Applying Prototyping and Exploratory Testing to Ensure Software
Quality in an Information System for Power Tampering Detection: An
Experience Report
Sabryna Araujo
1 a
, Ramille Santana
1 b
, Joana Silva
1 c
, Arthur Passos
1,2 d
, Matheus Menezes
3 e
,
Felipe Feyh
3 f
, Carlos Moura
3 g
, Lucas Pinheiro
3 h
, Auriane Santos
3 i
, Aristofanes Silva
1,2 j
,
Jo
˜
ao Dallyson
1,2 k
, Italo Francyles
1,2 l
and Luis Rivero
1,2 m
1
N
´
ucleo de Computac¸
˜
ao Aplicada (NCA), Federal University of Maranh
˜
ao (UFMA), S
˜
ao Lu
´
ıs, MA, Brazil
2
Programa de P
´
os-Graduac¸
˜
ao em Ci
ˆ
encia da Computac¸
˜
ao (PPGCC), Federal University of Maranh
˜
ao (UFMA), S
˜
ao Lu
´
ıs,
MA, Brazil
3
Instituto de Ci
ˆ
encia e Tecnologia Grupo Equatorial, S
˜
ao Lu
´
ıs, MA, Brazil
Keywords:
Exploratory Testing, Prototype, Software Quality, Software Engineering.
Abstract:
This paper presents an experience report on the application of exploratory testing in the development of a
system aimed at detecting illegal connections in the electricity supply, a critical problem that causes financial
losses and compromises the safety and efficiency of power grids. The research utilized a high-fidelity prototype
developed in the Figma tool as a basis for planning and executing tests, allowing the identification of functional
and usability defects in an agile and collaborative manner. The adopted methodology involved the use of
iterative meetings for continuous validation, ensuring alignment between requirements and implementation.
During the process, 49 defects were recorded and categorized, enabling significant system improvements and
ensuring higher quality in the final product. The results highlight the effectiveness of integrating prototypes
and exploratory testing to reduce validation time, identify critical issues, and promote team alignment. As
future work, it is proposed to expand the system’s prioritization criteria and conduct user tests in real scenarios.
This study contributes to the literature by reinforcing the role of agile methodologies and modern testing
techniques in the development of robust and effective technological solutions.
1 INTRODUCTION
The practice of makeshift solutions, characterized by
improvised solutions to technical or operational prob-
a
https://orcid.org/0009-0001-5460-1261
b
https://orcid.org/0009-0008-4071-8064
c
https://orcid.org/0009-0004-2216-357X
d
https://orcid.org/0000-0002-2823-3645
e
https://orcid.org/0000-0001-8676-1131
f
https://orcid.org/0009-0008-3593-9225
g
https://orcid.org/0009-0005-8552-6136
h
https://orcid.org/0000-0002-4641-3703
i
https://orcid.org/0009-0003-3873-4990
j
https://orcid.org/0000-0003-0423-2514
k
https://orcid.org/0000-0001-7013-9700
l
https://orcid.org/0000-0002-2041-7538
m
https://orcid.org/0000-0001-6008-6537
lems, is a phenomenon widely observed in Brazil and
in several other developing countries. These practices
generally emerge in scenarios of financial resource
constraints or insufficient infrastructure and are of-
ten associated with improvisations in electrical sys-
tems, hydraulic systems, or even technological de-
vices. Furthermore, with the increase in the number
of households, energy companies face the challenge
of managing a growing customer base (Vidinich and
Nery, 2009). Studies indicate that these solutions, de-
spite being creative, can pose significant risks to both
the safety and performance of critical systems.
In this context, a specific module for the automatic
prioritization of makeshift solutions was developed,
which uses the Internal Rate of Return (IRR) as the
main evaluation metric. The system combines data
analysis and managerial reports to support operational
380
Araujo, S., Santana, R., Silva, J., Passos, A., Menezes, M., Feyh, F., Moura, C., Pinheiro, L., Santos, A., Silva, A., Dallyson, J., Francyles, I. and Rivero, L.
Applying Prototyping and Exploratory Testing to Ensure Software Quality in an Information System for Power Tampering Detection: An Experience Report.
DOI: 10.5220/0013483000003929
Paper published under CC license (CC BY-NC-ND 4.0)
In Proceedings of the 27th International Conference on Enterprise Information Systems (ICEIS 2025) - Volume 2, pages 380-387
ISBN: 978-989-758-749-8; ISSN: 2184-4992
Proceedings Copyright © 2025 by SCITEPRESS – Science and Technology Publications, Lda.

teams in identifying critical points, allowing compa-
nies to prioritize interventions with higher economic
and strategic returns. Additionally, the module helps
prioritize corrective actions with the best cost-benefit
ratio for the company, optimizing available resources
and minimizing the negative impacts of irregularities.
The goal of this paper is to report the experience
of applying exploratory testing in the development of
a system aimed at detecting makeshift solutions in the
electricity supply. These makeshift solutions, known
as irregular electrical connections, represent a seri-
ous problem for power distributors, causing financial
losses, increasing the risk of accidents, and compro-
mising the efficiency of the electrical grid. To ad-
dress this challenge, it was necessary to invest in an
approach that ensured software quality, from the pro-
totyping phase to testing, using best development and
validation practices.
During the process, prototyping played an essen-
tial role, serving not only as a tool for the initial
planning of the system but also as a practical doc-
umentation tool for testing. The prototype guided
the development and application of exploratory tests,
enabling the identification of functional and usabil-
ity issues even before the final implementation. Fur-
thermore, this approach ensured that the requirements
were continuously reviewed and improved, reinforc-
ing the alignment between the development team and
the project’s objectives.
2 RELATED WORK
2.1 Exploratory Testing and
Prototyping
Exploratory testing has emerged as a complemen-
tary approach to automation, leveraging the tester’s
knowledge to identify problems and propose im-
provements in developing systems. Unlike automated
testing, which follows predefined scripts, exploratory
testing allows for the dynamic creation of test sce-
narios, increasing the likelihood of discovering unex-
pected defects.
The study (Silva et al., 2024) employed design
thinking and high-fidelity prototypes developed in
Figma to create a mobile application aimed at dis-
seminating scientific knowledge. During prototyping,
a panel of judges evaluated the prototype’s usability
using the SUS (System Usability Scale), achieving
a satisfaction score above 85%. However, validation
took approximately 60 days, including a second round
of adjustments for items that did not meet the mini-
mum content validity index (IVC over 0.800). This
approach, although detailed, proved to be limited in
agility and identifying functional defects. In contrast,
the method proposed in our work prioritizes agility
and direct collaboration with the team. We used the
prototype as a central ”oracle” to identify and clas-
sify functional and usability defects in just 2-3 hours
of team meetings. This approach not only drastically
reduced the time needed for validation but also en-
abled faster and more accurate defect detection. Addi-
tionally, our methodology included immediate defect
classification, facilitating prioritization and allowing
the team to promptly address the identified issues.
The study (Yu, 2018) presented an agile ex-
ploratory testing model that integrates manual and au-
tomated methods to evaluate functionalities, regres-
sion, and acceptance. The model was implemented
in a university system through four iterative cycles,
where tests were performed in distinct stages by two
separate groups. Each cycle required preparatory
tests, pre-tests, functionality, regression, and accep-
tance testing, resulting in an extensive and fragmented
process. Dividing tasks between groups was effective
in detecting defects, especially in the graphical user
interface (GUI), but the time required to coordinate
and integrate the results made the process longer. Our
work simplifies and accelerates the process by bring-
ing the entire team together in a single meeting, en-
abling defects to be identified, categorized, and prior-
itized collaboratively and immediately. This approach
eliminates the need for long and separate cycles, sig-
nificantly reducing time and improving team align-
ment efficiency. While Yu presents a robust model,
it does not explore the possibility of rapid and direct
integration that our methodology offers, highlighting
the difference in focus and impact on productivity.
The paper (Fulcini and Ardito, 2022) explored the
use of gamification in exploratory GUI (Graphical
User Interface) testing through a prototype integrated
with the Scout tool. This prototype enabled the ex-
ecution of manual tests on web applications, enrich-
ing the system interface with elements such as high-
lighted clickable widgets, coverage metrics, and vi-
sual feedback for testers. The main objective was to
assess how gamification could increase tester engage-
ment and efficiency, promoting greater interface ele-
ment coverage and better user experience. Although
the prototype was essential for applying the tests, it
was not used as a reference to identify or classify sys-
tem defects. Moreover, the adopted method relied on
separate sessions with distinct groups of testers, re-
sulting in a more fragmented process. The study also
does not address how the defects found could be prior-
itized or corrected collaboratively, nor does it present
strategies to integrate the obtained results directly into
Applying Prototyping and Exploratory Testing to Ensure Software Quality in an Information System for Power Tampering Detection: An
Experience Report
381

system development.
(Azevedo and Castro, 2022) developed a proto-
type for a mobile application aimed at ac¸a
´
ı shops,
using Figma to structure and simulate functionalities
and design. The work employed UML diagrams and
validated the prototype through the SUS question-
naire, applied to 28 participants, highlighting ease of
use (89.3%) and high aesthetic acceptance (82.2%).
The focus was on pre-implementation validation, pro-
moting communication between teams. However, the
prototype was only used for aesthetic and functional
validation, without exploring its potential as a guide
for defect detection during implementation. Strate-
gies for identifying or correcting functional failures
were not addressed, nor was the use of collaborative
processes to integrate the prototype into development.
Differently, our work uses the prototype as a cen-
tral reference to guide defect detection and prioritiza-
tion in quick team meetings. This approach broadens
the prototype’s role, ensuring functional and techni-
cal alignment while accelerating the identification and
correction of failures.
2.2 Comparison with Other Agile
Testing Methods
Agile methodologies incorporate various testing ap-
proaches that aim to ensure software quality through
iterative and incremental development. Among them,
Test-Driven Development (TDD) focuses on writing
tests before implementing the actual code, enforcing
strict validation at an early stage (Erdogmus et al.,
2005). While TDD increases code reliability, it may
not capture usability or exploratory aspects effec-
tively. Behavior-Driven Development (BDD), on the
other hand, emphasizes user stories and specifica-
tions in natural language, facilitating communication
between stakeholders (Wynne and Hellesoy, 2012).
However, BDD heavily relies on predefined scenar-
ios, potentially missing unexpected defects. Scrum
Testing, which integrates testing within sprints, sup-
ports continuous validation but often requires auto-
mated test cases to be effective (Crispin and Gregory,
2009).
In contrast, our approach leverages prototyping
and exploratory testing, allowing testers to dynami-
cally explore the system, uncovering both functional
and usability issues early in the development cycle.
This strategy enables rapid defect identification with-
out being constrained by predefined test scripts, mak-
ing it highly effective for agile environments requiring
quick adaptability and user-driven validation.
While some studies discuss using interactive pro-
totypes for usability and design validation, few ex-
plore their application as a basis for exploratory test-
ing in agile projects. This paper contributes to the
literature by reporting the experience of using inter-
active prototypes as a central reference in exploratory
testing in the context of developing a prioritization
system for power distribution companies. In the fol-
lowing sections, we present the development con-
text, testing process, and lessons learned from this ap-
proach.
3 METHODOLOGY
3.1 Project Context
The electricity market is fundamental to the function-
ing of public and private services, and solving prob-
lems that impact its quality is essential. Combat-
ing irregular energy connections represents a signif-
icant challenge for companies in the sector, as these
practices result in financial losses, compromise sup-
ply quality, increase accident risks, and affect the
sustainability of the service. In this context, the
Applied Computing Group (N
´
ucleo de Computac¸
˜
ao
Aplicada - NCA) group at Federal University of
Maranh
˜
ao (UFMA), Brazil, develops innovative soft-
ware projects in partnership with companies. The
group developed a prioritization system focused on
areas without formal connection to the power grid,
considering aspects such as cost, financial return, and
strategic factors. The goal is to improve data analysis
and facilitate decision-making regarding these areas,
which, by operating outside formal contracts, gener-
ate financial impacts and risks to users’ health and
safety. The solution, which combines data analysis
with managerial reports, enables operational teams
to identify critical points and prioritize corrective ac-
tions that provide the best economic and strategic re-
turns for the company. With this in mind, the fol-
lowing deployment diagram (Figure 1) illustrates how
the selected technologies interact within the system’s
context.
Figure 1: Deployment Diagram of the System.
ICEIS 2025 - 27th International Conference on Enterprise Information Systems
382

3.2 Prototyping
According to (Sommerville, 2011), a prototype is an
initial version of a system used to demonstrate con-
cepts, explore design alternatives, and evaluate prob-
lems and potential solutions. The main goal of the
prototyping technique is to create a tangible repre-
sentation of the system, aiding in the definition and
validation of the gathered requirements (Budde and
Zullighoven, 1990). However, if errors are introduced
during the prototyping process, the presentation of the
prototype can generate a distorted perception of the
system, compromising the validation of the require-
ments. Additionally, the prototype may include func-
tionalities that do not belong to the scope of the sys-
tem under development, contrary to the initial inten-
tion of using prototyping as a resource to ensure qual-
ity and adherence to the system’s objectives.
In this context, the production of the prototype and
continuous validation play fundamental roles in en-
suring that the system meets user expectations and
aligns with the project’s objectives. For this pur-
pose, the Figma tool was used, allowing the creation
of high-fidelity prototypes that simulate the complete
operation of the system. At the beginning of the
project, meetings were held with clients to thoroughly
understand their needs and goals, and from these in-
teractions, it was possible to elicit the requirements
necessary for system development. During the proto-
type creation process, new meetings were periodically
held to validate the developed functionalities, make
adjustments to the interface, functionalities, and nav-
igation flows. This iterative process ensured that the
final prototype was sufficiently robust and served as
a solid foundation for the development team to begin
system implementation.
The main flows defined in the prototype reflect
the most important scenarios for the user’s experience
with the system, among which the following stand
out:
(a) Enter Scenario Data: The scenario creation flow,
was designed to collect the initial information needed
about the scenario that will be configured by the user.
The interface aims to capture the data that will form
the basis for the next step. It is composed of three
fields: the scenario name, the scenario description
(optional), and the company name. Below is the ini-
tial screen of the scenario registration process created
in Figma.
(b) Create Groups: In the ”Create Groups” function-
ality, part of Step 4 of the system, the user can auto-
matically group the irregular connections by density.
The generated groups are visually displayed on a map,
considering the provided parameters, such as the min-
imum number of points per group and the radius size
used in the analysis.
(c) Validate Groups: In the ”Validate Groups” func-
tionality, part of Step 5 of the system, the user can
change groups manually, making additions or chang-
ing existing ones, through unions or separations. The
generated groups are visually displayed on the map,
considering the actions taken, without any limit es-
tablished in the analysis.
In each step, the user needs to input data, and
the system must verify the possible inputs and gen-
erate a response for each one, including alternative
flows, such as when the user provides optional data in
the system, and exceptions for invalid input data. At
the end of the design process, the high-fidelity proto-
type was finalized in Figma, containing all the flows
and elements necessary to guide the system’s devel-
opment.
3.3 Application of Exploratory Testing
Based on the Prototype
Exploratory testing is a software testing approach that
involves actively and dynamically exploring the ap-
plication or system under test. Instead of following
a predefined testing script, exploratory testers inter-
act with the software, attempting to identify flaws,
defects, and unexpected behaviors in an unstructured
manner. This implies a dynamic process that encom-
passes learning, test planning, and execution simulta-
neously. The task is carried out through a constant cy-
cle, marked by alignment with the mission, which in-
volves formulating questions about the product. An-
swering these questions contributes to fulfilling the
mission, which in turn guides the design of tests to
obtain the desired responses and the subsequent ex-
ecution of the tests, as explained by (Eduardo et al.,
2021).
After the system was built, an exploratory test
was conducted to verify whether all previously identi-
fied requirements were being satisfactorily met before
presenting the final version to the client. For this pur-
pose, a joint meeting was organized between the de-
velopment team and the analyst team, during which
the tests were conducted with the participation of all
involved. The meeting was recorded using an online
conferencing tool, allowing the material to be revis-
ited and analyzed later.
During the exploratory test, the responsible ana-
lyst presented the system in detail, testing all possi-
ble flows and inputs to verify whether the expected
output was produced in the prototype, checking the
system’s navigability, and ensuring that the included
business rules were correctly implemented. Each
Applying Prototyping and Exploratory Testing to Ensure Software Quality in an Information System for Power Tampering Detection: An
Experience Report
383

screen was compared with its respective version cre-
ated in Figma, and if differences were identified, they
were highlighted and discussed in real time.
Some of the main flows included: to upload files
containing points that would be analyzed; editing the
files; defining groups to be considered when prior-
itizing possible tampering locations, classifying the
data and viewing the results from the classification.
This approach not only allowed the identification of
defects but also proposed improvements that could
be incorporated into the system in an agile manner.
At the end of the process, the video of the meeting
was made available to the team and other stakehold-
ers, promoting transparency and facilitating progress
tracking.
From the meeting held by the team, a detailed
spreadsheet was created with the purpose of central-
izing and organizing all information related to the
defects found during the exploratory testing process.
During this meeting, an analyst, utilizing their knowl-
edge of the system’s objectives and requirements,
recorded each identified defect, detailed the circum-
stances under which they were found, and carefully
analyzed each one. Based on this analysis, it was pos-
sible to determine the severity of each defect, clas-
sifying them into categories such as high, medium,
and low, according to their potential impact on sys-
tem functionality and the user experience. Out of the
50 defects identified during the test, 20 were listed as
priorities on the spreadsheet due to the potential im-
pact they could cause. In this paper, we will present
the defects classified as high severity, considering that
these represent the most critical issues that must be
addressed before the system’s release. This prioriti-
zation was based on factors such as the impact on the
system’s core functionalities and the user experience.
However, the complete Table 1, can be consulted in
the Footnote
1
.
The mentioned spreadsheet details the defects
found during the testing process, including the ex-
pected system behavior and the severity classification
(high, medium, low). As the team had limited time to
implement corrections before the final delivery, this
artifact became essential for prioritizing the neces-
sary changes without having to redo entire workflows
within the system to identify the defects again. This
allowed the team to quickly implement the missing
functionalities, enabling new tests to be conducted on
the implemented changes for further validation by the
company’s Analyst.
Although exploratory testing is often associated
with traditional software testing, in this study, it was
applied as a complementary approach to previously
1
To access the full Table 1, click here.
executed validation methods. The primary goal was to
enhance the verification process by leveraging a more
flexible and dynamic testing strategy that allowed for
rapid defect identification.
This testing phase did not replace structured val-
idation efforts but rather supplemented them by en-
abling real-time validation based on the system’s pro-
totype. The prototype served as a key reference doc-
ument, ensuring that the final implementation aligned
with the intended requirements and expected behav-
iors. This approach aligns with modern agile method-
ologies by providing an iterative mechanism for re-
fining the system while fostering collaboration among
development and testing teams.
By integrating exploratory testing into the valida-
tion process, the team was able to identify usabil-
ity and functional issues that might not have been
captured through automated or scripted testing ap-
proaches. Furthermore, this strategy allowed for im-
mediate feedback, rapid prioritization of critical is-
sues, and iterative adjustments based on stakeholder
input. Contrary to the perception that this approach
reflects pre-Agile software testing methods, it en-
hances agility by streamlining defect detection, pro-
moting team collaboration, and improving the overall
quality of the final product.
4 RESULTS AND DISCUSSIONS
Table 1 presents examples of the process of analyz-
ing the defects found. In these examples, we high-
light two main items: (a) ”The ’view scenario’ option
should be disabled until the scenario is finalized.”;
and (b) ”The map must contain a default functional-
ity when clicking on the regions, allowing initial in-
teraction.” For each item analyzed, we gathered data
on where these problems occurred and how they were
reported during the evaluation by the testers. We ana-
lyzed and extracted the characteristics or quality at-
tributes associated with these issues and translated
them into requirements using the language of soft-
ware engineering (i.e., detailing the objects of atten-
tion and their expected functionalities or how they
should be implemented). Furthermore, to support
the development team in implementing the require-
ments related to each identified item, we analyzed and
grouped all reported improvement suggestions, devel-
oping specific instructions for the improvements ac-
cording to the nature of each item.
For illustrative purposes, some of the identified
defects were highlighted, showcasing the process in-
volved in their correction and the application of im-
provement suggestions. In Figure 2, the identified de-
ICEIS 2025 - 27th International Conference on Enterprise Information Systems
384

Table 1: Collection of defects found in the exploratory test.
ID Defect What was expected Severity
D01 Button ”Forgot password?” does nothing The button should redirect to a page with a password recovery
form, including fields for email and a send button
High
D02 Invalid email allows login Invalid email should not allow clicking the ”Login” button High
D03 Allowing anyone to register in the system Omit the ”Register” button High
D04 When entering an end date earlier than the start
date, nothing happens
It should display an error/some kind of notification High
D05 It is not possible to view the scenario because there
was no result (it was not finalized, still under con-
struction)
Have an alternative flow to copy the scenario without reach-
ing the finalization step (with a pop-up), allowing it to be
edited
High
D06 Option to ”view scenario” enabled after deleting 1
scenario
Viewing the scenario should be disabled until it is finalized High
D07 Clicking on ”view scenario,” when it is still under
construction, loads the data
Should not return anything, as it was still under construction High
D08 There are no ”groups” or ”marked points,” but it is
marked as ”finalized”
Should remain ”under construction” High
D09 When sending a file that should cause an error, it
loaded
It should not have loaded High
D10 Allows a file with points without data and does not
display an error message
Alert screen showing what to do with this type of file (this
will be the ”error message”)
High
D11 Delete all files at once Have the functionality to delete/edit only 1 file High
D12 Does not show replicated and empty points from
the file
Should plot replicated and empty points, and create a check-
list column on the right asking if that point should be deleted
(displaying it in light gray) and update the message
High
D13 Logged out while working Renew the authentication token while working, for about 10
minutes
High
D14 Even without points to fill in, it is possible to click
the ”fill data” button
”Fill data” should be disabled High
D15 Clicking the ”next” button displays a warning mes-
sage
The ”next” button should be disabled High
D16 In defining groups, only the map is shown, without
any mapping
Show mapped points as if they belong to the same group
(gray) before starting the interaction
High
D17 On the map showing 5008 points but only 4,999 in
the file
Should show 4,999 points on the map High
D18 Without selecting a functionality, nothing can be
done on the map
A default functionality should already be pre-defined when
clicking on the regions
High
D19 When selecting points, it is not possible to alter
them
Have a functionality to modify points High
D20 Whover on ”Select Module” does not make the
change identifiable
Make the ”Select Module” have a hover effect that makes it
bold
High
fect was: ”When setting the end date earlier than the
start date, nothing happens.” To address this, an error
message was implemented to indicate that the start
date must be earlier than the end date. The use of the
color red was intentional, as it visually signals that
something is wrong. Additionally, the search button
was disabled to prevent such queries from being exe-
cuted. In Figure 3, the identified defect was: ”Allows
files with points missing data and does not display an
error message.” The solution involved adding an alert
screen to inform users that the file contains unfilled
points. Users were given the option to resolve the is-
sue immediately or later, placing them at the center
of the process and ensuring flexibility for future ad-
justments if needed. Finally, in Figure 4, the identi-
fied defect was: ”In defining groups, only the map is
displayed, with no mapping.” This issue was resolved
by displaying all points in the same color before se-
lecting a group. This solution eliminated the previous
ambiguity, enabling users to understand the status of
the points before making a selection.
Therefore, the detailed documentation of the de-
fects found and corrected has significantly contributed
to a clear understanding of the system’s critical areas,
allowing for agile and effective adjustments. The use
of tools such as Figma and spreadsheets for record-
ing and prioritizing issues reinforced the transparency
and organization of the process, ensuring that correc-
tions were implemented in a structured manner.
Despite the positive results obtained with the
adopted approach, the absence of tests in a real op-
erational environment may limit the generalization of
the results. So far, evaluations have been conducted in
a controlled environment, enabling the efficient iden-
Applying Prototyping and Exploratory Testing to Ensure Software Quality in an Information System for Power Tampering Detection: An
Experience Report
385

Figure 2: Search Scenario Functionality Screen - Error.
Figure 3: Search Scenario Functionality Screen.
tification of functional and usability flaws. However,
this scenario does not account for external variables
that may impact system performance and user expe-
rience in real-world situations. As future work, we
propose conducting practical tests in the system’s op-
erational context, allowing for the analysis of fac-
tors such as variable electrical infrastructure, different
user profiles, and integration with legacy systems.
Thus, introducing these tests will enable the vali-
dation of the approach’s effectiveness in an environ-
ment closer to production, ensuring greater reliabil-
ity of the results and identifying possible improve-
ments to enhance the system’s robustness. Addition-
ally, considering challenges such as high data volume
and adverse operational conditions will help consoli-
date the solution’s applicability in the energy sector,
ensuring it meets the real demands of companies and
technical personnel involved.
Figure 4: Search Scenario Functionality Screen.
5 CONCLUSIONS
The development and validation of the detection sys-
tem for irregular connections through the combina-
tion of high-fidelity prototyping and exploratory test-
ing proved to be effective strategies for ensuring soft-
ware quality and meeting the needs of the energy sec-
tor. The adopted approach allowed for the identifica-
tion and correction of defects in an agile and collabo-
rative manner, integrating the development and anal-
ysis teams in an iterative and well-documented pro-
cess. The use of the prototype as a central tool in the
planning and execution of tests was crucial for align-
ing the system requirements with stakeholder expec-
tations, ensuring that the implemented functionalities
were robust and functional.
Additionally, the adopted strategy shares princi-
ples of the Minimum Viable Product (MVP), allow-
ing for the rapid validation of essential functionalities
before full implementation. The use of prototyping
made it possible to test and refine the system’s work-
flows without the need for extensive code develop-
ment, reducing rework and ensuring that adjustments
were made based on continuous team feedback. This
iterative approach enabled a more efficient develop-
ment process, focusing on the most relevant func-
tionalities for the end user. Thus, the use of MVP
combined with exploratory testing facilitated a cy-
cle of continuous improvement, making the process
more efficient and contributing to the development of
a more robust software solution aligned with the de-
mands of the energy sector.
The results obtained, including the reduction of
the time required for validation and the identification
of improvements in flows and functionalities, high-
light the importance of integrating good development
practices with techniques that can be implemented in
an agile manner. The documentation of the defects
ICEIS 2025 - 27th International Conference on Enterprise Information Systems
386

found and corrected also contributed to a clear view
of the system’s critical areas, enabling quick and effi-
cient adjustments. Moreover, the use of tools such as
Figma and detailed spreadsheets to record problems
reinforced the transparency and organization of the
process, fundamental elements for the project’s suc-
cess.
Finally, the lessons learned from this project can
serve as a basis for the application of similar method-
ologies in other contexts, expanding the use of pro-
totypes and exploratory testing as pillars for devel-
oping high-quality technological solutions. As future
work, we intend to expand the prioritization system
by incorporating new analysis criteria, such as envi-
ronmental and social indicators, which can influence
decisions related to intervention areas. Moreover, the
methodology used has shown promising results in im-
proving software quality through exploratory testing
and prototyping, but its application is still limited to a
specific system context. However, this approach has
been applied to other projects developed by the Ap-
plied Computing Center (NCA) at the Federal Univer-
sity of Maranh
˜
ao (UFMA), covering different types
of systems, such as service management, healthcare
solutions, and organizational process optimization.
Thus, future studies could further explore the adap-
tation of this methodology to other critical systems,
such as applications in the financial and transporta-
tion sectors, where early defect detection is essential
to ensure reliability and security. We hope that this
work will inspire new initiatives in the energy sector
and other areas, promoting innovation and the contin-
uous pursuit of excellence in software development.
ACKNOWLEDGMENTS
This work was supported by the Instituto de Ci
ˆ
encia
e Tecnologia Grupo Equatorial and Grupo Equato-
rial through the PDI ANEEL program under grant
PD-00037-0047/2022. The authors also acknowledge
the Coordenac¸
˜
ao de Aperfeic¸oamento de Pessoal de
N
´
ıvel Superior (CAPES), Brazil - Finance Code 001,
Conselho Nacional de Desenvolvimento Cient
´
ıfico e
Tecnol
´
ogico (CNPq), Brazil, and Fundac¸
˜
ao de Am-
paro
`
a Pesquisa Desenvolvimento Cient
´
ıfico e Tec-
nol
´
ogico do Maranh
˜
ao (FAPEMA) (Brazil) for the fi-
nancial support.
REFERENCES
Azevedo, S. D. B. J. d. S. and Castro, A. F. d. (2022).
Development and evaluation of a prototype interface
for an ac¸a
´
ı sales application. Undergraduate The-
sis (TCC), Universidade Federal Rural do Semi-
´
Arido
(UFERSA).
Budde, R. and Zullighoven, H. (1990). Prototyping revis-
ited. In COMPEURO’90: Proceedings of the 1990
IEEE International Conference on Computer Systems
and Software Engineering-Systems Engineering As-
pects of Complex Computerized Systems, pages 418–
427. IEEE.
Crispin, L. and Gregory, J. (2009). Agile Testing: A Prac-
tical Guide for Testers and Agile Teams. Addison-
Wesley.
Eduardo, J., Paiva, A., Ferreira, V., Rocha, S., Santos,
´
I.,
Rivero, L., Almeida, J., Braz Junior, G., Paiva, A.,
Silva, A., et al. (2021). Applying exploratory testing
and ad-hoc usability inspection to improve the ease of
use of a mobile power consumption registration app:
An experience report. In HCI International 2021-
Late Breaking Papers: Design and User Experience:
23rd HCI International Conference, HCII 2021, Vir-
tual Event, July 24–29, 2021, Proceedings 23, pages
326–341. Springer.
Erdogmus, H., Morisio, M., and Torchiano, M. (2005).
On the effectiveness of test-first approach to program-
ming. IEEE Transactions on Software Engineering,
31(1):1–12.
Fulcini, T. and Ardito, L. (2022). Gamified exploratory
gui testing of web applications: a preliminary evalua-
tion. In 2022 IEEE International Conference on Soft-
ware Testing, Verification and Validation Workshops
(ICSTW), pages 215–222.
Silva, M., Fabrizzio, G., Ribeiro de Jesus, E., Barra, D., and
Lorenzini, E. (2024). Construction and usability val-
idation of a mobile application prototype for knowl-
edge dissemination from the journal texto & contexto
enfermagem. Texto & Contexto - Enfermagem, 33.
Sommerville, I. (2011). Software engineering (ed.). Amer-
ica: Pearson Education Inc.
Vidinich, R. and Nery, G. A. L. (2009). Research and de-
velopment against energy theft. Revista Pesquisa e
Desenvolvimento da ANEEL–P&D, 15.
Wynne, C. and Hellesoy, A. (2012). The Cucumber Book:
Behaviour-Driven Development for Testers and De-
velopers. Pragmatic Bookshelf.
Yu, J. (2018). Design and application on agile software ex-
ploratory testing model. In 2018 2nd IEEE Advanced
Information Management,Communicates,Electronic
and Automation Control Conference (IMCEC), pages
2082–2088.
Applying Prototyping and Exploratory Testing to Ensure Software Quality in an Information System for Power Tampering Detection: An
Experience Report
387
