Multi-Agent Causal Reinforcement Learning

Andr

e Meyer-Vitali

Deutsches Forschungszentrum f

ur K

unstliche Intelligenz GmbH (DFKI), Saarbr

ucken, Germany

Keywords:

Software Engineering, Artiﬁcial Intelligence, Trust, Transparency, Robustness, Causality, Agency.

Abstract:

It has become clear that mere correlations extracted from data through statistical processes are insufﬁcient to

give insight into the causal relationships inherent in them. Causal models support the necessary understanding

of these relationships to make transparent and robust decisions. In a distributed setting, the causal models

that are shared between agents improve their coordination and collaboration. They learn individually and

from each other to optimise a system’s behaviour. We propose a combination of causal models and multi-

agent reinforcement learning to create reliable and trustworthy AI systems. This combination strengthens

the modelling and reasoning of agents that communicate and collaborate using shared causal insights. A

comprehensive method for applying and integrating these aspects is being developed.

1 INTRODUCTION

The development of reliable and trustworthy AI sys-

tems requires new methods and metrics for their cre-

ation and veriﬁcation. However, not everything needs

to be developed from scratch, because the experience

of decades of systems and software engineering, as

well as research in the foundations of AI systems, pro-

vides ample opportunities to reuse and adapt existing

methods. We outline some principles of AI Engineer-

ing in section 2. We dive deeper into two of the prin-

ciples, namely agency in section 3 and causality in

section 4. Consequently, in section 5, the combina-

tion of causality and multi-agent reinforcement learn-

ing (MARL) is investigated. A use case concerning

urban mobility and energy consumption is presented

in section 6. Finally, some conclusions and an outlook

are provided in section 7.

2 PRINCIPLES OF TRUSTED AI

The design and development of complex systems has

a long-standing tradition in software architecture and

engineering (Gamma et al., 1994; Booch et al., 2005).

This experience can be used to build better AI sys-

tems, including the current wave of data-driven and

hybrid systems, that are reliable and worthy of trust.

Trust is deﬁned as the willingness of a trustor to

https://orcid.org/0000-0002-5242-1443

be vulnerable to the actions of an actor (trustee) that

she cannot directly control. It requires the existence

of uncertainty and risks. The level of trust increases

with the trustor’s perceived benevolence, competence

and integrity of the trustee (Lewis and Weigert, 1985;

Rousseau et al., 1998; Mayer et al., 1995; Jacovi

et al., 2021; Lewis and Marsh, 2022; de Brito Duarte

et al., 2023). Trust calibration is the process of ad-

justing and aligning actual and perceived trustwor-

thiness, where actual trustworthiness is the degree to

which a system or actor complies with its required

or promised expectations and performance (Okamura

and Yamada, 2020; de Visser et al., 2020; Visser et al.,

2023; Chi and Malle, 2023)).

In order to achieve trustworthiness and trust, an

AI system should include a number of characteristics,

such as those listed by the High-Level Expert Group

(HLEG) of the EU. Their Assessment List for Trust-

worthy Artiﬁcial Intelligence, ALTAI (Directorate-

General for Communications Networks, Content and

Technology (European Commission), 2020)) lists:

1. Human Agency and Oversight;

2. Technical Robustness and Safety;

3. Privacy and Data Governance;

4. Transparency;

5. Diversity, Non-discrimination and Fairness;

6. Societal and Environmental Well-being;

7. Accountability.

Meyer-Vitali, A.

Multi-Agent Causal Reinforcement Learning.

DOI: 10.5220/0013400100003896

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 13th International Conference on Model-Based Software and Systems Engineering (MODELSWARD 2025), pages 435-442

ISBN: 978-989-758-729-0; ISSN: 2184-4348

435

An analysis of AI engineering methods for trust

(Meyer-Vitali and Mulder, 2024a; Meyer-Vitali and

Mulder, 2024b) reveals the following four main prin-

ciples.

Models & Explanations. Reliable predictions and

decisions about system behaviour for insightful

and plausible explanations and simulations with

generalised models from knowledge and training.

Causality & Grounding. Identiﬁcation and predic-

tions of cause-effect relationships for informed

predictions and actions, as well as anchoring of

meaning in real-world context and phenomena.

Modularity & Compositionality. Design of com-

plex systems broken down into comprehensible

and manageable parts (functions and features), re-

liably composed in system architectures.

Human Agency & Oversight. Overview, ﬁnal deci-

sion, and human responsibility for the actions of

AI systems, also when delegating tasks to au-

tonomous agents in hybrid collaborative teams.

An important aspect to consider is that we should not

aim to reinvent the wheel, time and time again. In-

stead, we should augment what is already established

knowledge and build on top of existing models and

methods (Schreiber et al., 1999; Tiddi et al., 2023).

Furthermore, it is not sufﬁcient to determine statisti-

cal patterns and correlations in data. What machine

“learning” achieves is just that – which is not learn-

ing as a desire to understand. Beyond “learning”, we

should aim for understanding concepts and relation-

ships. AI can become a tool for scientiﬁc discovery if

developers and systems understand what they learned

and manage to convert experimental insights into hy-

potheses and theories that serve as stepping stones

for further experiments. This is the scientiﬁc method

that was successful for centuries and which should

not be given up for fancy trompe l’oeils (Goldstein

and Goldstein, 1978; Gower, 1996; Nola and Sankey,

2007; Grifﬁn et al., 2024; Jamieson et al., 2024).

3 AGENCY

Agency is the level of control that an entity has over

itself and its behaviour (van der Vecht et al., 2007).

Agents are “systems that can decide for themselves

what they need to do in order to satisfy their de-

sign objectives” (Wooldridge in (Weiss, 2000)). Thus,

agents reason and take deliberate decisions on their

behalf and initiative (Wooldridge and Jennings, 1995;

Wooldridge, 2009). Agents are fundamental build-

ing blocks of AI systems (Russell and Norvig, 2020;

OECD, 2022), which were investigated for a long pe-

riod and are currently of major interest, again, for the

future of AI (Larsen et al., 2024).

In technical terms, we are interested in agents as

autonomous and communicative entities (software or

robots) that learn, reason, plan and act to achieve

some goals. Each agent can communicate with its en-

vironment (physical or virtual) and with other agents,

including humans. Due to their autonomy, agents

can process data and knowledge efﬁciently in a dis-

tributed fashion, which also beneﬁts scalability and

sovereignty.

Agents don’t come alone. In multi-agent systems

(MAS) (Weiss, 2000) agents take roles and interact

with each other to achieve their individual or col-

lective goals. They communicate using communica-

tive or speech acts (Searle, 1969)according to a vari-

ety of interaction patterns and protocols, such as ne-

gotiations, auctions or queries (Poslad and Charlton,

2001).

The beneﬁts of multi-agent systems for building

reliable AI systems include

• modularisation and compositionality by deﬁning

speciﬁc roles and protocols for communicating

among agents;

• separation of concerns, where agents have their

individual roles, values and duties;

• agreements are reached by negotiations, such that

outcomes can be explained; and

• distribution of logic and processing for efﬁciency,

scalability and sovereignty.

4 CAUSALITY

Causality refers to our ability to understand and pre-

dict how things are connected through cause and ef-

fect – speciﬁcally, what causes what, and why (Pearl

and Mackenzie, 2018). When artiﬁcial intelligence

systems can grasp these causal connections, they be-

come capable of making better predictions and solv-

ing complex problems. This represents a crucial shift

in focus: rather than simply identifying correlations

(when things happen together), we need to understand

causation (when one thing directly leads to another).

This transition from correlation-based to

causation-based thinking is becoming increas-

ingly crucial, particularly as we seek to understand

the reasoning behind AI predictions and decisions

(Pearl et al., 2016). Understanding the true causes

behind outcomes, rather than just their associations,

is essential for explaining why AI systems make

speciﬁc choices.

MBSE-AI Integration 2025 - 2nd Workshop on Model-based System Engineering and Artiﬁcial Intelligence

436

Causal inference considers how and when causal

conclusions can be drawn from data. Complex sys-

tems of interacting variables can be described with

a Structural Causal Model (SCM) (Pearl, 2009; Pe-

ters et al., 2017; Nogueira et al., 2022). Such a

model describes the causal mechanisms and assump-

tions present in an arbitrary system. The relationships

between (endogenous) variables can be visualised in

a directed acyclic graph (DAG), wherein nodes repre-

sent variables and directed paths represent causal in-

ﬂuences between variables. These inﬂuences do not

need to be deterministic, but can be probabilistic, in-

clude external factors (exogenous variables) and are

valid for linear as well as non-linear functions, dis-

crete as well as continuous variables.

A structural causal model (SCM) is a triple

(Pearl, 2009)

M = ⟨U,V,F⟩,

where:

• U is a set of background variables, (also called

exogenous), that are determined by factors outside

the model;

• V is a set {V

,·· · ,V

} of variables, called en-

dogenous, that are determined by variables in the

model;

• F is a set of functions { f

, f

,·· · , f

} such that

each f

is a mapping from U

∪ PA

to V

: v

(pa

),i = 1, ··· ,n.

A causal model M can be visualised as a directed

acyclic graph, G(M), in which each node corresponds

to a variable and the directed edges point from mem-

bers of PA

and U

toward V

. This graph is the causal

diagram associated with M. From a causal diagram,

it is easy to read dependencies between variables by

examining the three different types of connections

– chains, forks, and colliders – using d-separation

Graphs also help to identify confounders: variables

that inﬂuence both the treatment (cause) and the out-

come (effect). Confounders, as common causes, cre-

ate a spurious association between treatment and out-

come.

The Law of Conditional Independence (d-

separation)

(XsepY |Z)

G(M)

⇒ (X ⊥⊥ Y |Z)

P(v)

describes the consequence of separation in the model

as independence in the distribution.

Interventions (or experiments) correspond to forc-

ing a variable X to take on value x, thereby removing

dependencies on parent variables to examine changes

denotes the parents of V

d stands for directional.

in one variable (representing a state, action or event)

and whether they cause changes in another, in order

to distinguish between correlated and causal relation-

ships in data.

An intervention I in an SCM M entails changing

some set of structural assignments in M with a new set

of structural assignments. Assume the replacement is

on X

given by assignment X

f (

), where

are the parents in the new graph.

Counterfactuals refer to alternative choices that

could have been made in the past and the correspond-

ing effects that they might have caused. Therefore,

they allow for exploring possibilities to ﬁnd alterna-

tive outcomes according to a causal model, allowing

to change policies accordingly in the future.

The Law of Counterfactuals

(u) = Y

(u)

states that a model M generates and evaluates all

counterfactuals. M

is a modiﬁed structural submodel

of M, where the equation for X is replaced by X = x.

This allows for generating answers to an enormous

number of hypothetical questions of the type “What

would Y be had X been x?” (Pearl et al., 2016).

An SCM can be interpreted as a probability distri-

bution P with density p over variables X in the causal

system. According to the Ladder of Causation (Pearl

and Mackenzie, 2018), three classes of reasoning ex-

ist.

1. Seeing (associations) encapsulates statistical rea-

soning.

P(y|x)

2. Doing (interventions) contains randomised con-

trol trials (RCTs) and RL methods (cf. section

5).

P(y|do(x), z)

3. Imagining (counterfactuals) allows for reasoning

about outcomes of alternative choices.

P(y

′

)

Consequently, this formalism allows for explicit rea-

soning about each action an agent does, can, and

could have taken. Interestingly, causality provides

means to understand the story behind data, i.e., a

causal model can be seen as a data generator that re-

ﬂects the causal relationships. Therefore, it can ex-

plain those relationships and is seen as a necessary

requirement for explainability (Carloni et al., 2023;

Rawal et al., 2023; Ganguly et al., 2023). An SCM

can be used for planning, such that causes are de-

termined to achieve desired effects (Meyer-Vitali and

Mulder, 2023).

Multi-Agent Causal Reinforcement Learning

437

5 MULTI-AGENT CAUSAL

REINFORCEMENT LEARNING

Reinforcement Learning (RL) (Sutton and Barto,

2018) is a method for agents to learn how to map sit-

uations to actions from interacting with an environ-

ment. Agents act and receive feedback on the quality

or performance of their actions (rewards), which they

use for updating their strategy or policy.

Typically, the strategy is deﬁned as a Markov De-

cision Process (MDP). Markov decision processes

include three aspects: sensation, action, and goal.

MDPs consist of a ﬁnite set of states S, a ﬁnite set of

actions A, a reward function R : S ×A ×S → R, a state

transition probability function T : S × A × S → [0, 1]

and an initial state distribution.

More realistically, not all relevant information can

be sensed or observed from the environment and the

set of states and actions is inﬁnite. Therefore, Par-

tially Observable MDPs (POMDP) are often used

(Kaelbling et al., 1998). POMDPs do not sense the

states directly, but receive observations which depend

(in a probabilistic or deterministic way) on the state

of the environment. Agents will need to take into ac-

count the history of past observations to infer the pos-

sible current state of the environment.

In a distributed setting, Multi-Agent Reinforce-

ment Learning (MARL) concerns multiple agents

learning concurrently or collaboratively in the same

environment (Bus¸oniu et al., 2010; Now

e et al., 2012;

Zhang et al., 2021; Gronauer and Diepold, 2022; Al-

brecht et al., 2024). For example, in Partially Observ-

able Stochastic Games (POSG) all agents have the

same reward function, joint observations and a joint

action set. They are also known as “Decentralized

POMDP” (Dec-POMDP) and are used in the area of

multi-agent planning (Oliehoek, 2012; Oliehoek and

Amato, 2016). However, in a generalised approach,

agents do not need to obey to the same reward func-

tion for distributed learning and control.

Finally, agents, causality and reinforcement learn-

ing come together. The reader may appreciate that the

similarity between interventions and counterfactuals

in causal models with agents’ actions and rewards in

reinforcement learning provides a useful synergy. An

approach at this combination was already presented

by (Maes et al., 2007; Grimbly et al., 2021; Jiao

et al., 2024), where multi-agent causal models are in-

troduced. Agents share an environment and have ac-

cess to private and public variables of interest.

A Multi-Agent Causal Model (MACM) consists

of n agents, each of which contains a semi-Markovian

model M

= ⟨V

,P(V

),K

⟩,i ∈ {1, ··· ,n}

• V

is the subset of variables that agent a

can ac-

cess.

• G

is the causal graph over variables V

• P(V

) is the joint probability distribution over

• K

stores the intersections V

with other

agents a

, {V

∩V

}, assuming that the agents

agree on the structure and distribution of their in-

tersections.

MACMs are useful as shared causal models in teams

of agents. Each agent reasons according to its indi-

vidual POMDP with endogenous and exogenous vari-

ables and corresponding observations of the environ-

mental state. Agents share histories of observations

and rewards (state-action trajectories), but take indi-

vidual coordinated actions based on their individual

rewards. An MACM can be seen as a generalisation

of Dec-POMDPs.

Multi-Agent Causal Reinforcement Learning

(MACRL) allows for causal inference in a dynamic

learning environment with a multitude of agents

(Casini and Manzo, 2016; Pina et al., 2023a; Pina

et al., 2023b; Richens and Everitt, 2024). With fur-

ther elaboration of these basic ideas, MACRL could

evolve into several design patterns for neuro-symbolic

AI systems (van Bekkum et al., 2021), where neuro-

causal agents combine explicit prior knowledge in

the form of (hypothetical) causal models with dis-

covery (Pearl, 2019) and learning for continuous self-

improvement.

6 SCENARIO: URBAN AGENTS

Urban life has many peculiar characteristics (WBGU

– German Advisory Council on Global Change, 2016;

Angelidou et al., 2022; Oliveira et al., 2020; Popelka

et al., 2023; Petrikovi

cov

a et al., 2022; Hashem et al.,

2023). Many different streams of information, activi-

ties and resources are intertwined and have conﬂicting

requirements and characteristics, such as energy, mo-

bility, food, water, waste, healthcare, commerce, and

many more (Nevejan et al., 2018). They all share the

same limited spatial and temporal constraints. The ur-

ban context requires and involves many interactions at

high speed with lots of people, high density and diver-

sity of the population, land use, displacements (geo-

graphical, social and occupational mobility), as well

as ﬂuent and heterogeneous communities.

The interactions in an urban environment are di-

verse, complex and conﬂicting. Many interests of hy-

brid actors are related and depend on each other. In

the urban context, an overall goal for sustainable use

MBSE-AI Integration 2025 - 2nd Workshop on Model-based System Engineering and Artiﬁcial Intelligence

438

Temperature ComfortWeather

Emissions

Heating

Values

Moving

Bicycle

Car Energy

Electricity

Gas

Fuel

Goals

Working /

Living

maximise

minimise

Duties

specifyspecify

Public

Transport

observe

Figure 1: A causal model for living and working in the urban context.

of resources could be the reduction of energy con-

sumption.

Some causal relationships in an urban context, fo-

cusing on a combination of energy consumption and

mobility, are shown in ﬁgure 1. In the urban causal

model, values, duties and the weather are exogenous

variables. They need to be accepted as they are and

are independent. Goals, working/living and moving

are causes that determine the behaviour of agents.

Energy and com f ort are the effects that we want to

achieve and to optimise.

The consumption of various types of energy is af-

fected by the need and desire to move about the city

and to heat buildings at home and at work (and for

leisure, shopping, etc.). Values and duties are the

main sources that drive urban behaviour and exter-

nal factors, such as the weather, inﬂuence decision-

making. This causal model explains the relationships

among several important behavioural aspects, but it is

not deterministic. Individual behaviour is inﬂuenced

by exogenous variables and cooperative behaviour re-

sults in complex interactions.

Each of the variables is modelled using a quan-

titative metric. The transfer functions are to be de-

termined using causal machine learning, based on the

behaviour of actors.

A shared goal can be seen and modelled as an ef-

fect, that is caused by one or more interventions (ac-

tions or events). Consequently, in order to decide and

plan which actions to take, it is necessary to under-

stand which actions or events cause the intended ef-

fects. For example, your goal can be to arrive at a

destination at a given time (work, home, leisure, etc.).

By reasoning back which actions are required to get

you there, piece by piece, a connected causal path can

be constructed to determine the departure time and

modes of trafﬁc along the route. Due to shared in-

tentions and causal models, humans and agents can

mutually trust each other regarding their actions and

outcomes.

7 CONCLUSIONS AND

OUTLOOK

After looking at agency, causality and reinforcement

learning separately, the combination in Multi-Agent

Causal Reinforcement Learning (MACRL) provides

a path towards more robust, transparent and explain-

able AI systems, such that they become more trust-

worthy (concerning some of the characteristics of the

ALTAI). Model-based software engineering for such

AI systems promotes reliability and trust, because the

actions and interventions that agents take are clearly

understandable. By investigating various ways of im-

plementing MACRL, a more robust software engi-

neering method may emerge. This paper gives some

insights and directions for such a method; more re-

search is needed and should be applied in real-world

use cases.

Multi-Agent Causal Reinforcement Learning

439

REFERENCES

Albrecht, S. V., Christianos, F., and Sch

afer, L. (2024).

Multi-Agent Reinforcement Learning: Foundations

and Modern Approaches. MIT Press.

Angelidou, M., Politis, C., Panori, A., Bakratsas, T., and

Fellnhofer, K. (2022). Emerging smart city, transport

and energy trends in urban settings: Results of a pan-

European foresight exercise with 120 experts. Techno-

logical Forecasting and Social Change, 183:121915.

Booch, G., Rumbaugh, J., and Jacobson, I. (2005). Uniﬁed

Modeling Language User Guide, The (2nd Edition)

(Addison-Wesley Object Technology Series). Addison-

Wesley Professional, 2nd edition.

Bus¸oniu, L., Babu

ska, R., and De Schutter, B. (2010).

Multi-agent Reinforcement Learning: An Overview.

In Srinivasan, D. and Jain, L. C., editors, Innovations

in Multi-Agent Systems and Applications - 1, pages

183–221. Springer, Berlin, Heidelberg.

Carloni, G., Berti, A., and Colantonio, S. (2023). The

role of causality in explainable artiﬁcial intelligence.

arXiv:2309.09901 [cs].

Casini, L. and Manzo, G. (2016). Agent-based models and

causality: a methodological appraisal. Link

oping

University Electronic Press.

Chi, V. B. and Malle, B. F. (2023). Calibrated Human-Robot

Teaching: What People Do When Teaching Norms to

Robots*. In 2023 32nd IEEE International Confer-

ence on Robot and Human Interactive Communica-

tion (RO-MAN), pages 1308–1314. ISSN: 1944-9437.

de Brito Duarte, R., Correia, F., Arriaga, P., and Paiva, A.

(2023). AI Trust: Can Explainable AI Enhance War-

ranted Trust? Human Behavior and Emerging Tech-

nologies, 2023:e4637678. Publisher: Hindawi.

de Visser, E. J., Peeters, M. M. M., Jung, M. F., Kohn, S.,

Shaw, T. H., Pak, R., and Neerincx, M. A. (2020). To-

wards a Theory of Longitudinal Trust Calibration in

Human–Robot Teams. International Journal of Social

Robotics, 12(2):459–478.

Directorate-General for Communications Networks, Con-

tent and Technology (European Commission) (2020).

The Assessment List for Trustworthy Artiﬁcial Intelli-

gence (ALTAI) for self assessment. Publications Ofﬁce

of the European Union.

Gamma, E., Helm, R., Johnson, R., Vlissides, J., and

Booch, G. (1994). Design Patterns: Elements of

Reusable Object-Oriented Software. Addison-Wesley

Professional, Reading, Mass, 1st edition edition.

Ganguly, N., Fazlija, D., Badar, M., Fisichella, M., Sikdar,

S., Schrader, J., Wallat, J., Rudra, K., Koubarakis, M.,

Patro, G. K., Amri, W. Z. E., and Nejdl, W. (2023). A

Review of the Role of Causality in Developing Trust-

worthy AI Systems. arXiv:2302.06975 [cs].

Goldstein, M. and Goldstein, I. F. (1978). How We Know:

An Exploration of the Scientiﬁc Process. Westview

Press.

Gower, B. (1996). Scientiﬁc Method: A Historical and

Philosophical Introduction. Routledge, London.

Grifﬁn, C., Wallace, D., Mateos-Garcia, J., Schieve, H.,

and Kohli, P. (2024). A new golden age of discovery.

Technical report, DeepMind.

Grimbly, S. J., Shock, J., and Pretorius, A. (2021). Causal

Multi-Agent Reinforcement Learning: Review and

Open Problems. arXiv:2111.06721 [cs].

Gronauer, S. and Diepold, K. (2022). Multi-agent deep re-

inforcement learning: a survey. Artiﬁcial Intelligence

Review, 55(2):895–943.

Hashem, I. A. T., Usmani, R. S. A., Almutairi, M. S.,

Ibrahim, A. O., Zakari, A., Alotaibi, F., Alhashmi,

S. M., and Chiroma, H. (2023). Urban Computing for

Sustainable Smart Cities: Recent Advances, Taxon-

omy, and Open Research Challenges. Sustainability,

15(5):3916. Number: 5 Publisher: Multidisciplinary

Digital Publishing Institute.

Jacovi, A., Marasovi

c, A., Miller, T., and Goldberg, Y.

(2021). Formalizing Trust in Artiﬁcial Intelligence:

Prerequisites, Causes and Goals of Human Trust in

AI. In Proceedings of the 2021 ACM Conference on

Fairness, Accountability, and Transparency, FAccT

’21, pages 624–635, New York, NY, USA. Associa-

tion for Computing Machinery.

Jamieson, K. H., Kearney, W., and Mazza, A.-M., editors

(2024). Realizing the Promise and Minimizing the

Perils of AI for Science and the Scientiﬁc Community.

University of Pennsylvania Press.

Jiao, L., Wang, Y., Liu, X., Li, L., Liu, F., Ma, W., Guo, Y.,

Chen, P., Yang, S., and Hou, B. (2024). Causal Infer-

ence Meets Deep Learning: A Comprehensive Survey.

Research, 7:0467. Publisher: American Association

for the Advancement of Science.

Kaelbling, L. P., Littman, M. L., and Cassandra, A. R.

(1998). Planning and acting in partially observable

stochastic domains. Artiﬁcial Intelligence, 101(1):99–

134.

Larsen, B., Li, C., Teeuwen, S., Denti, O., DePerro, J., and

Raili, E. (2024). Navigating the AI Frontier: A Primer

on the Evolution and Impact of AI Agents. Technical

report, World Economic Forum.

Lewis, J. D. and Weigert, A. (1985). Trust as a Social Real-

ity. Social Forces, 63(4):967–985.

Lewis, P. R. and Marsh, S. (2022). What is it like to trust

a rock? A functionalist perspective on trust and trust-

worthiness in artiﬁcial intelligence. Cognitive Systems

Research, 72:33–49.

Maes, S., Meganck, S., and Manderick, B. (2007). Infer-

ence in multi-agent causal models. International Jour-

nal of Approximate Reasoning, 46(2):274–299.

Mayer, R. C., Davis, J. H., and Schoorman, F. D. (1995).

An Integrative Model of Organizational Trust. The

Academy of Management Review, 20(3):709–734.

Publisher: Academy of Management.

Meyer-Vitali, A. and Mulder, W. (2023). Causing Intended

Effects in Collaborative Decision-Making. In Mu-

rukannaiah, P. K. and Hirzle, T., editors, Proceedings

of the Workshops at the Second International Confer-

ence on Hybrid Human-Artiﬁcial Intelligence, volume

3456 of CEUR Workshop Proceedings, pages 137–

144, Munich, Germany. CEUR. ISSN: 1613-0073.

MBSE-AI Integration 2025 - 2nd Workshop on Model-based System Engineering and Artiﬁcial Intelligence

440

Meyer-Vitali, A. and Mulder, W. (2024a). Engineering Prin-

ciples for Building Trusted Human-AI Systems. In

Arai, K., editor, Intelligent Systems and Applications,

pages 468–485, Cham. Springer Nature Switzerland.

Meyer-Vitali, A. and Mulder, W. (2024b). Human-AI En-

gineering for Adults. In HHAI 2024: Hybrid Human

AI Systems for the Social Good, pages 228–240. IOS

Press.

Nevejan, C., Sefkatli, P., and Cunningham, S. W. (2018).

City rhythm: logbook of an exploration. Delft Univer-

sity of Technology, Multi Actor Systems, Amsterdam,

ﬁrst edition edition. OCLC: 1312647218.

Nogueira, A. R., Pugnana, A., Ruggieri, S., Pedreschi, D.,

and Gama, J. (2022). Methods and tools for causal

discovery and causal inference. WIREs Data Mining

and Knowledge Discovery, 12(2):e1449. eprint:

https://onlinelibrary.wiley.com/doi/pdf/10.1002/widm.1449.

Nola, R. and Sankey, H. (2007). Theories of Scientiﬁc

Method: an Introduction. Routledge, London.

Now

e, A., Vrancx, P., and De Hauwere, Y.-M. (2012).

Game Theory and Multi-agent Reinforcement Learn-

ing. In Wiering, M. and van Otterlo, M., editors, Rein-

forcement Learning: State-of-the-Art, pages 441–470.

Springer, Berlin, Heidelberg.

OECD (2022). OECD Framework for the Classiﬁcation of

AI systems. Technical report, OECD, Paris.

Okamura, K. and Yamada, S. (2020). Adaptive trust cal-

ibration for human-AI collaboration. PLOS ONE,

15(2):1–20. Publisher: Public Library of Science.

Oliehoek, F. A. (2012). Decentralized POMDPs. In Wier-

ing, M. and van Otterlo, M., editors, Reinforcement

Learning: State-of-the-Art, pages 471–503. Springer,

Berlin, Heidelberg.

Oliehoek, F. A. and Amato, C. (2016). A Concise Introduc-

tion to Decentralized POMDPs. SpringerBriefs in In-

telligent Systems. Springer International Publishing,

Cham.

Oliveira, G. M., Vidal, D. G., and Ferraz, M. P. (2020).

Urban Lifestyles and Consumption Patterns. In

Leal Filho, W., Marisa Azul, A., Brandli, L.,

okc¸in

Ozuyar, P., and Wall, T., editors, Sustain-

able Cities and Communities, Encyclopedia of the

UN Sustainable Development Goals, pages 851–860.

Springer International Publishing, Cham.

Pearl, J. (2009). Causality: Models, Reasoning and

Inference. Cambridge University Press, Cam-

bridge, U.K. ; New York, 2nd edition edition.

https://bayes.cs.ucla.edu/BOOK-2K/.

Pearl, J. (2019). The seven tools of causal inference, with

reﬂections on machine learning. Communications of

the ACM, 62(3):54–60.

Pearl, J., Glymour, M., and Jewell, N. P. (2016). Causal

Inference in Statistics: A Primer. John Wiley & Sons.

Google-Books-ID: I0V2CwAAQBAJ.

Pearl, J. and Mackenzie, D. (2018). The Book of Why: The

New Science of Cause and Effect. Basic Books, New

York, 1st edition edition.

Peters, J., Janzing, D., and Sch

olkopf, B. (2017). Elements

of Causal Inference: Foundations and Learning Algo-

rithms. The MIT Press.

Petrikovi

cov

a, L., Kurilenko, V., Akimjak, A., Akimjakov

B., Majda, P.,

Datelinka, A., Biryukova, Y., Hlad,

L., Kondrla, P., Maryanovich, D., Ippolitova, L.,

Roubalov

a, M., and Petrikovi

c, J. (2022). Is the Size

of the City Important for the Quality of Urban Life?

Comparison of a Small and a Large City. Sustainabil-

ity, 14(23):15589. Number: 23 Publisher: Multidisci-

plinary Digital Publishing Institute.

Pina, R., De Silva, V., and Artaud, C. (2023a). Causal-

ity Detection for Efﬁcient Multi-Agent Reinforcement

Learning. In Proceedings of the 2023 International

Conference on Autonomous Agents and Multiagent

Systems, AAMAS ’23, pages 2824–2826, Richland,

SC. International Foundation for Autonomous Agents

and Multiagent Systems.

Pina, R., De Silva, V., and Artaud, C. (2023b). Learning In-

dependently from Causality in Multi-Agent Environ-

ments. arXiv:2311.02741 [cs].

Popelka, S., Narvaez Zertuche, L., and Beroche, H. (2023).

Urban AI Guide. Technical report, Zenodo.

Poslad, S. and Charlton, P. (2001). Standardizing Agent

Interoperability: The FIPA Approach. In Luck,

M., Ma

ık, V.,

ankov

a, O., and Trappl, R., ed-

itors, Multi-Agent Systems and Applications: 9th

ECCAI Advanced Course, ACAI 2001 and Agent

Link’s 3rd European Agent Systems Summer School,

EASSS 2001 Prague, Czech Republic, July 2–13, 2001

Selected Tutorial Papers, pages 98–117. Springer,

Berlin, Heidelberg.

Rawal, A., Raglin, A., Sadler, B. M., and Rawat, D. B.

(2023). Explainability and causality for robust, fair,

and trustworthy artiﬁcial reasoning. In Artiﬁcial Intel-

ligence and Machine Learning for Multi-Domain Op-

erations Applications V, volume 12538, pages 493–

500. SPIE.

Richens, J. and Everitt, T. (2024). Robust agents learn

causal world models. arXiv:2402.10877 [cs].

Rousseau, D. M., Sitkin, S. B., Burt, R. S., and Camerer, C.

(1998). Introduction to Special Topic Forum: Not so

Different after All: A Cross-Discipline View of Trust.

The Academy of Management Review, 23(3):393–404.

Publisher: Academy of Management.

Russell, S. and Norvig, P. (2020). Artiﬁcial Intelligence:

A Modern Approach. Pearson, Hoboken, NJ, 4th edi-

tion.

Schreiber, G., Akkermans, H., Anjewierden, A., de Hoog,

R., Shadbolt, N. R., Van de Velde, W., and Wielinga,

B. J. (1999). Knowledge Engineering and Manage-

ment: The CommonKADS Methodology. The MIT

Press.

Searle, J. R. (1969). Speech Acts: An Essay in the Phi-

losophy of Language. Cambridge University Press,

Cambridge.

Sutton, R. S. and Barto, A. G. (2018). Reinforcement Learn-

ing: An Introduction. A Bradford Book, Cambridge,

MA, USA.

Tiddi, I., De Boer, V., Schlobach, S., and Meyer-Vitali, A.

(2023). Knowledge Engineering for Hybrid Intelli-

gence. In Proceedings of the 12th Knowledge Cap-

ture Conference 2023, K-CAP ’23, pages 75–82, New

Multi-Agent Causal Reinforcement Learning

441

York, NY, USA. Association for Computing Machin-

ery.

van Bekkum, M., de Boer, M., van Harmelen, F., Meyer-

Vitali, A., and Teije, A. t. (2021). Modular design pat-

terns for hybrid learning and reasoning systems. Ap-

plied Intelligence, 51(9):6528–6546.

van der Vecht, B., Meyer, A. P., Neef, M., Dignum, F.,

and Meyer, J.-J. C. (2007). Inﬂuence-Based Au-

tonomy Levels in Agent Decision-Making. In Nor-

iega, P., V

azquez-Salceda, J., Boella, G., Boissier, O.,

Dignum, V., Fornara, N., and Matson, E., editors, Co-

ordination, Organizations, Institutions, and Norms in

Agent Systems II, Lecture Notes in Computer Science,

pages 322–337, Berlin, Heidelberg. Springer.

Visser, E. d., Momen, A., Walliser, J., Kohn, S., Shaw,

T., and Tossell, C. (2023). Mutually Adaptive Trust

Calibration in Human-AI Teams. In Murukannaiah,

P. K. and Hirzle, T., editors, Proceedings of the Work-

shops at the Second International Conference on Hy-

brid Human-Artiﬁcial Intelligence, volume 3456 of

CEUR Workshop Proceedings, pages 188–193, Mu-

nich, Germany. CEUR. ISSN: 1613-0073.

WBGU – German Advisory Council on Global Change

(2016). Humanity on the move: Unlocking the trans-

formative power of cities. Technical report, WBGU,

Berlin. Frauke Kraas, Claus Leggewie, Peter Lemke,

Ellen Matthies, Dirk Messner, Nebojsa Nakicenovic,

Hans Joachim Schellnhuber, Sabine Schlacke, Uwe

Schneidewind.

Weiss, G. (2000). Multiagent Systems: A Modern Approach

to Distributed Artiﬁcial Intelligence. MIT Press, Cam-

bridge, MA, USA, 1st edition.

Wooldridge, M. (2009). An Introduction to MultiAgent Sys-

tems. John Wiley & Sons, 2nd edition.

Wooldridge, M. and Jennings, N. R. (1995). Intelligent

agents: theory and practice. The Knowledge Engi-

neering Review, 10(2):115–152.

Zhang, K., Yang, Z., and Bas¸ar, T. (2021). Multi-Agent Re-

inforcement Learning: A Selective Overview of The-

ories and Algorithms. arXiv:1911.10635 [cs, stat].

MBSE-AI Integration 2025 - 2nd Workshop on Model-based System Engineering and Artiﬁcial Intelligence

442
