl, U., Klettke, M., and Scherzinger, S. (2020). Nosql

schema evolution and data migration: State-of-the-art

and opportunities. Advances in Database Technology

- EDBT, 2020-March:655–658.

Wang, Q., Du, Z., and Liu, N. (2012). Design and realiza-

tion of database online migration. In Proceedings of

2012 2nd International Conference on Computer Sci-

ence and Network Technology, pages 1195–1198.

Weyns, D. (2019). Software engineering of self-adaptive

systems. In Cha, S., Taylor, R. N., and Kang, K., ed-

itors, Handbook of Software Engineering, pages 399–

443, Cham. Springer International Publishing.

Weyns, D., Schmerl, B., Grassi, V., Malek, S., Mirandola,

R., Prehofer, C., Wuttke, J., Andersson, J., Giese, H.,

and Göschka, K. M. (2013). On patterns for decentral-

ized control in self-adaptive systems. In de Lemos, R.,

Giese, H., Müller, H. A., and Shaw, M., editors, Soft-

ware Engineering for Self-Adaptive Systems II: Inter-

national Seminar, Dagstuhl Castle, Germany, Octo-

ber 24-29, 2010 Revised Selected and Invited Papers,

pages 76–107, Berlin, Heidelberg. Springer Berlin

Heidelberg.

DynaSchema: A Library to Support the Relational Data Schema Evolution for the Self-Adaptive Software Domain

733
