Management of Customized Privacy Policies

Jens Leicht

and Maritta Heisel

Paluno - The Ruhr Institute for Software Technology, University of Duisburg-Essen, Germany

{jens.leicht, maritta.heisel}@uni-due.de

Keywords:

Data Value Chain, Data Protection Legislation, Data Accountability.

Abstract:

While privacy policies are well established to express data processing practices, customizable privacy policies

are a researched but not established practice to empower data subjects. One of the hurdles, hindering the

acceptance of customizable policies, is the management of large amounts of privacy policies, when each

data subject has their own policy. We propose a Privacy Policy Management (PPM) system, which handles

customized policies and distributes them to all data processors. In addition, our PPM keeps track of where

and why data are being transferred. This information can be provided to the data subjects, so that they can see

that the data controller complies to the policy agreed upon. The log of data transfers can also be used by data

protection authorities, to check the GDPR-compliance of the data controller or for investigations in case of a

data breach. We discuss the architecture of our PPM, how it operates, and integrate it into the Privacy Policy

Compliance Guidance framework.

1 INTRODUCTION

Privacy policies are an important tool for service

providers to be able to comply with data protection

legislation, like the General Data Protection Regula-

tion (GDPR) of the European Union (European Par-

liament and Council of the European Union, 2016).

These policies inform the data subjects about the data

processing practices of the data controller and are

used to collect data subjects’ consent. While there has

been development towards customizable privacy poli-

cies with, e.g., the Platform for Privacy Preferences

(P3P) or the PriPoCoG-framework, it remains open

how data controllers shall handle the large amount of

different customized privacy policies (Cranor et al.,

2006; Leicht et al., 2022). From this gap, we derived

the following research questions:

RQ1. How can data controllers and data processors

be supported, when using customizable privacy

policies?

RQ2. How can data ﬂows be made more transparent

towards the data subjects?

To address the research questions, we propose a

ports data controllers and processors in handling cus-

https://orcid.org/0009-0003-5612-5590

https://orcid.org/0000-0002-3275-2819

tomized privacy policies. We consider not only the

data controllers’ storage of customized privacy poli-

cies, but also the different stages of the distribution

of the policies. The privacy policies are transferred

along the data value chain, so that all data processors

know the agreed upon privacy policy and can adhere

to customized policies. Our PPM manages policy cus-

tomization by the data subject, as well as policy up-

dates by the data controller itself. We integrate our

PPM into the PriPoCoG-framework. Future work is

needed to implement and evaluate the proposed PPM.

In addition to the main purpose of policy manage-

ment, our approach also increases the transparency to-

wards the data subjects. This is achieved by providing

data transfer logs, which clearly state where data is

transferred to. Providing these logs to data subjects,

in addition to the privacy policy, may increase their

trust into the data controller. Furthermore, these logs

can be used by data protection authorities to check the

GDPR-compliance of the data controller, as well as in

investigations in case of a data breach. The logs pro-

vide accountability of which data processor received

data from which data subject.

Before we explain our privacy policy manage-

ment system in detail, we provide a concise back-

ground in Section 2, introducing all necessary con-

cepts. Next, we place the management system inside

the PriPoCoG-framework in Section 3. In Section

Leicht, J. and Heisel, M.

Management of Customized Privacy Policies.

DOI: 10.5220/0013365300003899

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 11th International Conference on Information Systems Security and Privacy (ICISSP 2025) - Volume 2, pages 385-396

ISBN: 978-989-758-735-1; ISSN: 2184-4356

385

4 we present our management concept, followed by

related work in Section 5. Finally, we close with a

conclusion and future work in Section 6.

2 BACKGROUND

In this section, we provide the necessary background

information for a better understanding of our privacy

policy management system.

2.1 General Data Protection Regulation

(GDPR)

The General Data Protection Regulation (GDPR) is

a regulation of the European Union (EU) (Euro-

pean Parliament and Council of the European Union,

2016). It was enacted to protect the privacy of Eu-

ropean citizens from unwanted data processing. The

GDPR not only applies to businesses inside the EU,

but also to anybody outside the EU who processes

personal data of EU citizens. Hence, it is important

for businesses, called data controllers in the GDPR,

to be able to prove their GDPR-compliance by keep-

ing track of consent provided by the end-users (data

subjects).

Data minimization is one of the concepts of the

GDPR. It aims to protect privacy by only allowing the

minimum data collection and processing necessary to

provide a service. The customizable privacy policies

of the PriPoCoG-framework (Leicht et al., 2022) en-

able data controllers and data subjects to practice data

minimization, while allowing them to include addi-

tional data processing if explicitly enabled by the data

subjects (cf. Section 3).

Informed consent is one of the legal bases for data

collection and processing, according to the GDPR.

Data controllers need to collect this informed consent

and need to be able to prove it towards data protection

authorities. Our PPM helps data controllers to man-

age customized privacy policies and informed consent

in a uniﬁed system.

2.2 Privacy Policy Life Cycle

The privacy policy life cycle presented in Figure 1

depicts the different phases of a privacy policy. The

life cycle starts with the creation of the privacy pol-

icy. The second step is the visualization of the pol-

icy towards the data subjects, followed by the col-

lection and management of data subjects’ consent.

When customizability is provided, we need to be able

to visualize and customize the policy again, even af-

ter the initial consent has been collected. Hence, the

Policy Creation Consent ManagementPolicy Visualization

Data Value ChainData Retention

Figure 1: Privacy Policy Life Cycle, with steps relevant to

our PPM highlighted in bold.

arrow from consent management to policy visualiza-

tion. Once the consent has been collected, the policy

needs to be available along the data value chain, so

that anybody handling the data can adhere to the pri-

vacy policy. The data value chain describes where

data are transferred to and who may process it. In

terms of the GDPR, it describes all data processors

that handle the data on behalf of the data controller.

The ﬁnal step that the privacy policy has to manage

is data retention, making sure that the data is not kept

longer than is stated in the privacy policy. We high-

light the phases Consent Management and Data Value

Chain in bold, as these are the phases where our PPM

comes into action.

3 FRAMEWORK

The Privacy Policy Compliance Guidance

(PriPoCoG) framework was developed to sup-

port the GDPR-compliance of data controllers by

augmenting the privacy policy deﬁnition process

with automated compliance checks (Leicht et al.,

2022). Furthermore, the framework empowers data

subjects in their privacy choices by making privacy

policies customizable, similar to the options provided

by cookie banners. Not only does the framework

check compliance of the privacy policies created

within it, but also supports policy authors in reusing

information from the software development process

for the deﬁnition of detailed and transparent privacy

policies (Leicht et al., 2023).

Our Privacy Policy Management (PPM) embeds

into the PriPoCoG-framework, as depicted in Figure

2. The PPM is highlighted in orange, and it con-

nects with each of the other four components of the

framework. Additionally, data subjects, as well as

data protection authorities, can interact with the PPM.

The other parties (policy authors and data processors)

interact, via existing components of the framework,

with the PPM.

In PriPoCoG, privacy policies are created using

the Privacy Policy Editor (Leicht and Heisel, 2024).

Using the DFD-Editor, the policy authors can im-

port information regarding data ﬂows from data-ﬂow

diagrams (DFDs) (Leicht et al., 2023). The policy,

ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy

386

PriPoCoG - framework

Interface

Threat

Modeler

implements

formalizes

Legislation

(GDPR)

Data

Protection

Authority

Data

Processor

Policy Enforcement

(P2BAC)

Policy Authors

Data

Protection

Oﬃcer

Data

Controller

Layered

Privacy

Language

P-LPL

(Prolog)

Data Subject

Management

GUI

DFD - Editor

GUI

Figure 2: Overview of the PriPoCoG-framework with the PPM and its connections highlighted in orange; unpublished and

open research highlighted in pink; based on (Leicht and Heisel, 2024, Figure 2).

when deﬁned by the data controller, is stored in the

PPM as a basis for the customized policies of the

data subjects. Compliance checks are performed by

P-LPL (Leicht et al., 2022), the Prolog - Layered Pri-

vacy Language, which is a formalized and extended

version of the Layered Privacy Language by Gerl

(Gerl, 2020) and the GDPR (European Parliament and

Council of the European Union, 2016).

Since there is no publication regarding the Pri-

vacy Policy Interface, we assume that it collects the

customized policies and consent from the data sub-

jects. We connect the PPM to the interface to be able

to process the customized policies. The PPM initially

provides the original policy of the data controller to

the data subject via the privacy policy interface. Af-

ter the data subject customized the policy and pro-

vided at least partial consent, the customized policy is

saved in the PPM. This actively customized policy is

a proof of consent that can be provided to data pro-

tection authorities. The interface between the Data

Subject and the PPM allows data subjects to retrieve

information about which data processor received their

data. This interface can for example be embedded in

the privacy settings on the account settings page of the

service. By providing this information to the data sub-

ject, the overall transparency is improved. The PPM

can use the P-LPL backend to check privacy policies

for GDPR-compliance and check the compatibility of

customized policies with the original policy of the

data controller. The customized privacy policies are

enforced at the data controller and data processor side

using Privacy Policy Based Access Control (P2BAC)

(Leicht and Heisel, 2023). Data are collected from

the data subject via the PPM, ensuring that policy en-

forcement is always used before accessing data. Data

Protection Authorities can use the PPM to retrieve

logs of data transfers, which can be used to further

check the GDPR-compliance of the data controller.

Additionally, these logs may be helpful in the event

of a data breach, providing accountability of who re-

ceived data from which data subject.

4 CONCEPT

In this section, we ﬁrst describe the running exam-

ple, which we use to explain our Privacy Policy Man-

agement (PPM). Next, we present the PPM features,

followed by a more detailed look at the architecture

and interaction between the different stakeholders and

components involved in the PPM.

4.1 Running Example

Figure 3 shows an abstract data-ﬂow diagram of our

running example, an online shop. We do not detail

which data are transferred or processed for the differ-

ent sub-services.

The diagram is split into three trust boundaries:

The Online Shop is the data controller; hence we

highlight the trust boundary in red. The second trust

boundary (to the left) represents a data processor, the

Shipping company, which delivers the online shop-

ping orders. Finally, the third trust boundary (to the

right) represents a Marketing company, which pro-

cesses the interests of the customer (data subject), to

provide personalized advertisements. We use the two

processes Shopping and Advertising to represent dif-

Management of Customized Privacy Policies

387

Online Shop

Shopping

Advertising

Customers

Orders

Customer

Shipping

Information

Marketing

Interests

place order

see advertisement

ship order

Figure 3: Abstract data-ﬂow diagram of our running example “Online Shop”.

ferent parts of the service provided by the online shop.

The customer can place orders in the shopping

process, which requires customer data and produces

order information, which are managed in the corre-

sponding data storage (Customers & Orders). When

the order is shipped, information like the delivery ad-

dress is shared with the external data processor Ship-

ping, who stores Shipping Information.

The second service provided by our online shop

is personalized Advertising, which selects interest-

based advertisements (ads) to be shown to the cus-

tomer. The controller uses an external Marketing

company for ad selection, which processes the inter-

ests of the customer.

Customers can prohibit the processing of their in-

terests by customizing the privacy policy of the on-

line shop. When they dissent the processing of their

interests, no information will be forwarded to the mar-

keting company. Instead, they will be prompted with

randomly selected advertisements.

4.2 Features

Our proposed Privacy Policy Management (PPM)

provides the following features:

F1 - Manage customized privacy policies.

F2 - Distribute customized privacy policies to data

processors.

F3 - Manage policy updates by data controllers.

F4 - Manage policy customization by data subjects.

F5 - Collect data subjects’ data according to the

customized privacy policy.

F6 - Keep track of data processors.

The features F1 and F2 build the basis for the ap-

plication of customized privacy policies in complex

systems. F3 improves the process of updating pri-

vacy policies. Currently, a new legal document has

to be deﬁned and changes and corrections are bun-

dled, before a new version of a policy is published.

With our PPM, small corrections and changes to the

policy can easily be deployed. Reacting to dynamic

policy customization is an important feature (F4), es-

pecially (partial) withdrawal of consent. We propose

that our PPM not only manages the policies, but also

collects data from the data subjects (F5). This better

protects data subjects from data misuse, as the data

cannot be processed by bypassing the policy enforce-

ment system. Finally, feature F6 provides account-

ability regarding data processors. The information

tracked can increase transparency towards data sub-

jects, if made accessible. Furthermore, data protec-

tion authorities can use this information for GDPR-

compliance checks as well as data breach investiga-

tions.

4.3 Architecture

In this section we ﬁrst discuss the privacy policy man-

agement architecture in general, before applying it to

our running example.

4.3.1 General Explanation

Figure 4 shows the architecture of our Privacy Pol-

icy Management (PPM), explaining how it integrates

with already existing systems of data controllers and

data processors. The bold rectangles outline the

boundaries of the PPM on the data controller’s (left)

and data processors’ (right) side. The PPM consists of

three components: the Privacy Manager, Policy Stor-

age, and Logging. Both parties run their own instance

of the PPM with similar functionalities. This ensures

ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy

388

Logging

Data

Storage

Policy Storage

Privacy Manager

Policy Storage

Data

Storage

Privacy Manager

User

Interface

Data Processor

Data Controller

Data Subject

Editor

Interface

Data Protection

Authorities

P-LPL

Task

Access Control (P2BAC)

Service

Data Controller

Access Control (P2BAC)

(r)

(q)

(a)

privacy

policy

▼

(o)

▲

data

processors

▼

(e)

(g)

(l₂)

(l₁)

◀ compliance logs

(b₂)

(c₂)

(b₁)

data processors + compliance logs ▶

(c₁)

(d₂)

1..*

(d₁)

1..*

(k₁)

(j₂)

(k₂)

(n₂)

(s₂)

(p₂)

(m₂)

(f)

(h)

(p₁)

(n₁)

(f)

1..*

(j₁)

(h)

1..*

(s₁)

(m₁)

(i)

▼

◀ data ▶

Figure 4: Architectural overview of the privacy policy management.

that all parties are able to manage customized policies

locally. It also reduces the overhead and decision time

of access requests, which would cause network trafﬁc

with a centralized PPM. Conﬁdentiality would also be

at risk, when using a more centralized PPM architec-

ture. Only the data controller side directly interacts

with the Data Subject (DS). Existing systems of the

data controllers and data processors are visualized as

white, and other PriPoCoG components as light gray

rectangles. In the following, we reference interfaces

from the architecture using their corresponding let-

ters, e.g., (a).

The Data Controller (DC) uses the Privacy Policy

Editor (a), which provides the deﬁned privacy policy

to the Privacy Manager (PM) via interface (e). The

DS customizes the privacy policy via the Privacy Pol-

icy Interface (o), which forwards the resulting pol-

icy to the PM (g). Data subject’s data are collected

via the User Interface (q) and forwarded to the PM

via interface (i). This separation of interfaces is nec-

essary, as the privacy policy interface is not able to

collect data from the DS, instead data are collected

in various ways through the user interface of the ser-

vice. The PM stores privacy policies and data in their

corresponding databases (m

) and (k

). The DS inter-

acts with the PM, retrieving a list of data processors,

via the user interface of the service (q), which is con-

nected to the service via interface (r).

The PM is responsible for transferring privacy

policies and data to the data processors via (f) and (h);

not only initially, but also once a privacy policy is up-

dated. This provides reliable intervenability, where all

parties involved in processing data are informed about

any withdrawn consent. The PM informs the Privacy

Policy Based Access Control (P2BAC) about changes

in the customized policy, via interface (l

), which in

turn can interrupt current data processing if consent

has been withdrawn. We explain how policy updates

are performed, in more detail in Section 4.4.

When the service requires some personal data, it

requests access from the P2BAC system (s

). P2BAC

retrieves the corresponding policy from policy storage

) and decides whether access will be granted. If the

decision is positive, P2BAC grants the service access

to the data (p

) and (s

). When the service derives

new data concerning the DS, it provides this data to

the PM via interface (j

). The PM stores this new data

according to the privacy policy in the corresponding

data storage (k

Similar to the service (DC), the task (Data Proces-

sor, DP) interacts with P2BAC and the PM (s

), (n

), and (j

). Interface (j

) is also used to trigger

tasks, when data processing is requested via the PM

(cf. Section 4.4.2).

The PM keeps track of the data transfers it per-

forms. It logs all data processors that received

data from each DS and provides this information to

the Logging component (c

). On the DP side, the

PM keeps track of the data controllers that provided

data to the data processor (c

). Logs are stored in

databases for efﬁcient access and exportability. The

information from the logs is used, in case of a policy

change by the DS, to inform all data processors about

the updated policy. Additionally, this logging im-

proves transparency towards the DS by allowing them

to request a list of data processors (i) and (q). The DS

Management of Customized Privacy Policies

389

can clearly see where their data are transferred and

can compare the data transfers to the privacy policy

they consented to. The logs can also be accessed by

Data Protection Authorities (b

) when examining the

GDPR-compliance of a data controller or in case of

a data breach. Keeping track of data processors also

provides accountability regarding who is processing a

data subject’s data.

The PM can use P-LPL, via interface (d

) to check

privacy policies for GDPR-compliance and check the

compatibility of customized policies with the original

base policy of the data controller.

The interfaces (f) and (h) between data controller

and data processor are many-to-many connections. A

controller can have none, one, or many data proces-

sors, and a processor works for at least one controller.

The policies only ﬂow in one direction (f) from the

controller to the processor. Since the processor may

produce derived data, when performing its task, the

data connection is bidirectional (h).

4.3.2 Example

Applying this architecture to our example, we get the

following instantiation. The Online Shop constitutes

the data controller, and the Shipping company and the

Marketing company are data processors. Each com-

pany has their own instance of the privacy policy man-

agement as well as a local instance of the Privacy Pol-

icy Based Access Control (P2BAC).

The service on the controller side is divided into

the two sub-services: Shopping and Advertising.

Each of these sub-services interact with P2BAC and

the Privacy Manager (PM) to get access to data or

store newly derived data. If the data subject (DS), for

example, places an order, the service provides order

details to the PM of our online shop, to be stored in

the data storage.

If the DS consents to data processing by the ship-

ping company, the PM will inform the shipping com-

pany for which purpose the DS allows the process-

ing of their data. When an order is placed and ready

to ship, the PM will provide the necessary and con-

sented delivery details to the shipping company. The

P2BAC of the shipping company ensures that data are

only used for the consented purpose of delivering the

order. Further processing by the shipping company,

for example for marketing purposes, will be prohib-

ited by P2BAC.

If the DS does not consent to personalized adver-

tisements, the PM will not forward their privacy pol-

icy to the marketing company. It will also not forward

any information regarding the DS to the marketing

company. When the DS decides to enable personal-

ized advertisements later on, the new privacy policy is

provided to the marketing company by the PM of the

online shop. Afterward, information about the inter-

ests can be forwarded and collected by the marketing

company.

4.4 Modus Operandi

In the following we explain the modus operandi of the

sent Management and Data Value Chain. To be read-

able, the diagrams in this section abstract away some

detailed operations.

4.4.1 Consent Management

Consent Collection. The interaction visualized in

Figure 5 describes the initial collection of consent.

The Data Subject (DS) uses the Privacy Policy In-

terface, which requests the privacy policy, deﬁned by

the policy authors, from the Privacy Manager (PM)

on the Data Controller (DC) side. The interface then

presents the returned privacy policy to the DS, who

customizes the policy. When the DS submits the cus-

tomized policy, representing their informed consent,

the policy interface transmits the policy to the privacy

manager (DC). The privacy manager (DC) stores the

Privacy Manager

(Data Controller)

Interface

request original policy

original policy

customized policy + consent

Privacy Manager

(Data Processor)

Policy Storage

(Data Controller)

customized policy + consent

policy receipt

open interface

present original policy

customize policy

submit consent

download receipt

Data

Subject

ack

customized policy + consent

Figure 5: Sequence diagram describing the collection of consent.

ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy

390

policy, and hence the consent, in the Policy Storage

(DC). The policy can now be used to prove explicit

consent to data protection authorities and is also avail-

able for policy enforcement via P2BAC. All data pro-

cessors, that are involved in processing data for the

consented purposes, receive a copy of the customized

the PM of each individual data processor. To com-

plete the consent collection, the PM (DC) sends a re-

ceipt to the privacy policy interface, conﬁrming the

successful storing of the policy. The policy interface

then downloads the receipt to the device of the DS.

Applied to our example, the procedure can be de-

scribed as follows. The Data Subject (DS) wants to

place an order in our online shop. Therefore, they

open the website and are presented with the privacy

policy interface. The interface loads the privacy pol-

icy of our online shop and allows the DS to customize

it. The DS allows processing of their data for shop-

ping and for advertising. The customized policy is

transferred to the Privacy Manager (PM) of our on-

line shop and stored in our policy storage. Since

the DS allows external processing for advertising and

shipping, the policy is forwarded to the PMs of the

marketing company and the shipping company. To

conﬁrm the customized policy, the PM returns a pol-

icy receipt to the policy interface, which the DS can

store as a copy of the agreed privacy policy.

Policy Customization. When the Data Subject

(DS) wants to customize their privacy policy or wants

to withdraw consent for an already accepted purpose,

they open the privacy policy interface (cf. Figure 6).

The interface loads the stored policy via the Privacy

Manager (PM) of the Data Controller (DC). After the

DS further customized the policy to their preferences,

the interface sends the updated policy, and thus the

updated consent, to the PM (DC). The PM (DC) up-

dates the policy in the policy storage, keeping a copy

of the previous version of the policy. Each Data Pro-

cessor (PD), that had previously received a copy of

the policy, is also informed about the updated policy.

Additionally, any new DPs, which the DS may con-

sent to, will also be informed about the current pri-

vacy policy.

The PMs on both sides (DC and DP) inform their

corresponding P2BAC about the policy change. This

is important when the DS withdraws consent for a

purpose, for which data have already been accessed.

P2BAC can then prohibit further access to the data

for the withdrawn purpose. It can also inform the ser-

vice, which is processing the data, to stop processing.

When the service conﬁrms the successful adaptation

to the new policy, P2BAC can conﬁrm adaptation to

the PM (DC). Finally, the PM (DC) conﬁrms the pol-

icy update to the privacy policy interface, providing a

receipt of the newly enforced policy to the DS.

When the Data Subject (DS) decides to withdraw

consent for data processing for advertising purposes,

after using the online shop for some time, they re-open

the privacy policy interface. The interface loads the

previously customized policy from our Privacy Man-

ager (PM). After the DS adjusts the policy, withdraw-

ing consent for advertising purposes, the interface

submits the new version of the customized policy to

our PM. Our PM puts the new policy into the storage

and informs the PM of the marketing company about

the withdrawn consent. The marketing company stops

processing, analogously to the way it is described for

internal processing in Figure 6: P2BAC of the mar-

keting company is informed and informs the processes

performing the task of interest processing about the

withdrawn consent. The process stops processing the

data of our DS and conﬁrms this to P2BAC, which

Privacy Manager

(Data Controller)

updated policy + consent

update policy + consent

policy changed

[for all data processors]

loop

P2BAC

(Data Controller)

Service

(Data Controller)

Interface

Privacy Manager

(Data Processor)

Policy Storage

(Data Controller)

load stored policy

stored policy

request stored policy

customize policy

Data

Subject

open interface

present customized policy

submit updated consent

data processing

ack

policy receipt

download receipt

update policy + consent

stop processing

Figure 6: Sequence diagram describing the customization of the policy (partial withdrawal of consent) by the data subject

while using the service.

Management of Customized Privacy Policies

391

Editor

Privacy Manager

(Data Controller)

change policy

updated policy

ack

Data

Controller

Policy Storage

(Data Controller)

Interface

Data

Subject

updated policy

loop

[for all

customized policies]

load customized policy

customized policy

update

customized

policy

schedule consent collection

present updated policy

alt

[consent required]

schedule policy presentation

present updated policy

[else]

Figure 7: Sequence diagram showing how data subjects are informed when the data controller updates the policy, continued

in Figure 8.

conﬁrms policy enforcement to the local PM of the

marketing company. Finally, our PM conﬁrms the

new policy towards the privacy policy interface, by

providing the policy receipt.

Policy Update. A privacy policy update by the Data

Controller (DC) is also managed by the privacy policy

management. We split this process into two sequence

diagrams, Figures 7 and 8.

After the DC makes changes to the policy (cf. Fig-

ure 7), using the privacy policy editor, the updated

policy is handed to the Privacy Manager (PM) of the

DC. The PM (DC) pushes the policy to the policy stor-

age. Next, the PM (DC) checks all the customized

policies from the storage and updates them to the new

base policy (loop). When the changes require the col-

lection of consent by the Data Subject (DS), the PM

(DC) queues the privacy policy interface for the next

quired, e.g., when corrections are made, or processing

is removed from the policy, the privacy policy inter-

face is queued to inform the DS about the updated

policy. By default, the updated policies deny access

to data, for all new processing purposes that have not

been consented, yet.

In Figure 8 we show the rest of the policy update,

which happens after the DS is informed about the pol-

icy update, or provides consent to the updated pol-

icy. The DS can customize the updated policy, pro-

vide consent for the new purposes, or dissent them.

If no new consent is required, the update process au-

tomatically continues after the opt-frame. Regardless

of the need for consent described above, the PM (DC)

stores the updated policy in the policy storage. Next,

the PM (DC) distributes the updated policy to all data

processors. Afterward, the PM (DC) informs P2BAC

about the updated policy, which informs the service

about any adjustments that need to be made concern-

ing data processing.

In our example, we update the privacy policy for

our online shop. We add another purpose processing

our customers’ interests for the creation of customer-

speciﬁc mail marketing. Our Privacy Manager (PM)

saves the new policy in our policy storage. For all

our customers, our PM loads their customized poli-

cies and compares these with our updated base pol-

icy. Since we added a new purpose, requiring consent

collection, the PM schedules consent collection by the

our online shop, the privacy policy interface opens

Privacy Manager

(Data Controller)

Policy Storage

(Data Controller)

update policy + consent

P2BAC

(Data Controller)

Service

(Data Controller)

Privacy Manager

(Data Processor)

Interface

Data

Subject

opt

[consent required]

customize updated policy

submit updated consent

customized updated policy

ack

loop

[for all

data processor]

update policy + consent

ack

policy changed

adjust processing

ack

Figure 8: Sequence diagram showing the continuation of the policy update (cf. Figure 7).

ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy

392

automatically. Our customer dissents the new pur-

pose and submits their policy. The policy interface

forwards the policy to our PM, which stores the up-

dated policy in storage. Our PM provides the updated

policy of the customer to the PMs of the shipping

company and the marketing company. The marketing

company will only process this customer’s data for

interest-based advertisement selection, not for mail

marketing.

If our policy change would only include correc-

tions or removal of a purpose, we would not need to

wait for our customers’ consent. The policy interface

would be scheduled, to inform our customers about

the updated policy. Our PM would store the updated

customized policies, which it updated itself according

to our base policy (cf. Figure 7), and inform the data

processors and P2BAC immediately, without waiting

for updated consent.

4.4.2 Data Value Chain

Usage of the Service. The behavior in Figure 9 rep-

resents the normal usage of the service. Data, neces-

sary to provide the service, are assumed to be avail-

able in the data storage of the Data Controller (DC).

In Figure 9, P2BAC provides requested data to the

service, when access is granted. This is the case, as

the policy enforcement point of P2BAC would pro-

vide the requested data, which is not a separate com-

ponent in our diagram.

When the Data Subject (DS) wants to use the ser-

vice of the DC, the service requests the necessary

data from P2BAC. The policy enforcement system

requests the current privacy policy for this DS from

policy storage. Based on the loaded policy, P2BAC

makes an access decision and either grants access

to the data or denies access, preventing data misuse.

When access is granted, P2BAC returns the requested

data to the service. The service then starts processing

the data.

If a data processor is involved in service provi-

sion, the service requests the external processing of

data from P2BAC. External processing is only trig-

gered, when access to the resulting data is granted.

After the access decision, analogously to the one de-

scribed above, P2BAC requests the data processing at

the PM (DC). The PM (DC) forwards the request to

the privacy manager of the data processor (DP).

Detailed actions on the DP side are not visualized

in Figure 9. However, the PM (DP) triggers the task,

which requests necessary data from the correspond-

ing P2BAC. After completing, the task returns any

derived data to the PM (DP), similar to the service

on the DC’s side.

The PM (DP) returns the derived data to the PM

(DC), which stores the derived data in storage. After-

ward, the PM (DC) informs P2BAC, which then loads

the derived data. Finally, P2BAC provides the data to

the service. When the service derives new data from

the processing of data (by itself or by a data proces-

sor), it provides the data to the PM (DC), responsible

for storing the data in the database.

When the Data Subject (DS) places an order,

the order details are pushed to our Privacy Manager

(PM), which stores it in the database. This data col-

Privacy Manager

(Data Controller)

P2BAC

(Data Controller)

store derived data

Service

(Data Controller)

Privacy Manager

(Data Processor)

Policy Storage

(Data Controller)

use service

request access

request policy

policy

access denied

Task

alt

[access denied]

requested data

[access granted]

Data

Subject

data processing

request external processing

request policy

policy

[access denied]

access denied

forward request

derived data

trigger

derived data

request data processing

ack

requested derived data

[access granted]

provide service

ack

alt

Figure 9: Sequence diagram describing the regular usage of the service.

Management of Customized Privacy Policies

393

lection is not shown in Figure 9. Our service needs

access to customer data, e.g., the shipping address,

to be able to fulﬁll the order. The shopping process

requests this information from our P2BAC instance.

Since the DS provided consent for shopping as well

as advertising purposes, access is granted and the

necessary data are provided to the service. To show

interest-based advertisements in the shopping cart,

the service requests interest processing by the mar-

keting company. Our P2BAC forwards the request to

our PM, which requests the interest processing at the

PM of the marketing company. The interests are re-

turned to our PM, which places the information in our

database. Finally, P2BAC grants the service access

to the information, which then rolls out the best ﬁtting

interest-based advertisements.

4.4.3 Transparency

The logs created by the privacy managers support the

data controllers in increasing transparency towards

their data subjects. We do not visualize interactions

with the logs in this paper, but we describe them be-

low.

Data subjects can request a list of data processors

from the privacy manager. This request is done via a

part of the user interface of the service, e.g., a website.

Compared to a state-of-the-art privacy policy, this log

provides transparency about the actual data proces-

sors of the data, not just about the potential processing

of data.

In our online shop example, the data subject will

receive a list of all shipping companies, which have

transported their orders. Additionally, all marketing

companies, that our online shop cooperates with, will

be listed.

4.4.4 Accountability

The data transfer logs provide accountability regard-

ing who is processing a data subject’s data. This ac-

countability can be used by data protection authorities

and police when investigating data breaches. Data

protection authorities can also use them to check a

controllers GDPR-compliance.

5 RELATED WORK

Enterprise Privacy Authorization Language

(EPAL). is a complementary concept to the Plat-

form for Privacy Preferences (P3P) system (Cranor

et al., 2006). It was proposed by Ashley, et al.,

to make privacy enforceable (Ashley et al., 2003).

The enforcement concept of EPAL combines two

concepts of the PriPoCoG-framework into a single

component, while splitting other components apart.

Instead of having an access control system and

separate policy management, EPAL uses a single

enforcement and management component, which

accesses a Privacy Management Server (Schunter

and Ashley, 2002, Figure 1). Logging is not part

of EPAL’s management, but instead separated into

another component.

Our approach beneﬁts from the separation of the

enforcement and management, as our Privacy Policy

Management (PPM) can take on additional tasks like

keeping track of data transfers and providing com-

pliance logs towards data protection authorities. The

PPM can also provide the current privacy policy to

all data processors. This support along the data value

chain is not available in EPAL.

eXtensible Access Control Markup Language

(XACML). is a standardized access control policy

language and comes with an enforcement and man-

agement architecture (OASIS, 2013). XACML uses

a Policy Administration Point (PAP) for management

of different policies, which retrieves the policies from

a Policy Retrieval Point (database or ﬁle system).

Compared to our PPM, the PAP is limited to load-

ing and storing the policies, it does not transfer the

policies to other XACML systems, nor does it per-

form logging. Access control logs in XACML are

written by the Policy Enforcement Points. How these

logs operate for external data processing is unclear.

Sticky Policies. With the sticky policies approach

by Pearson and Casassa-Mont “Users can directly

control how their data should be processed, handled,

and shared by explicitly expressing their preferences

and data handling policies.” (Pearson and Casassa-

Mont, 2011) The user-speciﬁc privacy policy is at-

tached directly to the data and transferred as a bundle

to all data processors. Based on the attached policy,

the data processors know how they have to handle the

data.

We make use of the basic concept of transferring

a policy together with the data. However, we do not

attach the policy directly to the data. Instead, we have

a system and database which manage the policies sep-

arately from the normal data management of the data

handling entities. This allows a decoupling of the type

of policy and enforcement, from the general policy

management approach. Although we explain our ap-

proach using the PriPoCoG-framework it can also be

used with different privacy policy systems. Data pro-

cessors and data controllers may even use different

policy languages and systems, as the privacy policy

ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy

394

management could integrate policy converters, trans-

lating privacy policies from one policy language to

another.

6 CONCLUSION

We presented our Privacy Policy Management (PPM)

approach, which integrates into the PriPoCoG-

framework (Leicht et al., 2022). The PPM works for

the data controller and data processors, and stores and

manages the customized policies of the data subjects.

It distributes the policies to all data processors, ensur-

ing that every party handling a data subject’s data is

informed about the agreed upon privacy policy. Up-

dates to the policy by the data controller are compared

to already customized policies and data subjects are

informed about changes. In case explicit consent is

required, the PPM requests this consent from the af-

fected data subjects. When a data subject customizes

their privacy policy after submitting initial consent,

the PPM takes care of enforcing the withdrawal of

consent. The PPM in cooperation with P2BAC (Le-

icht and Heisel, 2023) ensures that data are only pro-

cessed according to the customized privacy policy,

which is achieved by collecting data via the PPM. Fi-

nally, the PPM logs all data processors, keeping track

of where data have been transferred.

Looking back at the research questions, stated in

Section 1, we conclude that

RQ1. How can data controllers and data processors

be supported, when using customizable privacy

policies?: Our PPM manages customizable pri-

vacy policies and data subjects’ (partial) consent.

The policies are propagated along the data value

chain, and all parties involved in data handling

and processing work with the latest version of a

data subject’s privacy policy. Updated policies

and consent withdrawal are propagated to all par-

ties that received some data from the data subject.

RQ2. How can data ﬂows be made more transpar-

ent towards the data subjects?: The logs created

by the PPM can be presented to the data subject,

so that they can transparently see where their data

have been transferred.

Using our PPM data controllers can demonstrate

their GDPR-compliance, regarding consent collec-

tion, to the data protection authorities. Compared to

regular consent mechanisms, we empower the data

subjects by allowing them to customize privacy poli-

cies; state-of-the-art privacy policies only allow a

take-it-or-leave-it approach. This customization is,

however, not achieved by the PPM alone, but rather

by the complete PriPoCoG-framework, which it inte-

grates into (Leicht et al., 2022).

Although we present our PPM tightly integrated

into the PriPoCoG-framework, it can easily be

adapted and used with other policy languages and

systems. It could for example be integrated into the

EPAL or XACML systems.

In the future, we plan to implement a prototype of

the proposed PPM and evaluate its applicability. Fur-

ther work around the PriPoCoG-framework should be

put into the privacy policy interface. The policy deﬁ-

nition process should also be further improved, to bet-

ter support data controllers in their work. Improve-

ments towards the data controllers may increase in-

dustry acceptance of the framework.

REFERENCES

Ashley, P., Hada, S., Karjoth, G., Powers, C., and Schunter,

M. (2003). Enterprise Privacy Authorization Lan-

guage (EPAL). IBM Research, 30:31.

Cranor, L., Dobbs, B., Egelman, S., Hogben, G., Humphrey,

J., Langheinrich, M., Marchiori, M., Presler-Marshall,

M., Schunter, M., and Wenning, R. (2006). The Plat-

form for Privacy Preferences 1.1 (P3P1. 1) Speciﬁca-

tion. W3C Working Group Note, page 57.

European Parliament and Council of the European Union

(2016). Regulation 2016/679 of the European Par-

liament and of the Council of 27 April 2016 on the

protection of natural persons with regard to the pro-

cessing of personal data and on the free movement of

such data, and repealing Directive 95/46/EC (General

Data Protection Regulation). Ofﬁcial Journal of the

European Union, pages 1–88.

Gerl, A. (2020). Modelling of a Privacy Language and Efﬁ-

cient Policy-Based De-Identiﬁcation. PhD thesis, Uni-

versit

at Passau.

Leicht, J. and Heisel, M. (2023). P2BAC: Privacy Pol-

icy Based Access Control Using P-LPL. In Mori, P.,

Lenzini, G., and Furnell, S., editors, 9th International

Conference on Information Systems Security and Pri-

vacy, pages 686–697. SciTePress.

Leicht, J. and Heisel, M. (2024). Extending PriPoCoG:

A Privacy Policy Editor for GDPR-Compliant Privacy

Policies. In ENASE, pages 307–318.

Leicht, J., Heisel, M., and Gerl, A. (2022). PriPoCoG:

Guiding Policy Authors to Deﬁne GDPR-Compliant

Privacy Policies. In Trust, Privacy and Security

in Digital Business: 19th International Conference,

TrustBus 2022, Vienna, Austria, August 24, 2022, Pro-

ceedings, pages 1–16. Springer.

Leicht, J., Wagner, M., and Heisel, M. (2023). Creating

Privacy Policies from Data-Flow Diagrams. In Kat-

sikas, S., Cuppens, F., Cuppens-Boulahia, N., Lam-

brinoudakis, C., Garcia-Alfaro, J., Navarro-Arribas,

G., Nespoli, P., Kalloniatis, C., Mylopoulos, J., Ant

on,

Management of Customized Privacy Policies

395

A., and Gritzalis, S., editors, Computer Security. ES-

ORICS 2023 International Workshops, pages 433–

453. Springer Nature Switzerland.

OASIS (2013). eXtensible Access Control Markup Lan-

guage (XACML) version 3.0.

Pearson, S. and Casassa-Mont, M. (2011). Sticky Policies:

An Approach for Managing Privacy Across Multiple

Parties. Computer, 44(9):60–68.

Schunter, M. and Ashley, P. (2002). The Platform for Enter-

prise Privacy Practices. Technical report, IBM Zurich

Research Laboratory. https://www.w3.org/2003/p3p-

ws/pp/ibm3.html.

ICISSP 2025 - 11th International Conference on Information Systems Security and Privacy

396
