Micro4Delphi: A Process for the Modernization of Legacy Systems in

Delphi to Microservice Architecture

Lucas Fernando Fávero

1,2

, Gabriel Soares Mário

1,3

and Frank José Affonso

1 a

Department of Statistics, Applied Mathematics and Computation, São Paulo State University – UNESP,

PO Box 178, Rio Claro, 13506-900, São Paulo, Brazil

Integrativa, Chile Street, 240, Catanduva, 15800-430, São Paulo, Brazil

SuperSoft, 16A Avenue, 1190, Rio Claro, 13506-720, São Paulo, Brazil

Keywords:

Software Modernization, Delphi, Legacy Systems, Microservice Architecture, MSA.

Abstract:

The modernization of legacy systems to microservice architecture (MSA) has been a subject of interest in both

academic and industrial areas. This architectural style has facilitated the development of software systems

by composing them as a collection of small and loosely coupled services, each running in its process and

communicating with lightweight mechanisms. In parallel, Delphi is an integrated development environment

(IDE), based on the Object Pascal programming language, that enables the rapid application development of

software for desktop, mobile, web, and console applications. Although the software systems developed in

Delphi have considerable relevance in contemporary software, there is a lack of documented processes that

facilitate the modernization of legacy systems in Delphi to MSA. This paper presents the Micro4Dephi, a

modernization process based on six well-deﬁned activities. Each activity is constituted by a step set, which

may vary in number and content, thus allowing such activities to be performed. A case study was conducted

to show the applicability of the process proposed in this paper. The results provide important evidence that

enables a clear perspective on the process’s contribution to software modernization.

1 INTRODUCTION

Microservice architecture (MSA) has emerged as a

feasible alternative for the design or modernization of

legacy or monolithic systems for computational sce-

narios that are more modern (e.g., elastic) and en-

able the absorption of new users or execution envi-

ronment needs. Such systems must be divided into

small and loosely coupled services, each running in

isolated processes and communicating via lightweight

mechanisms. Furthermore, it is suggested that these

services be designed around the business capabili-

ties of these systems and must be deployable inde-

pendently through automated processes (Lewis and

Fowler, 2019; Newman, 2021).

Drawing a parallel between legacy and mono-

lithic systems, Pressman and Maxim (2019) suggest

that legacy can be understood as a system developed

with obsolete computing resources (e.g., architectural

models, programming languages, databases) for the

current computing scenario. According to (Lewis and

Fowler, 2019), the absence of developers also be-

https://orcid.org/0000-0002-5784-6248

comes a system developed with current technologies

a legacy, as the developers must utilize techniques to

comprehend it for any maintenance activity. As ar-

gued by Dragoni et al. (2017), monolithic systems

were designed with an architectural organization that

presents challenges in terms of scalability and adapt-

ability to evolving requirements. Examples of adver-

sities associated with monolithic systems include high

coupling, concurrency in teams working on the same

code base, and the high impact of changes Newman

(2021). Therefore, regardless of the speciﬁc type of

software (i.e., legacy or monolithic), software mod-

ernization has been revealed as a feasible alternative

for companies that intend to overcome the aforemen-

tioned adversities and enhance the availability of their

systems to end users, considering recent technologies,

architectural models, and modern computing scenar-

ios (Soldani et al., 2018).

Regardless of the system’s organizational struc-

ture, whether monolithic or not, the focus of this pa-

per is on the modernization of legacy systems devel-

oped in Delphi for MSA. According to Embarcadero

(2024), Delphi is an integrated development environ-

328

Fávero, L. F., Mário, G. S. and Affonso, F. J.

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture.

DOI: 10.5220/0013434400003929

Paper published under CC license (CC BY-NC-ND 4.0)

In Proceedings of the 27th International Conference on Enterprise Information Systems (ICEIS 2025) - Volume 2, pages 328-339

ISBN: 978-989-758-749-8; ISSN: 2184-4992

ment (IDE), supported by the Object Pascal program-

ming language, that enables the rapid application de-

velopment of software for desktop, mobile, web, and

console applications. The decision to modernize sys-

tems developed in Delphi was predicated upon sev-

eral factors, including its sustained importance within

the current technological environment. This relevance

can be attributed to the IDE’s robust developer com-

munity and extensive development resources, such as

rapid development and seamless integration with cur-

rent technologies (TIOBE, 2024).

As revealed by the investigation conducted by

Almeida et al. (2024) and Fávero and Affonso (2024),

software modernization initiatives identiﬁed in the ex-

isting literature can be viewed as partial solutions, as

such initiatives address speciﬁc steps within a com-

plex and wide-ranging context. Therefore, it can be

stated that there is no modernization process in the

literature that provides a solid foundation for sup-

porting the transition of legacy systems from Delphi

to MSA, encompassing activities from understanding

the legacy system to monitoring microservices in the

execution environment. Aiming to contribute to the

presented research scenario, this paper presents Mi-

cro4Delphi, a process structured in six activities cov-

ering the spectrum of actuation, from legacy system

comprehension to microservice monitoring. It is im-

portant to highlight that each process’s activity has a

set of steps that can vary in number and purpose to

achieve the desired outcome.

The ﬁndings reveal that Micro4Delphi has a good

potential to contribute to software modernization, as

it is the ﬁrst initiative that addresses the moderniza-

tion of systems developed in Delphi to MSA. These

ﬁndings also suggest that Micro4Delphi represents a

theoretical framework by which this process may be

instantiated to support other programming languages.

Finally, it is important to highlight that the case study

detailed in this paper provides a signiﬁcant theoreti-

cal and practical contribution to the advancement of

microservice application development using Delphi.

The reminder of this paper is organized as follows:

Section 2 presents the background and related work; a

description of Micro4Delphi is provided in Section 3;

Section 4 presents a case study to show the applica-

bility of Micro4Delphi; and Section 5 summarizes the

conclusions and perspectives for further research.

2 BACKGROUND AND RELATED

WORK

This section presents the background and related

work that contributed to the development of Mi-

cro4Delphi. Initially, concepts of Delphi, MSA, and

software modernization are described. Next, related

work on the software modernization of legacy sys-

tems to MSA is addressed.

Delphi. According to Embarcadero (2024), Del-

phi is a robust and contemporary IDE that provides

the advantages of a uniﬁed code base with the bene-

ﬁts of publishing native applications for any device.

In terms of innovations, this IDE also provides sup-

port for the plugin architecture of artiﬁcial intelli-

gence (e.g., OpenAI

). Finally, it is also noteworthy

that Delphi has an active community, as evidenced by

its ranking on the Tiobe index (TIOBE, 2024). Based

on the presented context, the motivation for modern-

izing software developed in Delphi for MSA appears

to be well-founded and compelling.

MSA. Microservice architecture is an architec-

tural style that facilitates the development of appli-

cations as a set of small, loosely coupled, and in-

dependent microservices (Lewis and Fowler, 2019).

Regarding the development and deployment activity,

such microservices may be written in different pro-

gramming languages and use different databases. Be-

cause of loose coupling, microservices can be in-

dependently deployed by fully automated processes

through the utilization of lightweight, container-based

platforms (Soldani et al., 2018). Richardson (2018)

suggests that a pattern language for microservices can

be used to support the development of a new system

or the modernization of an existing one. These pat-

terns represent solutions to common knowledge prob-

lems that overcome adversities related to, for exam-

ple, decomposition, transactions, communication via

messages, service discovery, among others.

Software Modernization. The monolith was one

of the earliest architectural approaches utilized in

the software industry because of its ease of develop-

ment and deployment and inherent beneﬁts (e.g., sim-

pliﬁed code base management and direct scalability

within a single software unit). However, as mono-

lithic systems have grown in size, many adversities

have emerged, including low productivity, extended

delivery times, and the overall complexity of the code

bases (Soldani et al., 2018). These challenges have

impeded the ability to incorporate emerging technolo-

gies and potentially reduce development cycles and

releases. In this direction, Colanzi et al. (2021a) sug-

gests the modernization of legacy systems to MSA as

a feasible alternative to overcome such challenges.

As related work, to the best of our knowledge,

there is no process for the modernization of legacy

systems developed in Delphi to MSA. In order to en-

sure the originality of the process proposed in this

https://openai.com

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture

329

paper, a systematic mapping was conducted based

on guidelines established by Petersen et al. (2015).

After a systematic process of investigation, 43 stud-

ies were selected because they presented some evi-

dence related to software modernization (i.e., legacy

or monolithic) to MSA. Because of space and scope

limitations, the details of this mapping will not be pre-

sented in this paper. The detailed research protocol

and the list of primary studies that served as the basis

for the modernization process presented in this paper

are available in Fávero and Affonso (2024).

3 MICRO4DELPHI

This section presents Micro4Delphi, a process result-

ing from a collaborative endeavor involving software

engineering researchers and practitioners from two

companies that specialize in the development of soft-

ware systems in Delphi.

On the researchers’ side, a literature mapping

was conducted by Fávero and Affonso (2024) and the

ﬁndings provided concrete evidence regarding a set of

macro activities that are essential to a modernization

process, namely: planning, analysis, decomposition,

development, integration, and monitoring. Moreover,

such mapping also identiﬁed a sequence of steps that

can be followed to achieve the objectives of these ac-

tivities, generating the initial draft of the process.

On the practitioners’ side, a rigorous process

analysis was conducted to evaluate the relevance and

applicability of the outlined activities and steps (i.e.,

the initial version). Such analysis provided a set of ev-

idence that was used to improve the proposed process

(i.e., the second version). It is worth highlighting that

a presentation on software modernization and MSA

concepts was carried out before the aforementioned

analysis. The purpose of this presentation was to

establish a uniﬁed understanding of this background

among the practitioners engaged in this activity.

Based on the evidence provided by the practition-

ers specialized in Delphi, a meeting for conﬂict reso-

lution was conducted. The objective of this meeting

was to resolve discrepancies and uniform the consen-

sus between researchers and practitioners on the ac-

tivities and steps for the Micro4Delphi process. As a

result, a deﬁnitive version of the process was estab-

lished, as illustrated in Figure 1. Next, a description

of each activity and its respective steps is addressed.

As illustrated, the development team (i.e., domain

specialists and software architects) conducts the soft-

ware modernization of the legacy system to the MSA

through a cyclical and incremental approach. Ac-

cording to Pressman and Maxim (2019), iterative ap-

proaches have proven to be feasible in modernization,

enabling not only the translation of legacy systems

but also the incorporation of new requirements to ful-

ﬁll updated user demands. Regarding the legacy sys-

tem, the proposed process was designed without con-

sideration of the existence of documentation artifacts.

Therefore, it is anticipated that researchers and prac-

titioners interested in utilizing the process will have

access solely to the source code repository of this sys-

tem, to transform it into an executable system (see

Legacy System).

Planning is an indispensable activity in any soft-

ware development project, including the moderniza-

tion of legacy systems to MSA. By planning mod-

ernization activities, organizations and development

teams increase the chances of success by anticipat-

ing potential adversities and ensuring that objectives

are achieved within the deﬁned deadlines and re-

sources. In short, this activity involves the delineation

of the objectives, strategies, and resources necessary

to achieve the desired results. From the perspective

of the organization, the adoption of a development

support methodology and the use of infrastructure to

enable distributed application development have been

demonstrated to be effective approaches for conduct-

ing modernization practices (Auer et al., 2021; Li

et al., 2020). Next, the steps associated with the plan-

ning activity are described.

1.1.Scope deﬁnition. This step is essential for any

initiative that aims to support the modernization of

legacy systems to MSA, as it involves establishing a

precise deﬁnition of the scope and goals of the sys-

tems (i.e., legacy and modernized). To do so, this

step aims to establish a perimeter for the function-

alities/operations that must be migrated to microser-

vices, aligned with all requirements that must be met

for both legacy and modernized systems. Further-

more, this step must be conducted in a manner that

is aligned with the expectations of stakeholders and

focused on the successful delivery of the objectives of

the modernized system (Li et al., 2020).

1.2.Team structuring. This step proposes a reor-

ganization of the teams responsible for modernization

according to speciﬁc criteria, including size, multi-

disciplinary knowledge capacity, independence, au-

tonomy, and alignment with DevOps (Development

and Operations) practices. The delineation of respon-

sibilities, formation of a multidisciplinary team, es-

tablishment of leadership, promotion of collabora-

tion and communication, and fostering of continu-

ous learning can facilitate the organization of effec-

tive teams (Mazzara et al., 2021).

1.3.Organizational culture. This step is based on

the premise that modernization is an activity that goes

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

330

Micro4Delphi

1.1. Scope definition

1.2. Team structuring

1.3. Organizational culture

1.4. Training

2.1. Business model

2.2. Legacy system

2.3. Database

2.4. User interface

2.5. Technological structure

3.1. Microservice candidates

3.2. Microservice ranking

3.3. Decomposition design

3.4. Data restructuring

3.5. API modeling

3.6. QA and metrics

3.7. Documentation

4.1. Data repository

4.2. Test cases

4.3. Microservice development

4.4. Database migration

4.5. Version control

4.6. Monolith to microservices

5.1. Service Mesh

5.2. CI/CD

5.3. Test

6.1. Dashboard

6.2. Issue alerts

6.3. Maintenance

6.4. Rollback

6.Monitoring

1.Planning

2.Analysis

3.Decomposition

4.Development

5.Integration

Development team

Legacy System

Modernized

System

Microservices

Legend:

Loop activity

Figure 1: The Micro4Delphi Process.

beyond the translation of a legacy system into MSA,

requiring a change in the organizational culture of

companies. Such changes require a shift in focus from

business capabilities to the continuous and valuable

delivery of software. A learning-oriented mindset, en-

couragement of experimentation, collaboration, open

communication, resilience, ﬂexibility, and committed

leadership are some factors that can contribute to the

organizational culture of companies (Mazzara et al.,

2021; Colanzi et al., 2021b).

1.4.Training. This step has proven to be essential

for the planning activity in a modernization process.

In this direction, experience reports presented by Sol-

dani et al. (2018) suggested that an understanding of

the microservices architecture style and training in the

technology stack that will be utilized in the target sys-

tem are factors that can facilitate success in modern-

izing a legacy system to this architectural style.

Analysis is a crucial activity element in the mod-

ernization process, as it enables developers to ascer-

tain the availability of software artifacts from legacy

systems, including source code repositories, binary

systems, and documentation artifacts. As a result, it is

expected that enough information will be gathered to

facilitate the formulation of a decision-making pro-

cess that will determine the optimal point of initia-

tion for the decomposition process. This requires the

identiﬁcation of the legacy system’s constituent com-

ponents and functionalities, an understanding of its

business domain boundaries, an analysis of the de-

pendencies between the aforementioned components,

and the establishment of a preliminary foundation for

the design and implementation of the MSA (Krause

et al., 2020; Ma et al., 2022b; Bandara and Perera,

2020). Next, a description of the steps associated with

the analysis is addressed.

2.1.Business model. This step suggests that the

development team should have a comprehensive un-

derstanding of the business operations and processes

implemented in the legacy system. As a result, this in-

vestigation provides valuable insights to development

teams on how IT systems can best support and lever-

age the organization’s business objectives and opera-

tions. To do so, developers must investigate how the

different parts of the legacy system support or affect

the organization’s business processes. This investiga-

tion enables the system boundaries and interactions to

be deﬁned, which can then be redeﬁned or optimized

in the new architecture (Dehghani et al., 2022).

2.2 to 2.4 (Legacy systems, database, and user

interface). To ensure a comprehensive understand-

ing of the legacy system, the development team must

conduct an architectural evaluation in this step, cov-

ering internal and external components, functionali-

ties, integrations, database, and user interface. Here,

the objective is to identify problematic points, such as

obsolete code, complex dependencies, performance

bottlenecks, and areas of low scalability. This analy-

sis facilitates the team’s understanding of moderniza-

tion challenges and risks, enabling the formulation of

a suitable strategy to ensure the modernized system

aligns with company requirements (Trabelsi et al.,

2022). As evidenced by Lewis and Fowler (2019),

a microservice can be deﬁned as a self-contained ap-

plication that encompasses code for its functionality,

data storage, and user interface. Therefore, when

addressing limitations from the perspective of func-

tionality and database, it is imperative to consider

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture

331

how users interact with the aforementioned function-

ality (Ma et al., 2022b). This involves gathering feed-

back on usability, user experience, visual design, and

other aspects related to interacting with the software.

Based on such insights, the development team can de-

sign and implement a modern, intuitive, and effective

user interface for the microservices, ensuring a posi-

tive experience for end users (Prasandy et al., 2020).

2.5.Technological structure. This step concerns

the deﬁnition of the software architecture and the

technologies that will be adopted for the microser-

vice implementation. This includes selecting the pro-

gramming languages, frameworks, platforms, and in-

frastructure services to support the new architectural

design. The technology structure should be chosen

based on the business requirements, the features of

the legacy system, the need for scalability, availabil-

ity, and security, and the development team’s capabil-

ities. Effective planning at this step can facilitate a

seamless transition to the MSA and the success of the

modernization project (Michael Ayas et al., 2021).

Decomposition is an activity that focuses on soft-

ware architecture, with special attention on the ex-

traction of microservice candidates from the legacy

system. According to Lewis and Fowler (2019), the

design of microservices must consider the organiza-

tional and business aspects that they offer to users.

The challenge of this activity is to determine the op-

timal size for the microservices, which should be di-

vided into smaller units with low coupling and high

cohesion. Once designed, each microservice should

be responsible for a delimited context, providing a

cohesive set of functionalities with a well-deﬁned

scope to meet a speciﬁc business capability (Krause

et al., 2020). Although there are (semi)automated

techniques that facilitate the decomposition of sys-

tems into microservices, it is recommended that, ini-

tially, functionalities with low impact or risk be prior-

itized during a modernization process (Osman et al.,

2022). To do so, the development team must establish

a strategy for selecting candidate microservices that

will add greater value and have fewer external depen-

dencies. Next, the steps associated with the planning

activity are described.

3.1.Microservice candidates. During this step, a

rigorous analysis of legacy system functionalities is

essential to determine the viability of potential mi-

croservice candidates (Sellami et al., 2022). Among

the approaches existing in the literature that can sup-

port decomposition, the most frequently utilized are:

(i) decomposition by delimited context, which aims

to identify the areas of the system that have cohe-

sive and well-deﬁned responsibilities, representing a

delimited business context; (ii) adequate granularity,

which aims to evaluate the size and complexity of the

functionalities of the legacy systems. Microservices

that are too small can result in excessive communi-

cation, while those that are too large can compro-

mise the scalability and maintainability of the mod-

ernized system; and (iii) loose coupling, which aims

to identify functionalities with few external depen-

dencies that can be isolated and maintained indepen-

dently. This approach helps to minimize coupling be-

tween microservices and facilitates the evolution and

maintenance of the modernized system.

3.2.Microservice ranking. In this step, candidate

microservices are ranked in order of importance, aim-

ing to promote continuous and valuable software in-

tegrity (Sellami et al., 2022). In this sense, the investi-

gation conducted by Fávero and Affonso (2024) sug-

gests the following guidelines: (i) the most critical or

essential use cases for the business; (ii) the microser-

vices that offer the greatest commercial value or that

address the most urgent customer needs; (iii) the mi-

croservices that are prerequisites for other microser-

vices or that have few external dependencies; and

(iv) the microservices that are simpler to implement

or that have lower technical risk. It is also notewor-

thy that scoring and classiﬁcation strategies, such as

value versus effort analysis, have proven to be a fea-

sible alternative in other software domains and can be

easily adapted to the context of this paper.

3.3.Decomposition design. At this step, develop-

ers should focus on establishing the communication

interface for each microservice, respecting the sys-

tem’s business capabilities. In this sense, they should

also dedicate particular attention to the management

of dependencies between microservices, aiming to

minimize coupling and ensure independence. To do

so, it is recommended that architectural patterns and

good software engineering practices be used to de-

sign and implement microservices, such as contain-

ers, container orchestration, API Gateway, and Circuit

Breaker (Richardson, 2018). Moreover, robust test-

ing and validation strategies have also proven a fea-

sible alternative for the decomposition and design of

new microservices, thereby ensuring the quality and

integrity of these services (Trabelsi et al., 2022).

3.4.Data restructuring. Similarly to the previ-

ous step, the developers must restructure (i.e., de-

compose) the legacy system’s databases in this step

to make them compatible with the microservices that

will be developed. To do so, they should focus on

identifying the different types of data, relationships

between entities, and coupling of database entities.

This will facilitate the decomposition of the legacy

system’s data model into smaller, more specialized

schemas, which can then be tailored to meet the spe-

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

332

ciﬁc requirements of each microservice. Moreover,

it is recommended that this activity be carried out in

parallel with the previous one (Parikh et al., 2022).

3.5.API modeling. In this step, developers should

focus their efforts on modeling the APIs, which repre-

sent the microservices contracts (Kyryk et al., 2022).

This step can be summarized as follows (Erl et al.,

2012): (i) identiﬁcation of the resources or function-

alities (i.e., business entities) that will be exposed

by the microservices; (ii) deﬁnition of RESTful end-

points, ensuring that each resource is represented by a

unique URI (Uniform Resource Identiﬁer) and acces-

sible through standard HTTP methods, such as GET,

POST, PUT, and DELETE; (iii) selection of appropri-

ate data formats to represent the API resources (e.g.,

JSON - JavaScript Object Notation); (iv) documen-

tation of the API contracts clearly and comprehen-

sively, specifying the input parameters, expected re-

sponses, and possible HTTP status codes; (v) version-

ing the API to ensure compatibility with future ver-

sions; (vi) security-oriented design so that authentica-

tion and authorization mechanisms are implemented

in such APIs so that the system resources and data

be protected; (vii) API documentation to facilitate

discovery and understanding of its functionality; and

(viii) testing (e.g., unit, integration, and acceptance)

to ensure the correct functioning of the APIs and their

compliance with the speciﬁed contracts.

3.6.QA and Metrics. At this step, it is crucial

to determine which quality attributes (QA) and met-

rics should be associated with the modernized sys-

tem (Trabelsi et al., 2022). According to Fávero and

Affonso (2024), QA and metrics are indispensable el-

ements of microservice-based systems, given the in-

trinsic nature of such systems. This investigation also

revealed that code reviews, software testing, and static

code analysis can assist in defect identiﬁcation and

correction. In parallel, metrics can be used to ascer-

tain the efﬁcacy of tests, the rate of defects identiﬁed,

the average time to rectify defects, code coverage,

and so forth. From the product’s perspective, met-

rics can be adopted to evaluate the modernized sys-

tem’s reliability, performance, usability, and response

time (Krause et al., 2020).

3.7.Documentation. Developers should focus

their efforts on preparing documentation for the sys-

tem that will be modernized in this step. In short,

essential documentation artifacts must be concise

and understandable, accurately reﬂecting the system’s

logical models, design, and architecture. To do so,

it is recommended that these artifacts meet the fol-

lowing criteria: documentation coverage, target au-

dience, and access format. The documentation must

be consistently reviewed and updated throughout this

step, as inconsistencies may compromise the modern-

ization process and necessitate exclusive use of the

source code for all development (Parikh et al., 2022).

Once the scope of the problem has been delin-

eated and a preliminary solution of the modernization

has been proposed, teams can proceed with the mi-

croservices development activity. As evidenced by

the ﬁndings of the investigation conducted by Fávero

and Affonso (2024), this activity can be carried out

in two approaches: (i) developing new code from

scratch, and (ii) extracting microservices from the

legacy source code. First, the legacy code is identi-

ﬁed as having minimal value, and developers should

prioritize the preservation of the functionalities of the

legacy system by implementing a new source code.

Second, the legacy code is deemed valuable and can

be leveraged to extract and transform the functional-

ities of the legacy system into equivalent microser-

vices. Independent of the approach, it is also crucial

to consider the gradual migration strategy for this ac-

tivity, whereby the legacy system’s previous version

should be discontinued after the microservice imple-

mentation to prevent maintenance issues arising from

the coexistence of functionalities in two distinct lo-

cations (Prasandy et al., 2020; Michael Ayas et al.,

2021; Bandara and Perera, 2020).

4.1.Data repository. In this step, the company

must prepare the development infrastructure aligned

with the principles and practices of DevOps, en-

abling the independent and parallel development of

microservices by the development teams. Such struc-

ture facilitates continuous software delivery, thereby

ensuring the realization of the beneﬁts associated with

microservices-based development from both an orga-

nizational and customer perspective (i.e., those inter-

ested in modernization) (Mazzara et al., 2021).

4.2.Test cases. In this step, the execution scenar-

ios must be delineated to evaluate whether the sys-

tem or its functionalities meet the established require-

ments. Planning tests have been a feasible alternative

in modernizing legacy systems, as it involves identify-

ing the input conditions, the steps to be followed, and

the expected results for each functionality. Therefore,

it can be said that test cases serve as a basis for verify-

ing whether the software meets the requirements and

behaves as expected (Prasandy et al., 2020).

4.3.Microservice development. In this step, the

microservices are developed following the design and

technological speciﬁcations, as well as the business

and technical requirements established in the previ-

ous steps (i.e., 2.1, 3.1 to 3.7). As a result, the ob-

jective is to integrate the microservices in a way that

ensures their collective functionality. During imple-

mentation, it is recommended that developers adhere

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture

333

to best practices in software engineering, such as writ-

ing clean and modular code, to ensure the scalabil-

ity and resilience of the microservices. Moreover, it

is also suggested that tools be used to develop, man-

age versions of, and deploy the microservices. Once

the microservices have been developed, they are sub-

jected to a series of tests, debugging procedures, and

deployment in a production environment for use by

end users (Michael Ayas et al., 2021).

4.4.Database migration. In this step, the mi-

croservice databases must be created based on the un-

derstanding gathered in Steps 1.1, 2.1 to 2.4, and 3.4.

The database migration is a complex task, encom-

passing the transfer of both the data schema and the

data itself. According to Fávero and Affonso (2024),

this step must be carried out in parallel with the mi-

croservice development, since there is an intrinsic re-

lationship between the microservice functionality and

its data. Moreover, another relevant aspect to consider

for a successful database migration is the data migra-

tion between the old and the new schema to ensure

the integrity of information between the legacy and

modernized systems (Prasandy et al., 2020).

4.5.Version control. Version control is an essen-

tial practice in microservice-based development, as

it enables the tracking and management of changes

to both the source code and the system conﬁguration

over time. Furthermore, version control enables the

rollback to previous versions in the event of compli-

cations and facilitates the deployment of new software

versions in a regulated and automated manner. In this

direction, it is also recommended that versioning for

the microservice contract be deﬁned, as well as ver-

sion control of its source code. To do so, development

teams must create individual repositories for each mi-

croservice in this step (Freire et al., 2021).

4.6.Monolith to microservices. This step transi-

tions the system from its legacy version to a modern-

ized one. This transition should occur gradually as

the microservices develop, allowing both systems to

coexist (Bandara and Perera, 2020).

Integration is an activity that aims to combine

and synchronize the microservices developed to com-

pose the modernized system. During this activity,

the microservices are linked through APIs or other

communication channels, facilitating the transfer of

data and information essential for the system’s over-

all functionality. This activity may also entail the inte-

gration of the modernized system with other systems

or external components to address the novel system

requirements. Moreover, integration may involve the

conﬁguration of continuous deployment pipelines and

process automation, to facilitate the distribution of

microservices in different environments, such as de-

velopment, testing, and production. Upon completion

of this activity, the integrated system is expected to

be prepared for deployment and made accessible for

utilization by end users (Parikh et al., 2022).

5.1.Service Mesh. In this step, microservices

are packaged into images and deployed into contain-

ers for insertion into the operational environment.

This activity also includes deﬁning messaging, rout-

ing, load balancing, discovery services, among others.

The service mesh refers to the communication and in-

teraction between the various microservices that make

up a system, as well as the monitoring, diagnostics,

and maintenance mechanisms used to ensure their

health and performance (Parikh et al., 2022).

5.2.CI/CD. This step encompasses the following

activities: continuous integration (CI), continuous de-

livery (CD), and continuous deployment. CI requires

submitting code changes to be merged into the pri-

mary branch. Automated build and test processes

guarantee that the code in the main branch main-

tains production quality. Thus, teams can identify

problems related to compatibility or code conﬂicts,

mitigating the probability of introducing errors and

quality issues into the system. In CD, a production-

like environment automatically receives code changes

passing through the CI process. To ensure continuous

delivery in a microservice environment, it is impor-

tant to have a robust set of automation tools, com-

prehensive automated testing, and a culture of col-

laboration and effective communication between de-

velopment teams. Continuous deployment requires

that code modiﬁcations have undergone the preced-

ing two steps (i.e., CI/CD) and are prepared for auto-

mated deployment to the production environment. A

CI/CD process that is to be considered robust should

include the following features: (i) the creation and de-

ployment of microservices in an independent manner;

(ii) the deployment of said microservices in environ-

ments designated for development, testing, and qual-

ity assurance; (iii) the concurrent deployment of both

existing and new versions; and (iv) the packaging of

images in containers within the production environ-

ment (Dehghani et al., 2022; Parikh et al., 2022).

5.3.Test. This step represents the automation of

unit and integration tests for microservices. Unit tests

aim to verify the individual behavior of small parts of

the code, usually functions or methods, isolating them

from other system parts. These tests are automated to

be executed quickly and repeatedly whenever changes

exist in the code, ensuring that new features do not

break existing ones, and facilitating the early detec-

tion of bugs. Integration tests aim to verify the inter-

action between different system components, such as

modules, microservices, or external systems. These

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

334

tests automate the veriﬁcation of the functionality and

compatibility of the system as a whole, ensuring that

the individual components operate correctly together.

By automating unit and integration tests, development

teams can proactively identify and correct problems,

reducing the time needed to validate code changes

and increasing the reliability and stability of the soft-

ware. To automate tests, it is recommended to use

speciﬁc testing tools, development frameworks, and

continuous integration practices, which facilitate the

automatic execution of tests in controlled environ-

ments and the generation of detailed reports on test

results (Parikh et al., 2022; Prasandy et al., 2020).

Monitoring is an essential activity in

microservice-based systems because of the dis-

tributed and complex nature of these systems.

Therefore, monitoring in microservices environments

involves collecting and analyzing performance-

related metrics, such as response time, error rate,

resource usage (e.g., CPU, memory, network), and

availability. Such metrics are collected at runtime and

can be visualized through dashboards and reports,

providing valuable insight into the system’s health

and helping to identify bottlenecks, failures, and

optimization opportunities. Furthermore, monitoring

activities can include the early detection and alert-

ing of anomalies and potential problems, thereby

enabling operations and development teams to take

corrective action expeditiously and minimize the

impact on end users. The implementation of a

monitoring system in microservice environments

necessitates the utilization of specialized tools and

platforms for the collection, storage, and analysis of

monitoring data, as well as observability practices

aimed at enhancing system comprehension and

diagnosis in the event of problems (Ma et al., 2022a).

6.1.Dashboard. This step involves implementing

dashboards to provide centralized, continuous feed-

back on metrics and microservice’s health (Freire

et al., 2021). To do so, a set of tools can be utilized

as dashboards and, simultaneously, facilitate the ob-

servability of the modernized system, collecting a set

of metrics, trace information, and log (Tozzi, 2022).

Metrics can be deﬁned as a logical meter used to mea-

sure and record data over a speciﬁed period. Trace

information refers to data associated with the life cy-

cle of a single transactional object in a system, which

can be transaction speciﬁc or related to other aspects

of the system’s operation. Logs deal with discrete

events that occur while running a system, such as er-

ror messages, audit events, or request-speciﬁc meta-

data. Among the tools referenced in the literature,

Grafana

has distinguished itself as a valuable re-

https://grafana.com

source and an open-source solution.

6.2.Issue alerts. This step addresses the process-

ing of warning messages (or alerts) when the system

transitions to a critical or attention state. The alerts

may assist in the early detection and mitigation of

problems to prevent microservice disruption. Alert-

ing represents a key practice to microservice moni-

toring, as it enables immediate notiﬁcation to opera-

tions and development teams of signiﬁcant events or

issues that could impact system availability or perfor-

mance (Freire et al., 2021).

6.3.Maintenance. This step requires the collab-

oration of development teams to ensure the coordi-

nation and maintenance of preventive, corrective, and

improvement actions based on the data collected from

monitoring (i.e., dashboard). A development team

needs to be aware of the following maintenance activ-

ities: maintaining the latest software versions for mi-

croservices, monitoring and ﬁxing bugs that affect mi-

croservice behavior or functionality, identifying and

resolving performance issues in microservices, as-

sessing and adjusting microservice capacity to han-

dle trafﬁc spikes and increased demand, and ﬁnally,

maintaining constant monitoring to proactively iden-

tify problems and anomalies (Colanzi et al., 2021b).

6.4.Rollback. This step suggests that development

teams can rollback microservices (or system versions)

in case of failure. This enables the system to revert

to the legacy and stable environment, thus facilitating

the performance of effective maintenance. Therefore,

it can be said that enabling rollback is an important

practice during the microservice life cycle because

it provides a way to undo changes that have caused

problems or introduced regressions in the system. By

incorporating rollback strategies as a maintenance ap-

proach, teams can reduce the risk of system failures

and outages, and ensure a more reliable and consis-

tent user experience (Colanzi et al., 2021b).

4 CASE STUDY

This section presents a case study conducted to eval-

uate the applicability, strengths, and weaknesses of

Micro4Delphi. The subject of the empirical analysis

is a legacy system developed in Delphi that addresses

scholar evaluation, referenced from this point on for-

ward as Avance. Next, an overview of the subject

application and the empirical strategies adopted for

conducting this case study will be provided.

Subject Application. The Avance system was de-

veloped in Delphi 10.4 with a Firebird database ver-

sion 2.5. The system was organized in layers and

modules, with distinct layers separating the user in-

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture

335

terface components (i.e., forms), the business logic

of the system (i.e., units), and the database connec-

tion (i.e., data module). In terms of size, this sys-

tem has 15 forms, six reports, 11 data modules, 10

database tables, and 19 components of connectivity

to the database, including data sources, tables, and

queries (see Figure 2 – Side A).

In terms of functionality, the Avance system en-

ables users (i.e. students and teachers) to register with

personal data so that they can authenticate and per-

form operations according to each proﬁle. The system

was designed to distinguish between different classes

and the students enrolled in each one. In the teacher’s

proﬁle, the system enables each one to prepare lessons

for each class based on the content that must be regis-

tered in the system. Moreover, teachers can also pre-

pare exercises for each lesson, which must be com-

pleted by the students during the class period. Re-

garding the student’s proﬁle, the Avance system en-

ables each student to monitor the content they have

learned and the exercises they have completed, aim-

ing to facilitate the learning process. To do so, the

system enables the viewing of the number of correct

and incorrect answers in each exercise, as well as the

recommended solution for each exercise.

Empirical Strategy. Figure 2 shows the mod-

ernization of the Avance system to MSA, which was

based on the analysis of the system source code and its

database. The illustration on the left side (A) shows

the organization of the Avance system in three lay-

ers: user interface, business logic, and data access

layer. The illustration on the right side (B) shows the

microservices that emerged from the modernization

process, namely: MSClass, MsSchool, MsLesson,

and MsUser. Moreover, the illustration on side (B)

presents the organizational structure of the MsUser

microservice and the MSA elements in the bottom

part (i.e., Log, Config, and Catalog services).

In order to demonstrate the behavior of Mi-

cro4Delphi, only the tasks related to the transition

from the legacy system to the MsUser microservice

will be presented in this section due to space lim-

itations. Therefore, it can be stated that after the

planning activity (Step 1.1), the system was compre-

hended and a layered model was designed, as illus-

trated on the left side (A) of Figure 2. The remaining

steps of this activity were not carried out because of

the limitations in the size of the team responsible for

conducting this case study.

In the analysis activity, each of the prescribed

steps was visited. Initially, the analysis involved the

construction of an understanding regarding the legacy

system and its database, besides the business model

associated with such a system (Steps 2.1 to 2.3).

In this sense, some user-related functionalities were

identiﬁed, including, for instance, user authentication.

Additionally, database tables, such as User_Access

and User, were identiﬁed as potential sources of sup-

port for the MsUser microservice. Since the purpose

is to transform the legacy system into microservices,

it was decided that the user interface should be main-

tained and the native language of the system should

be preserved (Steps 2.3 and 2.4).

In the decomposition activity, the legacy code

must be analyzed to identify candidates for mi-

croservices (Step 3.1). As illustrated in Figure 2,

Side A, four microservices candidates were identi-

ﬁed: MsClass, MsSchool, MsLesson, and MsUser.

Since the Avance source code has proven to be of

high value, it is recommended that the system be

refactored so that its source code and data schema

can be reused in the microservices development stage

(Steps 3.2 to 3.4). Next, the equivalent APIs are

modeled for the identiﬁed microservices, which focus

on deﬁning how these microservices will communi-

cate with one another and/or components external to

the system (Step 3.5). Finally, the documentation of

these microservices via Swagger must be completed

(Step 3.7), as it aims to provide interested parties with

information on how to use them.

During the development phase, microservices

were implemented, as illustrated in Figure 2. As

illustrated, each microservice incorporates its own

database and necessitates a dedicated database con-

nection unit, as detailed in Listing 1. With microser-

vice decoupling from the user interface, the database

connection components were implemented on the

command line. In Line 3, the name of the database

connection is deﬁned, which is then used by the

cnxDef connection component instantiated in Line 6.

Between Lines 10 and 12, the database connection pa-

rameters (i.e., user, password, and database) are

deﬁned for each microservice. Finally, it is important

to note that the comments in Lines 2, 4, 8, 13, and

16 represent omitted code sections that do not require

conﬁguration details.

From this point forward, only an overview of

the organization of the MsUser microservice is pro-

vided because of the space limitations of this paper.

The model package contains a class designated User

(Model.User.pas). The dao package contains the

DAO.User.pas class, the purpose of which is to deal

with data persistence. To do so, this class implements

the getUser method to query users and the postUser

method to include users in the database. The util

package contains a set of utility classes for the MsUser

microservice to function. A comprehensive examina-

tion of the classes in the aforementioned packages is

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

336

Database

Data access layer

Business logic

User

Lessons

Classes

Schools

User Interface

Data

Module

Unit (.pas)

Form

Avance System

MsClass

MsSchool

MsLesson

MsUser

Microservices

DB = Database

DM = Data Module

Legend

Ms = Microservice

(A) Legacy System Modernized System (B)

util

model

dao

controller

connection

Log Config Catalog

Microservice

Architecture

Elements

Figure 2: Legacy System Modernization for MSA.

Listing 1: Connection unit.

1 unit udmUser;

2 //...

3 const CON_NAME = ’User_runtime’;

4 //...

5 procedure TdmFiredac.FDManagerBS(Sender:

→ TObject);

6 var cnxDef: IFDStanConnectionDef;

7 begin

8 //...

9 cnxDef.Name := CON_NAME;

10 cnxDef.Params.UserName := ’sysdba’;

11 cnxDef.Params.Password := ’masterkey’;

12 cnxDef.Params.Database :=

→ ’C:\Avance\User.fdb’;

13 //...

14 cnxDef.Apply;

15 end;

16 end.

outside the purpose of this paper.

The controller package contains the

Controller.User.pas class in the code frag-

ment shown in Listing 2. In short, the purpose of

this class is to facilitate interactions between the user

interface and the dao layer for data persistence. To

illustrate such interactions, this controller imple-

ments two procedures as GET (Line 17) and POST

(Line 26) methods. In both methods, it is possible

to observe the creation of the DAOUser object from

the dao layer in Lines 20 and 30, respectively.

In Lines 22 and 32, the calls to the getUser and

setUser methods of DAOUser are presented, both of

which have been previously described (dao package).

It should be highlighted that the MsUser microser-

vice development activity was concluded with the

documentation of the APIs via Swagger between

Lines 7 and 10 (Listing 2). Speciﬁcally, Line 7 de-

lineates the method that has been documented (i.e.,

Listing 2: Controller User.

1 unit Controller.User;

2 //...

3 type

4 //...

5 public

6 //...

7 [SwagPOST(’’, ’Post’, true)]

8 [SwagResponse(200, TModelUser,

→ ’Success’)]

9 [SwagResponse(400, TModelResponse,

→ ’Bad Request’)]

10 procedure post;

11 //...

12 constructor Create(Req: THorseRequest;

→ Res: THorseResponse);

13 end;

15 implementation

17 procedure TControllerUser.get;

18 //..

19 begin

20 DAOUser := TDAOUser.Create;

21 //...

22 FResponse.Status(200).Send<TJSONArray>

→ (DAOUser.getUser);

23 //...

24 end;

26 procedure TControllerUser.post;

27 //...

28 begin

29 User := getBody;

30 DAOUser := TDAOUser.Create;

31 //...

32 FResponse.Status(200).Send<TJSONObject>

→ (DAOUser.setUser(User));

33 //...

34 end;

35 end.

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture

337

POST), with the response messages associated with the

respective codes (e.g., 200 and ‘Success’) detailed in

Lines 8 and 9. The documentation for the get method

follows a similar structure; however, it has been omit-

ted because of space limitations.

Therefore, it can be stated that, upon conclusion

of the development activity, Steps 4.1 to 4.5 were

executed in full in this case study, as the microser-

vice is now prepared for deployment in its execution

environment. Concerning the other activities of the

Micro4Delphi process, it should be noted that the in-

tegration and monitoring activities were partially

conducted. Of particular note are the development

of tests (Step 5.3) through the Swagger API and the

monitoring of microservices in the execution environ-

ment (Step 6.1). Although these activities are relevant

to the modernization process, they do not address the

transition from legacy systems to microservices and,

therefore, will not be detailed in this section.

5 CONCLUSIONS

This paper presented the Micro4Delphi, a process de-

signed to support the modernization of legacy systems

developed in Delphi to MSA. To do so, each activ-

ity has a set of steps targeted to the legacy system

and organization of development teams or company

structure. Given the scenario described, the principal

contributions of this paper are outlined as follows.

The process proposed in this paper may prove ad-

vantageous for the development and software engi-

neering areas. To the best of our knowledge, it rep-

resents the ﬁrst initiative that can effectively support

the modernization of legacy systems to MSA (Fávero

and Affonso, 2024). This process has the potential to

serve as a theoretical framework that can contribute to

the formulation of new initiatives or improvements to

existing ones.

The case study presented in Section 4 provides an

overview of the modernization of legacy systems in

Delphi, emphasizing the organization of the modern-

ized system based on microservice organization. In

this sense, it is notable that this case study can serve as

a reference for others interested in transforming their

systems for the current computing scenario.

Regarding future work on Micro4Delphi, at least

three activities are planned: (i) the conduction of ad-

ditional case studies, which will enable a more com-

prehensive evaluation of this process across a range of

software domains, including web, mobile, and enter-

prise; (ii) the instantiation of Micro4Delphi for other

programming languages, which will facilitate an eval-

uation of its behavior when a new development envi-

ronment is used; and (iii) the use of this process in an

industrial setting, which will allow for an evaluation

of its behavior when applied in a larger, real-world

development and execution environment.

ACKNOWLEDGMENTS

This study was ﬁnanced in part by the Coordenação

de Aperfeiçoamento de Pessoal de Nível Superior -

Brasil (CAPES).

REFERENCES

Almeida, N. R., Campos, G. N., Moraes, F. R., and Af-

fonso, F. J. (2024). Modernization of legacy systems

to microservice architecture: A tertiary study. In The

23rd International Conference on Enterprise Informa-

tion Systems., pages 1–12. INSTICC, SciTePress.

Auer, F., Lenarduzzi, V., Felderer, M., and Taibi, D. (2021).

From monolithic systems to microservices: An as-

sessment framework. Information and Software Tech-

nology, 137.

Bandara, C. and Perera, I. (2020). Transforming mono-

lithic systems to microservices - an analysis toolkit for

legacy code evaluation. In 20th International Confer-

ence on Advances in ICT for Emerging Regions, ICTer

2020 - Proceedings, page 95 – 100. Institute of Elec-

trical and Electronics Engineers Inc.

Colanzi, T., Amaral, A., Assunção, W., Zavadski, A.,

Tanno, D., Garcia, A., and Lucena, C. (2021a). Are we

speaking the industry language? The practice and lit-

erature of modernizing legacy systems with microser-

vices. In The 15th Brazilian Symposium on Software

Components, Architectures, and Reuse, pages 61–70,

New York, NY, USA. Association for Computing Ma-

chinery.

Colanzi, T., Amaral, A., Assunção, W., Zavadski, A.,

Tanno, D., Garcia, A., and Lucena, C. (2021b). Are

we speaking the industry language? the practice and

literature of modernizing legacy systems with mi-

croservices. In ACM International Conference Pro-

ceeding Series, page 61 – 70. Association for Com-

puting Machinery.

Dehghani, M., Kolahdouz-Rahimi, S., Tisi, M., and Tamza-

lit, D. (2022). Facilitating the migration to the mi-

croservice architecture via model-driven reverse en-

gineering and reinforcement learning. Software and

Systems Modeling, 21(3):1115 – 1133.

Dragoni, Nicola, Giallorenzo, S., and Lafuente, A. L.

(2017). Present and ulterior software engineering.

In Microservices: Yesterday, Today, and Tomorrow.,

pages 195–216. Springer.

Embarcadero (2024). Native apps for any device from one

codebase with delphi! on-line. Avaliable in: https://

www.embarcadero.com/products/delphi, accessed on

March 20, 2025.

ICEIS 2025 - 27th International Conference on Enterprise Information Systems

338

Erl, T., Balasubramanian, R., Pautasso, C., Wilhelmsen, H.,

Carlyle, B., and Booth, D. R. (2012). SOA with REST.

Prentice Hall, Philadelphia, PA.

Freire, A. F. A. A., Sampaio, A. F., Carvalho, L. H. L.,

Medeiros, O., and Mendonça, N. C. (2021). Migrating

production monolithic systems to microservices using

aspect oriented programming. Software - Practice and

Experience, 51(6):1280 – 1307.

Fávero, L. F. and Affonso, F. J. (2024). A systematic

mapping study of legacy system modernization

to msa. on-line. https://drive.google.com/ﬁle/d/

1-sKo1mU54Q6QQY1l7slfuyxx0PwtxdmA/view?

usp=sharing, acessed on March 20, 2025.

Krause, A., Zirkelbach, C., Hasselbring, W., Lenga, S., and

Kroger, D. (2020). Microservice decomposition via

static and dynamic analysis of the monolith. In The

IEEE International Conference on Software Architec-

ture Companion, ICSA-C 2020, page 9 – 16. Institute

of Electrical and Electronics Engineers Inc.

Kyryk, M., Tymchenko, O., Pleskanka, N., and Pleskanka,

M. (2022). Methods and process of service migra-

tion from monolithic architecture to microservices. In

16th International Conference on Advanced Trends in

Radioelectronics, Telecommunications and Computer

Engineering, TCSET 2022, page 553 – 558. Institute

of Electrical and Electronics Engineers Inc.

Lewis, J. and Fowler, M. (2019). Microservices guide.

on-line. Avaliable in: https://martinfowler.com/

microservices, accessed on March 20, 2025.

Li, C.-Y., Ma, S.-P., and Lu, T.-W. (2020). Microservice

migration using strangler ﬁg pattern: A case study on

the green button system. In Proceedings - 2020 Inter-

national Computer Symposium, ICS 2020, page 519 –

524. Institute of Electrical and Electronics Engineers

Inc.

Ma, S.-P., Li, C.-Y., Lee, W.-T., and Lee, S.-J. (2022a).

Microservice migration using strangler ﬁg pattern and

domain-driven design. Journal of Information Science

and Engineering, 38(6):1285 – 1303.

Ma, S.-P., Lu, T.-W., and Li, C.-C. (2022b). Migrat-

ing monoliths to microservices based on the analy-

sis of database access requests. In IEEE International

Conference on Service-Oriented System Engineering,

SOSE 2022, page 11 – 18. Institute of Electrical and

Electronics Engineers Inc.

Mazzara, M., Dragoni, N., Bucchiarone, A., Giaretta, A.,

Larsen, S. T., and Dustdar, S. (2021). Microservices:

Migration of a mission critical system. IEEE Trans-

actions on Services Computing, 14(5):1464 – 1477.

Michael Ayas, H., Leitner, P., and Hebig, R. (2021). The mi-

gration journey towards microservices. Lecture Notes

in Computer Science, 13126 LNCS:20 – 35.

Newman, S. (2021). Building microservices. O’Reilly Me-

dia, Sebastopol, CA, 2 edition.

Osman, M. H., Saadbouh, C., Sharif, K. Y., Admodisastro,

N., and Basri, M. H. (2022). From monolith to mi-

croservices: A semi-automated approach for legacy

to modern architecture transition using static analysis.

International Journal of Advanced Computer Science

and Applications, 13(10):907 – 916.

Parikh, A., Kumar, P., Gandhi, P., and Sisodia, J. (2022).

Monolithic to microservices architecture - a frame-

work for design and implementation. In Interna-

tional Conference on Computer, Power and Commu-

nications, ICCPC 2022 - Proceedings, page 90 – 96.

Institute of Electrical and Electronics Engineers Inc.

Petersen, K., Vakkalanka, S., and Kuzniarz, L. (2015).

Guidelines for conducting systematic mapping stud-

ies in software engineering: An update. Information

and Software Technology, 64:1–18.

Prasandy, T., Titan, Murad, D. F., and Darwis, T. (2020).

Migrating application from monolith to microser-

vices. In Proceedings of 2020 International Con-

ference on Information Management and Technology,

ICIMTech 2020, page 726 – 731. Institute of Electrical

and Electronics Engineers Inc.

Pressman, R. and Maxim, B. (2019). Software Engineering:

A Practitioner’s Approach. McGraw-Hill Education.

9th Edition.

Richardson, C. (2018). Microservices patterns. Manning

Publications Company.

Sellami, K., Ouni, A., Saied, M. A., Bouktif, S., and

Mkaouer, M. W. (2022). Improving microservices ex-

traction using evolutionary search. Information and

Software Technology, 151.

Soldani, J., Tamburri, D. A., and Van Den Heuvel, W.-J.

(2018). The pains and gains of microservices: A sys-

tematic grey literature review. Journal of Systems and

Software, 146:215–232.

TIOBE (2024). Tiobe index for november 2024. on-line.

Avaliable in: https://www.tiobe.com/tiobe-index, ac-

cessed on March 20, 2025.

Tozzi, C. (2022). The 3 pillars of observabil-

ity: Logs, metrics and traces. Available:

https://www.techtarget.com/searchitoperations/tip/

The-3-pillars-of-observability-Logs-metrics-and-

traces, Accessed on March 20, 2025.

Trabelsi, I., Abdellatif, M., Abubaker, A., Moha, N.,

Mosser, S., Ebrahimi-Kahou, S., and Guéhéneuc, Y.-

G. (2022). From legacy to microservices: A type-

based approach for microservices identiﬁcation using

machine learning and semantic analysis. Journal of

Software: Evolution and Process.

Micro4Delphi: A Process for the Modernization of Legacy Systems in Delphi to Microservice Architecture

339
